User Manual for the PowerPanel LC isplay Expander
ocument Version 1.7
Thank you for your purchase of the PowerPanel - a tiny, lightweight Watt Meter for your model! This instruction manual will guide
you through the installation and operation of your PowerPanel LCD Display Please read the entire manual carefully before
proceeding. If, after you read the manual (including the Troubleshooting sections!) you have further questions or problems, see the
Support page on http://www eagletreesystems com for additional information, or email us at support@eagletreesystems com
Key Features
Here are a few of the features of the PowerPanel:
• Ultra-thin LCD display connects to the MicroPower with the included 11" (28cm) data cable
• Live Display of Amps, Volts, mAH, Temperatures, Wattage, and RPM (more coming soon, by simply download our latest
Windows program)
• Cumulative mAH display serves as a “gas gauge” for your battery pack By knowing how much has been used, you can know
approximately how much is left!
• Up to 4 parameters can be displayed per “virtual page” on the PowerPanel Each parameter has a programmable label
• Multiple “virtual pages” of data are supported, with programmable ways of switching between the pages
• Supports display of both Live data and Max values, with programmable ways of switching between Live and Max
• Supports “hot plugging” into the MicroPower after your session
• So light, it can easily be attached to the side of your model for live/max display all the time!
• System supports both Metric and English units
Supported Products
The PowerPanel works with the eLogger V1 through V3 To use the PowerPanel with the eLogger, you must update to Windows
Application version 3.64 or higher. This is described in the “Windows Application and Firmware Update” section below
Steps to Follow
Installation and use of your PowerPanel will be quite easy and enjoyable if you follow these few steps:
1 Read through the manual to understand the warnings, determine the installation and setup sequence, etc
2 Upgrade the Windows Application and Firmware for your MicroPower, if you purchased your MicroPower before the PowerPanel
was available This is described in the “Windows Application and Firmware Update” section below
3 Connect the PowerPanel to the MicroPower You should now see live data on the PowerPanel!
4 If desired, reconfigure the parameters displayed on the PowerPanel as described in the “Configuring the PowerPanel with the
Application” section below
5 Have fun!
Intended Uses
The PowerPanel is designed for use in Unmanned Radio Controlled models Using the PowerPanel for other purposes is not supported
Further, using the PowerPanel in situations where its use or failure could result in loss of life, bodily injury or property damage is
expressly prohibited
Packing List
Your package should include the following: the PowerPanel LCD Expander, and a printed version of this manual Please check the
support page of our website for the latest version of this manual, in case changes have been made since it was printed
NOTE: the PowerPanel is covered with protective clear shrinkwrap. o not remove the shrinkwrap!
Windows Application and Firmware Update
To use the PowerPanel with the MicroPower, you must update to Windows Application version 3.64 or higher. To update, download the latest
application from the support page of our website
After downloading and installing the Application, the firmware of your MicroPower may need to be updated Firmware version 4.45 or greater is
required for the PowerPanel to work correctly To upgrade your MicroPower firmware, choose “Tools, Firmware Control” and click the Update
button

Copyright © 2006 Eagle Tree Systems, LLC
Page 2
Connecting the PowerPanel to the eLogger V3
The PowerPanel plugs into the “LCD/TX” port of your eLogger V3, as shown in
Figure 1A
Connecting the PowerPanel to Your eLogger V1/V2
Connect the PowerPanel to the eLogger V1 or V2 AUX (or LCD) connector, as
shown in Figure 1 Note that the top row of pins is the correct row, and note that
the red wire of the PowerPanel should face outwardly
Configuring the PowerPanel with the Application
After you have completed the connection step above, the PowerPanel should be
preconfigured to show Amps, Volts, mAH, and Temperature No further
configuration is required if these are the only parameters you care about!
NOTE: The PowerPanel can be “hot plugged and unplugged” to the MicroPower even
when the MicroPower is powered by your battery pack
Once the PowerPanel is installed, you can change what is displayed on the PowerPanel,
change when the PowerPanel shows Live vs Max data, and change when the PowerPanel
switches between multiple display pages
Launching the PowerPanel Display Setup Utility
To configure the PowerPanel, connect the MicroPower to USB, and choose “Tools,
Configure PowerPanel Display” in the application The PowerPanel Setup Utility
should then appear
Using the PowerPanel Display Setup Utility
Figure 2 shows the main page of the Utility The Utility main page is divided into the following sections:
Select ata Parameter to Configure on the PowerPanel:
This section contains the tools to select what, how and where parameters are displayed on the LCD pages
To select and configure a parameter, choose the parameter to be configured
in the “Choose a Parameter you want to configure…” window A “o” next
to an item indicates that this item is already selected for display, and
choosing it will allow you to edit the item After selecting the parameter,
click the “Enable this parameter…” checkbox to enable the parameter to be
displayed/configured, or uncheck it to remove it from the list
Once the parameter is enabled, choose where the parameter will be displayed
by choosing the location in the “Select Display Location” window You can
choose both the display page, and the location on that display page, for the
parameter
Up to 4 parameters can be displayed on each page Normally, page 1 would
be filled with 4 parameters of your choice, and if you need to display more
than 4 parameters, the remaining parameters would be programmed to
display on page 2, etc Or, you can have one parameter per page, or any
other combination!
A “o” next to the location chosen means it is already in use by this or another
parameter Choosing a location that is in use already will cause the
parameter using it to be disabled
The window labeled “Enter the label to display ” indicates the 3 digit label
that will be displayed beside this parameter on the LCD You can change
this 3 digit label to be whatever you want For example, if Temperature
Sensor 1 was attached to your ESC, you might label the Temperature Sensor
1 parameter “ESC ”
Figure 2
NOTE: If the data for each parameter grows large, such as a large RPM, the middle character in the 3 digit label will be eliminated to show all the
numeric digits in the parameter For example, “RPM 0” would become “RM 40342” in this case

Copyright © 2006 Eagle Tree Systems, LLC
Page 3
Switching Between Multiple isplay Pages:
This section lets you indicate to the PowerPanel how you want it to switch between multiple display pages, when you have parameters on more than
one page (meaning more than 4 parameters total, since each page will hold up to 4 parameters)
If you want the PowerPanel to scroll between the pages automatically, select the “Switch Between Pages Every Two Seconds” option Then, the
PowerPanel will automatically switch between page 1, page 2, etc , for each page you have programmed with parameters
If you want to switch between the pages manually, select the “Switch Between Pages when Temperature 1 Sensor is disconnected and
reconnected” option When this option is selected, the PowerPanel will stay on the currently displayed page (starting with Page 1 when power is
applied) until the Temperature 1 Sensor is disconnected from the MicroPower, and then reconnected NOTE: only choose this setting if you are using
the optional temperature sensor!
isplaying Max vs Live Values on the PowerPanel:
This section lets you indicate to the PowerPanel how you want it to switch between displaying “live” data (real time data) for each parameter, and the
maximum value detected for each parameter (minimum value for pack voltage) Max values are indicated by an “up arrow” triangle next to the
parameter (“down arrow” triangle for pack voltage) Live values do not have this arrow
If you want the PowerPanel to show Max values detected automatically when the motor is not running (current draw is near zero) and show live values
when the motor is running, select the “Show Max when current draw is zero, and switch to Live when current draw is greater than one amp”
option Then, whenever the motor is not running, max values detected are displayed But, when the motor is running, the PowerPanel switches to live
display mode This setting is useful for bench testing
If you want the PowerPanel to be manually switched between showing Max and Live values, select the “Show Max when Temperature 1 sensor is
disconnected” option Then, whenever the Temperature 1 Sensor is disconnected , max values detected are displayed But, when the Temperature 1
Sensor is connected, the PowerPanel switches to live display mode NOTE: only choose this setting if you are using the optional temperature sensor!
If you want the PowerPanel to never show Max values, and only show Live values, select the “ on’t Show Max Values” option
NOTE: The PowerPanel remembers the Max values only during a single session Once the MicroPower is disconnected from power, the Max values
are cleared But, disconnecting the PowerPanel from the MicroPower does NOT clear the max values
Completing the PowerPanel Display Setup
Once all the parameters you wish to display are configured, you can review the parameters by clicking the Preview button as
shown in Figure 5 The Preview window is a handy way to see which parameters are configured on which LCD page
locations A “***” in a page location indicates that no parameter is displayed in that location
Once the parameters are configured to your satisfaction, click OK, which will download the settings to the PowerPanel Note
that you can change the parameters at any time by following the above steps
Note: If you wish to clear all previously configured parameters, hit the “Reset Parameters” button on the bottom of the utility
Using the PowerPanel at the Field
Once the parameters are configured to your satisfaction, it’s time to use it! You can either connect the PowerPanel to the
MicroPower for bench testing, or for checking your power system’s status before and after flying You can even permanently
mount it on the side of your model, with either Velcro or double-sided tape
NOTE: The first time the PowerPanel is plugged into the MicroPower after the MicroPower is turned on, the Max values are
cleared So, if you want to see, say, cumulative mAH, be sure to plug in the PowerPanel briefly before your session, but after
you have turned on power to your model
NOTE: IF YOU ECI E TO LEAVE THE POWERPANEL PERMANENTLY MOUNTE ON YOUR PLANE WHEN YOU FLY,
ON’T FORGET TO RANGE CHECK YOUR MO EL AFTER INSTALLATION, AS ESCRIBE IN YOUR RA IO MANUAL.
Though it is highly unlikely that the PowerPanel would cause any problems with range checking, it’s good practice to do this after changing
any equipment on your model!
Figure 3
Troubleshooting
Below is a list of problems that may be encountered, and steps to remedy them
A good first step to troubleshooting, if you are able to connect your MicroPower to your PC, is to download our latest software and update the
MicroPower’s Firmware via “Tools, Firmware Control ” Doing this will ensure that you have the latest software and firmware available
If your particular issue is not addressed by this update, or by the suggestions below, email support@eagletreesystems com for additional assistance
Include a full description of your problem, your PC configuration, type of model, and Windows application and MicroPower firmware version if
possible (from “Help, About” and “Tools, Firmware Control” in the app) and any other relevant details

Copyright © 2006 Eagle Tree Systems, LLC
Page 4
Issue: My PowerPanel display is blank
Solutions: Try to eliminate the problem in the following ways:
• Verify that you have the PowerPanel connected to the correct port on the MicroPower
• Make sure that you have the correct firmware version installed in the MicroPower, as described in the Firmware Update section above
• Verify that you have configured the PowerPanel to display something, by following the instructions in the “Configuring the PowerPanel with
the Application” section above
• Confirm that the MicroPower LED is blinking If it is not, power is not being applied to the MicroPower, or something is wrong with the
MicroPower If the MicroPower’s LED starts to blink after the PowerPanel is removed, verify you have plugged it into the right port
• Check to make sure the PowerPanel cable is not frayed or cut
Issue: The PowerPanel is displaying data, but some of the parameters do not appear to be correct
Solutions:
• Make sure the sensor for the parameter being displayed is correctly connected and installed on your model For example, RPM will read zero
if the RPM sensor is not connected See the MicroPower or sensor manuals for specific sensor information
• Try removing power from and restoring power to the MicroPower
Issue: I have the MicroPower connected to USB, but do not have a battery pack connected to the MicroPower The PowerPanel shows a nonzero
voltage, however
Solution: This is normal Connecting a battery pack to the MicroPower will result in correct display voltage
Issue: The Max values and “Cumulative mAH” feature of the PowerPanel is not working correctly I get low mAH readings after my session
Solution: The PowerPanel remembers the Max values only during a single session Once the MicroPower is disconnected from power, the Max
values are cleared But, disconnecting the PowerPanel from the MicroPower does NOT clear the max values
PowerPanel Specifications
Display: 16x2 Character LCD
Dimensions: Approximately 2 5” x 1” x 3/16” thick (6 5cm x 2 7cm x 4mm thick)
Weight: Approximately 0 5oz (14 g)
Length of Cable: Approximately 11” (28cm) - extendable with our “PowerPanel Extension Cable” on the MicroPower page of our website
Limited Warranty
Eagle Tree Systems, LLC, warrants the PowerPanel to be free from defects in materials and workmanship for a period of one (1) year from the date of
original purchase This warranty is nontransferable If your unit requires warranty service during this period, we will replace or repair it at our
option Shipping cost to us is your responsibility
To obtain warranty service, contact us by phone, fax or email to request an RMA number No returns will be accepted without this number
This limited warranty does not cover:
• The Software included with the MicroPower See the Software license agreement for more information on Software restrictions
• Problems that result from:
o External causes such as accident, abuse, misuse, or problems with electrical power
o Servicing not authorized by us
o Usage that is not in accordance with product instructions
o Failure to follow the product instructions
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE (OR JURISDICTION TO JURISDICTION) OUR RESPONSIBILITY FOR MALFUNCITONS AND DEFECTS IN HARDWARE IS
LIMITED TO REPAIR AND REPLACEMENT AS SET FORTH IN THIS WARRANTY STATEMENT ALL EXPRESS AND IMPLIED
WARRANTIES FOR THE PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES AND CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN TIME TO THE TERM OF THE LIMITED
WARRANTY PERIOD AS DESCRIBED ABOVE NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE
LIMITED WARRANTY PERIOD HAS EXPIRED SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THIS LIMITATION MAY NOT APPLY TO YOU
WE DO NOT ACCEPT LIABILITY BEYOND THE REMEDIES PROVIDED FOR IN THIS LIMITED WARRANTY OR FOR CONSEQUENTIAL
OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, ANY LIABILTY FOR THIRD-PARTY CLAIMS AGAINST YOU FOR
DAMAGES, FOR PRODUCTS NOT BEING AVAILABLE FOR USE, OR FOR LOST DATA OR LOST SOFTWARE OUR LIABILITY WILL BE
NO MORE THAN THE AMOUNT YOU PAID FOR THE PRODUCT THAT IS THE SUBJECT OF A CLAIM THIS IS THE MAXIMUM
AMOUNT FOR WHICH WE ARE RESPONSIBLE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU
