Eagle Eye DV207 User manual

Smallest Full Feature Pocket DVR
With high resolution in theworld
USER MANUAL
Please read this usermanualcarefully and thoroughly before any attemptto
Install and operate this product and retain itforyourfuturereference.

CATALOG
INTRODUCTION ..2
WARNING .. .. .. 3
FEATURES ... ...4
APPLICATION ...5
GETTINGSTAETED ... 6
Identifyingthe parts of the mainunit .. 6
Identifying the parts ofthe camera .. . .6
LCD screen indicators .. ..7
RecordingMode .. ........ 7
Playback Mode .. ..7
INSTALLATION .8-9
Batteryinstallation ... 8
Parameters for batteryusing .8
MiniSD Card installation ... ..9
BASIC OPERATION .. .. .. 10-13
Start Recording ... .10
Video content view .. 11
Delete the video files ..12
Connect withother A/Vdevice ...13
Connect withPC ... ..14-15
SYSTEMSETTING ...... ...16-27
Recordingmode setting ..16
Resolutionsetting .. ..17
Recordcontent setting .. ..18
Video Time and datesetting ... 19
Autocoversetting .20
Choose memory ...21
Current Timeand Datesetting ..22-23
Languagesetting ..24
Videooutputsetting .25-26
Automatic poweroff .27
AutomaticLCD off 28
Format memory .... 29
Software update 30
Revert the default setting 31
Memoryinformation ..32
Check systemversion ..32
PARAMETERS ..33
ACCESSORIES .34

INTRODUCTION
Thank youforpurchasingDV207 whichhas the unique, ultra-smallanddelicate design.
It canbe used inmanyrecording situations. DV207 rings more convenience, safetyand
funs to your dailylife.
Approval Information:
Allour products meet the requirements ofapprovalFCC or CE, and are granted the
FCC or CE certification. They are authorized to bear FCC or CE mark.
FCC:
This product has been tested and foundto complywiththe limits foraClass Bdigital
device, pursuant to Part 15 ofthe FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residentialinstallation.
CE:
This product complies withstandards includingLow Voltage Device Directive
73/23/EEC; EMC Directive89/336/EEC and R&TTE Directive1999/5/EC. It passed the
subject tests by the authority concerned andis authorized to bear CE mark.
OVERVIEW
Along withthe improvement ofpeople’slivingstandard and the development of
picture compressionand memorytechnology,the digitalvideo memoryhas been apart of
ourdailylife. DV207 ahigh-techproduct,just meets aplentyofneeds ofpeople and
market. It possesses aseries of advanced functions including digitalphotography,voice
memory, sound trigger recording, high speed USB data transferring and USB charging.
EU Environmental Protection
Waste electrical products shouldnot be disposed of with
household waste. Please recycle where facilities exist.
Check withyourLocalAuthority or retailerfor recycling
advice.

WARNING
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
Attention
The electromagnetic fields at the specificfrequencies mayinfluence the picture of
the recorder.Be sure to read the followingbefore usingthe recorder and the mini
camera.
Charging the Battery
The batteryicononthe screenwillcontinuous flashwhilelow power,thenplease
power off the unitand remove the batteryfor charging. For the first timeusing, it
is better to charge the batteryaround12 hours. (Make sure power off while
charging battery)
Use powercharger
1.Put the batteryinto the power charger.
2.Insert the charger to the home power supply.
3.The red indicator of the power charger will always on during charging.
4.Afterfull charge, the greenindicator willon instead of the red indicator.
Trial recording
Before yourecord one-timeevents, youmaywant to make atrialrecordingto
make sure that the recorder and the camera are working correctly.
Notes on image datacompatibility
Playback ofmoving images recorded with yourrecorder onother equipment and
playback ofmovingimages recorded oredited withotherequipment onyour
recorded are not guaranteed.
Do notshake orstrike the recorder
In additionto malfunctions and inability to record moving images, this may render
the SD card unusable ofimage data breakdown, damage or loss may occur.
LCD screen andmini camera
Be carefulwhenplacingthe camera nearawindow or outdoors. Exposingthe
LCD screenor the lens of camera to direct sunlightforlongperiod maycause
malfunctions.
Back up recommendation
To avoid the potential risk of data loss always copy data to a disk.

FEATURES
lMinidesignofthe mainunit, equip the buttoncamera, easy to be used inkinds of
situation.
lSupport flashmemoryrewrite automatically.
lOne key switch easily between regular mode and motion sensor mode of recording
lAudioand video isochronous record inreal time, the video willbe auto memory
into AVI format, convenient to playin the computer and upload to internet.
l2.0 inchhighdefinitionTFTLCD screen, 640*480 resolutionensure the good
performance in picture display
lSupport 16GB Mini-SD max
l720 x576 D1 PAL/720x480 D1 NTSC/640x480 VGA/320 x240 QVGAoptional
record resolution
lVideo frame: 30FPS
lUSB 2.0 high speed interface
lAVinput and output ready
lInterchangeable standardmobile Li-ionBattery

APPLICATION
Mountain bike video camera equipment
Snow videocamera equipment
Sky video cameraequipment

GETTINGSTARTED
Identifyingthe parts of the mini DVR
1.2"TFTLCD Screen7.FWD/Select key
2.AVIn jack to connect with the Mini camera/TV8.REV/Select key
3.USB jack to connect with PC 9.Mini SD Card Slot
4.AVOut jack to connect with TV10.Return key
5.Record/Playback switch11.LED Indicators
6.Play/Stop key
Remark: Long pressto hold key, long presstorelease key
The Parts OfThe Mini CAMERA
1.Lens
2.Interchangeable buttons and screws
3. Microphone

LCD screen indicators
Welcome Picture
Recording Mode
Recording symbol
Current time②
Video files③
Record time④
Card icon( ifmemory card available)⑤
Available memory⑥
Battery capacity⑦
Current time⑧
Picture quality of recording⑨
⑩Record content ( AVmeans audio and video included)
Circular record
Playback Mode
Folders icon
Sub folders②
Year/month/date③

INSTALLATION
Batteryinstallation
Open the backcover
Insert thebattery
Insert the battery with the label side up andthe connectors facing each other.
Attachthe battery cover and lockit
The battery of head unit isthe same as Sony Ericsson (BST-33).
Parameters for battery using:
Capability Charging time Standby time Playing time Recording time
1000mAh
Approx 4
hours
Approx 2
hours and19
minutes
Approx 4
hours
Approx one
hour and43
minutes
Precautions:For the first time usage, charge the battery at least 12hours.
Make sure the power is off when charging battery

Mini SD Cardinstallation
Install the Mini-SD cardcorrectly according to the illustration
The head-unit support128Mb~16GB 的Mini SDcard
Quality
Resolution High Medium Low Battery time
720x576 ≤45MB ≤36MB ≤20MB Approx. 1hour
and 40 minutes
720x480 ≤43MB ≤33MB ≤18MB Approx.1 hourand
30 minutes
640x480 ≤39MB ≤27MB ≤16MB Approx.1hour and
32 minutes
320x240 ≤12.4MB ≤9.8MB ≤8.3MB Approx. one hour
and 50 minutes
Parameters aboveonly for consult, the real parameters shallcontrol.

BASIC OPERATIONS
Please insert the MiniCamera connector into the AVinput jackof the main
unitunder “OFF”state.
Long press to power on the mainunit.
Start Recording
Glide [R/P] button to [R] side，the screen will display pictures that shot by the camera。
Longpress button②and enter thesettingmenu, use or to do the
“record mode”setting, “One key record”or “motion record”,
③Long press quit setting.
④Press start one-key recording or motion recording, the screen will displayif
recording condition.
⑤Pressstop one-key recording or motion recording, at the same the
Will disappear.
⑥Glide [R/P] button to [P] side，enter video files folders.
Precautions:
The device support low-power protection, while the icon continuous
flash, please unplug the power supplypromptly after finishing charging the
battery.

Videocontent view
Glide [P/R] button to [P] side.
Use②or choose the video storage folder.
Use③confirm and enter.
Video folders
Video files
Aft④er enter the video folders, use orto choose the video files thatyouwant
to play,for example, play,
Use orchoose and press to play.
Press second time to pause the playing.⑤
Press stop pl⑥aying and exit.
Continuous press⑦back to the video folders.
Attention:The nameofthe video folders and video files are created bythe date and time
when the video recorded, systematic arrangement.

Delete the video files
Press or tochoose the file youwant to delete, and thenlongpress ,
Enter the files delete interface.
ALL:Delete allvideo f②iles under folders, pressdelete.
Current: Delete the s③elected video file, pressdelete.
Cancel: Cancel the④operation
⑤After the operation confirmed,the systemwillgo back to the video folders interface
automatically.
Attention:
The video files can not be reverted after delete it. So please do it restrainedly. Commend
to copy the video files into your computer before your delete it.

Connect with otherA/Vdevice:
Instruction:
Glide [R/P] button to [ R] side, and enter record mode.
Insert the video cable (②2.5mmconnector)into the mainunit via the AVinput jack,
connect the RCAconnector with the camera.
Attention: yellow–video input ; Red- audio input (single track); Black–DC/5V
output.
Start record:
Press power on the mainunit;
Long press②enter the record mode setting, change the mode to “key record “.
Press③go back to the record interface.
Press④start recording.
Press⑤stop recording.
Attention: This player onlyhave one Video and one Audio, without right/left stereo
input. DC:5Vcable is useful whenrecording DVD or TVsignal

Connect with PC:
Connect the USB and MINI USB with computer and the mainunit separately.
②After connect with computer, DV207 will display“USB Connect”,recharge
indicator always on.
Remark:
Connect with computer at power on states, can not operate as it is ExternalHard Drive.
Connect with computer at power offstates, can do any operation as it is recharging.

Open “my computer”to check if there has the removable hard disk③,called
“NO_NAME”.
Picture details
Open the video files in the folders.④
Check the video files in the folders, and playit by the defaultmedia player inyour⑤
computer.
Attention
Connect the mainunit with PC under power off state，it is power charge mode，red
indicator flash at the same time, files in the storage can not be read. Connect the main
unit under power on state, the computer will read the files in the storage automatically
and power charging at the same time.

SYSTEMSETTING
Glide [P/R] buttonto [R] side., turnon the playerby longpressing,and thenpress
key till “Setup”menu appear on the screen.
1.Recording mode setting
Press enter REC Setting，press or to select your preference setting。
Press enter REC Mode，press or choose record mode，thenpress to
select, press exit setting
While choosing one keymode, press start normalrecording. While choosing
Motion Detect, press start motion recording, the device start recording
automatically while catching anymovement, device will continuous recordingif there is
continuous movement, ifno movement, thedevice will turn to standbymodel after 15
seconds.
Important:The motion detector support record 15 Seconds pictures before motion record
start. (That means it could catch somefast movement)

2.Resolution setting
Press or to choose the resolutionsettingmenu，press confirmand
enter the setting;
Press or to choose the resolution，press to save setting Press
exit setting.
Press or to choose the resolutionsettingmenu，press confirmand
enter the setting;

Press or tochoose the resolution，press to save settingPress exit
setting.
3.Record content setting
Press or tochoose the settingmenu，press confirmand enter the
setting。
Press or to choose the preference setting，press confirm。press
exit setting.

4. VideoTime and date setting
Press or tochoose the setting menu(Ifyoupreferthe video files displaythe
time/date),press to confirm and entersetting.
Press or to do the prefer setting，press to confirm,
press exit setting.
