EasyPro PCT810 User manual
Assembly Instructions
Thank you for purchasing EasyPro’s Pond Tent. Simple assembly, strong construction and large
coverage areas make these Pond Tents the perfect protection device for ponds, gardens or
landscape areas from leaves or a variety of unwanted pests.
CONTENTS
Tent body
Two berglass, collapsible poles
12 plastic stake anchors
Component bag (not pictured)
ASSEMBLY
Before beginning assembly conrm that all components are accounted for and in good condi-
tion. It is recommended to have two adults be involved in set up.
1 In an open area spread tent out at with pole sleeve side up. Assemble berglass poles by
pulling out each section and placing ends into the metal connectors.
2 Slide the assembled poles through the sleeves. Keep the sleeves in line and push the poles
through the sleeves. Toward the end it may work best to bunch up the last section of the
sleeve and then push the pole the rest of the way through.
PCT810 • PCT1014 • PCT1317
Please read this manual completely before assembling tent and save for future reference.
3 Starting at two adjoining corners insert pins located at each corner into the metal ends of the
berglass poles. There will be no tension on the netting at this point.
4 Move to the opposite ends of the poles and carefully ex the tent poles causing the tent
structure to rise. This step works best with two people working in tandem, but it can be
done one pole at a time. Smoothing out the sleeves helps this process as well. To secure the
poles, place the metal ends of the poles over the metal pins at the base of the tent.
Warning: To reduce the risk of injury to you or others be sure to grip poles securely and keep
body and face clear. Make sure poles are secured on corner pins during assembly. Do not use
damaged or broken berglass poles.
5 With two people move the assembled tent into desired position over pond, stream, land-
scape area, garden or other area requiring netting protection.
6 Secure pond tent by staking the unit. There are twelve stake locations as part of the tent:
One in each corner through the rings and two along each side under the skirt band. The
tie downs with D-rings along the side oer some adjustment to allow for tightening. Do not
remove the stakes by pulling on the tie downs.
Take care to snug up the tent evenly for all sides. Take care not to over stretch the tie downs or
sides causing possible tearing or damage to the tent. For odd shaped ponds where the stakes
may not be an option, the use of rocks or stones placed on top of the skirt band can provide
additional anchoring.
DISASSEMBLY AND STORAGE
To take down the tent, follow the steps above in reverse order. The tent should be folded into
equal parts and rolled into a tight roll the width of the component bag. Make sure the tent is
clean and dry before storing.
UV LIGHT
Ultraviolet light damage to fabric is caused by excessive exposure to sunlight. While our fabrics
are UV resistant, any synthetic fabric is susceptible to UV degradation. UV damage will cause
fabrics to become brittle and tear easily over time.
ALTERATIONS OR MODIFICATIONS
DO NOT misuse, modify or alter this product in any way from its condition at the time of sale.
Alteration, modication or any misuse of this product shall void the warranty and could cause
damage or injury to persons, animals and property.
REPLACEMENT ITEMS
Replacement Poles:
PCT810P - One collapsible pole for PCT810
PCT1014P - One collapsible pole for PCT1014
PCT1317P - One collapsible pole for PCT1317
Replacement Stakes:
PCTS - Packet of four stakes
Assemble poles and
insert into sleeves
QUICK ASSEMBLY GUIDE
Insert pins into end of two
poles on the same side
Flex poles up and insert
remaining two pins
Simple two person
assembly can be completed
in a few minutes
9527 • 10/19
800-448-3873 • Grant, Michigan
www.easypro.com
EasyPro Pond Products Limited Warranty
EasyPro Pond Products (“EasyPro”) warrants to the purchaser that this product
("Product") will be free from any mechanical or material defects for a period of one
year from the date of purchase.
This warranty only covers properly installed and
maintained Products sold by authorized EasyPro Sellers who are subject to and follow
EasyPro’s quality control standards. Please note that because EasyPro is unable
to control the quality of Products sold by unauthorized sellers, unless otherwise
prohibited by law, this warranty does not cover Products purchased from unauthorized
sellers.
This warranty does not cover normal wear and tear, nor any deterioration suered
through overloading, improper use, negligence, improper installation, acts of God or
accident. Similarly, any modication made by the purchaser to the Product will cause
the warranty to be null and void. This warranty does not cover any cost associated
with the installation or removal of the Product subject to a warranty claim.
All returned items will be inspected to determine cause of failure before a warranty
claim is approved. The exclusive remedies provided hereunder shall, upon EasyPro’s
inspection and option, be either repair or replacement of the Product or parts covered
under this warranty.
Making a Claim: A Return Authorization (“RA”) number must rst be obtained by
calling EasyPro at 800-448-3873 or via email at warranty@easypro.com. It is the
purchaser’s responsibility to pay the return shipping charges. Be sure to include the
RA number, original receipt (in the form of an invoice or sales receipt), your name, your
return address and your phone number inside of the package. No warranty claims will
be honored without the original receipt that shows that your purchase was made from
an Authorized EasyPro Seller. Ensure the product is properly packaged and insured for
the replacement value. Damage due to improper packaging is the responsibility of the
sender.
ALL OTHER EXPRESS OR IMPLIED WARRANTIES INCLUDING MERCHANTABILITY OF
FITNESS FOR A PARTICULAR PURPOSE ARE HEAREBY LIMITED IN DURATION TO THE
DURATION OF THE WARRANTY AS DESCRIBED ABOVE. Some States do not allow limitations
on how long an implied warranty lasts, so the above limitations may not apply to you.
EasyPro shall not be held liable for any damages caused by defective components or materials
of this Product; or for loss incurred because of the interruption of service; or any consequential/
incidental damages and expenses arising from the production, sale, use or misuse of this
Product. Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you.
EasyPro shall not be held liable for any loss of sh, plants or any other livestock as a result of any
failure or defect of this Product. This warranty gives you specic legal rights, and you may also
have other rights that vary from State to State.
