Echo MiniTech+ User manual

Echo MiniTech+
TM
Aid for Living Personal Listener
Hearing Products
International Limited
www.hear4you.com

Echo MiniTech+TM is an aid fo r living for use with Headset or NeckLoop, with microphone or optional
Direct Audio input.
Please read and follow the safety instructions before using the product
Safety Instructions and Precautions
·The MiniTech+TM is a personal listener that amplifies ambient sound. Listening to uncomfortable sound levels
for prolonged periods could adversely affect your hearing.
·The supplied stubby microphone (or approved line input) MUST be fully inserted into the microphone socket
before turning the unit on. Failure to do so can result in high sound levels that could adversely affect your
hearing.
·The supplied headset or neck loop MUST be fully inserted into the headset socket before turning the unit on.
Failure to do so can result in high sound levels that could adversely affect your hearing.
·Using this product inappropriately could adversely affect your hearing. Please follow the step-by-step
instructions carefully!
·Do not use in an environment that is damp, wet, very hot or very cold.
·To clean the MiniTech+TM and its accessories, use only a soft cloth and an inorganic cleaner.
·Always use the correct dry cells (commonly known as batteries) 1.5v Type AA, (LR6).
·Never use old and new dry cells together, as the old one will make the new one discharge quickly.
·Dispose of the old dry cells in an environmentally friendly way.
Contents
MiniTech+TM with steto clip headset
MiniTech+TM with Neck Loop
INSTRUCTIONS

(Please refer to the diagrams for details)
Figure 1 Figure 2
Figure 3
Using this product inappropriately could adversely affect your hearing.
Please follow the step-by-step instructions carefully!
1) Make sure the ON/OFF (4) switch is in the OFF position (figure 1). Remove Battery cover (1) and insert dry cells,
ensuring they are placed the correct way round, as illustrated on diagram inside battery compartment.
2) Replace Battery cover securely (figure 2).
3) Fully insert the “stubby”microphone (c) or the microphone on lead (d) into socket (3) (figure 1).
Use the “stubby”microphone for one to one conversation meetings and taking out & about.
Or you can use the microphone on lead to pick up sound from a TV or radio by placing the microphone head by
the speaker. It can be kept in position by using the Velcro®pad provided (figure 3). To increase the distance the

user can be from the sound source, the 3 metre extension lead (e) can be connected between the MiniTech+TM
unit and the microphone. Up to 2 extension leads can be used to extend the distance between the MiniTech+TM
unit and the sound source. Care must be taken in positioning the leads to avoid the danger of tripping etc.
4) Fully insert headset or neck loop into socket (2) (figure 1).
5) If using neck loop, switch hearing aid to “T”position.
6) Set ON/OFF switch (4) to ON position, the LED Light (8) will show Green (figure 1).
7) Increase volume by gently pressing on pad (5). To reduce volume press pad (6).
IMPORTANT –If the volume does not increase switch the MiniTech+TM OFF and check that microphone and
headset or neck loop is inserted fully in the correct sockets before switching on again (figure 1).
8) To adjust tone, turn wheel (7) Anti-clockwise for treble boost. Clockwise for bass boost (figure 1).
PLEASE NOTE
When the unit is switched on, the Power indicator light (8) will show GREEN if dry cells are okay.
If Power indicator shows RED when switched on, or changes to RED when in use, then the dry cells are running low
and will need to be replaced within approximately 8 hours.
If there is no Light when the unit is switched on, this normally indicates the dry cells are completely discharged and
should be replaced.
Optional Combination Audio Lead (Purchased separately)
The combination lead can be used to connect the Echo MiniTech+TM directly to the SCART, Phono/Phono or
headphone sockets on a TV, CD, and Radio etc. instead of using a microphone. Care must be taken in positioning
the leads to avoid the danger of tripping etc.
Technical Specifications
Frequency response: 65Hz-6.5KHz Physical size: 95mm x 55mm x 22mm
Maximum Gain: 45dB Overall weight: 95gms (including dry cells)
Maximum power output: 110 dB Dry cells: 2 x AA size (LR6)
Tone control: 10 dB range 300Hz, 10 db range 5KHz Power supply: +3v DC
Current consumption: 30mA with 32ohm headphones and
no signal Microphone: Electret condenser
AGC: Attack time 0.3ms, Release time 3ms Headset Socket: 3.5mm Stereo
EC Conformity: EN 50081-1 and EN 50082-1
Hearing Products International Limited
Echo House, 26/27 Haigh Park, Stockport, SK4 1QR, England
Tel. [phone] Fax [phone] www.hear4you.com
Hearing Products International Ltd. reserve sole right to alter prices, design and/or technical specifications
or colours without prior notice. E & O.E. 17/05/07. 940-1000-03 MiniTech+ Instructions.
© Copyright Hearing Produ cts International limit ed 2008
UK: Waste electrical products and batteries should not be disposed of with household waste. Separate disposal
facilities exist, for your nearest facilities see www.recycle-more.co.uk or Hearing Products International Limited for full
details www.hear4you.com
