Chapter 1 Introduction
A Tie Cabinet can be installed as a wall-mounted bypass or to provide support for a
parallel system for redundancy or extra capacity.
A wall-mounted bypass switch is used to bypass the UPS during maintenance or
servicing, providing wrap-around bypass for UPS service without shutting down the
load.
A parallel (load sharing) system provides more capacity than a single UPS and can
provide backup, depending on the load and configuration. In addition, when one UPS
is taken out of service for maintenance or is not operating properly, a redundant UPS
continues to supply uninterrupted power to the critical load. A parallel Powerware Hot
Sync®CAN Bridge Card provides connectivity for system metering and operational
mode control. The parallel system consists of two to four UPSs, each with a parallel
CAN Bridge Card and a parallel cabinet.
Figure 1 shows the Eaton 9355 UPS.
Figure 1. The Eaton 9355 UPS

INTRODUCTION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
2

Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 3
Chapter 2 Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation and maintenance of
the UPS and batteries. Please read all instructions before operating the equipment and save this manual for
future reference.
DANGER
This UPS contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED
SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the UPS.
WARNING
SThis UPS contains its own energy source (batteries). The UPS output may carry live voltage even when
the UPS is not connected to an AC supply.
STo reduce the risk of fire or electric shock, install this UPS in a temperature and humidity controlled,
indoor environment, free of conductive contaminants. Ambient temperature must not exceed 40°C
(104°F). Do not operate near water or excessive humidity (95% maximum).
STo reduce the risk of fire, connect only to a circuit provided with 125 amperes maximum branch circuit
overcurrent protection in accordance with the National Electrical Code, ANSI/NFPA 70.
SOutput overcurrent protection and disconnect switch must be provided by others.
CAUTION
SBatteries can present a risk of electrical shock or burn from high short circuit current. Observe proper
precautions. Servicing should be performed by qualified service personnel knowledgeable of batteries
and required precautions. Keep unauthorized personnel away from batteries.
SProper disposal of batteries is required. Refer to your local codes for disposal requirements.
SNever dispose of batteries in a fire. Batteries may explode when exposed to flame.

SAFETY WARNINGS
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
4
Consignes de Sécurité
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVER CES INSTRUCTIONS
Ce manuel comporte des instructions importantes que vous êtes invité à suivre lors de toute procédure
d'installation et de maintenance des batteries et de l'onduleur. Veuillez consulter entièrement ces
instructions avant de faire fonctionner l'équipement et conserver ce manuel afin de pouvoir vous y reporter
ultérieurement.
DANGER!
Cet onduleur contient des TENSIONS MORTELLES. Toute opération d'entretien et de réparation doit être
EXCLUSIVEMENT CONFIÉE A UN PERSONNEL QUALIFIÉ AGRÉÉ. AUCUNE PIÈCE RÉPARABLE PAR
L'UTILISATEUR ne se trouve dans l'onduleur.
AVERTISSEMENT!
SCette onduleur possède sa propre source d'alimentation (batteries). Il est possible que la sortie de
l'onduleur soit sous tension même lorsque l'onduleur n'est pas connectée à une alimentation CA.
SPour réduire les risques d'incendie et de décharge électrique, installer l'onduleur uniquement à
l'intérieur, dans un lieu dépourvu de matériaux conducteurs, où la température et l'humidité ambiantes
sont contrôlées. La température ambiante ne doit pas dépasser 40 °C. Ne pas utiliser à proximité d'eau
ou dans une atmosphère excessivement humide (95 % maximum).
SAfin de réduire les risques d'incendie, n'effectuez le raccordement qu'avec un circuit muni d'une
protection de surintensité du circuit de dérivation maximum de 125 ampères conformément au Code
Électrique National (National Electrical Code) des États-Unis ANSI/NFPA 70.
SLa protection de surintensité de sortie ainsi que le sectionneur doivent être fournis par des tiers.
ATTENTION!
SLes batteries peuvent présenter un risque de choc électrique ou de brûlure provenant d'un courant de
court-circuit haute intensité. Observez les précautions appropriées. L'entretien doit être réalisé par du
personnel qualifié connaissant bien les batteries et les précautions nécessaires. N'autorisez aucun
personnel non qualifié à manipuler les batteries.
SUne mise au rebut réglementaire des batteries est obligatoire. Consulter les règlements en vigueur dans
votre localité.
SNe jamais jeter les batteries au feu. L'exposition aux flammes risque de les faire exploser.

SAFETY WARNINGS
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 5
Advertencias de Seguridad
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
GUARDE ESTAS INSTRUCCIONES
Este manual contiene instrucciones importantes que debe seguir durante la instalación y el mantenimiento
del SIE y de las baterías. Por favor, lea todas las instrucciones antes de poner en funcionamiento el equipo y
guarde este manual para referencia en el futuro.
PELIGRO
Este SIE contiene VOLTAJES MORTALES. Todas las reparaciones y el servicio técnico deben ser efectuados
SOLAMENTE POR PERSONAL DE SERVICIO TÉCNICO AUTORIZADO. No hay NINGUNA PARTE QUE EL
USUARIO PUEDA REPARAR dentro del SIE.
ADVERTENCIA
SEste SIE contiene su propia fuente de energía (baterías). La salida del SIE puede transportar voltaje
activo aun cuando el SIE no esté conectado con una fuente de CA.
SPara reducir el riesgo de incendio o de choque eléctrico, instale este SIE en un lugar cubierto, con
temperatura y humedad controladas, libre de contaminantes conductores. La temperatura ambiente no
debe exceder los 40°C. No trabaje cerca del agua o con humedad excesiva (95% máximo).
SPara reducir el riesgo de incendio, realice la conexión únicamente hacia un circuito que cuente con un
máximo de 125 amperios de protección contra sobrecorriente de circuito derivado, de acuerdo con el
Código Eléctrico Nacional, ANSI/NFPA 70.
SLa protección contra sobrecorriente de salida y el conmutador de desconexión debe suministrarse por
parte de terceros.
PRECAUCIÓN
SLas baterías pueden constituir un riesgo de descarga eléctrica o quemaduras por corriente alta de corto
circuito. Adopte las precauciones debidas. Personal calificado de servicio que conozca de baterías y esté
al tanto de las precauciones requeridas debe darle servicio al equipo. Mantenga al personal no
autorizado alejado de las baterías.
SEs necesario desechar las baterías de un modo adecuado. Consulte las normas locales para conocer los
requisitos pertinentes.
SNunca deseche las baterías en el fuego. Las baterías pueden explotar si se las expone a la llama.

SAFETY WARNINGS
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
6

Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 7
Chapter 3 Tie Cabinet Installation
The Eaton 9355 has the following power connections:
S3‐phase (L1, L2, and L3), neutral, and ground connection for rectifier/bypass input
S3‐phase (L1, L2, and L3), neutral, and ground connection for load output
The nominal input/output voltages are:
S120/208 or 127/220 Vac
Output overcurrent protection and disconnect switch must be provided by others.
Figure 9 and Figure 11 beginning on page 15 show the oneline diagrams.
WARNING
Only qualified service personnel (such as a licensed electrician) should perform the UPS installation and
initial startup. Risk of electrical shock.
To hardwire the Tie Cabinet:
1. Verify that the electrical connections to the installation site have been properly
installed.
2. A wall-mounted, user‐supplied, readily‐accessible disconnection device must be
incorporated in the input wiring.
Compare the circuit breaker ratings to the ones in Table 1 on page 11.
NOTE To accommodate the feature of easy system expandability, it is recommended that initial installation
of the Eaton 9355 UPS contain wiring to support the maximum capacity of the UPS cabinet.
3. Switch off utility power to the distribution point where the Tie Cabinet and UPSs
will be connected. Be absolutely sure there is no power.
4. Determine your equipment's grounding requirements according to your local
electrical code.

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
8
5. Remove the Tie Cabinet front cover (see Figure 2).
Figure 2. Tie Cabinet Front Cover
6. Remove the internal covers to gain access to the breakers (see Figure 3).
Figure 3. Internal Covers

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 9
7. Punch holes for the conduit (AC input, UPS output, load connection, and
maintenance bypass contact wires) using a Greenlee®punch or similar device.
8. Verify that the Tie Cabinet bypass breaker is in the OFF position (see Figure 4).
Figure 4. Tie Cabinet Bypass Breaker
9. Mount the Tie Cabinet to the wall and install the conduit.

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
10
10. From each UPS, remove the UPS front door.
11. Verify that the UPS input circuit breaker is in the OFF position.
12. Verify that each UPS battery circuit breaker is in the OFF position (see Figure 5).
13. If you ordered the UPS with the optional output circuit breaker, verify that the
output circuit breaker is in the OFF position.
14. Remove the UPS wiring access cover and retain.
Battery Circuit
Breaker
Wiring Access
Cover
Input Circuit
Breaker
Output Circuit
Breaker (optional)
Figure 5. UPS Front View
15. Remove the UPS conduit landing box from the rear panel and retain.
16. Punch two holes in the conduit landing box for the input and output conduit using
a Greenlee punch or similar device.
17. Route the wiring from the back of the UPS, through the wiring tray, to the front
of the UPS.

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 11
18. Hardwire the UPS input terminations.
See Table 1 for specifications and Figure 6 for a detailed view of the UPS
terminal block.
NOTE Input neutral must be wired for proper operation or the UPS will not start.
NOTE The Eaton 9355 UPS is shipped as a single-feed UPS and can be converted to a dual-feed UPS in the
field.
NOTE DO NOT overtighten the screws; be sure to use the specified tightening torque values shown in
Table 1.
Table 1. Terminal Block Wiring
20 kVA
System Voltage Wire Function Feeder Circuit Breaker Rating L1, L2, L3, N Wire Size1Ground Wire Size1Tightening Torque Conduit Size2, 3
(Number of Conduits)
208 Input 100A 1 AWG 6 AWG
120 lb in
(13.5 Nm)
2.00”Conduit (1)
220 100A 1 AWG 6 AWG
480 (with transformer) 45A 8 AWG 10 AWG
1.00”Conduit (1)
600 (with transformer) 35A 8 AWG 10 AWG
208 Output 1 AWG 6 AWG
120 lb in
(13.5 Nm) 2.00”Conduit (1)
220 1 AWG 6 AWG
480 (with transformer) 1 AWG 6 AWG
30 kVA
System Voltage Wire Function Feeder Circuit Breaker Rating L1, L2, L3, N Wire Size1Ground Wire Size1Tightening Torque Conduit Size2, 3
(Number of Conduits)
208 Input 125A 1/0 AWG 6 AWG
120 lb in
(13.5 Nm)
2.00”Conduit (1)
220 125A 1/0 AWG 6 AWG 2.00”Conduit (1)
480 (with transformer) 60A 6 AWG 10 AWG 1.00”Conduit (1)
600 (with transformer) 50A 8 AWG 10 AWG 1.00”Conduit (1)
208 Output 1/0 AWG 6 AWG
120 lb in
(13.5 Nm) 2.00”Conduit (1)
220 1/0 AWG 6 AWG
480 (with transformer) 1/0 AWG 6 AWG
1Use only 90°C-rated copper wire. Minimum wire size is based on 120/208 full load ratings applied to NEC Code Table 310‐104(A). Code may require a
larger AWG size than shown in this table because of temperature, number of conductors in the conduit, or long service runs. Follow local requirements.
2Per NEC article 300‐20(a) for Ferrous Metal Raceways, all three-phase conductors must be run in the same conduit. Neutral and ground must be run in
the same conduit as the phase conductors.
3Conduit is sized to accommodate one neutral conductor the same size as the phase conductor and one ground conductor. If two neutral conductors or
an oversized neutral conductor are to be installed, check the size of the conduit needed to accommodate the extra wire or size and use that conduit size
in place of the conduit size listed. Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW‐2, TW, THW, THHW, THW‐2.

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
12
Jumpers
(remove three
wires for
dual-feed)
Input Terminal
Block
L1, L2, L3, N, N
Output Terminal
Block
L1, L2, L3, N, N
Remote DC
(battery)
DC +, DC –
Maintenance
Bypass Auxiliary
Contacts (TB4)
Ground
TB4
Figure 6. UPS Terminal Block
NOTE The two input neutral terminals are jumpered together; use either one of these terminals to make
the input neutral connection.
NOTE The two output neutral terminals are jumpered together; use either one of these terminals to make
the output neutral connection.

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality 13
19. Hardwire the output terminations from the UPS to the Tie Cabinet (see Figure 7).
20. Repeat Steps 11 through 19 for each UPS.
Neutral
Ground
Line 1
Line 2
Line 3
Figure 7. UPS Output to Tie Cabinet Wiring

TIE CABINET INSTALLATION
Eaton 9355 Tie Cabinet (20/30 kVA) Installation Guide S164201630 Rev D www.eaton.com/powerquality
14
21. Hardwire the load to the Tie Cabinet (see Figure 8).
Neutral
Line 1
Ground
Line 2
Line 3
Maintenance Bypass
Wiring to UPS TB4
Figure 8. Load Connections
