EasyIO EIO-NSA-7000 User manual

EIO-NSA-7000
Flush Mount Network Sensors
Installation Guide
P/N 24-11070-00027 Rev. — Issue Date: 12 2020
Building Eciency
Headquarters: Milwaukee, Wisconsin, USA
Branch Officies: Principal Cities World-wide
Johnson Controls®are registered trademarks of Johnson Controls.
All other marks herein are the marks of their respective owners.
© Copyright 2020 Johnson Controls. All rights reserved. Any unauthorized use or copying is strictly prohibited.
www.johnsoncontrols.com
87.75
87.75
14.20
39.20 60.00
> 50 cm
> 150 cm
°C
AUTO °C/°F
OFF
• Ambient
• 室温
MAX
45 °C
113 °F
MIN
-0 °C
-32 °F
MAX
60 °C
140 °F
MIN
-10 °C
-14 °F
MAX 90% RH
MIN 10% RH
Printed Circuit Board
Main Network
Port
Pin Number Assignment for
Straight-Through Cable
6 5 4 3 2 1
Pin 6 Pin 5 Pin 4 Pin 3 Pin 2 Pin 1
PWR
(sensor)
COM
(sensor)
PWR
(tool)
COM
(tool)
SA BUS
-
SA BUS
+
SA PWR 15 VDC
COM BUS COM
- SA BUS -
+ SA BUS +

EIO-NSA-7000
P/N 24-11070-00027 Rev. — Issue Date: 12 2020
INSTALLATION INSTRUCTIONS FOR THE TECHNICIAN / FITTER
READ THIS INSTRUCTION SHEET AND THE SAFETY WARNINGS CAREFULLY BEFORE
INSTALLING AND SAVE IT FOR FUTURE USE
REPAIR AND REPLACEMENT
Do not attempt to repair the EIO-NSA-7000 sensor. In case of improperly functioning control, contact the nearest Johnson
Controls® representative, and specify the desired product code number. When contacting the supplier for a replacement
please state the type/model number of the control located on the data plate or cover label.
IMPORTANT
• Use this EIO-NSA-7000 sensor only as an operating control. Where failure of malfunction of the EIO-NSA-7000 sensor
could lead to personal injury or property damage to the controlled equipment or other property, additional precautions
must be designed into the system. Incorporate and maintain other devices such as supervisory or alarm systems or
safety or limit controls intended to warn of, or protect against, failure or malfunction of the EIO-NSA-7000 sensor.
• Do not install this sensor in condensing, wet, or damp environment. Moisture may cause damage to the sensor.
• Do not remove PCB from the enclosure cover. Removing the PCB from the enclosure cover voids the product warranty.
• Make all wiring connection in accordance with local, nation, and regional regulations. Do not exceed the EIO-NSA-7000
sensor electrical ratings.
• Remove LCD plastic cover before use.
WARNING
Disconnect power supply before making electrical connections. Contact with components carrying hazardous voltages can
cause electrical shock and may result in severe personal injury or death.
• Risk of Electrical Shock and Property Damage: Insulate and secure each unused wire lead before applying power
to the device. Failure to insulate and secure each unused wire lead may result property damage, electrical shock, and
severe personal injury or death.
English
SETUP AND ADJUSTMENT
Press button for 5 seconds, to get in parameter list, press button to switch over setting items and use and
button to change parameter value.
ALARM CODE DESCRIPTION
Item Parameter Default Function
01 Display language 00 00: Chinese
01: English
02 Units 00 00: °C
01: °F
03 Address 00 00-16(199-215)
04 Temperature Setpoint adjustment type 00 00: Setpoint
01: W/C
05 Humidity display
(only for NSA-FHR71X3-0, NSA-FHD7003-0)
00 00: Enable
01: Disable
06 Default display 00 00: Room temperature
01: Setpoint temperature
02: Relative humidity (only when Humidity display is available)
07 Backlight time 30 05 to 60, reduce backlight after xx seconds
08 Keypad Lock 00 00: No lock
01: Lock all keys
02: Lock the key except occupancy
Code or icon Description
E1 Internal sensor warning.
HI High temperature warning. Room temperature > 55°C (> 131°F)
LO Low temperature warning. Room temperature < 0°C (< 32°F) or internal sensor opened.
Communication fail

EIO-NSA-7000
P/N 24-11070-00027 Rev. — Issue Date: 12 2020
中国
安装指导
请在安装前仔细阅读该安装指导和安全警告
维修和替换
不要试图现场维修EIO-NSA-7000系列传感器。如果EIO-NSA-7000不能正常工作,请与附近江森自控办事处联系。当联系办事
处更换产品的时候,请说明外部标签或参数表上印有的类型/型号。
重要
• EIO-NSA-7000系列传感器仅用作设备控制。当EIO-NSA-7000系列传感器调节装置失灵或故障时可能会导致人员伤害,财产损失及其他配备损
坏。请增加预防措施,如常使用监控及报警系统、电压保护开关等,在安装系统中。来加强此温度调节装置的机能失常和失效时的保护。
• 不要把EIO-NSA-7000装在结露、潮湿或有湿气处。湿气会损坏温控器。
• 不要把封入前盖的PCB板移出,从前盖中把封入的PCB板拆卸移出将不再享有质保服务。
• 使所有接线符合国家、地区和当地的规定。不要超过EIO-NSA-7000系列传感器电流容量。
• 使用前请移除LCD塑料罩。
警告
在进行电器接线时确保电源断开。在带电时连接各部件可能引起电击,从而导致人员受伤甚至死亡。
• 电击危险和财物损失:在传感器通电前把未使用的线头保护好,使之绝缘。任何一个未使用的线头未被绝缘和保护可能导致财产损坏,电击
和人员伤亡甚至死亡。
编号 参数项 默认值 功能含义
01 语言 00 00:中文;
01:English
02 温度单位 00 00: °C
01: °F
03 通信地址 00 00-16 (199-215)
04 温度设定方式 00 00:设定值
01:热/冷
05 湿度显示(仅适用NSA-FHR71X3-0,
NSA-FHD7003-0)
00 00:启用
01:禁用
06 默认显示 00 00:室内温度
01:温度设定值
02:相对湿度(当湿度显示启用时)
07 背光 30 05~60,xx秒无操作,背光熄灭
08 按键锁 00 00:禁用
01:锁定所有按键
02:锁定有人/无人占用键以外所有按键
代码/图标 描述
E1 内置温度传感器故障
HI 高温报警,室内温度> 55°C (> 131°F)
LO 低温报警,室内温度< 0°C (< 32°F)或传感器开路
通讯故障
参数设定
按住 键5秒,即可进入参数设置页面,按 键循环选择需要设定的参数,按 和 键调节参数
报警代码描述

EIO-NSA-7000
P/N 24-11070-00027 Rev. — Issue Date: 12 2020
Compliance Johnson Controls declares that these products are in compliance with the essential requirements and other relevant
provisions °F the EMC Directive and Low Voltage Directive.
产品中有害物质的名称及含量
部件名称
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
塑胶部件 O O O O O O
电路板及组件 O O O O O O
金属部件 O O O O O O
本表格依据SJ/T11364的规定编制
○:表示该有害物质在该部件所有均质材料中的含量均在GB/T26572规定的限量要求以下
×:表示该有害物质在该部件所有均质材料中的含量超出GB/T26572规定的限量要求
(产品中使用的物料超出SJ/T11364标准,但在欧盟RoHS中,此项为豁免,因目前技术无法有符合SJ/T11364的替代材料)
European Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
NA/SA Single Point of Contact:
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
APAC Single Point of Contact:
JOHNSON CONTROLS
C/O CONTROLS PRODUCT MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142 - CHINA
