EasyCare HARVEST 2 Installation and operating manual

PUMP
General User/Safety Guide
HARVEST 2 PUMP
www.easycaresystems.co.uk
www.easycaresystems.co.uk

2
www.easycaresystems.co.uk

3
CONTENTS
WARNINGS & CAUTIONSWARNINGS & CAUTIONS
GENERAL INFORMATIONGENERAL INFORMATION
1 DEFINITION OF THE GROUPS MENTIONED1 DEFINITION OF THE GROUPS MENTIONED
2 NON-COMPLIANT USE2 NON-COMPLIANT USE
3 SAFETY INSTRUCTIONS3 SAFETY INSTRUCTIONS
3.1 GENERAL SAFETY INSTRUCTIONS3.1 GENERAL SAFETY INSTRUCTIONS
3.2 SAFETY INFORMATION FOR THE OPERATOR3.2 SAFETY INFORMATION FOR THE OPERATOR
3.3 SAFETY INFORMATION FOR THE USER3.3 SAFETY INFORMATION FOR THE USER
3.4 SYMBOLS USED3.4 SYMBOLS USED
3.5 CLEANING & DISINFECTION
3.6 SERVICING & MAINTENANCE
3.7 SERVICE LIFE & DISPOSAL
TECHNICAL SPECIFICATIONTECHNICAL SPECIFICATION
OVERVIEWOVERVIEW
OPERATIONOPERATION
CLEANING & CARECLEANING & CARE
ROUTINE MAINTENANCE AND SERVICINGROUTINE MAINTENANCE AND SERVICING
TROUBLESHOOTINGTROUBLESHOOTING
PARTS LISTPARTS LIST
GUARANTEES & WARRANTIESGUARANTEES & WARRANTIES
DECLARATION OF CONFORMITYDECLARATION OF CONFORMITY
4-5
6-10
7
7
7
7
8
8
9
10
10
10
11
12 -13
14
15
16-17
18-21
22
23
24
www.easycaresystems.co.uk

4
WARNINGS &
CAUTIONS
READ THIS INSTRUCTION MANUAL AND OBSERVE SAFETY
INSTRUCTIONS.
WARNING
This pump must be properly installed and operated as directed by this user manual.
The pump should be checked regularly to ensure correct operation. Loss of function
will remove all pressure relieving properties.
This pump, when connected to a pressure relieving system, is intended for use as part
of a pressure ulcer prevention program; do not rely solely on this device to achieve
the result. The medical professional is responsible for applying best medical judgment
when using this system.
Select the correct setting for the occupant’s weight and therapy required. Care should
be taken not to accidently change pressures once set as the effectiveness of the
therapy may be reduced.
All hoses must be free of kinks, twists and must be properly connected and positioned
so as not to cause any obstruction.
Do not position the pump in a way that prevents access to the disconnection device
(mains power plug).
Ensure the mains lead or pump cannot become trapped or crushed, e.g. by raising or
lowering of bed or bed rails or any other moving object.
Check the mains lead is damage free and positioned so as not to cause an
obstruction or injury e.g. strangulation or trip hazard.
Ensure that the electricity supply is of the type stated on the pump unit.
Do not place pump on or near a heat source or cover with bedding.
Harvest Healthcare advise against smoking whilst the system is in use to prevent the
accidental ignition of associated items which may be ammable, such as bed linen.
We advise a risk assessment is carried out before using any medical equipment to
protect the user and service user.
•
•
•
•
•
•
•
•
•
•
•
www.easycaresystems.co.uk

5
Do not expose the pump to liquids.
Wireless equipment such as mobile phones should be kept at least 10ft/3m away from
the system.
The mattress/cushion and pump should be cleaned between patient uses.
Do not use bleach, chlorine releasing agents in concentrations over 1000 ppm,
solvents or alcohol-based cleansers, e.g. Phenicol, Hibiscrub, Clearsol, Stericol and
Hycoline as these will destroy the mattress material. Full cleaning instructions can be
found on page 15.
Suitable for continuous use.
Do not modify the mattress/cushion or pump unit in any way.
Do not connect to any other medical device or equipment.
Not for use in an oxygen enriched environment.
Not for use in an outdoor environment.
Store the system in a clean and dry environment, out of direct sunlight.
•
•
•
•
•
•
•
•
•
•
Electrical equipment can be hazardous. Only authorised technical
personnel should remove the rear pump case for maintenance.
Removal of the case by unqualied personnel will invalidate the
warranty.
Before cleaning the unit ensure that the electrical supply to the pump
has been disconnected by removing the plug from the power supply.
WARNINGS &
CAUTIONS
www.easycaresystems.co.uk

6
GENERAL
INFORMATION
Harvest 2 is our mid-range pump designed to provide controlled compressed air to a pressure
care mattress. The inated cells within the supplied mattress provide an alternating pressure
surface designed to reduce surface pressure on the skin and therefore reduce risk of the
development of pressure ulcers in susceptable patients.
It is ideal for use in both community and nursing home settings. This pump has an audible
and visual alarm with static mode. A range of features are available with the Harvest 2
including a power failure, cycle fault and low pressure alarm, and LED display. The capacity
of the pump is suitable for mattresses and active seat cushions. The Harvest 2 pump gives
a greater weight limit than that of the Harvest 1, and ts all our active overlays and standard
replacement mattresses.
Harvest Healthcare supply a pump and mattress but it is the user’s responsibility to ensure
each system meets the guidelines set out in the pump and mattress guide (shown below).
Failure to do this could put the service user at risk. This could prolong the recovery process or
increase the risk of further tissue damage.
For information on our mattress range please refer to the mattress user manuals, available on
our website, www.harvesthealthcare.co.uk.
GENERAL INFORMATION
Read through this instruction manual conscientiously from start to nish.
Note the safety instructions which must be observed.
BEFORE USING THIS SYSTEM FOR THE FIRST TIME:
-
-
Harvest Healthcare products bear the CE mark and meet all safety and functionality
requirements.
These safety requirements can only be met if the user is satised with the proper condition of
the product (including accessories) before use.
Harvest 1 Harvest 2 Harvest 3
Kensington Overlay 
Sandringham

Hampton 
Windsor
  
Hampton Extra   
Prime Comfort Active

Duke   
Duke Extra
  
Active Mattress and Pump Guide

7
USER/CARE PERSONNEL
Users are persons who as a result of their vocational training, experience or brieng are
authorised to operate the equipment.
Furthermore, the user/care personnel can recognise and avoid potential dangers and assess
the clinical condition of the service user.
PATIENT/OCCUPANT/SERVICE USER
The person in need of pressure care support, due to being identied as at risk of developing
of pressure ulcers by a suitably qualied carer or other.
QUALIFIED PERSONNEL
Qualied personnel are employees of the operator who as a result of their vocational
training or brieng are entitled to deliver, assemble, disassemble and transport the product.
2 NON-COMPLIANT USE
All uses deviating from the intended purpose, which may also be hazardous as a result.
This includes for example:
• Incorrect installation.
• Operation by persons who have not been instructed in its use.
• Using the system with non-approved parts/accessories.
• Using the system if any of the components are damaged or faulty.
GENERAL
INFORMATION
1 DEFINITION OF THE GROUPS MENTIONED
OPERATOR
An operator is any natural or legal person who uses the equipment or on whose instruction
it is used (e.g. nursing homes, specialised retailers, health insurance companies, medical
suppliers).
3.1 GENERAL SAFETY INSTRUCTIONS
During the brieng, specic attention must be drawn to any potential dangers
which can occur despite correct operation. Before putting the product into service
for the rst time, the Instruction Manual must be read conscientiously and in detail
by the user/care personnel.
Programming of the system should be carried out by competent trained personnel.
Use only spares and accessories supplied or approved by Harvest Healthcare.
Only suitably trained personnel are allowed to operate the system.
3 SAFETY INSTRUCTIONS

8
GENERAL
INFORMATION
The mains cable must be free and not be allowed to be caught up in the bed’s
moving mechanisms. The mains cable may be damaged or it may be pulled out of
its socket and electric leads exposed as a result.
If the mains cable or the mains plug are damaged, the relevant part must be
replaced. This work should be carried out by the manufacturer or authorised
service agents.
When connecting the mains plug do not use multiple sockets since liquids may
penetrate into these (re hazard and electric shock).
3.2 SAFETY INFORMATION FOR THE OPERATOR
With the help of this instruction manual, instruct each user in the safe operation of
this system before it is put into service for the rst time.
Advise the user of any hazards which may occur if not handled correctly.
Only persons who have been properly instructed may operate this system. This
also applies for persons who only operate the system on a temporary basis.
3.3 SAFETY INFORMATION FOR THE USER
Ensure that the operator instructs you in the safe operation of this system.
In addition, pay particular attention to the ‘Warnings and Cautions’ (page 4-5) and the
‘General Safety Information’ as described in 3.1.
If there is a suspected fault or damage, switch off the pump and unplug the mains plug from
the socket. Clearly mark “Out of Order”, take out of service immediately and inform the person
in charge without delay.
www.easycaresystems.co.uk

9
This symbol indicates general hazards. There is a danger to life and health.
Conformity mark in accordance with the Medical Device Directive (93/42 EEC).
The symbol for Protection Class II device, double insulated.
The symbol for type B device according to EN 60601-1.
Handle with care.
This way up.
Keep dry.
Recycling symbol. Refers to packaging that can be recycled (cardboard).
Fragile, handle with care.
This product must be disposed of in a designated refuse bin for waste
electronic devices (WEEE) in the European Union. Do not dispose of as normal
domestic waste.
No smoking. No naked ames.
Read instructions / consult manufacturers guide.
This symbol indicates electrical hazards. There is danger to life and health.
3.4 SYMBOLS USED
GENERAL
INFORMATION
www.easycaresystems.co.uk

10
GENERAL
INFORMATION
3.5 CLEANING & DISINFECTION
Do not immerse electrical components in water but wipe with a damp cloth only.
The electrical components must not be cleaned with a high-pressure cleaner or
water jet. Disinfection by wiping only is allowed.
Full cleaning and disinfection instructions can be found on page 15.
3.6 SERVICING & MAINTENANCE
Servicing must only be carried out by qualied personnel.
A technical check and/or safety inspection must be conducted at least once a year
or after a lengthy break in use.
Any defects, damage or signs of wear must be rectied without delay. Only original
spare parts from Harvest Healthcare may be used, otherwise all guarantees or
warranties will be invalidated.
See pages 16-17 for ‘Routine Maintenance’ and ‘Routine Servicing’.
3.7 SERVICE LIFE & DISPOSAL
Our full terms & conditions including product warranties are available by request or can be
found on our website www.harvesthealthcare.co.uk.
PARTS AND DATA MAY UNDERGO FURTHER DEVELOPMENT AND
THEREFORE DEVIATE FROM THE DETAILS GIVEN.
The system must not be disposed of as normal domestic waste after its service life,
but must be disposed of in a designated refuse bin for waste electronic devices
(WEEE) in the European Union. Do not dispose of as normal domestic waste.
www.easycaresystems.co.uk

11
TECHNICAL
SPECIFICATION
HARVEST 2 TECHNICAL SPECIFICATION
Pump Model No.
Operating Cycle
Dimensions
Weight
Air Flow Output
Pressure Setting
HPU2
10 minutes
130 x 140 x 270mm
1.7 kg
9 lpm
Manual
PUMP POWER REQUIREMENTS
Power Rating
Voltage
Fuse
Medical Classication
Safety Standards
9VA
AC230V / 50Hz
T 1AH 250V
Type B Applied Part
EN 60601-1. EN 60601-1-2
www.easycaresystems.co.uk

12
OVERVIEW
Feed Tube Connection
Comfort Setting
Power Switch
Visual and Audible Low-Pressure
and Power Failure Warning/Alarm
with mute
A
B
C
D
E
F
Alternating/Static Mode Indicator
Auto-Lock Indicator
Static Mode
Bed Hooks
PUMP OVERVIEW
A
B
D
F
E
C
G
G
Power failure: The alarm will sound until the power is reinstated. If the
‘Mute’ button is pressed to silence the alarm, you must press the on/
off switch to restart the pump. When the power is reinstated check
the status of the pump and ensure it is switched ON.
‘Static Mode’ is only to be used for patient care.
H
H
www.easycaresystems.co.uk

13
Feed Tube Connector
The pipes from the mattress will connect here. It is important that pump can be
disconnected in an emergency if CPR is to be administrated.
A
Comfort Setting
The pump has a scale printed on the front panel in kilograms. Press the comfort
control button until the nearest desired weight setting is illuminated on the display
panel. When the mattress is in use the user can adjust the comfort setting as required
for the service user’s needs. A slight increase of the comfort setting may be required if
the service user needs extra support when the bed is proled. When the bed platform
is laid at readjust the setting as required for the service user.
B
Power Switch
Press the power button on the front control panel once to start and stop the pump.
If you cannot change the setting check the lock out mode is not activated. - See ‘F’
C
Visual and Audible Low Pressure and Power Failure Warning/Alarm
The pump is tted with an audible and visual alarm. Press the ‘Mute’ button to
reset the alarm. The alarm will activate after 45 mins if the mattress has not fully
inated while in the start-up mode. When the mattress is inated the alarm mode
will reset and the alarm will now activate if it detects a fault on the system.
The LED next to ‘Fault’ will illuminate red when a fault is detected with the system.
The LED next to ‘Power Failure’ will illuminate red when a fault is detected with the
power supply.
D
Alternating/Static Mode Indicator
When the pump is switched on for the rst time it will enter ‘Start-up Mode’ and
inate all the cells. The ‘Alternating Mode’ LED will ash to indicate that the pump
is in ‘Start-up Mode’. Once all the cells have been inated the LED will change to
a constant light and ‘Alternating Mode’ will be activated automatically. The cells in
the mattress will then inate and deated to prove pressure relief for the service
user.
E
Auto-Lock Indicator
The pump ‘Auto-Lock’ will activate automatically after the controls have not been used
for one minute, signied by an illuminated LED green light next to the unlock symbol
illuminating. This function will prevent alteration of the settings on the pump unless
unlocked. Unlock the auto-lock by pressing and holding on the unlock button. Wait
until the pump bleeps once and the LED light extinguishes. Access to the different
functions will now be made available.
F
Static Mode
The static mode can be operated by the user to inate all the cells for patient care.
Press the static mode button, the static mode LED will illuminate when this mode is
engaged. The static mode will stop working after 30 mins and the pump will revert
back to the alternating mode if there is no further interaction with the pump.
G
OVERVIEW
Bed Hooks
Attach the pump to the foot end of the bed. Adaptor brackets are available to t
different sizes of beds. If the pump cannot be attached to the foot end of the bed it is
the user’s responsibility to ensure that the pump is placed in such a position that it will
not cause harm or injury to the service user. The pump unit must be placed so
that it can clearly be seen and monitored at all times.
H

14
OPERATION
INFLATING THE MATTRESS/CUSHION
Plug in at the mains supply and press the ON button on the control panel. The control
panel will light up to indicate that there is a power supply.
The ‘Alternating Mode’ LED will now start ashing to indicate the pump is in ‘Start Up
Mode’. Once the mattress is fully inated the LED will stop ashing. While in ‘Start Up
Mode’ DO NOT select ‘Static Mode’ as the pump will alarm. If this occurs, switch
off the pump and switch it back on to reinate the mattress.
The mattress is now ready to be used.
1
2
Set the pump to run at the correct pressure to suit the weight of the
service user. Refer to the ‘Pump Control Panel’ on the front of the
pump.
If the pump needs to be disconnected for any reason attach the transport cap to the feed
tube connector. This will prevent deation by retaining the remaining air within the mattress.
The alternating action stops in this mode.
TRANSPORT MODE
To turn off the system press the power button to OFF and unplug from
the mains supply.
When the mattress is fully inated set the pump to the service user’s approximate
weight. Position the service user in the lying position. If required, reset the weight
setting to meet the patient’s comfort needs.
Ensure that the comfort setting is altered correctly when the patient moves from a lying
to a sitting position and vice versa. If a patient is being moved to a sitting position, the
comfort control dial should be increased to provide more support for the patient. For
example, if the patient is 50kg and is in the sitting position the comfort dial will need to
be increased to the 60kg setting.
Note: The static mode is only to be used for patient care. Switch off after use.
1
2
SETTING UP PROCEDURE
It is important to follow the correct setting up procedure to ensure the patient receives
sufcient support whilst achieving maximum pressure relief and comfort.
Failure to follow this procedure could result in the service user being put at risk.

15
CLEANING & CARE
PUMPS
For general cleaning wipe with a soft cloth dampened with a mild detergent and water
solution. This may be followed by either wiping with a sodium hypochlorite solution to a
dilution of 1000ppm (parts per million) or by using alcohol wipes.
DO NOT USE HYPERCARBONATE, PHENOL-BASED CLEANING
SOLUTIONS, ABRASIVE COMPOUNDS OR CLEANING PADS.
NOTES FOR CARE OF ASSOCIATED PRODUCTS
Following the use of a detergent and or disinfectant solution rinse the mattress cover
with clean water using a clean cloth and allow to dry.
Frequent or prolonged exposure to high concentrations of disinfectant solutions will
reduce the useful life of the mattress cover.
Where high concentration disinfectants e.g. > 10,000ppm chlorine releasing
agent (e.g. Haztab or bleach) or combined cleaning/chlorine releasing agent (e.g.
Chlorcleam, Actichlor) and detergent solutions are used to remove blood or other
body uids, mattresses should be thoroughly rinsed with clean water to remove any
residues. This will help prevent any long term compatibility issues associated with
disinfectant residues.
Alternatively, disinfection may be achieved by laundering at temperatures not
exceeding 80°C for 10 minutes which may include a chlorine rinse.
•
•
•
•
TRANSPORT & STORAGE
Storage conditions as follows:
–15 °C without relative humidity control; and +40 °C at a relative humidity up
to 93%, non-condensing. An atmospheric pressure range of 700 hPa to 1 060 hPa.
Suitable for all standard modes of transport when in the correct packaging.
Operation Conditions:
A temperature range of +5 °C to +35 °C and relative humidity range of 15% to 93%, non-
condensing. Operational atmospheric pressure 700 hPa to 1060 hPa. Suitable for pollution
degree 2. Operational altitude ≤2000 m.
Transportation of the mattress system:
The mattress should be loosely rolled lengthwise with the cover innermost, taking care not to
strain the feed pipes. It can then be stored/transported in the carry bag with the pump, mains
cable and this booklet. Do not stack bagged mattresses more than two high.

16
ROUTINE
MAINTENANCE
These checks should be carried out at each decontamination process, i.e.
between patients or patient occupancy and weekly for longer term patients.
PUMP
1Check the pump casing for cracks or other damage that could be dangerous.
2Check the power cord (ensure there are no bare wires).
If any faults are detected remove the equipment from use and contact the Harvest Healthcare
Service Department or your distributor.
OTHER COMPONENTS
Check air cells and mattress interior for signs of damage or contamination, e.g.
staining or uid ingress at each decontamination process, i.e. between patients or
patient occupancy (or weekly for longer term patients).
The individual cells can be wiped clean with a mild antiseptic solution.
All cells are replaceable and can be sourced from Harvest Healthcare.
•
•
•
POWER UNIT
Disconnect the power unit from the electricity supply before carrying out maintenance, repairs
or cleaning.
Check all electrical connections and power lead for signs of wear and damage.
The power unit can be wiped down with a detergent or disinfectant solution. Do not use
solvents. Unsuitable for sterilisation.
The use of inappropriate cleaning and detergent materials on medical equipment could damage
surfaces and may compromise the ability to decontaminate medical devices adequately or may
interfere with device function.
When the pump or mattress is no longer required dispose of the equipment in accordance
with the local regulations. WEEE requirements do apply to the pump unit and any electrical
components including cables which are used for or with this product.
www.easycaresystems.co.uk

17
ROUTINE
SERVICING
The Harvest 2 pump should be serviced every 12 months by Harvest Healthcare approved
personnel using genuine Harvest Healthcare spare parts.
SERVICING YOUR SYSTEM
Failure to follow the service schedule may invalidate future
warranty claims (‘Guarantees & Warranties’ can be found on page
23).
www.easycaresystems.co.uk

18
18
TROUBLESHOOTING
CHECK THATFAULT STAGE 2 CHECK
Pump shows no indication that it is powered up.
Mains plug is plugged in and power switched on. The power switch on the pump is switched on. The fuse in the mains plug is not blown. The wall socket that the pump is connected to is working correctly.
1. 2. 3. 4.
Connect the pump to the nearest (working) mains outlet. Replace the plug fuse with the correct 5A fuse. Try a different device in the mains outlet.
1. 2. 3.
IF PROBLEM PERSISTS
Contact Harvest Healthcare technical support. Before calling: Please ensure you have the serial number and model of equipment. Please record details of the results of the recommended tests. (Notes pages are provided at the back of this user manual).

19
18 19
CHECK THATFAULT STAGE 2 CHECK
The pump appears to be running but the mattress is not inating correctly and or the low pressure light is illuminated.
IF PROBLEM PERSISTS
Contact Harvest Healthcare technical support. Before calling: Please ensure you have the serial number and model of equipment. Please record details of the results of the recommended tests. (Notes pages are provided at the back of this user manual).
PLEASE NOTE Ination can take up to 30 minutes.
The hoses are routed correctly (not kinked) and connected to the pump correctly. The CPR valve is not trapped and is in the closed position.
1. 2.
There are no leaks in the mattress. The tubes in the mattress are not disconnected or kinked.
1. 2.
Disconnect and then re- connect the hoses to the outlet on the side of the pump. Open then reclose the CPR valve, make sure the valve is not trapped in the bed mechanism.
1. 2.
Replace any damaged or leaking mattress parts with the correct genuine Harvest Healthcare spare parts. Straighten out any kinked pipes and reconnect any disconnected joints.
1. 2.

20
20
TROUBLESHOOTING
Some of the cells appear to be deated.
This is normal for alternating pressure therapy. The mattress is made up of individual air cells. The alternating section is split up into 2 sections consisting of odd cells e.g. 1,3,5 etc and even cells e.g. 2,4,6 etc. These two sections will alternate through a 10 minute cycle in which time both sets of alternating air cells will have inated and deated sequentially.
CHECK THATFAULT STAGE 2 CHECK
The system does not appear to be alternating.
Check that the static mode is not turned on. Carefully mark one of the inated cells with a pen. Ensure that there are no kinks in the pipework down the side of the mattress.
1. 2. 3.
Monitor the cell for 7 minutes to see if it deates. Straighten out any kinked pipes.
1. 2.
IF PROBLEM PERSISTS
Contact Harvest Healthcare technical support. Before calling: Please ensure you have the serial number and model of equipment. Please record details of the results of the recommended tests. (Notes pages are provided at the back of this user manual).
