EAW KF730 Reference guide

Loud Technologies, Inc.
CE DECLARATION OF CONFORMITY
Manufacturer’s Name:
Location of Declarations:
EAW (Eastern Acoustic Works)
Loud Technologies, Inc. 16220 Wood-Red Rd. 98072 Tel: [phone]
Manufacturer Address(s):
Eastern Acoustic Works
1 Main St.
Whitinsville, MA 01588
Tel: [phone] or 800.992.5013
Fax: [phone] or 800.322.8251
Declares that the following product(s)
Product
(Produit, Erzeugnis): Commercial Audio – Speakers and Rigging Systems
Model Numbers
(Marque Commercial,
Warenbezeichnung):
KF730, SB730 and Flybar Rigging
Conforms to the following international standards and Directives:
Radiated and
Conducted Emissions
and Immunity:
EN 55103-1:1990
CISPR 22:1997 : Electromagnetic Compatibility Product Family Standard for Audio,
Video, Audio-Visual and Entertainment Lighting Control Apparatus for Professional
Use: Emissions.
Council Directives 73/23/EEC (Low Voltage Directive)
98/37/EEC (Lifting Accessories)
89/336/EEC (EMC Directive) All applicable amendments
89/37/CE (Machinery Directive – Part 4)
FEM 1.001 (EU Rules for the Design of Hoisting Appliances)
BGV-C1 (German Standard for Audio Rigging)
DIN 56950 (German Machinery Installation – Safety)
Safety: IEC 60065 – Professional Audio With All Country Deviations
Signature: Place: Woodinville, WA. USA
Full Name: Kevin Cyrus Date: 9 November 2006
Position: Director of Compliance Engineering

CE DECLARATION OF CONFORMITY
PRODUCT
Product Model: KF730 p/n 0006108
Description: Loudspeaker
Dimensions (h x w x d): 330 mm x 724 mm x 446 mm / 13.0 in x 28.5 in x 17.54 in
Material: 19 ply-per inch Baltic birch plywood
Integral aluminum rigging fittings
Supplied Accessories: 6x Connecting Pin p/n 0006122
OR Button Head Connecting Pin p/n 0020558
Accessories: KF730/SB730 Fly-Bar p/n 0006265
Spare Connecting Pin p/n 0006122
KF730 Caster Pallet p/n 0006385
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The KF730 loudspeaker is to be suspended below or stacked on top of the KF730 Fly-Bar.
When used in accordance with the KF730 Owner’s Manual the Working Load Limits (WLL) and Design
Factor are:
Nominal Weight 34.9 kg / 77 lb
WLL (for enclosure corner rigging points) 680.4 kg / 1500 lb
Ultimate Strength Design Factor >10:1
STANDARDS CONFORMITY
The KF730 loudspeakers are designed and intended to be suspended only from the KF730 Fly-Bar in
accordance with the KF730 / SB730 Loudspeaker Owner’s Manual.
Up to eighteen (18) KF730 loudspeakers may be vertically suspended in a column below the KF730 Fly-Bar.
The maximum recommended quantity of stacked KF730s is six (6).
Combinations of KF730s and SB730s may be flown in the same array. Because KF730s and SB730s have
different weights, the total weight of any combination must not exceed the WLL of the integral rigging
components or that of the KF730 Fly-Bar. For combinations of KF730 and SB730, use these formulas to
determine maximum quantities of each. In all cases, round the answer DOWN to the nearest integer. This
keeps the total weight of the KF730/SB730 combination within the above-specified WLL.
Maximum total quantities for suspended configurations using a combination of KF730 and SB730
loudspeakers are:
Product Maximum Total Combination
KF730 Maximum quantity KF730 = 18 - (quantity SB730 x 1.5)
SB730 Max quantity SB730 = 12- (quantity KF730/1.5)
The maximum recommended quantity for a stacked combination of KF730/SB730 is six (6) KF730 over four
(4) SB730.
The ultimate strength for the KF730 integral rigging points was determined utilizing calibrated and certified
destructive pull-tests.
Page 1 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

Eastern Acoustic Works, as the manufacturer, hereby certifies that, in their delivered versions,
The KF730 complies with the provisions of the directives and standards listed below.
European Council Directive on Lifting Accessories, 98/37/EEC
European Council Directive on Low Voltage, 73/23/EEC
EN 60065:2002 Audio, video, and similar electronic apparatus - safety requirements
European Council Directive on Electromagnetic Compatibility 89/336/EEC and 93/68/EEC
EN 55103-1:1997 Electromagnetic compatibility. Product family standard for audio, video, audio-visual, and
entertainment lighting control apparatus for professional use - Emission
EN 55103-2:1997 Electromagnetic compatibility. Product family standard for audio, video, audio-visual, and
entertainment lighting control apparatus for professional use - Immunity
BGV-C1: (German Standard for Lifting Accessories and Audio Rigging)
DIN 56950 (German Machinery Installation – Safety)
Harmonized Standards:
EN55103-1 emissions
EN55022 Radiated and Conducted Emissions
EN55103-2 immunity
EN60065 safety
The Technical Report/File is maintained at:
LOUD Technologies Inc. Worldwide Headquarters
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
Tel: [phone]
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Authorized Representative:
Kevin Cyrus
Director of Compliance
LOUD Technologies Inc.
Issued: November, 2006
Page 2 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

CE DECLARATION OF CONFORMITY
PRODUCT
Product Models: SB730 p/n 0006108
Description: Loudspeaker
Dimensions (h x w x d): 482 mm x 724 mm x 724 mm / 19.0 in x 28.5 in x 28.5 in
Material: 19 ply-per inch Baltic birch plywood
Integral aluminum rigging fittings
Supplied Accessories: 4x Connecting Pin p/n 0006122
OR Button Head Connecting Pin p/n 0020558
Accessories: KF730/SB730 Fly-Bar p/n 0006265
Spare Connecting Pin p/n 0006122
SB730 Caster Pallet p/n 0006386
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The SB730 loudspeaker is to be suspended below or stacked on top of the KF730 Fly-Bar.
When used in accordance with the KF730 / SB730 Owner’s Manual the Working Load Limits (WLL) and
Design Factor are:
Nominal Weight 50.3 kg / 111 lb
WLL (rigging points at corners) 680.4 kg / 1500 lb
Design Factor 10:1
STANDARDS CONFORMITY
The SB730 loudspeakers are designed and intended to be suspended only from the KF730 Fly-Bar in
accordance with the KF730 / SB730 Loudspeaker Owner’s Manual.
Up to twelve (12) SB730 loudspeakers may be vertically suspended in a column below the KF730 Fly-Bar.
The maximum recommended quantity of stacked SB730s is four (4)
Combinations of KF730s and SB730s may be flown in the same array. Because KF730s and SB730s have
different weights, the total weight of any combination must not exceed the WLL of the integral rigging
components or that of the KF730 Fly-Bar. For combinations of KF730 and SB730, use these formulas to
determine maximum quantities of each. In all cases, round the answer DOWN to the nearest integer. This
keeps the total weight of the KF730/SB730 combination within the above-specified WLL.
Maximum total quantities for suspended configurations using a combination of KF730 and SB730
loudspeakers are:
Product Maximum Total Combination
KF730 Maximum quantity KF730 = 18 - (quantity SB730 x 1.5)
SB730 Max quantity SB730 = 12 - (quantity KF730/1.5)
The maximum recommended quantity for a stacked combination of KF730/SB730 is six (6) KF730 over four
(4) SB730.
The ultimate strength for the SB730 integral rigging points was determined utilizing calibrated and certified
destructive pull-tests.
Page 3 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

Eastern Acoustic Works, as the manufacturer, hereby certifies that, in their delivered versions,
The SB730 complies with the provisions of the directives and standards listed below..
European Council Directive on Lifting Accessories, 98/37/EEC
European Council Directive on Low Voltage, 73/23/EEC
EN 60065:2002 Audio, video, and similar electronic apparatus - safety requirements
European Council Directive on Electromagnetic Compatibility 89/336/EEC and 93/68/EEC
EN 55103-1:1997 Electromagnetic compatibility. Product family standard for audio, video, audio-visual, and
entertainment lighting control apparatus for professional use - Emission
EN 55103-2:1997 Electromagnetic compatibility. Product family standard for audio, video, audio-visual, and
entertainment lighting control apparatus for professional use – Immunity
BGV-C1: (German Standard for Lifting Accessories and Audio Rigging)
DIN 56950 (German Machinery Installation – Safety)
Harmonized Standards:
EN55103-1 emissions
EN55022 Radiated and Conducted Emissions
EN55103-2 immunity
EN60065 safety
The Technical Report/File is maintained at:
LOUD Technologies Inc. Worldwide Headquarters
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
Tel: [phone]
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Authorized Representative:
Kevin Cyrus
Director of Compliance
LOUD Technologies Inc.
Issued: November, 2006
Page 4 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

CE DECLARATION OF CONFORMITY
PRODUCT
Product Models: KF730/SB730 Fly-Bar p/n 0006265
Description: Rigging frame structure
Dimensions (h x w x d): 152 mm x 622 mm x 724 mm / 6.0 in x 24.5 in x 28.5 in
Material: Aluminum
Supplied Accessories: 4x Connecting Pin p/n 0006122
OR Button Head Connecting Pin p/n 0020558
4x Leveling Mount p/n 0006202
Accessories: Spare Connecting Pin p/n 0006122
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The KF730 Fly-Bar is for suspending KF730 and/or SB730 loudspeakers below and for stacking KF730
and/or SB730 loudspeakers on top.
When used in accordance with the KF730 / SB730 Owner’s Manual the Working Load Limits (WLL) and
Design Factor are:
Nominal Weight 20.4 kg / 45 lb
WLL 680.4 kg / 1500 lb
Design Factor >10:1 (two pick points)
>7:1 (one pick point)
STANDARDS CONFORMITY
The KF730 Fly-Bar is designed and intended for suspending and stacking KF730 and SB730 loudspeakers
in accordance with the KF730 / SB730 Loudspeaker Owner’s Manual.
Up to eighteen (18) KF730 loudspeakers may be vertically suspended in a column below the KF730 Fly-Bar.
Up to twelve (12) SB730 loudspeakers may be suspended in a column below the KF730 Fly-Bar.
Combinations of KF730s and SB730s may be flown in the same array. Because KF730s and SB730s have
different weights, the total weight of any combination must not exceed the WLL of the integral rigging
components or that of the KF730 Fly-Bar. For combinations of KF730 and SB730, use these formulas to
determine maximum quantities of each. In all cases, round the answer DOWN to the nearest integer. This
keeps the total weight of the KF730/SB730 combination within the above-specified WLL.
Maximum total quantities for suspended configurations using a combination of KF730 and SB730
loudspeakers are:
Product Maximum Total Combination
KF730 Maximum quantity KF730 = 18 - (quantity SB730 x 1.5)
SB730 Max quantity SB730 = 12 - (quantity KF730/1.5)
The maximum recommended quantity for a stacked combination of KF730/SB730 is six (6) KF730 over four
(4) SB730.
The ultimate strengths for the KF730 Fly-Bar and its integral rigging points and were determined utilizing
calibrated and certified destructive pull-tests.
Page 5 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

Eastern Acoustic Works, as the manufacturer, hereby certifies that, in their delivered versions,
The KF730 Fly-Bar complies with the provisions of the directives and standards listed below.
European Council Directive on Lifting Accessories, 98/37/EEC
EN 60065:2002 Audio, video, and similar electronic apparatus - safety requirements
BGV-C1: (German Standard for Lifting Accessories and Audio Rigging)
DIN 56950 (German Machinery Installation – Safety)
Harmonized Standards:
EN60065 safety
The Technical Report/File is maintained at:
LOUD Technologies Inc. Worldwide Headquarters
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
Tel: [phone]
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Authorized Representative:
Kevin Cyrus
Director of Compliance
LOUD Technologies Inc.
Issued: November, 2006
Page 6 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com

CE DECLARATION OF CONFORMITY
PRODUCT
Product Models: Connecting Pin KF730/SB730 p/n 0006122
Button Head Connecting Pin p/n 0020558
Description: Double action quick release pin accessory for KF730, SB730, KF730/SB730 Fly-Bar
Nominal length: 38 mm / 1.5 in
Material (Handle): Aluminum
(Shaft): Alloy steel
Accessories: n/a
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The Connecting Pins are for fastening KF730s and/or SB730s to each other and to the KF730 Fly-Bar for
suspension and stacking.
When used in accordance with the KF730 / SB730 Owner’s Manual the Ultimate strength is:
Ultimate Strength (double shear) 9344 kg / 20 600 lb
WLL 1600 lb
Design Factor >12:1
STANDARDS CONFORMITY
The Connecting Pins are designed and intended for fastening together suspended and stacked KF730 and
SB730 loudspeakers in accordance with the KF730 / SB730 Loudspeaker Owner’s Manual.
The ultimate strength is as certified by the original equipment manufacturer.
Eastern Acoustic Works, as the manufacturer, hereby certifies that, in their delivered versions, the
Connecting Pin complies with the provisions of the directives and standards listed below.
European Council Directive on Lifting Accessories, 98/37/EEC
EN 60065:2002 Audio, video, and similar electronic apparatus - safety requirements
Harmonized Standards:
EN60065 safety
The Technical Report/File is maintained at:
LOUD Technologies Inc. Worldwide Headquarters
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
Tel: [phone]
Tel: [phone]
Fax: [phone]
e-mail: [email protected]
Authorized Representative:
Kevin Cyrus - Director of Compliance
LOUD Technologies Inc. Issued:November, 2005
Page 7 of 7 November 2006
Eastern Acoustic Works Tel: [phone]
One Main Street e-mail: [e-mail]
Whitinsville, Ma 01588 www.eaw.com
