Echelon i.LON SmartServer 2.0 User manual

078-0348-01E
®
i.LON SmartServer 2.0
Power Line Repeating Guide

ii Preface
Echelon, i.LON, LON, LONWORKS, LonTalk, Neuron, LONMARK,
3120, 3150, LNS, LonMaker, and the Echelon logo are
trademarks of Echelon Corporation registered in the United
States and other countries. LonPoint and LonSupport are
trademarks of Echelon Corporation.
Other brand and product names are trademarks or
registered trademarks of their respective holders.
Neuron Chips, LonPoint Modules, and other OEM Products
were not designed for use in equipment or systems which
involve danger to human health or safety or a risk of property
damage and Echelon assumes no responsibility or liability for
use of the Neuron Chips or LonPoint Modules in such
applications.
Parts manufactured by vendors other than Echelon and
referenced in this document have been described for
illustrative purposes only, and may not have been tested by
Echelon. It is the responsibility of the customer to determine
the suitability of these parts for each application.
ECHELONMAKES NO REPRESENTATION, WARRANTY, OR
CONDITION OF ANY KIND, EXPRESS, IMPLIED, STATUTORY, OR
OTHERWISE OR IN ANY COMMUNICATION WITH YOU,
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF
MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR ANY
PARTICULAR PURPOSE, NONINFRINGEMENT, AND THEIR
EQUIVALENTS.
No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, photocopying, recording, or
otherwise, without the prior written permission of Echelon
Corporation.
Printed in the United States of America.
Copyright ©1997–2008 by Echelon Corporation.
Echelon Corporation
www.echelon.com

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide iii
Table of Contents
Preface .................................................................................................... vi
Welcome.........................................................................................................vii
Purpose ..........................................................................................................vii
Audience.........................................................................................................vii
Models............................................................................................................vii
Network Installation Equipment......................................................................vii
Device Requirements..............................................................................viii
Hardware Requirements.........................................................................viii
Software Requirements ..........................................................................viii
Network Installation Process.........................................................................viii
i.LON SmartServer 2.0 Documentation...........................................................x
Related Reading..............................................................................................x
Content............................................................................................................x
For More Information and Technical Support................................................. xi
Using the SmartServer Help Files............................................................ xi
Viewing the SmartServer 2.0 ReadMe.....................................................xii
Using Technical Support..........................................................................xii
1Preparing a Power Line Repeating Network for Installation......... 1
Preparation Overview......................................................................................2
Loading Street Lighting Helper to the Pocket PC.....................................2
Copying Files to the SmartServer.............................................................5
Copying Application Image Files........................................................6
Copying External Interface Files ........................................................6
Copying Resource Files .....................................................................6
Setting the SmartServer to Standalone Mode..........................................7
Placing a Network in Standalone Mode .............................................7
Network Limitations in Standalone Mode...........................................8
Configuring the LONWORKS Channel for Power Line Repeating ..............8
2Installing a Power Line Repeating Network.................................. 11
Installation Overview .....................................................................................12
Commissioning a Power Line Repeating Network in the Correct
Order.......................................................................................................13
Installing a Three-Phase Power Line Repeating Network......................14
Attaching an External GSM Modem to the SmartServer........................14
Installing a Power Line Repeating Network with a Pocket PC ................................14
Using Street Lighting Helper...................................................................14
Acquiring Device Locations and Neuron IDs....................................15
Configuring Street Lighting Helper Connections..............................16
Configuring Street Lighting Helper Settings.....................................17
Connecting the PC Pocket to the SmartServer ......................................19
Using a Serial Connection................................................................19
Using a LAN Connection..................................................................19
Using iLonProxyPocket...........................................................................20
Starting and Configuring iLonProxyPocket on a Serial
Connection .......................................................................................20
Starting and Configuring iLonProxyPocket on a LAN
Connection .......................................................................................21
Sending Device Data to the SmartServer...............................................22
Installing a Power Line Repeating Network with SmartServer Web
Pages.............................................................................................................24
Creating Devices.....................................................................................24

iv Preface
Entering Device Locations and Neuron IDs............................................26
Automatically Acquiring the Neuron ID.............................................26
Automatically Acquiring the Neuron ID with
Overview - Devices Web Page..................................................26
Automatically Acquiring the Neuron ID with
LON Device Driver Web Page...................................................29
Manually Acquiring the Neuron ID....................................................30
Selecting Devices....................................................................................32
Installing Devices with Smart Network Management..............................32
Enabling Smart Network Management.............................................32
Installing Devices..............................................................................33
Checking Device Installation Status.................................................33
Troubleshooting Power Line Repeating Network Installation.................35
3Maintaining a Power Line Repeating Network.............................. 37
Maintenance Overview..................................................................................38
Analyzing a Power Line Repeating Network...........................................38
Adding Devices.......................................................................................47
Upgrading Devices..................................................................................47
Replacing Devices ..................................................................................51
Replacing Devices with the Pocket PC............................................51
Replacing Devices with the SmartServer.........................................51
Automatically Replacing Devices...............................................51
Manually Replacing Devices......................................................54
Decommissioning Devices......................................................................55
Setting Devices Offline............................................................................56
Testing Devices.......................................................................................57
Querying Devices.............................................................................57
Winking Devices...............................................................................59
Deleting Devices.....................................................................................60
Switching to LNS Mode and Synchronizing to an LNS Database..........60
4Controlling a Street Lighting Network with the Scheduler
Application....................................................................................... 67
Scheduling Overview.....................................................................................68
Configuring the Real-Time Clock............................................................68
Setting the SmartServer Time..........................................................69
Adding an SNTP Time Server....................................................69
Manually Configuring the Time..................................................71
Entering the Location of the SmartServer........................................72
Creating Event Schedulers.....................................................................74
Selecting Data Points..............................................................................77
Creating Daily Schedules........................................................................80
Defining Daily Schedules..................................................................80
Creating Daily Schedule Events.......................................................82
Creating Exception Schedules................................................................84
Creating One-Time Exceptions ........................................................84
Creating Exceptions .........................................................................87
Defining Exception Dates and Recursions ................................87
Creating Exception Events.........................................................91
Demonstrating a Street Lighting Schedule....................................................95
Creating the Weekday Schedule ............................................................95
Creating the Weekday Daily Schedule.............................................96
Creating the Weekday Exception Schedule.....................................97
Creating the Weekend and Holiday Exception Schedules ...................102
Copying Event Schedulers to other SmartServers......................................108

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide v
5Connecting Devices on a Power Line Repeating Network........ 109
Connecting Devices Overview.....................................................................110
Using Type Translators to Connect Devices within a Network.............110
Creating a Type Translator.............................................................110
Selecting Input and Output Points..................................................113
Selecting or Creating a Type Translation.......................................114
Creating a Custom Scalar-Based Translation .........................115
Creating a Custom Rule-Based Translation............................117
Example Type Translator for Street Lighting Network ...................119
Creating Web Connections...................................................................120
Connecting Repeating Devices on the Same Network..................121
Connecting Repeating Devices to Other Networks........................122
Testing Web Connections ..............................................................125
Appendix A Glossary......................................................................... 127

vi Preface
Preface
The i.LON® SmartServer can automatically install and manage a LONWORKS network
running over a PL-20 power line channel. The SmartServer features a standalone
network management mode in which it can install and maintain a LONWORKS
network without LNS network management services. Specifically for PL-20 power
line channels, the SmartServer uses a repeating function called the Enhanced
LonTalk®Proxy Protocol to transmit messages to the devices attached to the power
line, overcoming impediments posed by power line channels such as excessive noise
and long distances between devices. The standalone network management mode and
repeating function make the SmartServer the ideal tool for managing, controlling, and
monitoring street lighting and other power line networks where long distances
separate devices and the use of LNS network management services is not practicable.

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide vii
Welcome
When running on a noisy PL-20 power line channel, the SmartServer can use a repeating function to
transmit network messages to the devices closest to it, which in turn relay the messages to the devices
located further down the power line, and so on until the message reaches the target device. The
repeating function enables the network management commands sent by the SmartServer to reach the
target devices, overcoming impediments posed by power line channels such as excessive noise and
long distances between devices.
Purpose
This document describes how to manage, control, and monitor a power line repeating network using
the SmartServer.
Audience
This guide is intended for system designers and integrators with an understanding of control networks.
Models
The power line repeating guide is intended for models of the SmartServer that operate on PL-20 power
line channels (models 72103R-430, 72103R-439, and 72103R-445). PL-20 models of the SmartServer
may include programming and IP-852 routing features (you can license IP-852 routing for units that do
not have this feature enabled). There is also a PL-20 model of the SmartServer (model 72103R-450)
that includes an external coupling option, which enables the SmartServer to communicate over
virtually any AC or DC power mains, including three-phase systems. The inputs and outputs of each
model are slightly different, as noted in the i.LON SmartServer 2.0 Hardware Guide.
You cannot use earlier versions of the i.LON hardware (v1.0, e2, or e3) to install or manage a power
line repeating network.
Note: The IP-852 routing feature is disabled when managing a PL-20 repeating channel. This is
because IP-852 routing is not supported when the SmartServer is operating in standalone mode, and
standalone mode is required for the SmartServer to manage a PL-20 repeating channel.
Network Installation Equipment
The installation of a power line repeating network entails attaching LONWORKS repeating devices
(Neuron-hosted devices or host-based ShortStack devices) to the power line and sending their Neuron
IDs, and optionally their locations, to the SmartServer using a Pocket PC, the SmartServer Web pages,
or a custom C# application. Upon receiving the device data, the SmartServer discovers the repeating
path for each device, and if you are using a Pocket PC, it commissions the devices, and then loads, re-
commissions, and places the devices online. The process of commissioning, loading,
re-commissioning, and placing the devices online is optional if you are using the SmartServer Web
pages or a custom C# application
The recommended installation method for a power line repeating network entails using a bar code
scanner and a Windows-based Pocket PC with built-in GPS receiver (or a Pocket PC and separate GPS
receiver with Bluetooth connections) to acquire the Neuron IDs and geographic locations (coordinates)
of the devices. After acquiring the Neuron IDs and locations, they are sent from the Pocket PC to the
SmartServer. Once the SmartServer receives the device data, it automatically installs the devices.
Note that you can manually enter the Neuron IDs and locations of the devices using the SmartServer
Web interface; however it may not practicable or efficient to do so. This is especially true if the
installers are not trained on using the SmartServer Web interface, or if the installation is for an outdoor
system such as street lighting, where access to an Ethernet, GPRS, or dial-out connection may not be
readily available or is cost-prohibitive.

viii Preface
Device Requirements
The Neuron-hosted devices and host-based ShortStack devices to be installed on a power line repeating
network must be enabled for repeating. This is because the devices may need to be used to relay
network messages from the SmartServer to devices located further down the power line. To enable
repeating on a device, your device manufacturer must update your devices so that they support the
repeating function. For more information on installing application device repeating on your
Neuron-hosted devices and host-based ShortStack devices, contact your Echelon sales representative.
Hardware Requirements
The hardware and accessories required for the recommended power line repeating network installation
method is as follows:
•Windows-based Pocket PC with internal GPS receiver, and RS-232 serial connection or built-in
Wi-Fi connection.
•GPS receiver with Bluetooth connection (if Pocket PC does not include integrated GPS).
•Wireless bar code scanner with a compatible connection to the Pocket PC.
•Serial sync cable. This cable physically connects the Pocket PC to a RS-232 null modem cable.
This accessory is required to connect the Pocket PC to the SmartServer via an RS-232 serial
connection.
•RS-232 null modem cable. This cable physically connects the serial sync cable attached to the
Pocket PC to the SmartServer console port.
•SmartServer hardware (PL-20 model) loaded with the SmartServer embedded software.
Software Requirements
The Pocket PC requires the following software for collecting device Neuron IDs and coordinates and
transmitting the device data to the SmartServer: Street Lighting Helper, iLONProxyPocket, and
iLONProxy. These files are provided on the i.LON SmartServer 2.0 DVD, and they are downloaded to
the LonWorks\iLon100\LonWorks\iLon100\unsupported\StreetLightingHelper\Bin folder on your
computer when you install the i.LON SmartServer 2.0 software. Each of these programs is described
as follows:
•Street Lighting Helper. This application collects the Neuron IDs acquired with the bar code
scanner, lists the Neuron IDs and corresponding coordinates (if acquired with GPS receiver), and
saves them to XML and CSV (comma separated value) files.
Note: Street Lighting Helper is an unsupported sample application. You can use Street Lighting
Helper as a starting point for creating your own custom application that you can be used to collect
device locations and Neuron IDs. The sample code for Street Lighting Helper is provided on the
i.LON SmartServer 2.0 DVD, and it is downloaded to the
LonWorks\iLon100\unsupported\StreetLightingHelper\Src folder on your computer when you
install the i.LON SmartServer 2.0 software.
•iLONProxyPocket. This application is used to transmit the device file created with the Street
Lighting Helper program to the SmartServer via an RS-232 serial connection.
•iLONProxy. This application serves as proxy for SOAP/HTTP requests between the SmartServer
and the Street Lighting Helper program on the Pocket PC. This program can be used over a
TCP/IP connection (providing debug information) or a serial connection.
Network Installation Process
The following section lists the basic steps required to install a power line repeating network that are
detailed in this guide. These steps assume that a Pocket PC is being used as an installation tool.

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide ix
1. Install the applications on the Pocket PC to be used for collecting device coordinates and Neuron
IDs and transmitting them to the SmartServer that is attached to the power line repeating network.
2. Copy the application image files (.apb extension) and external interface files (.xml or .xif
extensions) provided by the device manufacturer to the lonworks/import folder on the SmartServer
flash disk.
Note: If you are installing devices pre-loaded with the current application image files and external
interface files, skip this step. This ensures that the SmartServer does not overwrite the files
currently on the devices.
3. Switch the SmartServer to standalone mode. To do this, follow these steps:
a. Open the SmartServer Web interface, click Driver, and then click the Net network. The
Setup – LON Network Driver page opens.
b. In the Network Management Service property, click Standalone, and the click Submit.
Note that it may take a few minutes for the SmartServer to switch to standalone mode.
4. Configure the LONWORKS channel attached to the SmartServer for power line repeating. To do
this, follow these steps:
a. Click Driver, expand the network icon, and then click the LON channel. The Setup – LON
Channel Driver Web page opens.
b. In the Channel Type property, select the PL-20C channel, select the Repeating check box,
and then click Submit.
5. Open the application on the Pocket PC that is used to collect device coordinates and Neuron IDs
and transmit them to the SmartServer.
6. Acquire the coordinates of a device with the built-in GPS receiver on the Pocket PC, or a
standalone GPS receiver with Bluetooth connection to the Pocket PC.
7. Acquire the Neuron ID of the device using the bar code scanner.
8. Add the Neuron ID and location of the device to the list of devices to be installed.
9. Repeat steps 6–8 for each device to be installed.
10. If sending device data over a serial connection, connect the Pocket PC to the SmartServer console
port using an RS-232 serial sync and an RS-232 null modem cable.
11. Transmit the Neuron IDs and coordinates of the devices from the Pocket PC to the SmartServer
over the RS-232 console port (via serial sync and RS-232 null modem cables). Alternatively, you
can send the device data over a wireless LAN using the built-in Wi-Fi connection on the Pocket
PC.
12. The SmartServer commissions, loads, re-commissions, and places the devices online upon
receiving the device data.
13. If you have access to the SmartServer Web interface, verify that the devices transmitted to the
SmartServer have been added to the SmartServer tree. To do this, expand the network icon,
expand the LON channel, and then verify that the devices appear below the LON channel.
14. If you have access to the SmartServer Web interface, check device installation status. To do this,
right-click the SmartServer icon, point to Setup, and then click LON Command Queue on the
shortcut menu. Alternatively, you can click Setup and then click LON Command Queue.
See Chapter 1, Preparing a Power Line Repeating Network for Installation, and Chapter 2, Installing a
Power Line Repeating Network, for more information on these steps.

x Preface
i.LON SmartServer 2.0 Documentation
The documentation for the SmartServer is provided as Adobe Acrobat PDF files and online help files.
The PDF file for this document is installed in the Echelon i.LON SmartServer 2.0 Software
program folder when you install the i.LON SmartServer 2.0 software. You can also download the
latest SmartServer documentation, including the latest version of this guide, from Echelon’s Website at
www.echelon.com/support/documentation/manuals/cis.
This user’s guide, the online help files, and the following documents comprise the SmartServer
documentation suite:
•i.LON SmartServer 2.0 User’s Guide. Describes how to configure the SmartServer and use its
applications to manage control networks.
•Echelon Enterprise Services 2.0 User’s Guide. Describes how to use the i.LON AdminServer to
rapidly and automatically deploy and install LONWORKS networks and how to use the LNS Proxy
Web service to manage LNS networks.
•i.LON Vision 2.0 User’s Guide. Describes how to create custom Web pages for monitoring and
controlling LONWORKS networks and other control networks.
•i.LON SmartServer 2.0 Programmer’s Reference. Describes how to configure the SmartServer
using XML files and SOAP calls. This allows you to create your own applications that you can
use to configure the i.LON.
•i.LON SmartServer 2.0 Programming Tools User’s Guide. Describes how to write custom built-in
applications called Freely Programmable Modules (FPMs) and deploy them on the SmartServer.
FPMs let you implement custom functionality and tailor the SmartServer to meet your needs.
•i.LON SmartServer 2.0 Hardware Guide. Describes how to assemble, mount, and wire the
SmartServer hardware.
•i.LON SmartServer 2.0 Quick Start Guide. Contains all the information you will need to connect
the SmartServer hardware, install the i.LON SmartServer 2.0 software, and configure the
SmartServer using the SmartServer configuration Web pages.
•IP-852 Channel User’s Guide. Describes how to configure an IP-852 channel with the Echelon
LONWORKS®/IP Configuration Server. You will need this information if you plan to use the
i.LON as an IP-852 router.
Related Reading
The following additional documents may be useful if you are using certain features of the SmartServer.
You can download these documents from Echelon’s Web site at www.echelon.com/docs.
•NodeBuilder User’s Guide. Describes how to use the NodeBuilder tool to develop and test
applications for Neuron-hosted devices.
Content
This guide includes the following content:
•Preparing a Power Line Repeating Network for Installation. Describes the tasks required for
preparing a PL-20 power line repeating network for installation. Describes how to install the
Street Lighting Helper sample application used to store and transmit device locations and Neuron
IDs to a Pocket PC that is being used as an installation tool. Describes how to upload application
image files (.apb extension), external interface files (XIFs), and resource files to the SmartServer.
Describes how to place the SmartServer in standalone mode, configure the LONWORKS channel
attached to the SmartServer as a PL-20 channel, and enable repeating on the PL-20 channel.

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide xi
•Installing a Power Line Repeating Network. Describes how to acquire the geographic locations
(coordinates) and Neuron IDs of the devices to be attached to the PL-20 channel, including how to
use a bar code scanner and Pocket PC to acquire the device data. Describes how to transmit the
device data to the SmartServer and install the devices, including how to link a Pocket PC to the
SmartServer and use the Pocket PC to upload the device data to the SmartServer and install the
devices. Explains how to troubleshoot the installation of a power line repeating network.
•Maintaining a Power Line Repeating Network. Describes how to analyze and debug the power
line repeating channel using the Power Line Repeating Analysis Web page on the SmartServer.
Explains how to replace, upgrade, test, add, and delete devices with the SmartServer. Describes
how to switch the network to LNS management mode and synchronize the network to an LNS
database so that it can be managed with an LNS application such as the LonMaker tool.
•Controlling a Street Lighting Network with the Scheduler Application. Describes how to use the
Scheduler application on the SmartServer to control the devices on a street lighting network.
Explains how to create exception schedules and how to add events to the schedules so that devices
such as luminaries can be turned on and off based on calculated sunrise and sundown times.
Describes how to duplicate a Scheduler application so that you can create additional
pre-configured Event Schedulers to the SmartServer.
•Connecting Devices on a Power Line Repeating Network. Describes how to use type translators
and Web connections to connect devices on a power line repeating network together and to
devices on other networks.
•Appendix A – Glossary. Provides definitions for key terms associated with a power line repeating
network.
For More Information and Technical Support
If you need help using the SmartServer, you can use the online help files, view the i.LON SmartServer
2.0 ReadMe, or read the i.LON SmartServer 2.0 documentation. If none of these sources, answer your
questions, you can contact technical support if you have purchased support services from Echelon or
an Echelon support partner.
Using the SmartServer Help Files
If you need more information on how to use a particular SmartServer Web page, you can click Help to
open a new window with context-sensitive help for that Web page.
If you need more information on how to use a particular SmartServer Web pages, you can click Help
to open a new window with context-sensitive help for that Web page.

xii Preface
If you need help with a particular dialog in the SmartServer Web interface, you can click the “?” icon
in the upper-right hand corner of the dialog to open a new window with context-sensitive help for that
dialog.
Viewing the SmartServer 2.0 ReadMe
The SmartServer 2.0 ReadMe provides descriptions of known problems, if any, and their workarounds.
To view the SmartServer 2.0 ReadMe, click Start, point to Programs, point to Echelon i.LON
SmartServer 2.0 Software, and then select i.LON SmartServer 2.0 ReadMe First. You can also
find additional information about the i.LON SmartServer 2.0 online at www.echelon.com/ilon.
Using Technical Support
If you have technical questions that are not answered by this document, the SmartServer 2.0 online
help, or the SmartServer 2.0 ReadMe document, you can contact technical support. Free e-mail
support is available or you can purchase phone support from Echelon or an Echelon support partner.
See www.echelon.com/support for more information on Echelon support and training services.

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide xiii
You can also view free online training or enroll in training classes at Echelon or an Echelon training
center to learn more about developing devices. You can find additional information about device
development training at www.echelon.com/training.
You can obtain technical support via phone, fax, or e-mail from your closest Echelon support center.
The contact information is as follows (check www.echelon.com/support for updates to this
information):
Region Languages Supported Contact Information
The Americas English
Japanese Echelon Corporation Attn. Customer Support
550 Meridian Avenue
San Jose, CA 95126
Phone (toll-free):
1.800-258-4LON (258-4566)
Phone: [phone]
Fax: [phone]
[e-mail]
Europe English
German
French
Italian
Echelon Europe Ltd.
Suite 12
Building 6
Croxley Green Business Park
Hatters Lane
Watford
Hertfordshire WD18 8YH
United Kingdom
Phone: [phone]
Fax: [phone]
[e-mail]
Japan Japanese Echelon Japan
Holland Hills Mori Tower, 18F
5-11.2 Toranomon, Minato-ku
Tokyo 105-0001
Japan
Phone: [phone]
Fax: [phone]
[e-mail]
China Chinese
English Echelon Greater China Rm. 1007-1008, IBM Tower
Pacific Century Place
2A Gong Ti Bei Lu
Chaoyang District
Beijing 100027, China
Phone: [phone]
Fax: [phone]
[e-mail]
Other Regions English
Japanese Phone: [phone] Fax: [phone]
[e-mail]

xiv Preface

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide 1
1
Preparing a Power Line Repeating
Network for Installation
This chapter describes the tasks required for preparing a PL-20 power line repeating
network for installation. It describes how to download the Street Lighting Helper
sample application used to store and transmit device locations and Neuron IDs to a
Pocket PC that is being used as an installation tool. It describes how to upload
application image files, external interface files (XIFs), and resource files to the
SmartServer. It explains how to place the SmartServer in standalone mode, configure
the LonWorks channel attached to the SmartServer as a PL-20C channel, and enable
repeating on the PL-20C channel.

2 Preparing a Power Line Repeating Network for Installation
Preparation Overview
Before a PL-20 power line repeating network can be installed, you need to perform a few tasks to
prepare your Pocket PC (if you are using one to install the power line repeating network) and the
SmartServer to be attached to the network for the installation.
If you are using a Pocket PC as an installation tool, you need to install the Street Lighting Helper
application (or your own custom Street Lighting Helper application) and the iLONPocketProxy
application to your Pocket PC.
You need to upload to the SmartServer flash disk the application image files (.apb extensions) of the
devices to be attached to the network, the external interface files (XIFs) of the devices, and resource
files.
Using the SmartServer Web pages, you need to place the SmartServer in standalone mode and
configure the LONWORKS channel attached to the SmartServer for power line repeating. In standalone
mode, the SmartServer serves as a network manager that can directly load, commission, set
online/offline, wink, test, and reset the devices attached to its channel without sending any network
management commands through LNS. The SmartServer needs to be in standalone mode in order to
establish and maintain the appropriate repeating chain on the PL-20 channel.
This chapter details the following tasks required for preparing a power line repeating network for
installation:
1. Loading StreetLighting applications on your Pocket PC (if you are using a Pocket PC as an
installation tool).
2. Copying device application image files, XIFs, and resource files to the SmartServer.
3. Setting the SmartServer in standalone mode.
4. Configuring the LONWORKS channel attached to the SmartServer for power line repeating.
Loading Street Lighting Helper to the Pocket PC
If you are using a Pocket PC as an installation tool for collecting device Neuron IDs and coordinates
and transmitting this data to the SmartServer, you need to install the Street Lighting Helper file on the
Pocket PC. The Street Lighting Helper file contains the following two applications:
•Street Lighting Helper. This application collects the Neuron IDs acquired with the bar code
scanner, lists the Neuron IDs and corresponding coordinates (if acquired with GPS receiver), and
saves them to XML and CSV (comma separated value) files.
•iLONProxyPocket. This application is used to transmit the device file created with the Street
Lighting Helper program to the SmartServer via an RS-232 or Bluetooth serial connection.
To install the Street Lighting Helper on the Pocket PC, follow these steps:
1. Install the i.LON SmartServer 2.0 software from the i.LON SmartServer 2.0 DVD following the
steps described in Chapter 2 of the i.LON SmartServer 2.0 User’s Guide.
2. Download the .NET Compact Framework 2 Service Pack 2 to your Pocket PC. This service pack
is required to run the Street Lighting Helper program. To download the service pack, go to
www.microsoft.com/downloads/details.aspx?familyid=AEA55F2F-07B5-4A8C-8A44-
B4E1B196D5C0&displaylang=en.
3. Download Microsoft ActiveSync to your computer. You can use this program to copy the Street
Lighting Helper file from your computer to your Pocket PC. To download the latest version of
ActiveSync, go to www.microsoft.com/windowsmobile/activesync/default.mspx.
4. Start Microsoft ActiveSync. To do this, click Start on the taskbar, point to Programs, and click
Microsoft ActiveSync.

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide 3
5. Connect the Pocket PC to your computer via a USB or serial connection.
6. Set up a sync partnership between your computer and the Pocket PC. Your computer is now
connected to the Pocket PC and you can begin copying files.
7. Download or copy the Street Lighting Helper file to your Pocket PC. To copy the file, skip to step
8. To download the file, follow these steps:
a. On your computer, browse to the C:\LonWorks\iLon100\unsupported\iLonProxy\Install
folder and then double-click the setup.exe file. The Echelon Street Lighting Helper wizard
opens.
b. Click Next. The Select Installation Folder window appears.
c. The Street Lighting Helper application will be installed in the C:\Program Files\Echelon\
Echelon Street Lighting Helper folder by default. You can click Browse to select a different
destination folder. Click Next. The Confirm Installation window opens.

4 Preparing a Power Line Repeating Network for Installation
d. Click Next to start the Street Lighting Helper installation.
e. After Street Lighting Helper has been installed, a window appears stating that the installation
has been completed successfully. Click Close. If the Application Already Installed dialog
opens, click Yes. The Street Lighting Helper application is downloaded to the Pocket PC.
f. When the Street Lighting Helper download is complete, the Application Downloading
Complete dialog opens.
g. Click OK. On your Pocket PC the following dialog opens, confirming that the Street
Lighting Helper has been downloaded to the Pocket PC

i.LON SmartServer 2.0 Power Line Repeating Network Management Guide 5
h. On the Pocket PC, tap OK.
8. To copy the Street Lighting Helper files from your computer to the Pocket PC, follow these steps:
a. On your computer, browse to the LonWorks\iLon100\unsupported\iLonProxy\bin folder on
your computer and then copy the StreetLightingHelper.exe, iLonProxyPocket.exe, and
iLonProxy.exe files.
b. In Microsoft ActiveSync, click Explore, browse to the Mobile Device\Program Files folder
on your Pocket PC, and then paste the files.
c. Optionally, you can create a new folder called “iLON Tools” or some other descriptive name
in the Program Files folder on the Pocket PC and then paste the files to that new folder.
Note: Uninstalling the Street Lighting Helper application also uninstalls the iLONProxyPocket
application. If you want to use the iLONProxyPocket application with your custom Pocket PC
solution, you can copy the iLONProxyPocket.exe file located in the
LonWorks\iLon100\LonWorks\iLon100\unsupported\StreetLightingHelper\Bin folder on your
computer to your Pocket PC.
Copying Files to the SmartServer
You can use the SmartServer to download the latest application image files (.apb extension) to the
devices on a power line repeating network when installing the network. To do this, you upload the
application image files provided by the device manufacturer to the root/LonWorks/import folder on the
SmartServer flash disk. If the device interface has changed, you can also upload the updated external
interface files that should be provided by the device manufacturer to the root/LonWorks/import folder.
When the SmartServer receives the Neuron ID of a device being installed, it fetches the program ID
from the device. The SmartServer then locates the application image file and XIF on its flash disk that
have program IDs matching that of the device, and it downloads the application image file to the
device and loads the XIF.
Note: If you are installing devices that are pre-loaded with the current application image files, and you
are using the sample Street Lighting Helper application to install the devices, the SmartServer will
overwrite the current application image file stored on the devices when they are added. This is because
the SmartServer will automatically download the application image files in the root/LonWorks/import
folder that have program IDs matching those of the pre-loaded devices.
This section details how to copy the following types of files to the SmartServer flash disk:

6 Preparing a Power Line Repeating Network for Installation
•Application image files (.apb extension). The application that determines how a device functions.
•External interface files. The logical interface to a device. It can either be a device interface file
(.xif extension) or a device template (.xml extension).
•Resource files. Defines the components of the device interface, including network variable types,
configuration property types, format types, and functional profiles implemented by the device
application.
Copying Application Image Files
The application image is a file provided by the device manufacturer that determines how a device
functions. It consists of the object code generated by the Neuron C compiler and includes other
application-specific parameters such as self-identification data and program ID string.
To copy an application image to the SmartServer, follow these steps:
1. Verify that you have the correct user name and password to access the SmartServer via FTP and
that FTP access is enabled on your SmartServer. To do this, follow these steps:
a. Right-click the SmartServer icon, point to Setup, and then click Security on the shortcut
menu. Alternatively, you can click Setup and then click Security. The Setup – Security
Web page opens.
b. In the General property, check the FTP/Telnet User Name and FTP/Telnet Password
properties.
c. In the Service property, verify that the Enable FTP check box is selected.
2. In the browser of an FTP client such as Microsoft Internet Explorer 7, enter the FTP URL of your
SmartServer (ftp://192.168.1.1, for example).
3. Enter the FTP/Telnet user name and password for accessing your SmartServer via FTP.
4. Use FTP to access the root/lonworks/import directory on the SmartServer flash disk.
5. Upload the application image (.apb extension) from the location where it is saved, which could be
a shared network drive with read/write permissions, to the root/lonworks/import folder on the
SmartServer flash disk. Note that you cannot copy a file from one SmartServer and directly paste
it into another.
Copying External Interface Files
The external interface file (XIF) is a file provided by the device manufacturer that defines the logical
interface for a device. The file can be a device interface file (.xif extension) or a device template file
(.xml extension). The XIF specifies the number and types of functional blocks, and the number, types,
directions, and connection attributes of data points. The program ID field is used as the key to identify
each external interface. Each program ID uniquely defines the static portion of the interface.
•To copy a device interface file (.xif extension) to the SmartServer, follow the steps outlined in the
previous section, Copying Application Image Files.
•To copy a device template file (.xml extension) to the SmartServer, follow the steps outlined in the
previous section, Copying Application Image Files, except that in step 4, access the
root/config/template directory on the SmartServer flash disk, and then in step 5, copy the device
template to that directory.
Note: If you upload any XIFs to the SmartServer, you should also upload any used user-defined types.
Copying Resource Files
A resource file defines the components of the device interface, including network variable types,
configuration property types, format types, and functional profiles implemented by the device
application. Resource files allow for the correct formatting of the data generated or configured by the
