e-survey E3L User manual

Shanghai eSurvey GNSS Co., Ltd.
1st Edition
V1.1
E3L
USER GUIDE
TOTAL STATION

SHANGHAI ESURVEY GNSS CO., LTD.
Copyright © Shanghai eSurvey GNSS Co., Ltd. 2021. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means
without prior written consent of Shanghai eSurvey GNSS Co., Ltd.
Trademarks and Permissions
and other eSurvey trademarks are trademarks of Shanghai eSurvey GNSS Co.,
Ltd.
All other trademarks and trade names mentioned in this document are the property of their
respective holders.
Notice
The purchased products, services and features are stipulated by thecontract made between
eSurvey and the customer. All or part of the products, services and features described in
this document may not be within the purchase scope or the usage scope.
The information in this document is subject to change without notice. Every effort has been
made in the preparation of this document to ensure accuracy of the contents, but all
statements, information, and recommendations in this document do not constitute a
warranty of any kind, express or implied.

SHANGHAI ESURVEY GNSS CO., LTD.

SHANGHAI ESURVEY GNSS CO., LTD.
I
Contents
1 Before You Start ....................................................................................... 1
1.1 Precautions for Safe Operation...............................................................................1
1.1.1 Warning...............................................................................................................1
1.1.2 Caution................................................................................................................1
1.2 Exceptions from Responsibility..............................................................................2
1.3 Safety Standards for Laser......................................................................................2
2 E3L at a Glance......................................................................................... 3
2.1 Overview ...................................................................................................................3
2.2 Trigger Key ...............................................................................................................3
2.3 Operating Panel........................................................................................................4
2.4 Display ......................................................................................................................5
2.4.1 Soft Keys.............................................................................................................5
2.4.2 Symbols...............................................................................................................6
2.5 Input Mode................................................................................................................7
2.6 Battery.......................................................................................................................7
2.6.1 Replace and Mount the Battery...........................................................................8
2.6.2 Recharge the Battery...........................................................................................8
3 Quick Start ................................................................................................ 9
3.1 Set up the Instrument ............................................................................................10
3.2 Center with the Laser Plummet.............................................................................10
3.3 Do Levelling-up ......................................................................................................11
3.3.1 Do Basic Levelling-up........................................................................................11
3.3.2 Do Accurate Levelling-up...................................................................................11
3.3.2.1 Do Accurate Levelling-up with the Tubular Level........................................12
3.3.2.2 Do Accurate Levelling-up with the Electronic Level on the Screen .............12
3.4 Set EDM...................................................................................................................13
3.5 Start Measurement.................................................................................................13
4 Function Key........................................................................................... 14
4.1 Level / Plummet......................................................................................................14
4.2 Target Offset...........................................................................................................14
4.3 Target Set................................................................................................................15
4.4 Delete Last Record.................................................................................................15
4.5 Height Transfer.......................................................................................................16
4.6 Hidden Point...........................................................................................................17

SHANGHAI ESURVEY GNSS CO., LTD.
II
4.7 Free-Coding............................................................................................................19
4.8 Laser Pointer ..........................................................................................................20
4.9 Check Tie ................................................................................................................20
4.10 Main Settings........................................................................................................21
4.11 Tracking ................................................................................................................21
4.12 Light On/Off ..........................................................................................................21
4.13 Units ......................................................................................................................21
5 Menu Key................................................................................................. 22
5.1 Overview .................................................................................................................22
5.2 Program Menu........................................................................................................23
5.2.1 Surveying...........................................................................................................24
5.2.1.1 Set a Job.....................................................................................................24
5.2.1.2 Set the Station.............................................................................................25
5.2.1.3 Set the Orientation ......................................................................................25
5.2.1.4 Start Survey ................................................................................................26
5.2.2 Stake out ...........................................................................................................27
5.2.2.1 Set a Job.....................................................................................................27
5.2.2.2 Set the Station.............................................................................................27
5.2.2.3 Set the Orientation......................................................................................27
5.2.2.4 Start Staking out..........................................................................................28
5.2.3 Free Station.......................................................................................................31
5.2.3.1 Set a Job.....................................................................................................32
5.2.3.2 Set Accuracy Limit ......................................................................................32
5.2.3.3 Start Free Station........................................................................................33
5.2.4 COGO................................................................................................................34
5.2.4.1 Set a Job.....................................................................................................35
5.2.4.2 Set the Station.............................................................................................35
5.2.4.3 Set the Orientation......................................................................................35
5.2.4.4 Start COGO.................................................................................................35
5.2.4.4.1 Set Inverse or Traverse Computation...................................................35
5.2.4.4.1.1 Set Inverse Computation................................................................36
5.2.4.4.1.2 Set Traverse Computation .............................................................37
5.2.4.4.2 Set Intersections...................................................................................38
5.2.4.4.2.1 Set Bearing-bearing.......................................................................38
5.2.4.4.2.2 Set Bearing-distance......................................................................39
5.2.4.4.2.3 Set Distance-distance....................................................................40
5.2.4.4.2.4 Set Four Points ..............................................................................41
5.2.4.4.3 Set Offset..............................................................................................42
5.2.4.4.3.1 Set Distance-offset.........................................................................42
5.2.4.4.3.2 Set Point by....................................................................................43
5.2.4.4.4 Set Extension .......................................................................................44
5.2.5 Tie Distance.......................................................................................................45
5.2.5.1 Set a Job.....................................................................................................46
5.2.5.2 Set the Station.............................................................................................46
5.2.5.3 Set the Orientation ......................................................................................46

SHANGHAI ESURVEY GNSS CO., LTD.
III
5.2.5.4 Start Tie Distance........................................................................................46
5.2.6 Area and Volume...............................................................................................48
5.2.6.1 Set a Job.....................................................................................................50
5.2.6.2 Set the Station.............................................................................................50
5.2.6.3 Set the Orientation ......................................................................................50
5.2.6.4 Start Area and Volume................................................................................50
5.2.7 Remote Height...................................................................................................51
5.2.7.1 Set a Job.....................................................................................................52
5.2.7.2 Set the Station.............................................................................................52
5.2.7.3 Set the Orientation......................................................................................52
5.2.7.4 Start Remote Height....................................................................................52
5.2.8 Reference Line/Arc............................................................................................53
5.2.8.1 Set a Job.....................................................................................................53
5.2.8.2 Set the Station.............................................................................................53
5.2.8.3 Set the Orientation ......................................................................................53
5.2.8.4 Start Reference Line/Arc.............................................................................54
5.2.8.4.1 Set Reference Line...............................................................................54
5.2.8.4.2 Set Reference Arc ................................................................................56
5.2.9 Construction ......................................................................................................59
5.2.9.1 Set a Job.....................................................................................................59
5.2.9.2 Set EDM......................................................................................................59
5.2.9.3 Set the New Construction Site ....................................................................59
5.2.9.4 Continue the Previous Site..........................................................................60
5.2.10 Lead Measure..................................................................................................61
5.2.10.1 Set a Job...................................................................................................61
5.2.10.2 Start Lead Measurement...........................................................................61
5.2.10.2.1 Set the Lead .......................................................................................62
5.2.10.2.2 Set the Station....................................................................................63
5.2.10.2.3 Measure the Point...............................................................................63
5.2.10.2.4 Calculate the Lead..............................................................................64
5.2.10.2.5 View Data ...........................................................................................65
5.2.10.2.6 Transfer Data......................................................................................65
5.2.11 2D-Road ..........................................................................................................65
5.2.11.1 Set a Job...................................................................................................66
5.2.11.2 Set the Station...........................................................................................66
5.2.11.3 Set the Orientation ....................................................................................66
5.2.11.4 Start 2D-Road...........................................................................................66
5.2.11.4.1 Define Road........................................................................................67
5.2.11.4.1.1 Set a Reference Point..................................................................67
5.2.11.4.1.2 Define Road(2D) Data..................................................................68
5.2.11.4.1.2.1 Set Main Point.......................................................................69
5.2.11.4.1.2.2 Set Intersection Point ............................................................70
5.2.11.4.2 Set Road Staking out..........................................................................71
5.2.11.4.3 View Data ...........................................................................................72
5.2.11.4.4 Transfer Data......................................................................................73
5.3 Setting Menu...........................................................................................................74
5.4 EDM Menu...............................................................................................................77
5.4.1 Common Parameters.........................................................................................77

SHANGHAI ESURVEY GNSS CO., LTD.
IV
5.4.2 Atmospheric Parameters ...................................................................................78
5.4.3 Times of Distance Measuring............................................................................79
5.4.4 Projection Scale.................................................................................................79
5.4.5 Signal Intensity ..................................................................................................79
5.5 Job Menu.................................................................................................................80
5.5.1 Job.....................................................................................................................80
5.5.2 Fixed points .......................................................................................................81
5.5.3 Measurements...................................................................................................81
5.5.4 Codes................................................................................................................82
5.5.5 Initialize Memory................................................................................................82
5.5.6 Memory Statistics ..............................................................................................83
5.5.7 Memory Selection..............................................................................................83
5.5.8 USB...................................................................................................................84
5.5.9 File Copy ...........................................................................................................84
5.5.10 DAT Data Change ...........................................................................................84
5.6 Adjust Menu............................................................................................................85
5.6.1 Horizontal Collimation........................................................................................85
5.6.2 Vertical Index.....................................................................................................88
5.6.3 View Adjustment Value......................................................................................90
5.6.4 Tilt Offset ...........................................................................................................90
5.7 Com Menu...............................................................................................................92
5.8 Download Menu......................................................................................................93
5.9 Start Menu...............................................................................................................94
5.10 Info Menu ..............................................................................................................95
6 Maintenance............................................................................................ 96
6.1 Cleaning and Drying ..............................................................................................96
6.2 Storage....................................................................................................................96
6.3 Transportation........................................................................................................96
6.4 Check ......................................................................................................................96
7 Check and Correction............................................................................. 97
7.1 Instrument Constant ..............................................................................................97
7.2 Tubular Level..........................................................................................................98
7.3 Circular Level..........................................................................................................98
7.4 Optical Sight of the Telescope..............................................................................99
7.5 Laser Centering Device .........................................................................................99
7.6 Vertical Line of the Telescope Reticle................................................................100
7.7 Collimation Error of the Instrument....................................................................101
7.8 Index Error of the Vertical Circle.........................................................................101
7.9 Zero Position Error of the Tilt Offset ..................................................................101
7.10 Optical Axis and Telescope Sighting Axis for Distance Measurement .........101

SHANGHAI ESURVEY GNSS CO., LTD.
V
8 Appendix............................................................................................... 102
8.1 Atmospheric Correction Formula and Chart (Just for reference)....................102
8.2 Correction for Refraction and Earth Curvature .................................................103
8.3 Assembling and Disassembling for the Three-jaw Tribrach ............................104

SHANGHAI ESURVEY GNSS CO., LTD.
VI

SHANGHAI ESURVEY GNSS CO., LTD.
1
1 Before You Start
Before you start, please carefully read this part.
1.1 Precautions for Safe Operation
For the safety of your product and prevention of injury to operators and other persons as
well as prevention of property damage, please read this part carefully before using your
product.
Precautions can be divided into the following types according to the degree of loss or
injury in case of negligence or omission:
Warning: Precautions requiring special attention. Ignoring this indication may
possibly result in death or serious injury to the operator.
Caution: Precautions mainly for informing, such as supplementary instructions and
using limitations. Ignoring this indication may possibly result in personal injury or
property damage.
1.1.1 Warning
This instrument is only for qualified surveyor or professional users who have a good
knowledge of surveying.
Please wear the required protectors (safety shoes, helmet, etc.) when operating.
Only e-Survey authorized distributors can disassemble or rebuild the instrument.
Please do not collimate the sun directly. Otherwise, eye injury or blindness and
objective damage may occur.
Please do not cover the charger when charging. Otherwise, fire may occur.
Please do not use wet battery or charger, defective power cable, socket or plug,
and power cable and battery not specified by e-Survey. Otherwise, fire or electronic
shock may occur.
Please do not put the instrument close to burning gas or liquid and the battery in the
fire or high temperature condition, and do not use the instrument in coal mine.
Otherwise explosion may occur.
Please avoid short circuit of the battery. Otherwise, fire may occur.
Please avoid disturbance of severe electrostatic discharge. Otherwise, this
instrument may have some degradation of performance like switching on/off
automatically and so on.
1.1.2 Caution
Please set up the instrument on the tripod, and make sure the connection between
the tripod and instrument is firm. It is better to work with wooden tripod for the
accuracy of measurement.
Please correctly and carefully assemble the tribrach on the instrument for if it is not
correctly or stably installed, the accuracy may be affected, and frequently check the
tribrach to make sure all screws that connect the tribrach and alidade are tightly
locked, and the central fixing screw is tight.
When transporting, please try your best to lighten libration on the instrument.
When carrying the instrument, please tightly hold the handle.

SHANGHAI ESURVEY GNSS CO., LTD.
2
The sharp temperature changing on the instrument or prism will shorten the
distance measurement range. Therefore, after taking the instrument out from a
condition in which the temperature is totally different from now, please wait for some
time until the instrument adapts to the surrounding condition.
Please do not take out the battery when the instrument is on, and replace the
battery after powering off the instrument. Otherwise, the stored data may be lost.
Please do not touch the instrument with wet hand. Otherwise, there is danger of
electric shock.
Please do not arbitrarily stand or seat on the carrying case, or turn over it.
Otherwise, the instrument may be damaged.
Please be careful of the tripod tiptoe when setting up or moving it.
Please do not drop the instrument or the carrying case, or use defective belt,
agraffe or hinge. Otherwise, the instrument may be damaged.
Please do not touch liquid leaking from the instrument or battery. Otherwise,
harmful chemicals could cause burn or blisters.
1.2 Exemption from Responsibility
You are expected to follow all operating instructions and regularly check the performance
of this instrument.
The manufacturer assumes no responsibility for any damage and loss of profits caused by
the following conditions:
A faulty or intentional usage or misuse.
Any disasters, such as earthquakes, storms, floods etc.
A change of data, loss of data, an interruption of business etc.
Wrong transport, or actions due to connecting with other products.
Usage not explained in the user guide.
1.3 Safety Standards for Laser
E3L adopts the safe and visible laser on the basis of Specification Standard of radiant
products (FDA CDRH.21CFR Part 1040.10 and 1040.11) and Safety of laser products –
parts 1: Equipment classification, requirements and user’s guide (IEC 60825-1:2001).
According to above standards, E3L is class IIIa/3R laser products. When the prism or
reflective sheet is selected in Config mode as target, the output is equivalent to the safer
class 1.
Warnings for Safety
To avoid permanent eye damage, please pay special attention to the following warnings:
Never point the laser beam at other’s eyes.
Never directly look into the laser beam source.
Never stare at the laser beam.
Never look at the laser beam through a telescope or other optical devices.

SHANGHAI ESURVEY GNSS CO., LTD.
3
2 E3L at a Glance
E3L is a high-quality electronic total station, designed for the construction site. Its
innovative technology and simple operations make the daily surveying jobs easier.
Undoubtedly, it is ideally suited for simple construction surveys and stake out tasks.
2.1 Overview
Each part of E3L is as follows:
2.2 Trigger Key
The trigger key has the following settings, activated in SETS menu:
ALL
DIST
OFF
See Setting Menu for details.

SHANGHAI ESURVEY GNSS CO., LTD.
4
2.3 Operating Panel
The operating panel is as follows:
Key
What it does
Power key
To turn on the instrument in no time or turn off the instrument.
Backlight key
To turn on / off the backlight.
Laser pointer key
To turn on / off the laser pointer.
Levelling-up key
To do levelling-up. See 3.3 Do Levelling-up for details.
Function key
To perform sorts of fast function settings defined by program
screen.
Selection keys
To select the functions matching the soft keys. About soft keys, see
2.4.1 Soft Keys for details.
Page key
To go to the next page when a display consists of several pages.
Menu key
To access to 9 main menu. See 5 Menu Key for details.
Enter key
To confirm an entry or selection.
Navigation keys
To control the focus bar within the screen and the entry bar within
a field.
Escape key
To quit a screen or edit mode without saving changes.
Alphanumeric
keys
To directly enter characters (including numbers on keys and letters
above keys). See 2.5 Input Mode for details.
Star key
To access star setting mode and do some basic essential settings,
including backlight, contrast, reticle illumination, tilt correction, and
laser pointer.
User key
It is configurable with function from the Function key.
Shift key for
character entry
To shift between number and alphabet when inputting, and to shift
target model when measuring.
Stake out key
A shortcut key for staking out.

SHANGHAI ESURVEY GNSS CO., LTD.
5
2.4 Display
E3L is equipped with two large LCD screens (240 * 128dots). And the LCD could display 8
lines with 24 characters per line.
Note: Please do not touch the display with sharp things.
The main display is as follows:
2.4.1 Soft Keys
Under soft keys, a selection of commands and functions are listed at the bottom of the
display. You can press F1 ~ F4 on the operating panel to execute the related command.
Main soft keys include the following:
Soft key
What it does
ALL
To start distance and angle measurements and save measured values.
DIST
To start distance and angle measurements without saving measured values.
REC
To save the currently displayed values.
ENT
To confirm an entry or selection.
ENH
To open the coordinate input mode.
LIST
To display the list of available points.
FIND
To start the search for the point entered.
EDM
To display EDM settings.
PREV
To return to the last active display.
↓
To go to the next display.
→|
To go to the first display.
OK
To set the displayed message or display and quit display.
SHIFT=0
To set the value to zero.
STOP
To stop procedure being carried out.
ALF
Alphabet mode. Its function is equivalent to Shift key.
NUM
Numeric mode. Its function is equivalent to Shift key.

SHANGHAI ESURVEY GNSS CO., LTD.
6
2.4.2 Symbols
Symbols indicate a particular operating status of E3L.
Main symbols include the following:
Symbols
What it means
It indicates the level of the remaining battery capacity.
The compensator is on.
The compensator is off.
The prism type is prism.
The prism type is sheet.
The prism type is no prism.
Internal storage mode.
External storage mode.
The instrument is connected to the Bluetooth. When the symbol
does not show, the instrument is communicated by RS232 serial
port.
I / II
When Face I Definition is set to Face_I, I means face left, and II
means face right; when it is set to Face_II, I means face right,
and II means face left.
◀/▶/▲ / ▼
Choice fields (setting the options).
The vertical distance between the station and the target point.
The horizontal distance between the station and the target point.
The slant distance between the station and the target point

SHANGHAI ESURVEY GNSS CO., LTD.
7
2.5 Input Mode
Insert Characters
If a character is skipped (e.g.13 instead of 123), you can insert it later by doing the
following:
1. Place the cursor on 1.
2. To insert an empty character on the right of 1, press F1 INSERT.
3. Input the new character 2.
Delete Characters
You can delete characters after inputting by doing the following:
1. Place the cursor on the character to be deleted.
2. To delete the character, press F2 DELET.
Clear Characters
You can clear characters by doing the following:
1. Place the cursor on any position among character fields.
2. Press F3 CLEAR.
Toggle through Characters
You can toggle through characters by doing one of the following:
To input numbers, directly press the Alphanumeric key.
To input letters, press Shift / F4 ALF/NUM and the Alphanumeric key.
To input numbers and letters at the same time, continuously press the
Alphanumeric key several times.
Example
Press number 7 several times to toggle through 7 → A → B → C → 7 → A...
2.6 Battery
About the battery, please note the following:
The battery’s working time will be affected by many factors, such as ambient
temperature, recharging time, recharging and discharging times. Therefore, it is
suggested to recharge the battery full or prepare several full batteries before
operation.
The battery symbol only indicates power capability for current measurement mode.
The power consumption in distance measurement mode is more than in angle
mode, if the instrument enters into distance measurement mode from angle mode,
the power maybe auto-off because of lower battery.
The symbol only indicates the supply power but not the instantaneous power
change. And if the measurement mode changes, the symbol will not immediately
show the power’s decrease or increase.
It is suggested to check every battery power before field work.

SHANGHAI ESURVEY GNSS CO., LTD.
8
2.6.1 Replace and Mount the Battery
To replace and mount the battery, do the following:
1. Turn the battery lock button to unlock status :
2. Pull the battery lock button out to open the battery cover.
3. Remove the battery by pulling it toward you.
4. Insert the new battery to the instrument.
5. Close the battery cover, and turn the battery lock button to lock status.
2.6.2 Recharge the Battery
New battery or battery that has not used for several months should be recharged for at
least 10 hours to attain best status.
The status of the battery charging:
Red light is always on: in charging.
Green light is always on: charging is completed.
At this time, please recharge the battery continuously for another 1~2 hours, which
is good for the battery.
Red light flashes: waiting for charging, without a load, poor contact or battery failure
To recharge the battery, do the following:
1. Connect the charger connector to the battery:
2. Plug the charger on 220V AC power supply. The red lamp becomes lighting.
At this time, if the red light flashes, please take off the battery charger and plug it on
220V AC power supply after a while.

SHANGHAI ESURVEY GNSS CO., LTD.
9
3 Quick Start
The process of quick start is as follows:
Note: When the instrument is working, it is normal if you hear the noise from
instrument motor, it will not affect the instrument work.

SHANGHAI ESURVEY GNSS CO., LTD.
10
3.1 Set up the Instrument
To set up the instrument, do the following:
1. To set up the tripod, do the following:
a. Extend the extension legs to suitable lengths.
b. Tighten the screws on the legs, and make sure the legs are spaced at equal
intervals and the head is approximately level.
c. Set the tripod so that the head is positioned over the surveying point.
d. Make sure the tripod shoes are firmly fixed in the ground.
2. To attach the instrument on the tripod head, do the following:
a. Carefully mount the instrument on the tripod head.
b. Supporting it with one hand, tighten the centering screw on the bottom of the
unit to make sure it is secured to the tripod.
3.2 Center with the Laser Plummet
External influences and the surface conditions may lead to the requirement of the
adjustment of the laser intensity. The laser can be adjusted in 25% steps as required. If
the instrument is equipped with laser plummet, after activating electronic level, the laser
plummet adjusting bar will display.
To center with laser plummet, do the following:
1. To enter LEVEL/PLUMMET display, press Fn, and press F1 / 1.
2. To turn on / off the laser plummet, press ◀/ ▶.
