E-line CJ-HDR104 User manual

HD Analog Recorder
User’s Manual
Model No. CJ-HDR104
CJ-HDR108
Version 1.0.4

i
Table of Contents
1FEATURES AND SPECIFICATIONS..................................................................1
1.1 Overview.......................................................................................................................1
1.2 Features........................................................................................................................1
1.3 Specifications...............................................................................................................2
1.3.1 CJ-HDR104 / CJ-HDR108.....................................................................................2
2OVERVIEW AND CONTROLS ...........................................................................4
2.1 Front Panel...................................................................................................................4
2.1.1 CJ-HDR104 / CJ-HDR108.....................................................................................4
2.2 Rear Panel....................................................................................................................5
2.2.1 CJ-HDR104 / CJ-HDR108.....................................................................................5
2.3 Connection Sample.....................................................................................................6
2.3.1 CJ-HDR104 / CJ-HDR108.....................................................................................6
2.4Mouse Control..............................................................................................................7
3INSTALLATION AND CONNECTIONS............................................................... 9
3.1 Check Unpacked DVR ...............................................................................................9
3.2 About Front Panel and Rear Panel ..........................................................................9
3.3 HDD Installation...........................................................................................................9
3.3.1 CJ-HDR104 / CJ-HDR108.....................................................................................9

ii
3.4 Connecting Power Supply .......................................................................................10
3.5 Connecting Video Input and Output Devices........................................................10
3.5.1 Connecting Video Input........................................................................................10
3.5.2 Connecting Video Output.....................................................................................11
3.6 Connecting Audio Input & Output, Bidirectional Audio........................................11
3.6.1 Audio Input.............................................................................................................11
3.6.2 Audio Output..........................................................................................................11
3.7 RS485 .........................................................................................................................12
3.8 Other Interfaces.........................................................................................................12
4OVERVIEW OF NAVIGATION AND CONTROLS .............................................13
4.1 Boot up and Shutdown .............................................................................................13
4.1.1 Boot up....................................................................................................................13
4.1.2 Shutdown................................................................................................................13
4.1.3 Auto Resume after Power Failure ......................................................................13
4.1.4 Replace Button Battery ........................................................................................13
4.2 Startup Wizard ...........................................................................................................14
4.3 Manual Record ..........................................................................................................17
4.3.1 Live Viewing...........................................................................................................17
4.4 Right-Click Menu .......................................................................................................19
4.4.1 Color........................................................................................................................20
4.4.2 PTZ Control............................................................................................................21
4.4.3 Playback.................................................................................................................26
4.4.4 Manual Record ......................................................................................................26
4.4.5 Window Switch ......................................................................................................26
4.5 Navigation Bar ...........................................................................................................27
4.5.1 Main Menu..............................................................................................................27
4.5.2 Output Screen........................................................................................................27

iii
4.5.3 Tour.........................................................................................................................27
4.5.4 Favorites.................................................................................................................27
4.5.5 Channel...................................................................................................................28
4.5.6 PTZ..........................................................................................................................28
4.5.7 Color........................................................................................................................28
4.5.8 Playback.................................................................................................................28
4.5.9 Alarm Status...........................................................................................................28
4.5.10Channel Info...........................................................................................................28
4.5.11Network...................................................................................................................29
4.5.12HDD Manager........................................................................................................29
4.5.13USB Manager ........................................................................................................29
4.6 USB Device Auto Pop-up.........................................................................................29
4.7 Main Menu..................................................................................................................29
4.8 Operation....................................................................................................................30
4.8.1 Playback.................................................................................................................30
4.8.2 Backup....................................................................................................................37
4.8.3 Shut Down..............................................................................................................39
4.9 Information..................................................................................................................40
4.9.1 System Info ............................................................................................................40
4.9.2 Event.......................................................................................................................43
4.9.3 Network...................................................................................................................44
4.9.4 Log...........................................................................................................................46
4.10 Setting .........................................................................................................................48
4.10.1Camera...................................................................................................................48
4.10.2Network...................................................................................................................53
4.10.3Event.......................................................................................................................65
4.10.4Storage....................................................................................................................73
4.10.5General...................................................................................................................83
5WEB OPERATION.............................................................................................99
5.1 Network Connection .................................................................................................99
5.2 Login............................................................................................................................99

iv
5.3 LAN Mode.................................................................................................................100
5.4 Live ............................................................................................................................102
5.5 PTZ............................................................................................................................102
5.6 Image ........................................................................................................................104
5.6.1 Image ....................................................................................................................104
5.7 WAN Login ...............................................................................................................104
5.8 Setup .........................................................................................................................105
5.8.1 Camera.................................................................................................................105
5.8.2 Network.................................................................................................................111
5.8.3 Event.....................................................................................................................123
5.8.4 Storage..................................................................................................................128
5.8.5 General.................................................................................................................131
5.9 Info.............................................................................................................................142
5.9.1 Version..................................................................................................................142
5.9.2 Log.........................................................................................................................143
5.9.3 Online User ..........................................................................................................144
5.10 Playback ...................................................................................................................144
5.10.1Playback Record.................................................................................................144
5.10.2File List..................................................................................................................145
5.10.3Playback...............................................................................................................145
5.10.4Download..............................................................................................................146
5.10.5Load more ............................................................................................................147
5.11 Alarm .........................................................................................................................148
5.12 Log out ......................................................................................................................149
5.13 Un-install Web Control............................................................................................149

v
6FAQ..................................................................................................................150
APPENDIX A HDD CAPACITY CALCULATION ..................................................155

vi
Welcome
Thank you for purchasing our HD Analog Recorder (DVR)!
This user’s manual is designed to be a reference tool for the installation and operation of your
system.
Here you can find information about this series DVR features and functions, as well as a detailed
menu tree.
Before installation and operation please read the following safeguards and warnings carefully!

vii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the DVR before completing installation.
Do not place objects on the DVR
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
The DVR should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
This series product shall be transported, storage and used in the specified environments.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!

1
1FEATURES AND SPECIFICATIONS
1.1 Overview
This series product is an excellent digital monitor product designed for security field. It adopts embedded
Linux OS to maintain reliable operation. It is easy to use and can realize surveillance function after some
simple setups. It has various functions such as record, playback, monitor at the same time and can
guarantee audio video synchronization. This series product has advanced technology and strong
network data transmission function.
This series device adopts embedded design to achieve high security and reliability. It can work in the
local end, and at the same time, when connecting it to the professional surveillance software (PSS), it
can connect to security network to realize strong network and remote monitor function. It can realize HD
monitor without changing current cable layout
This series product can be widely used in various areas such as banking, telecommunication, electric
power, interrogation, transportation, intelligent resident zone, factory, warehouse, resources, and water
conservancy.
1.2 Features
This series product has the following features:
Real-time monitor
It has analog output port, VGA port and HDMI port. You can use monitor or displayer to realize
surveillance function.
System supports VGA/HDMI output at the same time.
Storage function
Special data format to guarantee data security and can avoid vicious data modification.
Compression format
Support multiple-channel audio and video. An independent hardware decodes the audio and video
signal from each channel to maintain video and audio synchronization.
Backup function
Support backup operation via USB port (such as flash disk, portable HDD, burner).
Client-end user can download the file to local HDD to backup via network.
Record playback function
Support each channel real-time record independently, and at the same time it can support playback,
forward play, network monitor, record search, download and etc.
Support various playback modes: slow play, fast play, backward play and frame by frame play.
Support time title overlay so that you can view event accurate occurred time
Support specified zone enlargement.

2
Network operation
Support network remote real-time monitor, remote record search and remote PTZ control.
Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
The alarm input port and output has the protection circuit to guarantee device safety.
Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC COM to
upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
PTZ control
Support PTZ decoder via RS485.
Support various decode protocols to allow the PTZ to control the speed dome.
Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
UPnP
It is to establish the mapping relationship between the LAN and the WAN via the UPnP protocol.
Slight function differences may be found due to different series.
1.3 Specifications
1.3.1 CJ-HDR104 / CJ-HDR108
Model
CJ-HDR104
CJ-HDR108
Video / Audio IF
Video Input
4 CH, BNC
8 CH, BNC
Type
HDCVI
720p/ 1080p HDCVI
Analog
NTSC/PAL
Video Output
1 HDMI, 1 VGA
Audio Input
1 CH, RCA
Audio Output
1 CH, RCA
Two-way Talk
Reuse audio input/output CH1
Display
Output Resolution
1920×1080, 1280×1024, 1280×720, 1024×768
Multiscreen Mode
1/4
1/4/8/9
Privacy Masking
4 rectangular zones (each camera)
OSD
Camera title, Time, Video loss, Camera lock, Motion
detection, Recording

3
- Auto Reboot (once a week)
-Recording rate of CH 1 or CH 5 set at 1080p (16~25/30fps), will only allow
the other channels to record at 1080P (1~7fps) or 720p (1~15fps).
Video / Audio Format
Video/Audio Compression
H.264/G.711
Record
Rate*
Main Stream
1080P (1~12/15fps)/ 720P/ 960H/ D1 (1~25/30fps)
Extra Stream
CIF/ QCIF (1~25/30fps), D1 (1~12/15fps)
Bit Rate
96~4096Kb/s
Record Mode
Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval
1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-
record: 10~300 sec
Alarm /Event
Trigger Events
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot,
Buzzer & Screen tips
Video Detection
Motion Detection, MD Zones: 396(22×18), Video Loss &
Camera Blank
Playback & Backup
Sync Playback
1/4
1/4/9
Search Mode
Time/Date, MD & Exact search (accurate to second)
Playback Functions
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file,
Previous file, Next camera, Previous camera, Full screen,
Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode
USB Device/Network
Network
Network Interface
RJ-45 port (10/100M)
Network Functions
HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. User Access
128 users
Mobile Device
iPhone, iPad, Android
HDD
Type
1 SATA port, up to 6TB
External Interface
USB Interface
2 ports(1 Rear), USB2.0
RS485 Camera Interface
1 port, For PTZ Control
General Specifications
Power Supply
DC12V/4A
Power Consumption
10W (without HDD)
Working Environment
-10°C~+55°C / 10%~90%RH / 86~106kpa
Dimension(W×D×H)
Mini 1U, 325mm×255mm×55mm
Weight
1.5KG (without HDD)

4
2Overview and Controls
This section provides information about front panel and rear panel. When you install this series DVR for
the first time, please refer to this part first.
2.1 Front Panel
2.1.1 CJ-HDR104 / CJ-HDR108
The front panel is shown as below. See Figure 2-1.
Figure 2-1
Please refer to the following sheet for front panel button information.
Name
Icon
Function
Power button
Press this button to boot up or shut down the device.
USB port
Connect to USB2.0 storage device, mouse and etc.
Up
Down
/
Activate current controls, and then move up, move down
or jump.
Change setup, increase/decrease numeral.
Assistant function such as PTZ menu.
Switch channel when playback.
Left
Right
/
Switch current activated controls, move up and down.
When device is in 1-channel playback mode, use it to
control playback control bar process.
Cancel
ESC
Go to previous menu, or cancel current operation (Close
the top interface or controls).
When playback, click it to restore real-time monitor mode.
Confirm
ENTER
Confirm current operation
Go to default button
Go to the menu.
Assistant
FN
One-window monitor mode, click this button to display
assistant function: PTZ control and image color.
In menu control interface click to switch PTZ control
menu.
In motion detection setup, working with Fn and direction
keys to realize setup.
Backspace function: in numeral control or text control,
press it for 1.5seconds to delete the previous character
before the cursor.
In HDD information interface, click to switch HDD record
time and other information.
Realize other special functions.
Power
indicator
POWER
Light turns on when power connection is OK.

5
Name
Icon
Function
Network
indicatior
NET
Light turns on when network connection is abnormal.
Alarm indicator
ALARM
Light turns on when alarm occurs.
HDD indicator
HDD
HDD error occurs or HDD capacity is below specified
threshold value or HDD being overwritten.
The light turns on to alert you, please check HDD status at the
GUI.
2.2 Rear Panel
2.2.1 CJ-HDR104 / CJ-HDR108
The 4-channel series rear panel is shown as below. See Figure 2-2.
Figure 2-2
The 8-channel series rear panel is shown as below. See Figure 2-3.
Figure 2-3
Please refer to the following sheet for detailed information.
SN
Icon
Name
Note
1
Power on-off button
Power on/off button.

6
2
VGA
VGA video output
port
VGA video output port. Output analog video
signal. Can connect to the monitor to view
analog video output.
3
AUDIO IN
Audio input port
Connect to audio input device such as speaker.
4
VIDEO IN
Video input port
Connect to analog camera, video input signal.
5
Power input port
Input 12V DC.
6
USB2.0 port
Connect to USB storage device, mouse,
burning DVD-ROM and etc.
7
A
RS485（RS-485）
communication port
RS485_A port. It is the cable A. You can
connect to the control devices such as speed
dome PTZ.
B
RS485_B.It is the cable B. You can connect to
the control devices such as speed dome PTZ.
8
Network port
100M Ethernet port
9
HDMI
High definition media
interface
High definition audio and video signal output
port. It transmits uncompressed high definition
video and multiple-channel data to the HDMI
port of the display device.
10
AUDIO OUT
Audio output port
Connect to video output device such as sound
box.
2.3 Connection Sample
2.3.1 CJ-HDR104 / CJ-HDR108
Please refer to Figure 2-4 for connection sample.
The following figure is based on the 4-channel series product.
Figure 2-4

7
2.4 Mouse Control
Left click
mouse
System pops up password input dialogue box if you have not logged in.
In real-time monitor mode, you can go to the main menu.
When you have selected one menu item, left click mouse to view menu
content.
Implement the control operation.
Modify checkbox or motion detection status.
Click combo box to pop up drop down list
In input box, you can select input methods. Left click the corresponding button
on the panel you can input numeral/English character (small/capitalized). Here
← stands for backspace button. ＿stands for space button.
Double left
click mouse
Implement special control operation such as double click one item in the file list
to playback the video.
In multiple-window mode, double left click one channel to view in full-window.
Double left click current video again to go back to previous multiple-window
mode.
Right click
mouse
In real-time monitor mode, pops up shortcut menu: color setting,
Pan/Tilt/Zoom, main menu, playback, manual, one-window, four-window, eight-
window and nine-window.
Among which, Pan/Tilt/Zoom and color setting applies for current selected
channel.
If you are in multiple-window mode, system automatically switches to the
corresponding channel.
Exit current menu without saving the modification.
Press
middle
button
In numeral input box: Increase or decrease numeral value.
Switch the items in the checkbox.
Page up or page down

8
Move mouse
Select current control or move control
Drag mouse
Select motion detection zone
Select privacy mask zone.
Mouse
rolling
Normal mouse rolling operation in live view
Rolling forward and backward for Channel or Window switching.
Click on Enlarge button in the Live View menu bar for digital zoom.
Rolling backward to zoom in
Rolling forward to zoom out

9
3Installation and Connections
Note: All the installation and operations here should conform to your local electric
safety rules.
3.1 Check Unpacked DVR
When you receive the DVR from the forwarding agent, please check whether there is any visible
damage. The protective materials used for the package of the DVR can protect most accidental clashes
during transportation. Then you can open the box to check the accessories.
Please check the items in accordance with the list. Finally you can remove the protective film of the DVR.
3.2 About Front Panel and Rear Panel
The model label in the front panel is very important; please check according to your purchase order.
The label in the rear panel is very important too. Usually we need you to represent the serial number
when we provide the service after sales.
3.3 HDD Installation
Important
Shut down the device and then unplug the power cable before you open the case to
replace the HDD!
All figures listed below for reference only!
You can refer to the Appendix for recommended HDD brand. Please use HDD of 7200rpm or higher.
Please follow the instructions below to install hard disk.
3.3.1 CJ-HDR104 / CJ-HDR108
The series DVR has one SATA HDD.
①Loosen the screws of the upper
cover and side panel.
②Fix four screws in the HDD (Turn
just three rounds).
③Place the HDD in accordance
with the four holes in the bottom.

10
④Turn the device upside down and
then turn the screws in firmly.
⑤Fix the HDD firmly.
⑥Connect the HDD cable and
power cable.
⑦Put the cover in accordance with the
clip and then place the upper cover
back.
⑧Secure the screws in the rear panel
and the side panel.
Important:
You can connect the HDD data cable and the power cable first and then fix the HDD in the device.
Please pay attention to the front cover. It adopts the vertical sliding design. You need to push the
clip first and then put down.
3.4 Connecting Power Supply
Please check input voltage and device power button match or not.
We recommend you use UPS to guarantee steady operation, DVR life span, and other peripheral
equipments operation such as cameras.
3.5 Connecting Video Input and Output Devices
3.5.1 Connecting Video Input
The video input interface is BNC. The input video format includes: PAL/NTSC BNC（1.0VBP- P ，
B75Ω.）
The video signal should comply with your national standards.
The input video signal shall have high SNR, low distortion; low interference, natural color and suitable
lightness.
Guarantee the stability and reliability of the camera signal:
The camera shall be installed in a cool, dry place away from direct sunlight, inflammable, explosive
substances and etc.
The camera and the DVR should have the same grounding to ensure the normal operation of the
camera.

11
Guarantee stability and reliability of the transmission lineBTTTB
Please use high quality, sound shielded BNC. Please select suitable BNC model according to the
transmission distance.
If the distance is too long, you should use twisted pair cable, and you can add video compensation
devices or use optical fiber to ensure video quality.
You should keep the video signal away from the strong electromagnetic interference, especially the high
tension current.
Keep connection lugs in well contactBTTTB
The signal line and shielded wire should be fixed firmly and in well connection. Avoid dry joint, lap
welding and oxidation.
3.5.2 Connecting Video Output
Video output includes a BNC (PAL/NTSC1.0VP-P ，75Ω）output, a VGA output and HDMI output.
System supports BNC, VGA and HDMI output at the same time.
When you are using pc-type monitor to replace the monitor, please pay attention to the following points:
To defer aging, do not allow the pc monitor to run for a long time.
Regular demagnetization will keep device maintain proper status.
Keep it away from strong electromagnetic interference devices.
Using TV as video output device is not a reliable substitution method. You also need to reduce the
working hour and control the interference from power supply and other devices. The low quality TV may
result in device damage.
3.6 Connecting Audio Input & Output, Bidirectional Audio
3.6.1 Audio Input
These series products audio input port adopt BNC port.
Due to high impedance of audio input, please use active sound pick-up.
Audio transmission is similar to video transmission. Try to avoid interference, dry joint, loose contact and
it shall be away from high tension current.
3.6.2 Audio Output
The audio output signal parameter is usually over 200mv 1KΩ (BNC or RCA). It can directly connect to
low impedance earphone, active sound box or amplifier-drive audio output device.
If the sound box and the pick-up cannot be separated spatially, it is easy to arouse squeaking. In this
case you can adopt the following measures:
Use better sound pick-up with better directing property.
Reduce the volume of the sound box.
Using more sound-absorbing materials in decoration can reduce voice echo and improve acoustics
environment.
Adjust the layout to reduce happening of the squeaking.

12
3.7 RS485
When the DVR receives a camera control command, it transmits that command up the coaxial cable to the
PTZ device. RS485 is a single-direction protocol; the PTZ device can’t return any data to the unit. To enable
the operation, connect the PTZ device to the RS485 (A,B) input on the DVR.
Since RS485 is disabled by default for each camera, you must enable the PTZ settings first. This series
DVRs support multiple protocols such as Pelco-D, Pelco-P.
To connect PTZ devices to the DVR:
1. Connect RS485 A,B on the DVR rear panel.
2. Connect the other end of the cable to the proper pins in the connector on the camera.
3. Please follow the instructions to configure a camera to enable each PTZ device on the DVR.
3.8 Other Interfaces
There are still other interfaces on the DVR, such as USB port.
