Eastwood 33934 User manual

RECHARGEABLE
COB LED PENLIGHT
INSTRUCTIONS
© Copyright 2020 Eastwood Automotive Group LLC 11/20 Instruction item #33934Q Rev 1
If you have any questions about the use of this product, please contact
The Eastwood Technical Assistance Service Department: 800.343.9353 >> email: [e-mail]
PDF version of this manual is available at eastwood.com
The Eastwood Company 263 Shoemaker Road, Pottstown, PA 19464, USA 800.343.9353 eastwood.com
Item #33934
OPERATION
• Place the base or back against any ferrous metal surface for magnetic attachment.
• Depress and release rectangular rubber button located at the housing once for High-Intensity
COB LED Illumination, 2nd time for Low-Intensity COB LED Illumination and a 3rd time for
the Flashlight.
• Depress Button once again to turn off.
CHARGING
• When the Indicator light above the
Charging Port illuminates RED, the
battery requires a charge. To do so:
- Flip up rubber seal and plug the
Type-C terminal of the included
Power Cord into the Type-C port on
the side of the housing (FIG 1).
- Plug the USB terminal of the Power
Cord into a standard USB port with
5V 1A output.
- Allow 2 hours for full charge.
- Do not use Light while charging.
- The indicator light Indicator light above the Charging Port will glow RED while charging
then change to GREEN indicating full charge (FIG 1).
- Do not leave Light on charge beyond 24 hours.
Batteries will automatically discharge without use and must be charged every
3 months even if the light has not been used.
Do Not charge batteries in temperatures below 40°F [4.4°C].
FIG. 1

2Eastwood Technical Assistance: 800.343.9353 >> [e-mail] To order parts and supplies: 800.343.9353 >> eastwood.com 3
LITHIUM BATTERIES STORE A LARGE AMOUNT OF ENERGY AND WILL ERUPT
IN FLAMES OR VIOLENTLY EXPLODE IF NOT PROPERLY HANDLED.
READ INSTRUCTIONS
• Thoroughly read and understand this manual before using.
• Save for future reference.
SERIOUS INJURY, FIRE & EXPLOSION HAZARD!
• Keep Dry – Do Not open unit, drop, short circuit, incinerate, expose to
temperatures greater than 140°F [60°C].
• Do Not charge or use if damaged.
• Do Not submerge lamp.
• Do Not operate in explosive atmospheres such as explosive vapors,
flammable liquids, gasses or dust.
• Not a toy. Keep out of the reach of children.
• Charge lamp only according to these instructions.
EYE INJURY HAZARD!
• DO NOT allow LED lamp to project directly into eyes. Temporary blindness
may occur.
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTICE is used to address practices not related to personal injury.
SAFETY INFORMATION
The following explanations are displayed in this manual, on the labeling, and on all other information
provided with this product:
The Eastwood RECHARGEABLE COB LED PENLIGHT utilizes the latest COB LED technology to provide
highly efficient, energy saving lighting. A four-position switch allows instant switching from the low to
high-intensity COB LED to the focused flashlight LED. A lightweight and rugged aluminum housing with
shock resistant protection provides tactical level reliability. The convenient dual magnetic mount design
allows for maximum flexibility and the USB Charging Cord terminal offers go anywhere capability.
CONTENTS
(1) Eastwood Rechargeable LED Penlight
(1) 39” [1.0m] USB to Type-C Cord
SPECIFICATIONS
• 3.7 Volt, 800mAh, Li-Ion Integral Rechargeable Battery
• Light Output (In Lumens)
- High COB Worklight = 200 Lumens
- Low COB Worklight = 100 Lumens
- LED Flashlight = 100 Lumens
• Working time (In Hours).
- High COB Worklight = 1.5 Hours
- Low COB Worklight = 3 Hours
- LED Flashlight = 3 Hours
• 2 Hour charge time
• IK07 Impact Resistance rating
FEATURES
• Four-function Switch:
- Press once and release, On, High Intensity COB LED Illumination
- Press again and release, Low Intensity COB LED Illumination
- Press again and release, Flashlight Illumination
- Press again and release, Off
• Dual Magnets at base and back of housing
• Pocket Clip
