Coleman 2000007827 Manual

MODEL 2000007827
Main Body Pole, black, long
Ridge Pole, black, short
2
1
5010000541
5010000541
5010000547
5010000547
1
2
Pole
Sleeve
Fig. 1
1
Fig. 3
Fig. 2
Fig. 5
Fig. 4
STITCH LINE
TENT SETUP INSTRUCTIONS
2
Connect Poles to Tent
t Insert one pin into one end of the pole. (Fig. 3 and 4)
t Go to opposite end of pole and carefully insert the pin into the
other pole end. (Fig. 4)
t Repeat for all poles.
3
Attach Tent to Body Poles
Using Clips
t Attach clips along the edges of tent to body poles. (Fig. 5)
t Make any adjustments to the tent stakes, if needed.
4
Attach Rainfly
t Attach top ridge pole to underside of rainfly with straps and
insert the tips of the top ridge pole into the pockets on underside
of rainfly. (Fig. 6 & 7)
t Drape rainfly over tent. (Fig. 8)
t Connect the elastic loops with “S” hooks, (found at the rainfly
corners) to the rings found at the tent corners. (Fig. 9)
t Secure rainfly with straps located on the underside of
rainfly. (Fig. 10)
t Attach and stake out elastic cord at ground vent and
guylines. (Fig. 8)
HINT: During setup, keep door zipped to keep proper tension
on fabric.
(continued on other side)
1
Layout & Positioning
of Tent and Poles
t Layout and position the tent with door facing desired
direction. (Fig. 1)
t Stake down tent corners first through the stake rings. (Fig. 2)
t Keep the floor taut.
t Stake down the remainder of the stake rings.
t Assemble all poles by unfolding and interlocking the shock-
corded pole sections.
t Insert the body poles into the pole sleeves.
Before you begin
t Read all instructions before set up.
t Select a level site clear of rocks, branches, and other hard or
sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
t Do not set up your tent under trees because of potential
lightning strikes or falling tree limbs in inclement weather.
t Secure with all stakes and guylines provided to prevent
property damage or personal injury.
t For best results in windy conditions, position narrow end of
tent into the wind.
t Enlist the help of at least one other person to assist you
when it is time to assemble the tent.
Pole Descriptions
Description Qty. Pole
Repair Kit
Pole
Replacement Kit
No.
Pin
Tent
Stake
Stake Ring
Pole Clip
Pole

Fig. 8
Fig. 6
(Bottom View)
Rainfly
Rainfly
Guyline
Fig. 10
Fig. 9
4010009308 (20100614)
Fig. 7
5
NOTE: Use only UL
approved cords rated for
outdoor usage. (Fig. 11)
Electrical
Cord
Access
Fig. 11
STITCH LINE
1. All poles and stakes must be placed in the storage bag to
prevent damage to the fabric items placed in the carry case.
2. Make sure tent is clean and dry before placing in carry case.
3. Remove rainfly, spread out on floor of tent, then unzip
door & vents before taking tent down for storage.
4. Neatly fold tent to width of pole storage bag, place on tent, roll
tightly, and place in carry case.
5. Store in a clean, dry area.
6
To Store
Pole
Strap
“S”
Hook
Things You Should Know:
t Under certain conditions (cold weather, high humidity, etc.) condensation will form on the inside of your tent. Condensation is caused
by water vapor from your breath, perspiration, or any wet clothing inside the tent. It is NOT LEAKAGE through the tent fabric. It can be
minimized by removing wet clothing from your tent and by providing good ventilation through the tent.
t Tree limbs, tree sap, bird droppings, or moisture steadily dripping off tree limbs can cause damage to the tent fabric and its coating
resulting in leaks or loss of flame-resistant properties.
t Never store tent, even for a short period of time, without drying it thoroughly and brushing off caked dirt. Do not pack stakes or poles
inside your tent. Use a separate storage bag.
t Stakes should be removed by pulling on the stake itself. NEVER PULL ON THE TENT TO REMOVE STAKES AS THIS COULD RESULT IN
PROPERTY DAMAGE OR PERSONAL INJURY.
t Tent poles should not be left telescoped together during storage.
t Do not leave your tent set-up for weeks at a time. Be aware that exposure to ultraviolet rays from the sun can seriously damage material
and/or cause it to become discolored.
WARNING: Keep all flame and heat sources away from this tent fabric.
This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact with any flame source. The
application of any foreign substance to the tent fabric may render the flame-resistant properties ineffective.
