Mega Motion M5 User manual

Electric Scooter
User Manual Model No.: M5

ＥＮ-------------------------------------------------01
ＦＲ-------------------------------------------------14
ＤＥ-------------------------------------------------28
ＥＳ-------------------------------------------------42
ＩＴ--------------------------------------------------56
ＮＬ------------------------------------------------70

SAFETY REMINDER-------------01-02
PRODUCT OVERVIEW--------------03
SPECIFICATIONS--------------------04
E-SCOOTER INSTRUCTION----05-06
E-SCOOTER APP-------------------07
HOW TO RIDE---------------------08
RIDING NOTICE ------------------09
DAILY CARE AND
MAINTENANCE----------------10-11
QUESTION & ANSWER-------12-13
ＥＮ
?

SAFETY REMINDER
01
△WARNING
Wear helmets and knee pads in case of falls and injuries when you learn to
ride the scooter.
The electric scooter is a leisure device. But once they're in a public area, they'll be
seen as vehicles, subjecting to any risks faced by vehicles. For your safety, please
follow instructions in the manual and traffic laws and regulations set forth by
government and regulatory agencies.
●At the same time, you should understand that risks cannot be entirely avoided as
others may violate traffic regulations and drive incautiously, and you're exposed to road
accidents just as when you're walking or biking. The faster the scooter is, the longer it
takes to stop. On a smooth surface, the scooter may slip, lose balance, and even
result in a fall. Thus it is crucial that you use caution, keep proper speed and distance,
especially so when you're unfamiliar with the place.

SAFETY REMINDER
02
●Closely follow the safety instructions in the manual. Seller shall not be liable for any
financial losses, physical injuries, accidents, legal disputes and other interest conflicts
resulted from actions that violate user instructions.
●Check the scooter before every use. When you note loosen parts, low battery alerts,
excessive wear, strange sounds, malfunctions and other abnormal conditions, stop riding.
●Do not lend your scooter to whoever doesn't know the operations. And when you do
lend it to your friends, please take the responsibility to ensure he/she knows the opera-
tion and wears the safety gear.
●Respect pedestrians' Right of Way. Try not to startle them while driving, especially
children. When you ride from behind pedestrians, ring your bell to give them a heads-up
and slow your scooter to pass from their left (applicable to countries where vehicles drive
on the right). When you ride across pedestrians, keep to the right at a low speed. When
you drive across pedestrians, keep the lowest speed or getting off the vehicle.

PRODUCT OVERVIEW
03
1. LED display
2. Handle
3. Brake
4. Accelerator/Throttle
5. Headlight
6. Lever bar
7. Rubber plug hole
8. Fixed leg
9. Folding bar
10. Folding spanner
11. Anti-slip pedal
12. Rear fender
13. Disc brake
14. Tail lights
15. Reflective sticker
16. Rear wheel
17. Disc brake disc
18. Front fender
19. Motor
20. Reflective sticker
21. Kickstand
22. Bottom cover
23. Side LED lights
24. Frame
26. Electronic brake
25. Bell
Product Contents Quantity
Electric Scooter 1
Charger 1
User Manuel 1
Tool kit (Including screws
and hex wrench) 1
1
8
18
15
16
17
22
24
2
4
3
25
26
5
6
7
10
11
21
23
12 13
14
9
19
20

SPECIFICATIONS
04
Motor 350W
Battery 36V/7.5AH
Charging time 4-6H
Display LED
Frame Material
Aluminum alloy + ABS + PC
Tires Rubber Tubeless
Wheel Size 8.5inch
Climbing Degree
15°
Riding Modes
Beginner Mode: 9.3mph (15km/h)
Normal Mode: 13.6mph (22km/h)
Sports Mode: 18.5mph (30km/h)
Double Braking System
Front: Electric brake
Rear: Disc brake
Voltage
36V
Load Range
55-220 lbs (25-100kg)
Age
16-50
Dimensions
46.5* 19.7*43.7inches (118*50*111 cm)
Dimensions (After folding)
44.1*13.0*16.9inches (112*33*43 cm)

E-SCOOTER INSTRUCTION
05
Note :Do not keep your feet on the rear mudguard.
1. To turn on/off the power: press the power button for 3 seconds.
2. To accelerate: When the scooter starts to coast, put both feet on the deck and press
the accelerator.
3. To brake: Release the accelerator and squeeze the brake lever for a sudden brake.
4. To switch different speeds modes by tabbing power button
Beginner mode:”S” gear characters display in blue
Normal mode: ”S” gear characters display in yellow
Sports mode: ”S” gear characters display in red
5. To turn on/off the Headlights: Double tab the power button.
6. To switch (KM/H) & (Mph): Treble tab the power button.
7. Cruise Control: Keep current speed for 6 seconds to activate the cruise mode. To
deactivate the cruise mode by pressing accelerator again or brake.

E-SCOOTER INSTRUCTION
06
Speed
Bluetooth
Gear indicator
Headlight Battery indicator
Switch
Digital display mode
LED Display
Branke handbar
Handle
Throttle button
Bell
Switch
Electronic brake

E-SCOOTER APP
07
Download "Cxinwalk" from "App Store"(iPhone) or "Google Play"(Android), or scan the QR
code as below to install the App, then connect to your scooter.
PASSWORD: 000000

08
HOW TO RIDE
Before riding: Wear helmets and knee pads in case of falls and injuries when you learn to
ride the scooter.
● Turn on the scooter, and check the power indicator.
● Step on the deck with one foot, and slowly kicks off the other on the ground.
● When the scooter starts to coast, put both feet on the deck and press the accelerator.
● Release the accelerator and squeeze the brake lever for a sudden brake.
● Tilt your body to the steering direction as you turn, and slowly turn the handlebar.

09
RIDING NOTICE
● Do not ride in the rain.
● Look out for doors, elevators and other overhead obstacles.
● Do not accelerate when you go downhill.
● Do not press the accelerator when you're walking alongside the scooter
● Always steer clear of obstacles.
● Do not hang bags or other heavy stuff on the handlebar.
● Keep both feet on the deck all time.
● Keep your speed between 3.1-6.2 mph when you ride through speed bumps, elevator
door sills, bumpy roads or other uneven surfaces. Slightly bend your knee to better adjust
mentioned surfaces.
● Do not ride in traffic lanes or residential areas where vehicles and pedestrians are both
allowed
● Do not turn the handlebar violently during high-speed riding
● Do not ride in a ponding that is higher than 0.78 inches
● Do not ride with anyone else, including children

DAILY CARE AND MAINTENANCE
10
Cleaning and storage
If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't
scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off
with a damp cloth. Notes: do not clean the scooter with alcohol, gasoline, kerosene or
other corrosive and volatile chemical solvents to prevent dire damage. Do not wash the
board with a high-pressure water spray. During cleaning, make sure that the scooter's
turned off, the charging cable is unplugged, and the rubber flap is closed as water leakage
may result in electric shock or other major problems.When the scooter not in use, keep it
indoors where it is dry and cool. Do not put it outdoors for long time. Excessive sunlight,
overheating and overcooling accelerate the battery pack's lifespan．
Battery maintenance
1. Use original battery packs, use of other models or brands may bring about safety
issues.
2. Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts
away from metal objects to prevent short circuit which may result in battery damage or
even injuries and deaths.
3. Use original power adapter to avoid potential damage or fire.

DAILY CARE AND MAINTENANCE
11
4. Mishandling of used batteries may do tremendous harm to the environment. To
protect natural environment, please follow local regulations to properly dispose used
batteries.
5. After every use, fully charge the battery to prolong its lifespan.
Store
1. Please try to store the scooter in a cool and dry place between 14°F and 104°F.
extremely humid environments the interior of the scooter may suffer condensation or
even water accumulation, which may damage the battery rapidly.
2. In daily use, try to avoid recharging the scooter after completely exhausting the
battery. If the battery is low, charge it as soon as possible.
3. Please charge the scooter every other month to preserve the battery.

QUESTION & ANSWER
12
?
1.What if the E-Scooter arrived missing accessory or broken part?
A: Please take a photo and send to Hiboy Support Team by sending email: support@mega-
motion.eu
And Hiboy Support Team will reply you soon and send correct accessory or part replace-
ment.
2. Is that possible to replace some components for example the rear cover?
A: Yes, please take a photo and send to Hiboy Support Team by sending email:
[email protected]
And Hiboy Support Team will reply you soon.
3. What operating temperatures are recommended? Is it waterproof?
A: Operating temperatures: 14°F-104°F; Storage temperature: -4°F-113°F;
Waterproof: IP54 resistance, which means that it is protected from water spray from any
direction.

QUESTION & ANSWER
13
?
4.Is there an Android/iOS app? If so, what does it do?
A: Yes, the app is Cxinwalk app.
Simply pair the Electric Scooter via Bluetooth and use the app to view current speed,
remaining power, and other real-time riding statistics. Firmware updates ensure that you
always have the best riding experience possible. Using the core cruise control technology
in cars, the Electric Scooter uses a unique algorithm that receives signal input from speed
sensors to maintain smooth and stable cruise control. This reduces tension and fatigue for
riders, as well as optimizes battery for longer rides.

RAPPEL DE SECURITE---------15-16
PRESENTATION DU PRODUIT----17
CARACTERISTIQUES---------------18
L’UTILISATION DE LA
TROTINETTE ELECTRIQUE----19-20
LES APPLICATIONS POUR LA
TROTINETTE ELECTRIQUE--------21
COMMENT LA PRENDRE EN
MAIN ?----------------------------22
NOTICE D’USAGE --------------23
SOINS ET ENTRETIENS
QUOTIDIENS ----------------24-25
QUESTIONS-REPONSES---26-27
ＦＲ
?
14

RAPPEL DE SECURITE
15
△ATTENTION
Le port d'un casque et de protections aux genoux est conseillé en cas de chute
durant l’utilisation.
La trotinette électrique est un dispositive de loisir. Mais une fois dans un lieu public,
ce produit est consideré comme un véhicule, soumis aux risques de la route. Pour
votre sécurité, veuillez suivre les instructions du manuel et les lois et règlements de
la circulation établis par le gouvernement et les organismes de réglementation.
●Dans le même temps, vous devez comprendre que les risques ne peuvent pas être
entièrement évités, car d’autres personnes sur la route peuvent enfreindre les règles de
celle-ci, conduire avec prudence, et vous serez moins exposé aux accidents de la
route, tout comme lorsque vous marchez ou faites du vélo. Plus la trotinette est rapide,
plus le temps d'arrêt est long. Sur une surface lisse, la trotinette peut glisser, perdre
son équilibre et même entraîner une chute. Il est donc crucial d’être prudent, de
maintenir une vitesse ainsi qu’ une distance appropriées, en particulier lorsque vous ne
connaissez pas l’endroit.

RAPPEL DE SECURITE
16
●Suivez attentivement les consignes de sécurité du manuel. Le vendeur ne saurait
être tenu responsable des pertes financières, des dommages corporels, des
accidents, des litiges et autres conflits d’intérêts résultant d’actes enfreignant les
instructions de l’utilisateur.
●Vérifiez l’appareil avant chaque utilisation. Lorsque vous voyez des pièces desserrées,
des alertes de batterie faible, une usure excessive, des sons étranges, des dysfonctionne-
ments et autres conditions anormales, arrêtez de conduire.
●Ne prêtez pas votre appareil à quiconque ne connaît pas les conditions d’utilisation.
Et lorsque vous le prêtez à vos amis, veillez à ce qu'il / elle connaisse les conditions
d’utilisation et porte l'équipement de sécurité.
●Respecter le droit de passage des piétons. Essayez de ne pas les surprendre en
conduisant, surtout les enfants. Lorsque vous roulez derrière les piétons, sonnez à votre
guise pour les avertir et ralentissez le passage de votre trotinette par la gauche (applica-
ble aux pays où les véhicules roulent à droite). Lorsque vous laissez traverser des
piétons, restez à droite à basse vitesse. Lorsque vous passez devant des piétons,
maintenez la vitesse la plus basse ou descendez du véhicule.

PRESENTATION DU PRODUIT
17
1. Affichage LED
2. Manipulateur
3. Frein
4. Accélérateur
5. Phare
6. Barre à levier
7. Trou de bouchon en
caoutchouc
8. Support fixe
9. barre à plier
10. Levier
11. Pédale anti-dérapante
12. garde-boue arrière
13. frein à disque
14. grandes lumières
15. autocollant réfléchissant
16. roue arrière
17. disque de frein à disque
18. garde-boue avant
19. moteur
20. autocollant réfléchissant
21. béquille
22. couvercle inférieur
23. lumières latérales de LED
24. Cadre
25. Cloche
26. Frein électronique
Contenu dans la livraison Quantité
Trotinette éléctrique 1
Chargeur 1
Manuel d’utilisation 1
Boîte à outils (vis et clé
héxagonale) 1
1
8
18
15
16
17
22
24
2
4
3
25
26
5
6
7
10
11
21
23
12 13
14
9
19
20
