Eaton Aethon Manual

Fix the fixing plate
to the wall.
Installation
Easy Hang Wall Plate
Luminaire Bracket
Fixing Plate with Gasket
Fix the Luminaire to the fixing plate on
the wall by hooking the over the top of
the fixing plate. Once secure, lower the
luminaire into position (left) and lock via
the two screws at the bottom (right).
Note: Take care of supply cable whilst
locating luminaire
Instruction Manual - K1098V1
October 2017
Aethon
K1098V1
Eaton
Wheatley Hall Road, Doncaster, South Yorkshire, DN2 4NB
Sales
T: [phone]
F: [phone]
E: [e-mail]
General
[phone]
[phone]
[e-mail]
International Sales
[phone]
[phone]
[e-mail]
Wiring Terminate 3-core cable using suitable method (ensure IP rating is
maintained if required.
Ensure Live, Earth and Neutral polarities are observed (see left)
Finally restore mains supply and test fitting’s functionality
Brown - Live
Green/Yellow - Earth
Blue - Neutral
Luminaire Cleaning
Safe Operation
1. To prevent damage to driver, do not mix with conventional magnetic ballasts on the same electrical circuit.
2. Check the rating label for voltage and frequency before connecting this luminaire to the electrical supply.
3. Ensure that the mains supply is switched off when working on this luminaire.
4. Where use in more onerous situations is required, e.g. Where ambient temperatures are outside the normal temperature
range,then consult our Sales Office
5.The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent or a similar qualified
person.
Servicing and Lamp Disposal
1. At commissioning and handing over of installation ensure that a copy of these instructions is presented to the authority responsible
for the operation and maintenance of the luminaries.
2. Servicing, e.g. cleaning, must only be carried out after the electricity supply has been switched off. It must not be assumed that unlit
luminaires are switched off- always check before servicing.
3. Cleaning should be carried out at regular intervals to ensure that dirt does not accumulate to an extent that will impair the thermal
safety of the luminaire. Regular cleaning will also ensure that the optical performance of the luminaires is maintained.
4. At the end of life the luminaire is classed as WEEE under directive 2002/96/EC and should be disposed of in accordance with local
legislation.
5. All other parts of these luminaries, in small quantities, may be disposed of in the normal way. However, if large quantities of plastic
are to be incinerated special precautions should be taken against the fumes which may be given off.
End of Life and Components Disposal
WEEE
IP67
 Product luminaires comply with EN60598 and are suitable for use in normal exterior conditions.
o o
 This luminaire has an ambient temperature range of -40 C to 50 C .
 All dimensions on this leaflet are in millimetres
Instruction Leaflet K1098V1
Aethon
May 2017
332.0
463.2
91.0
393.7
674.5
110.8
Small
Large
Dimensions
560.4 380.8

Open flap and mount
luminaire to surface
using the two fixing
holes (ø12.8mm) on the
back of the mounting arm
(as shown bottom right).
Once secure,
wire terminations
and place the flap back
into position and secure
with the two screws.
Set the Aethon to face in the correct
direction and fix into
position by tightening
the bolts from the bracket to the luminaire.
1
Installation
B
Make terminal connections
and fix end plate back into
position.
Large
Small
A
20.0 80.0
ø20.0 ø5.0
100.0
ø20.0 ø12.0
Fix bracket to surface using below
fixing detail.
C
Large Yoke
Installation
Mounting Arm
Remove screws (x2)
to release flap for
mounting arm.
A
380.8
B
Installation
Pole Mounting Arm
Installation
Two Piece Bracket
Locate luminaire
onto pole and lock
into position with
two bolts.
Fixing Dimensions
106.0
All values in mm
ø63.9
ø6.9 (x4)
31.0
ø9.0 (x4)
Set angle of bracket
and fix with a
locking screw.
Ensure holes
in the bracket
are aligned
before
fixing
position
B
Fix bracket to chosen surface. Use
fixing details as shown below.
To the luminaire
To the surface
A
ø31.0
ø8.0 (x2)
50.0
ø20.5
16.1
74.0
