EAST COAST Langham Nuovo User manual

Langham Nuovo
Drawer

IMPORTANT
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
Please read the instructions and warnings carefully before use to ensure safe and satisfactory operation
of this product.
Your child’s safety is your responsibility. If you have a query with this product or require replacement
parts, please contact 01692 408802.
Lay out the parts on a soft level surface and compare to the part/fixing checklist below. Do not discard
any packaging until you are sure that you have all the parts.
Keep children clear during assembly as pack contains small parts which may present a choking hazard.
You will need the following tools to complete assembly:
Flat-headed screwdriver, Cross-point screwdriver.
2
Parts
Drawer front
Base joiner
Drawer
base (2)
Drawer side (L & R)
Drawer back
Hardware
B x 6
(40mm)
A x 9
C x 4
(25mm)
D x 1
E x 1
I x 6
H x 2
G x 4
F x 2
Spanner

Drawer assembly 1
Drawer front
Drawer back
A
x 8
D
x 1
Drawer assembly 2
Drawer side
Drawer side
Base joiner
E
x 1
C
x 4
NOTES:
1) Insert part "E" with the arrow in the face
pointing to the Drawer front.
2) Tighten part "E" using a wide flat-bladed
screwdriver. Turn approximately 1/2 turn
clockwise until resistance is felt.
Drawer front
A
x 1
Drawer assembly 3
B
x 6
x 6
I
NOTES:
1) Ease Drawer sides apart to fit
dowels into holes in the Drawer
back.
2) Insert parts "I" with slot visible
and pointing towards screw hole,
then insert screws.
Drawer base
Drawer base
Drawer Back

Drawer assembly 4
Drawer assembly 5
NOTE:
Insert Castors (G) into holes and tighten using the
spanner provided
G
x 4
H
x 2
F
x 2
Customer Care Hotline For this Product 01692 408802
East Coast Nursery Ltd. Robertson House, North Walsham, Norfolk,
NR28 0BX
7561-1
Care & maintenance
Regularly check the tightness of screws and tighten as necessary.
Check for damage which could render your drawer unsafe or cause splinters.
To clean use a damp cloth, avoiding the use of strong detergents or abrasives.
An occasional light application of a wax polish will help maintain a good appearance.
