EASY DOCTOR Q21 User manual

國品字第B00371號
An all-around healthcare device
www.easydr.com.tw
Lightweight and convenient | Accurate measurement | Cloud management
ECG Recorder
Model No. : Q21

1
2
1. Finger electrodes: Supported in resting mode; recording time: 30 or 60 seconds
1
RA
RL LL
37±3g
Lightweight and portable with 24-hour recording capacity
The device supports both resting and ambulatory recording modes. For recording tool, you
can choose between finger electrodes and cable electrodes based on recording time and
needs. Results are available in as quick as 30 seconds (when resting mode is selected).
The single-lead EasyDoctor ECG recorder is portable, lightweight and compact. It is
convenient for both home use and on-the-go recording. You can monitor your heart
rhythm anytime and anywhere through the EasyDoctor app.
ECG results in 30 seconds with medical grade material
2. Cable electrodes: Supported in both resting and ambulatory modes; recording
time: 30 seconds to 24 hours
*Resting mode: Must be used while at rest.
*Ambulatory mode: Can be used while performing daily activities. Select “Record-
ing offline” to allow the device to continue detecting your ECG signal while offline.
Portable, 24-hour
recording

3
4
While recording in ambulatory mode, you can press the power button on the ECG record-
er when you feel chest pain or discomfort. The moment when discomfort is felt will be
recorded on the ECG result for further interpretation by the physician.
On-the-spot discomfort marking
While recording in resting mode, eight test results are available, including premature
ventricular contraction (PVC), arrythmia, tachycardia and bradycardia.
Accurate analysis with 8 types of ECG results
Subject : Tony
Ratio
Number
of results
1,400 97.2%
0.3%
100.0%
2.5%
1,440
36
4
Result
No abnormalities
suspected
Abnormalities
suspected
Unable to analyze
Total
25 mm/s 10 mm/mV
ECG
Time:
Maximum heart rate:
Number of self-entered discomfort:
Result:
Average heart rate:
10/10 09:45 - 09:46
Arrhythmia suspected
68 bpm
86 bpm
2
Moment of discomfort
Ambulatory
Relax, stay still and record with cable electrodes
in resting mode. Please consult a doctor if you have
chest pain or discomfort. Recording result may
show “Arrhythmia suspected” if an intense
exercise is carried out during recording.
Oct.10, 2018 09:22 total 24hrs 00min
Number of self-entered discomfort: 20
Subject : Tony
Resting
Relax, stay still and record with cable electrodes
in resting mode. Please consult a doctor if you have
chest pain or discomfort.
Oct.15, 2019 10:00:03 total 60secs
Record again
View health log of Tony
25 mm/s 10 mm/mV
25 mm/s 10 mm/mV
Time:
Result:
Average heart rate:
10:00:03 - 10:00:33
Premature Ventricular
Contraction suspected
70 bpm
Time:
Result:
Average heart rate:
10:00:33 - 10:01:33
No abnormal waveforms
detected
78 bpm
Record an ECG

5
6
Through “Health Log” you can view past records and export the data for family’s or
physician’s reference.
Health records at a glance with cloud storage
Create a family group in the EasyDoctor app and you can easily view measurements from
all members in the group. When there is an abnormal data, the app will deliver a notifica-
tion so you can take action to care for your family.
Family care at your fingertips
The ECG result of “Mom”
is abnormal!
Message Notification
System message Famiiy message
Edit
3
Dec.05, 2019
The ECG recording results of family
“Tony” are suspected abnormal!
Nov.25, 2019
The fasting Blood Glucose date of family
"Tony" out of normal range!
Nov.20, 2019
Oct.31, 2019
The Blood Pressure data of family "Tony"
out of normal range!
The Blood Pressure data of family "Tony"
out of normal range!
Nov.25, 2019
The fasting Blood Glucose date of family
"Tony" out of normal range!
Nov.20, 2019
Oct.31, 2019
The Blood Pressure data of family "Tony"
out of normal range!
The Blood Pressure data of family "Tony"
out of normal range!
Ratio
Number
of results
1,400 97.2%
0.3%
100.0%
2.5%
1,440
36
4
Result
No abnormalities
suspected
Abnormalities
suspected
Unable to analyze
Total
Tony Last 50
readings
Tap on any graph to view data
Resting Resting
Ambulatory
Oct.10, 2018 09:22:03 total 30secs
Result: No abnormalities suspected
Sept.21, 2018 23:44 total 24hrs 00min
Number of self-entered discomfort : 20
ECG
Uric
Acid
Blood
Glucose
Blood
Pressure
Total
Cholester
壓
Health Log
90%下午 1: 10BELL
Export ECG reports
A maximum of two 30s ECG reports will be
exported
Resting recording:
Health Log
90%下午 1: 10BELL
Recommendation:
Clinical doctors are usually able to interpret
from the partial ECG provided here. There is
no need to export the entire data.
25 mm/s 10 mm/mV
HCG
Health Log
90%下午 1: 10BELL
00:18 01:00
Time:
Maximum heart rate:
Number of self-entered discomfort:
Result:
Average heart rate:
10/10 09:45 - 09:46
Arrhythmia suspected
68 bpm
86 bpm
2

國品字第B00371號
This product receives multiple international standard certifications,
meets ECG recorder standards (IEC60601-2-25:2011 & IEC
60601-2-47:2012), and receives the “Symbol of National Quality
(SNQ): Medical Appliance Category” certification.
*SNQ (Symbol of National Quality) certifies the safety and quality of
a product. It is one of the most authoritative indicators of quality
evaluation, providing professional certification for the selection of
high-quality products.
2 years warranty of accuracy
*The results from this product can only be used as reference for physicians and not as a diagnostic
result.
Download the EasyDoctor app
Compatible with
Android 5.0 or
later
Compatible with
iOS 9.0 or later
Health records at a glance | Family care at your fingertips | Secure data with cloud
storage
Rechargeable and eco-friendly built-in lithium battery
The built-in rechargeable lithium battery allows the device to be charged with Micro
USB even when you are outdoors or on the road. It is also environmentally friendly
and saves the cost of battery replacement.
You can create multiple family groups and
assist family members to take measure-
ments. You can view family measurements
at any time for a more complete manage-
ment of your family’s health.
Group1
+Add a new group member
Tony
Wendy
Alex9899
(3people)
Click to edit family group
Edit

Q21-202005-V2
An all-around healthcare device
www.easydr.com.tw
LINE@Customer Service
Product Information
ECG Recorder
Manufacturer : Inventec Appliances Corporation
Address : 1F, No. 37, Wugong 5th Road, Wugu
District, New Taipei City
E-mail : [email protected]
Customer Service Hotline : [phone]
Service Time : Mon. - Fri., 09:00 - 17:00
MOHW-MD-No. 006588
NTPC-DH-MD-AD-No. 10901017
Please carefully review the caution section in the
instruction manual before using the product.
