e-mio Agile User manual

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery
electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7
1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

1
3
2
4
5
6
7
8
9
10
11
12
1415 13
DEAR CUSTOMER!
We welcome you among lucky owners and users of
electric motorbikes! To fully enjoy a safe and happy
ride, please read the full content of these operating
instructions before you start. Your road safety is not
only related to your skills but also to the operation and
knowledge of motorbike mechanics. Each time before
driving, check the basic parameters of the motorbike
and its parts. Periodic maintenance of motorbikes
components is a prerequisite for complete satisfaction
in using the vehicle. It should be remembered that
some operations may require carrying out by a qualied
diagnostic or repair station. We recommend regular
visits to qualied diagnostic or repair stations.
Read the entire instruction manual before riding
an electric motorbike!
INTRODUCTION
This product is intended for transport and is environ-
mentally friendly. The following are the features and
benets of an electric motorbike.
• High performance brushless DC motor.
•
Digital controller with indicator and overvoltage
and undervoltage protection.
•
Braking system with power cut-o to ensure safe
driving.
•
High-performance battery for greater electric current
and longer driving range.
•
Front and rear suspension for a smooth and com-
fortable ride.
ATTENTION:
1. Familiarize yourself with the local laws and
ordinances that regulate or limit the age of
the driver who will be able to use this electric
vehicle. Laws and regulations sometimes
dier signicantly depending on the country
in which you reside. It is your responsibility
to know and comply with local restrictions.
2. Do not remove or disassemble the vehicle
parts yourself. Contact a qualied diagnostic
or repair station to replace or repair parts.
3.
Do not lend your vehicle to anyone who
does not have the required license to drive
this vehicle.
4.
To prevent an accident, avoid sudden stop-
ping or braking.
5.
Never drive with one hand, avoid driving
under the inuence of alcohol or other in-
toxicants.
SAFE DRIVING RULES
The main rules
•
When driving this vehicle, always wear an approved,
certied helmet and follow the helmet manufacturer’s
instructions regarding t, use and care.
•
When driving, you must comply with the same trac
rules as all other road vehicles, including giving way
to pedestrians and stopping at the red trac light
and stop signs. You are a road participant with all
the consequences.
•
Drive predictably and in a straight line. Never perform
sudden maneuvers, especially in trac jams. Drive
conservatively and condently. You may be hard to
see for other road users. Use the correct indicator
lights to indicate turning or stopping. Use appropriate
protective clothing with parts that ensure visibility
in the evening and at night.
•
Focus on the road ahead. Avoid holes, gravel, wet
roads, oil stains, curbs, speed thresholds, drainage
grates and other obstacles that may cause slip or
wheel/wheels blockage.
•
Expect the unexpected. Pay special attention to
situations such as the sudden opening of a car door
or an unexpected appearance of a vehicle from
behind of another vehicle. Use extreme caution
at intersections and when preparing to overtake
other road users.
•
Get to know all the functions of your vehicle. Practice
using the warning lights, braking and using the horn.
• Do not carry packages or passengers that could
interfere with the visibility or control of your vehicle.
Do not use objects that may limit hearing.
•
Keep a comfortable distance to ensure proper and
collision-free braking in front of other vehicles or
objects on the road. The safe braking distance and
forces applied to the vehicle depend on the prevailing
weather conditions.
•
If you have a poor pavement or uncertain pavement,
drive slowly and carefully.
• Do not exceed the maximum load of your vehicle.
This will aect the driving range.
Rainy weather
• Use extreme caution in rainy weather.
• Brake earlier to keep a greater distance to stop.
•
Reduce your speed, avoid sudden braking and turn
with extreme caution.
• Be more visible on the road.
• Wear reective clothing, use safety lights.
•
In the rain, slippery surfaces, such as road mark-
ings or lanes at pedestrian crossings, become very
dangerous and threaten wheel slip when braking.
Communication wells or tram tracks also become
more dangerous when wet.
Night driving
• Make sure the headlights are on.
• Wear bright and reective clothing.
•
Ride at night only when needed. If possible, slow
down and use known roads with street lighting.
ATTENTION: Modifying the vehicle is illegal.
Modifying the vehicle will aect its structure
or performance, which will shorten its lifetime.
The modied vehicle will not be covered by the
warranty. It is necessary to buy original spare
parts from authorized dealers. The manufacturer
is not able to guarantee the quality or durability
of the vehicle when buying non-original spare
parts on the market.
ATTENTION: Familiarize yourself with the
local laws and ordinances that regulate or limit
the age of the driver when using this electric
vehicle. Laws and regulations sometimes dier
signicantly depending on the country in which
you reside. It is your responsibility to know and
comply with local restrictions.
TECHNICAL SPECIFICATIONS
• Vehicle category: L1e-B
•
Required driving permissions: depends on the
specic country
• Battery: lithium-ion, removable
• Battery capacity: 60 V / 20 Ah (160 cells)
• Cell manufacturer: Samsung
• Battery weight: 9 kg
• Input voltage: 230/240 V
• Charging time: 5-6 hours
• Number of charging cycles: 800
• Charger: external with cooling, 67.2 V / 8 A
• Motor power: 2000 W
• Motor type: brushless
• Maximum torque: 35 Nm (at 2000 W power)
• Power transmission: directly in the wheel
• Maximum speed: 45 km/h
• Maximum range: 60* km
• Hill climbing ability: 15°
• Weight: 65 kg (without batteries)
• Maximum load: 150 kg
• Length: 1670 mm
• Width: 700 mm
• Height: 1120 mm
• Wheelbase: 1225 mm
• Front tire: tubeless, 3.00-10, 42J, 43J
• Rear tire: tubeless, 3.00-10, 42J, 43J
• Front brake: disc, Ø180 mm
• Rear brake: drum brake
* actual range depends on many factors, including
temperature, mass of traveler, degree of inclination,
driving dynamics etc.
ATTENTION: Due to continuous product im-
provement, the specications and design of the
device are subject to change without notice.
CONSTRUCTION OF AN
ELECTRIC MOTORBIKE
1. Rear-view mirrors (right and left)
2. Wind deector
3.
Headlight with direction indicators (left and right)
4. Front wheel
5. Dashboard
6. Acceleration handle and brakes (rear and front)
7. Storage box with USB charger
8. Floor
9. Seat (opens with access to storage and battery)
10. Rear lights
11. Place for the license plate
12. Rear wheel
13. Passenger footrests (left and right)
14. Central foot
15. Side foot
ATTENTION: Do not use the horn in the area
of non-use.
DASHBOARD
1. Left turn signal indicator
2. Gear indicator
3. Speed indicator
4. Trac lights indicator
5. Right turn signal indicator
6. Indicator of traveled kilometers
7.
Battery charge and usage indicator: green means the
battery is fully charged, red means the battery is at
low charge. When the indicator indicates a yellow
area, the battery is half charged. When the indicator
indicates a red area, the battery needs charging.
8. Left rear view mirror
9. Right rear view mirror
10. Accelerator handle
11. Rear brake lever
12. Front brake lever
13. Light switch: parking and trac lights
14. Horn
15. Turning signal switch (left and right)
16. Alarm switch
17. Reverse gear switch
IGNITION SWITCH
1. Insert the key in the ignition and turn right to the ON
position to start the vehicle.
2.
With the vehicle running, turn the ignition key to the
OFF position to turn o the vehicle.
3.
With the vehicle switched o, turn the ignition key
to the left to open the storage compartment under
the seat.
4. With the vehicle switched o, press the ignition key
into the steering column and turn it to the left to lock
the front wheel of the vehicle.
ATTENTION: Never push the scooter when the
handlebar is locked. This can result in a loss of
balance and a fall of the vehicle.
ATTENTION: Lock the vehicle and take the
key after parking.
BATTERY CHARGING
Before using the electric motorbike for the rst time,
charge the batteries for 6-9 hours with the supplied
charger.
Important charging instructions
•
The power switch lock must be in the OFF position
when charging the electric motorbike.
•
The motorbike uses a 60 V lithium battery. The
electric motorbike must be charged after each ride.
You must charge the electric motorbike if it has not
been used for 30 days or more. The charging time
is 4-5 hours.
Charging an electric motorbike via the charging socket:
Turn o the motorbike by turning the ignition key to the
OFF position. Insert the output plug into the charging
socket of the motorbike (see g. 1) and connect the
220/110 V input plug to the wall socket (see g. 2). The
battery is fully charged when the charger indicator is
green. We suggest extending the charging time by
1-2 hours to achieve better battery condition. When
charging is complete, unplug the charger’s input plug
and then the output plug.
Direct charging of the electric motorbike battery: Switch
o the motorbike by turning the ignition key to the OFF
position. Open the storage compartment under the seat.
Carefully remove the plug from the battery. Insert the
output plug into the battery charging socket (see g.
1) and connect the 220/110 V input plug to the wall
socket (see g. 2). The battery is fully charged when the
charger indicator is green. We suggest extending the
g. dashboard
g. construction of an electric motorbike
R
L
3
4
2
1
km/h
km
iBike
MP
ECU !
1
2
8
34
5
6
9
11
10
12 16
15 17
13
14
7

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery

electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery
electric vehicles
visit e-mio.eu
3. When pressing the brake lever, release the
accelerator handle.
BEFORE DRIVING
Before riding an electric motorbike, do the following.
This will ensure a safe and satisfying ride.
•
Check the condition of the tires, make sure they are
not worn or cracked.
• Check the tire pressure.
•
Check the condition of the drive, make sure it moves
the wheel correctly.
•
Check the condition of the lights, make sure that all
the bulbs light up correctly and the lights respond
to commands given by switches.
•
Check the condition of all parts, make sure all bolts
are tight, check the tension of the front and rear
brake cables and make sure the brakes are working
properly.
•
Check all moving parts such as the steering wheel.
Make sure that they move lightly and without un-
necessary resistance, lubricate them if necessary.
•
Charge the battery regularly when you don’t use the
electric motorbike too often. To extend the battery
life, charging should take place every 15 days in
summer and every 30 days in winter.
DRIVING INSTRUCTIONS
• Fold the foot (center or side, depending on which
you use) and hold the steering wheel steady with
both hands. Take a well-balanced position, put your
foot on the ground.
•
Insert the key in the ignition switch and turn to the
ON position. After turning on the power, grasp the
accelerator lever.
•
Slowly rotate the accelerator lever to avoid sudden
acceleration. Move your foot to the vehicle oor.
The speed of the electric scooter will increase as
the accelerator handle is turned.
•
Release the accelerator lever and press the brake lever
to stop the vehicle. Control the speed of the electric
scooter using the accelerator levers and brakes.
•
Pressing the brake lever will cut o the acceleration
power.
charging time by 1-2 hours to achieve better battery
condition. When charging is complete, unplug the
charger’s input plug and then the output plug.
ATTENTION:
1. Do not place the battery near heat or re.
2. Do not place the charger near water.
3.
For safety reasons, use only the original
charger supplied with the vehicle. Follow
the loading instructions.
Foot
1. Central foot: use when parking for a long time.
2. Side foot: use for temporary parking.
ATTENTION: The side cut-out function is acti-
vated when the side stand is folded out, which
prevents the scooter from moving when the
accelerator handle is accidentally moved. The
electric scooter will only be able to move with
the side foot folded in.
Reverse gear
Use reverse gear only when the vehicle is standing still.
After stopping the vehicle, press the reverse button
and gently rotate the accelerator lever. The vehicle will
move backwards.
Floor
Do not place any heavy objects on the oor. This will
aect the balance of the motorbike and may cause
danger.
Seat
1. Seat lock: turn the key in the ignition switch to the
left - you will be able to raise the seat and gain access
to the storage compartment and battery.
2. Press the seat down and it will lock automatically.
Front (disc) and rear (drum) brakes
To adjust the brakes to your requirements and adjust
their clearance, use the adjustable nut.
ATTENTION:
1.
The brake works according to its sensitivity.
You should brake by simultaneously pressing
the front and rear brake levers to ensure a
better and more eective braking process.
2.
Avoid continuous braking for a long time
as this may overheat the brakes and reduce
their eciency.
MAINTENANCE AND ADJUSTMENT
Battery
To extend the life of the battery, store the electric
motorbike in the garage to prevent low temperature,
which signicantly aects battery performance.
• Do not disassemble batteries and cells.
• Keep batteries and cells out of reach of children.
•
Do not connect the chargers cathode and anode
during the charging and discharging process. It is
forbidden to use any wires to connect the cathode
with the anode. This will cause a short circuit.
• Do not immerse the battery in water.
• Do not heat the battery to temperatures above 60
Celsius degrees. Do not place the battery next to
high temperature sources such as a replace, wall
heating, etc.
•
Do not smash, do not puncture, do not pierce or
throw the battery.
•
In the event of a battery leak and eye contact, rinse
immediately with plenty of water and seek medical
attention.
•
If you notice a strange smell of the battery, its warm-
ing up, color change, distortion or other irregularities,
immediately stop using the battery and move away.
Recommendations for the storage and use of
lithium-ion batteries
To extend battery life, follow these guidelines:
Charging:
1. Use only the charger provided with the electric mo-
torbike. Connect the power supply to the charger.
Insert the charger output connector into the battery
input connector. When the indicator light for fully
charged battery comes on, rst pull the plug from the
battery input connector. The usual charging time is
about 4-5 hours. If the battery is damaged, charging
or discharging must stop.
2.
Avoid over-discharging the battery, charge the battery
before it is completely discharged. Full discharge of
the battery aects its life.
Storage:
1. Do not store the battery in rooms where it is too hot/
cold and/or humid. The optimum battery storage
temperature is from -20 to 55 Celsius degrees. The
room must be dry and clean. Batteries cannot be
stored in a stacked order.
2.
The battery cannot be stored for a long time without
charging. Charge the battery once a month. The
battery should be stored fully charged.
Maintenance:
1. When you test a single battery cell, you must test it
directly, not through, for example, a wire. In this way
a voltage drop can be avoided.
2.
You must put on gloves or cut nails before removing
a single battery cell so as not to damage the cell and
as a protection against the substances in the cell. Pay
special attention to the battery cover, do not damage it.
3. It is forbidden to bend the battery cell, drop it, hit it,
short circuit it or damage its seal.
4.
When assembling the battery, there are a few im-
portant things to remember: the temperature of the
soldering iron should not exceed 350 Celsius degrees,
the soldering time should not exceed 3 seconds, the
soldering frequency should not exceed 5 times, the
next soldering can be applied to the previous ones
only after it has cooled down.
Vehicle cleaning
•
Do not use high pressure water to clean the electric
motorbike. Wetted/wet electrical parts and wiring
will aect the vehicle’s performance.
• Do not apply grease to the drum brake and tire.
•
Use appropriate cleaning medium to clean the metal
parts of the electric motorbike. This will protect the
metal parts of the vehicle against corrosion.
•
Use a cleaning medium to clean varnished plastic
parts and clean them with a dry cloth.
Brakes check
Main front and rear wheel brake checkpoints:
1. Press the adapter (1), turn the adjusting nut (3) while
holding the brake lever (2) and squeezing the brake
lever until the distance is 1/3-1/2 L. The brake shoes
must t snugly against the brake disc. Press the brake
lever. When it reaches the braking performance,
tighten the adjustment nut.
2.
The distance between the brake shoes and the brake
disc should be 1.5 mm.
3.
Replace the brake shoes when the usable area reach -
es 1/2.
Charger control
1. Use only the original charger supplied with the motor-
bike scooter. Remember to check the mains voltage
in your country. Do not confuse the 110 V charger
with the 220 V charger.
2. The motorbike must be turned o during charging.
3.
Do not move, rotate or subject the battery to damage
while charging.
4.
Check the charger sockets, make sure that the soldered
components are not damaged.
Engine and driver maintenance
1. During the rainy season, do not let the water cross
the engine center line. This is to protect the engine
against burnout and damage.
2. Do not press the brake lever and accelerator handle
while starting the engine to avoid damaging other
parts of the vehicle.
3.
Slow down when the weather conditions on the road
are not good. High vibrations and humidity can break
the connection of electrical parts.
TROUBLESHOOTING
Problem Cause Solution
The power indicator will light
up but the electric otorcycle
is still not working.
1. The engine is not working properly.
2. The side foot has not been folded or is not
fully folded, which cuts o the power supply.
1. Replace the engine. Call your dealer to
order a new engine.
2. Fold the side foot.
The power indicator does
not work when the power is
turned on.
1. Blown fuse or fuse holder.
2. The battery is not inserted/connected
correctly.
1. Replace the fuse or fuse holder.
2. Set/connect the battery accordingly.
The distance traveled on one
charge is smaller than usual.
1. Insucient tire pressure.
2. Insucient charging or battery is dam-
aged.
3. Frequent stopping and starting, overload-
ing the vehicle, driving uphill, strong wind.
1. Inate the tires.
2. Charge or replace the battery. Contact
the seller to order a new battery.
3. Drive in good weather conditions, on
level roads, do not perform any rapid accel-
eration and braking maneuvers, maintain
your normal speed.
The electric motorcycle is
losing speed.
1. Low battery.
2. The battery is damaged.
1. Charge the battery for 4-5 hours.
2. Replace the battery. Contact the seller
to order a new battery.
The engine is not working.
1. Brake lines are not in place and cut o
the circuit. 1. Adjust and re-position the brake lines.
ATTENTION: If you encounter other problems, do not disassemble the electric scooter yourself, contact
an authorized dealer.
Maintenance schedule
check adjust replace oil/grease 
Parts to be checked daily
every
60
days
every
180
days
engine, moving parts  
tires and all light bulbs  
brake discs and pads  
wheels 
fork 
brakes  
horn, charger and battery  
USER
MANUAL
with
li-ion
battery
