Eaton Powerware 9125 User manual

Powerware 9125 Two-in-One UPS
5000/6000 VA
User’s Guide
®

Class A EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
ICES-003
This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing
Equipment Regulations ICES-003.
Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du
Canada.
EN 50091-2
Some configurations are classified under EN 50091-2 as “Class-A UPS for Unrestricted Sales Distribution.” For
these configurations, the following applies:
WARNING This is a Class A-UPS Product. In a domestic environment, this product may cause radio interference, in
which case, the user may be required to take additional measures.
Powerware, ABM, and FERRUPS are registered trademarks and X-Slot, ConnectUPS, and LanSafe are trademarks
of Eaton Power Quality Corporation. Greenlee is a registered trademark of Greenlee Textron. Modbus is a registered
trademark of Modicon.
ECopyright 2003–2005 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be
reproduced in any way without the express written approval of Eaton Corporation.

Requesting a Declaration of Conformity
Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:
SHarmonized Standards: EN 50091-1-1 and EN 50091-2; IEC 60950 Third Edition
SEU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits
93/68/EEC, Amending Directive 73/23/EEC
89/336/EEC, Council Directive relating to electromagnetic compatibility
92/31/EEC, Amending Directive 89/336/EEC relating to EMC
The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC
Declaration of Conformity, contact:
Eaton Power Quality Oy
Koskelontie 13
FIN-02920 Espoo
Finland
Phone: [phone]
Fax: [phone]

Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the
associated warning should be observed.
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
i
Table of Contents
1 Introduction 1.........................................................
2 Safety Warnings 3.....................................................
3 Installation 15..........................................................
Inspecting the Equipment 15................................................................
UPS Setup 15..........................................................................
Installing the UPS Internal Batteries 16.....................................................
Tower Setup 17......................................................................
EBM Installation 19......................................................................
Plug-Receptacle UPS Installation 21..........................................................
Remote Emergency Power-off Installation 22....................................................
Hardwired UPS Installation 24..............................................................
4 Operation 29...........................................................
Turning the UPS On 29....................................................................
Starting the UPS on Battery 29..............................................................
Turning the UPS Off 30....................................................................
Initiating the Battery Test 30................................................................
Transferring the UPS to Bypass Mode 31.......................................................
Operating Modes 31.....................................................................
Normal Mode 32.....................................................................
Battery Mode 33.....................................................................
Bypass Mode 34......................................................................
Standby Mode 34.....................................................................
5 Configuration 35........................................................
6 Communication 37......................................................
USB Port 37............................................................................
DB-9 Communication Port 38...............................................................
X-Slot Cards 39.........................................................................
7 UPS Maintenance 41....................................................
UPS and Battery Care 41..................................................................
Storing the UPS and Batteries 41..........................................................
When to Replace Batteries 41...............................................................

TABLE OF CONTENTS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
ii
Replacing Batteries 42....................................................................
How to Replace Extended Battery Modules 42................................................
How to Replace Internal Batteries 44.......................................................
Testing New Batteries 45..................................................................
Recycling the Used Battery or UPS 46.........................................................
8 Specifications 47.......................................................
9 Troubleshooting 51......................................................
Audible Alarms and UPS Conditions 51........................................................
Silencing an Audible Alarm 51............................................................
Service and Support 54...................................................................
10 Warranty 55...........................................................
Two-Year Limited Warranty (US and Canada) 55..................................................
Ten-Year Pro-Rated Limited Warranty (US and Canada) 57..........................................
Load Protection Guarantee (US and Canada) 59..................................................

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
1
Chapter 1 Introduction
The Powerware®9125 uninterruptible power system (UPS) protects your
sensitive electronic equipment from the most common power problems
including power failures, power sags, power surges, brownouts, line
noise, high voltage spikes, frequency variations, switching transients,
and harmonic distortion.
Power outages can occur when you least expect it and power quality
can be erratic. These power problems have the potential to corrupt
critical data, destroy unsaved work sessions, and damage hardware —
causing hours of lost productivity and expensive repairs.
With the Powerware 9125, you can safely eliminate the effects of power
disturbances and guard the integrity of your equipment. Figure 1 shows
the Powerware 9125 UPS with an optional Extended Battery Module
(EBM).
Figure 1. The Powerware 9125 UPS with Optional EBM

INTRODUCTION
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
2
Providing outstanding performance and reliability, the Powerware 9125’s
unique benefits include the following:
SOnline UPS design with pure sine wave output. The UPS filters and
regulates incoming AC power and provides consistent power to your
equipment without draining the battery.
S5U rack height with the highest power density for a 6000 VA UPS.
STwo-in-one form factor for using the UPS in a rack-mount
configuration or as a standalone cabinet.
SABM®technology that uses advanced battery management to
increase battery service life, optimize recharge time, and provide a
warning before the end of useful battery life.
SHours of extended runtime with up to four EBMs.
SStart-on-battery capability for powering up the UPS even if utility
power is not available.
SHot-swappable batteries that simplify maintenance by allowing you to
replace batteries safely without powering down the critical load.
SEmergency shutdown control through the remote emergency
power-off (REPO) port.
STwo standard communication options with a USB port and a DB-9
serial port.
SOptional X-Slottcards with enhanced communication capabilities for
increased power protection and control.
SAdvanced power management with the Software Suite CD for
graceful shutdowns and power monitoring.
SBacked by worldwide agency approvals.

EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
3
Chapter 2 Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and
maintenance of the UPS and batteries. Please read all instructions before operating the
equipment and save this manual for future reference.
DANGER
This UPS contains LETHAL VOLTAGES. All repairs and service should be performed by
AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS
inside the UPS.
WARNING
SThis UPS contains its own energy source (batteries). The output receptacles may carry
live voltage even when the UPS is not connected to an AC supply.
SFor 208–240V models, the output receptacles may remain electrically live. If the input
power source in your application is wired line-to-neutral (as in most European
applications), the voltage to the output receptacles is 0V. With line-to-line input wiring,
the voltage to the output receptacles is 110–120V (measured from line-to-ground or
line-to-neutral, depending on the UPS wiring).
SDo not remove or unplug the input cord when the UPS is turned on. This removes the
safety ground from the UPS and the equipment connected to the UPS.
STo reduce the risk of fire or electric shock, install this UPS in a temperature and humidity
controlled, indoor environment, free of conductive contaminants. Ambient temperature
must not exceed 40°C (104°F). Do not operate near water or excessive humidity (95%
maximum).
SFor UPS models with hardwired outputs, overcurrent protection for the output AC
circuit(s) is to be provided by others.
SFor UPS models with hardwired outputs, suitably rated disconnect switches for the
output AC circuit(s) are to be provided by others.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
4
CAUTION
SBatteries can present a risk of electrical shock or burn from high short-circuit current.
Observe proper precautions. Servicing should be performed by qualified service
personnel knowledgeable of batteries and required precautions. Keep unauthorized
personnel away from batteries.
SProper disposal of batteries is required. Refer to your local codes for disposal
requirements.
SNever dispose of batteries in a fire. Batteries may explode when exposed to flame.
Sikkerhedsanvisninger
VIGTIGE SIKKERHEDSANVISNINGER
GEM DISSE ANVISNINGER
DENNE BRUGERVEJLEDNING INDEHOLDER VIGTIGE
SIKKERHEDSANVISNINGER
FARE
Denne UPS indeholder LIVSFARLIG HØJSPÆNDING. Alle reparationer og vedligeholdelse bør
kun udføres af en AUTORISERET SERVICETEKNIKER. Ingen af UPS’ens indvendige dele kan
repareres af brugeren.
ADVARSEL!
SDenne UPS indeholder egen energiforsyning (batterier). Udgangsnetstikkene kan lede
strøm, selv når UPS’en ikke er tilsat en AC-energikilde.
SNetledningen må ikke fjernes og stikket må ikke trækkes ud, mens UPS’en er tændt.
Dette fjerner sikkerhedsjorden fra UPS’en og fra det udstyr, der er sat til.
SInstallér denne UPS i et temperatur- og fugtighedskontrolleret indendørsmiljø, frit for
ledende forureningsstoffer for at formindske risikoen for brand og elektrisk stød.
Rumtemperaturen må ikke overstige 40°C. UPS’en bør ikke betjenes nær vand eller høj
fugtighed (maksimalt 95%).
SFor UPS systemer med hårdledningsudgange, skal overstrømsbeskyttelse for
vekslestrømmens udgangskredsløb forsynes af andre.
SFor UPS systemer med hårdledningsudgange, skal egnede, nominelle afbryderkontakter
for vekslestrømmens udgangskredsløb forsynes af andre.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
5
ADVARSEL
SBatterier kan udgøre en fare for elektrisk stød eller forbrændinger forårsaget af høj
kortslutningsspænding. De korrekte forholdsregler bør overholdes.
SKorrekt bortskaffelse af batterier er påkrævet. Overhold gældende lokale regler for
bortskaffelsesprocedurer.
SSkaf dig aldrig af med batterierne ved at brænde dem. Batterierne kan eksplodere ved
åben ild.
Belangrijke Veiligheidsinstructies
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
BEWAAR DEZE INSTRUCTIES
DEZE HANDLEIDING BEVAT BELANGRIJKE
VEILIGHEIDSINSTRUCTIES
GEVAAR
Deze UPS bevat LEVENSGEVAARLIJKE ELEKTRISCHE SPANNING. Alle reparaties en
onderhoud dienen UITSLUITEND DOOR ERKEND SERVICEPERSONEEL te worden uitgevoerd.
Er bevinden zich GEEN ONDERDELEN in de UPS die DOOR DE GEBRUIKER kunnen worden
GEREPAREERD.
WAARSCHUWING
SDeze UPS bevat zijn eigen energiebron (batterijen). De uitgangsaansluitingen kunnen
onder spanning staan wanneer de UPS niet op een wisselstroom voeding is aangesloten.
SVerwijder de ingangsnoer niet of haal de stekker van de ingangsnoer er niet uit terwijl de
UPS aan staat. Hierdoor zou de UPS en uw aangesloten apparatuur geen
aardebeveiliging meer hebben.
STeneinde de kans op brand of elektrische schok te verminderen dient deze UPS in een
gebouw met temperatuur- en vochtigheidregeling te worden geïnstalleerd, waar geen
geleidende verontreinigingen aanwezig zijn. De omgevingstemperatuur mag 40°Cniet
overschrijden. Niet gebruiken in de buurt van water of bij zeer hoge vochtigheid (max.
95%).
SVoor UPS systemen met vast-bedrade uitgangen, moet de overstroombeveiliging voor
wisselstroom uitvoercircuit(s) door anderen worden geleverd.
SVoor UPS systemen met vast-bedrade uitgangen, moeten de juiste hoofdschakelaars
voor wisselstroom uitvoercircuit(s) door anderen worden geleverd.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
6
OPGELET
SBatterijen kunnen gevaar voor elektrische schok of brandwonden veroorzaken als gevolg
van un hoge kortsluitstroom. Volg de desbetreffende aanwijzingen op.
SDe batterijen moeten op de juiste wijze worden opgeruimd. Raadpleeg hiervoor uw
plaatselijke voorschriften.
SNooit batterijen in het vuur gooien. De batterijen kunnen ontploffen.
Tarkeita Turvaohjeita
TÄRKEITÄ TURVAOHJEITA - SUOMI
SÄILYTÄ NÄMÄ OHJEET
TÄMÄ OPAS SISÄLTÄÄ TÄRKEITÄ TURVAOHJEITA
VAARA
Tämä UPS sisältää HENGENVAARALLISIA JÄNNITTEITÄ. Kaikki korjaukset ja huollot on
jätettävä VAIN VALTUUTETUN HUOLTOHENKILÖN TOIMEKSI. UPS ei sisällä MITÄÄN
KÄYTTÄJÄN HUOLLETTAVIA OSIA.
VAROITUS
STämä UPS sisältää oman energialähteen (akuston). Ulostuloliittimissä voi olla jännite,
kun UPS ei ole liitettynä verkkojännitteeseen.
SÄlä poista tai irrota sisääntulojohtoa, kun UPS on kytkettynä. Tämä poistaa
turvamaadoituksen UPS-laitteesta ja siihen liitetystä laitteistosta.
SVähentääksesi tulipalon ja sähköiskun vaaraa asenna tämä UPS sisätiloihin,
joissa lämpötila ja kosteus on säädettävissä ja joissa ei ole virtaa johtavia
epäpuhtauksia. Ympäristön lämpötila ei saa ylittää 40 °C. Älä käytä lähellä vettä ja vältä
kosteita tiloja (95 % maksimi).
SUPS-järjestelmissä kiintealla asennuksella: kuormana olevien laitteiden ylivirtasuojaus ja
erotuskytkimet tulee toteuttaa kuormapiireissa.
VARO
SAkusto saattaa aiheuttaa sähköiskun tai syttyä tuleen, jos akusto kytketään oikosulkuun.
Noudata asianmukaisia ohjeita.
SAkusto täytyy hävittää säädösten mukaisella tavalla. Noudata paikallisia määräyksiä.
SÄlä koskaan heitä akkuja tuleen. Ne voivat räjähtää.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
7
Consignes de sécurité
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVER CES INSTRUCTIONS
CE MANUEL CONTIENT DES CONSIGNES DE SÉCURITÉ
IMPORTANTES
DANGER!
Cet onduleur contient des TENSIONS MORTELLES. Toute opération d’entretien et de
réparation doit être EXCLUSIVEMENT CONFIÉE A UN PERSONNEL QUALIFIÉ AGRÉÉ.
AUCUNE PIÈCE RÉPARABLE PAR L’UTILISATEUR ne se trouve dans l’onduleur.
AVERTISSEMENT!
SCet onduleur renferme sa propre source d’énergie (batteries). Les prises de sortie
peuvent être sous tension même lorsque l’onduleur n’est pas branché sur le secteur.
SNe pas retirer le cordon d’alimentation lorsque l’onduleur est sous tension sous peine de
supprimer la mise à la terre de l’onduleur et du matériel connecté.
SPour réduire les risques d’incendie et de décharge électrique, installer l’onduleur
uniquement à l’intérieur, dans un lieu dépourvu de matériaux conducteurs, où la
température et l’humidité ambiantes sont contrôlées. La température ambiante ne doit
pas dépasser 40 °C. Ne pas utiliser à proximité d’eau ou dans une atmosphère
excessivement humide (95 % maximum).
SPour les models UPS ayant des sorties câblées, la protection contre une surintensité pour
le(s) circuit(s) de sortie de courant alternatif doit être fournie par un autre fournisseur.
SPour les models UPS ayant des sorties câblées, les interrupteurs de déconnexion
convenables pour le(s) circuit(s) de sortie de courant alternatif doivent être fournie par un
autre fournisseur.
ATTENTION!
SLes batteries peuvent présenter un risque de décharge électrique ou de brûlure par des
courts-circuits de haute intensité. Prendre les précautions nécessaires.
SUne mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements
en vigueur dans votre localité.
SNe jamais jeter les batteries au feu. L’exposition aux flammes risque de les faire
exploser.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
8
Sicherheitswarnungen
WICHTIGE SICHERHEITSANWEISUNGEN AUFBEWAHREN.
DIESES HANDBUCH ENTHÄLT WICHTIGE
SICHERHEITSANWEISUNGEN.
WARNUNG
Die USV führt lebensgefährliche Spannungen. Alle Reparatur- und Wartungsarbeiten sollten
nur von Kundendienstfachleuten durchgeführt werden. Die USV enthält keine vom Benutzer
zu wartenden Komponente.
ACHTUNG
SDiese USV ist mit einer eigenen Energiequelle (Batterie) ausgestattet. An den
Ausgangssteckdosen kann auch dann Spannung anliegen, wenn die USV nicht an einer
Wechselspannungsquelle angeschlossen ist.
SDas Eingangskabel nicht entfernen oder abziehen, während die USV eingeschaltet ist,
weil hierdurch die Sicherheitserdung von der USV und den daran angeschlossenen
Geräten entfernt wird.
SUm die Brand- oder Elektroschockgefahr zu verringern, diese USV nur in Gebäuden mit
kontrollierter Temperatur und Luftfeuchtigkeit installieren, in denen keine leitenden
Schmutzstoffen vorhanden sind. Die Umgebungstemperatur darf 40°C nicht übersteigen.
Die USV nicht in der Nähe von Wasser oder in extrem hoher Luftfeuchtigkeit (max. 95 %)
betreiben.
SFür UPS-Systeme mit festverdrahteten Eingängen muß der Überstromschutz für die
Ausgangswechselstromkreise anderweitig bereitgestellt werden.
SFür UPS-Systeme mit festverdrahteten Ausgängen müssen Trennschalter für die
Ausgangswechselstromkreise mit passendem Nennwert anderweitig bereitgestellt
werden.
VORSICHT!
SBatterien können aufgrund des hohen Kurzschlußstroms Elektroschocks oder
Verbrennungen verursachen. Die entsprechenden Vorsichtsmaßnahmen sind unbedingt
zu beachten.
SDie Batterien müssen ordnungsgemäß entsorgt werden. Hierbei sind die örtlichen
Bestimmungen zu beachten.
SBatterien niemals verbrennen, da sie explodieren können.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
9
Avvisi di sicurezza
IMPORTANTI ISTRUZIONI DI SICUREZZA
CONSERVARE QUESTE ISTRUZIONI
QUESTO MANUALE CONTIENE IMPORTANTI ISTRUZIONI DI
SICUREZZA
PERICOLO
la TENSIONE contenuta in questo gruppo statico di continuità è LETALE. Tutte le operazioni
di riparazione e di manutenzione devono essere effettuate ESCLUSIVAMENTE DA
PERSONALE TECNICO AUTORIZZATO. All’interno del gruppo statico di continuità NON vi
sono PARTI RIPARABILI DALL’UTENTE.
AVVERTENZA
SQuesto gruppo statico di continuità contiene una fonte di energia autonoma (le batterie).
Le prese di uscita possono condurre tensione energizzata quando il gruppo statico di
continuità non è collegato con una fonte di alimentazione a corrente alternata.
SNon rimuovere nè scollegare il cavo di ingresso quando il gruppo statico di continuità è
acceso poichè in tal modo si disattiverebbe il collegamento a terra di sicurezza del
gruppo statico di continuità e dell’apparecchiatura ad esso collegata.
SPer ridurre il rischio di incendio o di scossa elettrica, installare il gruppo statico di
continuità in un ambiente interno a temperatura ed umidità controllata, privo di agenti
contaminanti conduttivi. La temperatura ambiente non deve superare i 40°C. Non
utilizzare l’unità in prossimità di acqua o in presenza di umidità eccessiva (95% max).
SNei sistemi UPS provvisti di uscite cablate, i dispositivi di protezione da sovracorrente
per il/i circuito/i a corrente alternata in uscita devono essere forniti da terzi.
SNei sistemi UPS provvisti di uscite cablate, i sezionatori di corrente nominale adeguata
per il/i circuito/i a corrente alternata in uscita devono essere forniti da terzi.
ATTENZIONE
SLe batterie possono presentare rischio di scossa elettrica o di ustioni provocate da alta
corrente dovuta a corto circuito. Osservare le apposite istruzioni.
SLe batterie devono essere smaltite in modo corretto. Per i requisiti di smaltimento fare
riferimento alle disposizioni locali.
SNon gettare mai le batterie nel fuoco poichè potrebbero esplodere se esposte alle
fiamme.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
10
Viktig Sikkerhetsinformasion
FARLIG
Denne UPS’en inneholder LIVSFARLIGE SPENNINGER. All reparasjon og service må kun
utføres av AUTORISERT SERVICEPERSONALE. BRUKERE KAN IKKE UTFØRE SERVICE PÅ
NOEN AV DELENE i UPS’en.
FARLIG
SDenne UPS’en har en egen energikilde (batterier). Stikkontaktene kan være strømførende
selv om UPS’en ikke er tilsluttet en vekselstrømforsyning.
SStrømforsyningskabelen må ikke fjernes eller trekkes ut når UPS’en er på, slik at ikke
sikkerhetsjordingen fjernes fra UPS’en og det utstyret som er forbundet med den.
SFor å redusere fare for brann eller elektriske støt, bør denne UPS’en installeres i et
innendørs miljø med kontrollert temperatur og luftfuktighet som er fritt for ledende,
forurensende stoffer. Romtemperaturen må ikke overskride 40°C. Den må ikke brukes i
nærheten av vann eller ved meget høy luftfuktighet (95% maks.).
SFor UPS systemer med fastkoplete uttak, må overstrømvern for vekselstrømuttak(ene)
stilles til rådighet av andre.
SFor UPS systemer med fastkoplete uttak, må passende utkoplingsbrytere for
vekselstrømuttak(ene) stilles til rådighet av andre.
FORSIKTIG
SBatterier kan forårsake elektriske støt eller forbrenning på grunn av høy
kortslutningsstrøm. Følg instruksene.
SBatterier må fjernes på korrekt måte. Se lokale forskrifter vedrørende krav om fjerning av
batterier.
SKast aldri batterier i flammer, da de kan eksplodere, hvis de utsettes for åpen ild.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
11
Regulamentos de Segurança
INSTRUÇÕES DE SEGURANÇA IMPORTANTES
GUARDE ESTAS INSTRUÇÕES
ESTE MANUAL CONTÉM INSTRUÇÕES DE SEGURANÇA
IMPORTANTES
CUIDADO
A UPS contém VOLTAGEM MORTAL. Todos os reparos e assistência técnica devem ser
executados SOMENTE POR PESSOAL DA ASSISTÊNCIA TÉCNICA AUTORIZADO. Não há
nenhuma PEÇA QUE POSSA SER REPARADA PELO USUÁRIO dentro da UPS.
ADVERTÊNCIA
SEsta UPS contém sua própria fonte de energia (baterias). Os receptáculos de saída
podem conter voltagem ativa quando a UPS não se encontra conectada a uma fonte de
alimentação de corrente alternada.
SNão remova ou desconecte o cabo de entrada quando a UPS estiver ligada. Isto
removerá o aterramento de segurança da UPS e do equipamento conectado.
SPara reduzir o risco de incêndios ou choques elétricos, instale a UPS em ambiente
interno com temperatura e umidade controladas e livres de contaminadores condutíveis.
A temperatura ambiente não deve exceder 40°C. Não opere próximo a água ou em
umidade excessiva (máx: 95%).
SPara sistemas UPS com saídas conectadas, a proteção de sobrecarga para circuitos de
saída de corrente alternada deve ser fornecida por outros.
SPara sistemas UPS com saídas conectadas, interruptores de desconexão devidamente
qualificados para circuitos de saída de corrente alternada devem ser fornecidos por
outros.
PERIGO
SAs baterias podem apresentar o risco de choque elétrico, ou queimaduras provenientes
de alta corrente de curto-circuito. Observe as instruções adequadas.
SSiga as instruções apropriadas ao desfazer-se das baterias. Consulte os códigos do local
para maiores informações sobre os regulamentos de descarte de produtos.
SNunca jogue as baterias no fogo, porque há risco de explosão.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
12
Предупреждения по мерам безопасности
ВАЖНЫЕ УКАЗАНИЯ ПО МЕ АМ БЕЗОПАСНОСТИ
СОХ АНИТЕ ЭТИ УКАЗАНИЯ
ДАННОЕ УКОВОДСТВО СОДЕ ЖИТ ВАЖНЫЕ
УКАЗАНИЯ ПО МЕ АМ БЕЗОПАСНОСТИ
ОПАСНО
В данном ИБП имеются СМЕРТЕЛЬНО ОПАСНЫЕ НАПРЯЖЕНИЯ. Все
работ по ремонту и обслуживанию должн в полняться ТОЛЬКО
УПОЛНОМОЧЕННЫМ ОБСЛУЖИВАЮЩИМ ПЕРСОНАЛОМ. Внутри
ИБП нет узлов, ОБСЛУЖИВАЕМЫХ ПОЛЬЗОВАТЕЛЕМ.
П ЕДУП ЕЖДЕНИЕ
SДанн й ИБП содержит собственн е источники энергии
(аккумулятор ). На в ходн х розетках может иметься напряжение,
даже когда ИБП не подключен к сети переменного тока.
SНе отсоединяйте сетевой шнур и не извлекайте его вилку из розетки
при включенном ИБП. При этом защитное заземление отключается
от ИБП и от оборудования, подключенного к ИПБ.
SДля снижения опасности пожара или поражения электрическим
током устанавливайте ИБП в закр том помещении с
контролируем ми температурой и влажностью, в котором
отсутствуют проводящие загрязняющие вещества. Температура
окружающего воздуха не должна прев шать 40°С. Не эксплуатируйте
устройство около вод или в местах с пов шенной влажностью
(макс. 95%).
ОСТО ОЖНО
SАккумулятор могут в звать опасность поражения электрическим
током или ожога от тока короткого зам кания. Соблюдайте
соответствующие мер предосторожности.
SНеобходимо соблюдать правила утилизации аккумуляторов.
Обратитесь к местн м нормативн м актам за информацией о
требованиях к утилизации.
SНикогда не бросайте аккумулятор в огонь. Аккумулятор могут
взорваться под воздействием огня.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
13
Advertencias de Seguridad
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
GUARDE ESTAS INSTRUCCIONES
ESTE MANUAL CONTIENE INSTRUCCIONES DE SEGURIDAD
IMPORTANTES
PELIGRO
Este SIE contiene VOLTAJES MORTALES. Todas las reparaciones y el servicio técnico deben
ser efectuados SOLAMENTE POR PERSONAL DE SERVICIO TÉCNICO AUTORIZADO. No hay
NINGUNA PARTE QUE EL USUARIO PUEDA REPARAR dentro del SIE.
ADVERTENCIA
SEste SIE contiene su propia fuente de energía (las baterías). Los receptáculos de salida
pueden transmitir corriente eléctrica aun cuando el SIE no esté conectado a un
suministro de corriente alterna (c.a.).
SNo retire o desenchufe el cable de entrada mientras el SIE se encuentre encendido. Esto
suprime la descarga a tierra de seguridad del SIE y de los equipos conectados al SIE.
SPara reducir el riesgo de incendio o de choque eléctrico, instale este SIE en un lugar
cubierto, con temperatura y humedad controladas, libre de contaminantes conductores.
La temperatura ambiente no debe exceder los 40°C. No trabaje cerca del agua o con
humedad excesiva (95% máximo).
SPara los sistemas UPS con salidas cableadas permanentamente, la protección contra
exceso de corriente para el/los circuito(s) de CA de salida será suministrada por terceros.
SPara los sistemas UPS con salidas cableadas permanentemente, los interruptores de
desconexión debidamente clasificados para el/los circuito(s) de CA de salida serán
suministrados por terceros.
PRECAUCIÓN
SLas baterías pueden presentar un riesgo de descargas eléctricas o de quemaduras
debido a la alta corriente de cortocircuito. Preste atención a las instrucciones
correspondientes.
SEs necesario desechar las baterías de un modo adecuado. Consulte las normas locales
para conocer los requisitos pertinentes.
SNunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a
la llama.

SAFETY WARNINGS
EATON Powerware®9125 Two-in-One UPS (5000/6000 VA) User’s Guide S164201513 Rev B
www.powerware.com
14
Säkerhetsföreskrifter
VIKTIGA SÄKERHETSFÖRESKRIFTER
SPARA DESSA FÖRESKRIFTER
DENNA BRUKSANVISNING INNEHÅLLER VIKTIGA
SÄKERHETSFÖRESKRIFTER
FARA
Denna UPS-enhet innehåller LIVSFARLIG SPÄNNING. ENDAST AUKTORISERAD
SERVICEPERSONAL får utföra reparationer eller service. Det finns inga delar som
ANVÄNDAREN KAN UTFÖRA SERVICE PÅ inuti UPS-enheten.
VARNING
SDenna UPS-enhet har en egen energikälla (batterier). De utgående kontakterna kan vara
strömförande när UPS-enheten inte är ansluten till en växelströmkälla.
STa aldrig bort nätsladden när UPS-enheten är påslagen. Detta tar bort skyddsjordningen
från både UPS-enheten och den anslutna utrustningen.
SMinska risken för brand eller elektriska stötar genom att installera denna UPS-enhet
inomhus, där temperatur och luftfuktighet är kontrollerade och där inga ledande
föroreningar förekommer. Omgivande temperatur får ej överstiga 40°C. Använd inte
utrustningen nära vatten eller vid hög luftfuktighet (max 95 %).
SÖverströmsskydd för de utgående växelströmskretsarna ska tillhandahållas av andra för
UPS-system med fasta utgångar.
SBortkopplingsswitchar med passande dimensionering för de utgående
växelströmskretsarna ska tillhandahållas av andra för UPS-system med fasta utgångar.
VIKTIGT
SBatterierna kan ge elektriska stötar eller brännskador från hög kortslutningsström. Följ
tillämpliga anvisningar.
SBatterierna måste avyttras enligt anvisningarna i lokal lagstiftning.
SAnvända batterier får aldrig brännas upp. De kan explodera.
