Echo PPSR-2433 User manual

POWERPRUNER
MODEL PPSR-2433
TYPE 1E
SERIAL NUMBER 504000 & UP
ECHO, INCORPORATED
400 OAKWOOD ROAD
LAKE ZURICH, IL 60047
99922203160
07/03

PPSR-2433 TYPE 1E
2
ENGINE\EXTERNAL, INTERNAL, CRANKCASE, FAN HOUSING, COVER
22
26
23
25
24
27
12
12
14
13
9
10
11
17
1
3
4
5
7
8
18
19 2021
15
6
7
2
5
8
10
12 16
28

PPSR-2433 TYPE 1E
3
KEY PARTNUMBER QTY DESCRIPTION REMARKS
1 10101108961 1 CYLINDER
2 90016205022 2 BOLT,H.S. 5X22
3 10101044332 1 GASKET,CYLINDERBASE INCLUDEDINKIT88900005960
4 10000009563 1 PISTONKIT INCLUDESITEMS5-8
5 10001109560 2 RING,PISTON
6 10001311520 1 PIN,PISTON
7 10001504630 2 CIRCLIP,PISTONPIN
8 10001411520 2 SPACER,PISTONPIN
9 ------------------ 1 CRANKCASEASY INCLUDESITEMS10-15(USESB1027)
10 10021242030 2 OILSEAL
11 10021503930 2 PIN,DOWEL
12 90081036201 2 BEARING, BALL 6201
13 ------------------ 1 GASKET,CRANKCASE INCLUDEDINKIT88900005960
14 90016205028 3 BOLT 5X28
15 ------------------ 1 CRANKSHAFTASY INCLUDESITEM16(USESB1027)
16 10001251230 1 BEARING,NEEDLE
17 10150744330 1 COVER,FAN
18 90016304018 4 BOLT 4X18
19 90014205028 2 BOLT 5X28
20 90060500005 2 WASHER, SPRING 5
21 90060000005 2 WASHER 5
22 90056550005 2 NUT, SQUARE 5
23 90025304012 2 SCREW
24 89011526360 1 LABEL,MODEL
25 10151444531 1 COVER,CYLINDER
26 15991244530 1 GUARD,TOP
27 90025305016 1 SCREW 5X16
28 89016022660 1 LABEL,CAUTIONI.S.O.
SB1027 1 SHORTBLOCK INCLUDESFACTORYASSEMBLED
CYLINDER,CRANKCASE,PISTON,
CRANKSHAFT,BEARINGS&SEALS
88900005960 1 GASKETKIT INCLUDESTHEFOLLOWING
10101044332 1 GASKET,CYLINDERBASE
14586642031 1 GASKET,MUFFLERLID
14551042031 2 GASKET,MUFFLER
------------------ 1 GASKET,CRANKCASE
13001042032 1 GASKET,INTAKE
13001642031 1 GASKET,INTAKE
13001005960 1 GASKET,INTAKE
61041401260 1 GASKET,GEARHOUSING
ENGINE\EXTERNAL, INTERNAL, CRANKCASE, FAN HOUSING, CYLINDER COVER

PPSR-2433 TYPE 1E
4
28
29
35
34
33
32
31
29
30
37
36
10 11
12
14
15
17
18
19
20
21
1
2
345
78
27 26 25
24
23 22
13
16
6
9
IGNITION, STARTER, CLUTCH, MUFFLER

PPSR-2433 TYPE 1E
5
KEY PARTNUMBER QTY DESCRIPTION REMARKS
IGNITION, STARTER, CLUTCH, MUFFLER
1 90016204022 2 BOLT 4X22
2 16201052830 1 LEAD
3 15901201620 1 CAP, SPARK PLUG
4 15901103432 1 COIL,SPARK PLUG CAP
5 99944500071 1 PLUG, SPARK BPM-7Y
5 15901010230 1 PLUG, SPARK BPMR-7A CANADIANMODELSONLY
6 15011244330 1 GROMMET,H.T.CORD
7 15662652730 1 MODULE, CDI W/O LEAD
8 17720244330 1 PAWL ASY, STARTER INCLUDES ITEMS 9 & 10
9 17723442030 1 SPRING,RETURN
10 17721844330 1 PAWL,STARTER
11 17720042033 1 STARTERASY INCLUDESITEMS12-18
12 17723644330 1 SCREW
13 17721544430 1 DRUM,STARTER
14 17722042030 1 SPRING,REWIND
15 17723242032 1 HOUSING,STARTER
16 ------------------ 1 ROPE,STARTER USEBULKROPE99944400040
DIA.3.0MM(.12")X1000MM(39.4")
17 17722742030 1 GUIDE, ROPE
18 17722806530 1 GRIP,STARTER
19 90016204016 4 BOLT 4X16
20 89011849130 1 LABEL,ECHO
21 15680109660 1 FLYWHEEL
22 17500056830 1 CLUTCHASY
23 17500544331 1 DRUM,CLUTCH
24 90070200032 1 CIRCLIP 32
25 90081406201 1 BEARING, BALL 6201
26 90070100012 1 CIRCLIP 12
27 17505304920 1 STOPPER
28 14580052630 1 MUFFLERASY INCLUDESITEMS29-35
29 14551042031 2 GASKET,MUFFLER INCLUDEDINKIT88900005960
30 14587144331 1 COVER,MUFFLER
31 14586240630 1 SCREEN,MUFFLER
32 14586642031 1 GASKET,MUFFLERLID INCLUDEDINKIT88900005960
33 14587642030 1 LID,MUFFLER
34 14581852130 1 GUIDE,EXHAUST
35 90023804010 3 SCREW4X10
36 90010505055 2 BOLTH.S.5X55
37 90060000005 2 WASHER 5

PPSR-2433 TYPE 1E
6
1
2
5
25
16
17
18
19
20
21 22
23
15
11
13
14
3
24
4
6
7
8
9
10
26
INTAKE, AIR FILTER, FUEL SYSTEM
27
12

PPSR-2433 TYPE 1E
7
KEY PARTNUMBER QTY DESCRIPTION REMARKS
INTAKE, AIR FILTER, FUEL SYSTEM
1 13001042032 1 GASKET,INTAKE INCLUDEDINKIT88900005960
2 90050000005 2 NUT 5MM
3 90023805020 2 SCREW 5X20
4 13030706761 1 CASE,AIRCLEANER
5 90024205065 2 SCREW 5X65
6 13031054130 1 FILTER,AIRH.D.
7 89012155230 1 LABEL,CHOKE
8 13031305863 1 COVER,AIRCLEANER
9 21041752730 1 BOLT,WING
10 89033552730 1 LABEL,METERING
11 12901106360 1 PLATE,PREVENT
12 12300052132 1 CARBURETOR WT-424B
13 13001005960 1 GASKET,INTAKE INCLUDEDINKIT88900005960
14 13001742031 1 INSULATOR
15 13130056430 1 VALVE, CHECK
16 13131239130 1 PIPE,VENT 3X5X70
17 13211546730 1 GROMMET,FUEL
18 13201309820 1 CLIP
19 13120507320 1 STRAINER,FUEL
20 13201056330 1 PIPE,RETURN
21 13201013930 1 PIPE, FUEL
22 13100546830 1 TANK,FUEL
23 90060300005 2 WASHER 5MM
24 90023805016 2 SCREW 5X16
25 30511042030 1 STAND
26 13100455830 1 CAP ASY, FUEL TANK INCLUDESITEM27
27 13101655830 1 GASKET, FUEL TANK CAP
REVISED02/00

PPSR-2433 TYPE 1E
8
HANDLES,THROTTLE,STOPSWITCH,DRIVESHAFT
1
2
3
4
5
6
7
7
8
9
10 11
12
13
14
15
16
17
18
19
20
21
22 23
24
25
25
26
27

PPSR-2433 TYPE 1E
9
KEY PARTNUMBER QTY DESCRIPTION REMARKS
1 35120121560 1 HANDLE ASY INCLUDESITEMS2-4
2 90016205030 2 BOLT 5X30
3 35161105360 1 PLATE, EYE
4 88995021560 4 SCREW
5 16340155630 1 SWITCH,IGNITION
6 17800352730 1 BRACKETSET,THROTTLE INCLUDESITEMS7-9
7 90050000005 2 NUT 5
8 90024205025 1 SCREW 5X25
9 90024205035 1 SCREW 5X35
10 17809052630 1 LOCKOUT,THROTTLECONTROL
11 17801352630 1 SPRING,THROTTLELOCKOUTCONTROL
12 35121352730 1 GRIP,HANDLETHROTTLE
13 30121252730 1 BAND INCLUDESITEM14
14 90024205014 1 SCREW 5X14
15 17801052130 1 CONTROL,THROTTLE
16 17804342230 1 SPRING,THROTTLERETURN
17 17801252730 1 LOCKOUT,THROTTLE
18 61027252730 1 BAND INCLUDESITEMS19&20
19 90024205028 1 SCREW 5X28
20 90050000005 1 NUT 5
21 61020626360 1 HOUSINGASY,DRIVESHAFT INCLUDESITEMS22&23
22 61021721560 1 LINER,FLEXIBLE
23 61024655330 2 FIXTURE,LINER
24 61001321560 1 SHAFT,FLEXIBLE
25 90050200006 2 NUT 6
26 17800151030 1 WIRE,THROTTLE
27 17812721360 1 TUBE
HANDLES,THROTTLE,STOPSWITCH,DRIVESHAFT

PPSR-2433 TYPE 1E
10
1
2
3
4
5
6
7
8
79
10 11
18
12
14 15
16
17
19
20
21
22
23
24
25
25
25
25
24
27
28
29
31
32
35
36
37
26
33
33
34
38
39 40
41
GEARCASE,GUIDEBAR,SAWCHAIN,AUTOOILER,TOOLS
13
30
42
43 44
45

PPSR-2433 TYPE 1E
11
KEY PARTNUMBER QTY DESCRIPTION REMARKS
90080 1 OILER/GEARBOXASY INCLUDESITEMS 1-39
1 V253000000 8 SCREW 5X25
2 C531000010 1 CASE, GEAR UPPER
3 43301903933 2 NUT 6
4 89011849130 1 LABEL, ECHO
5 C300000000 1 GUARD,SPROCKET
6 V583000010 1 RING
7 17501439130 2 WASHER,CIRCULAR 10
8 C580000070 1 SPROCKET,DRIVE
9 43724439130 1 PAD, FOAM
10 43700239130 1 AUTOOILERASY INCLUDESITEMS11-17
11 12312715030 1 CLIP
12 V253000010 2 SCREW 5X10
13 43701938330 1 SPRING,PLUNGER
14 43702437330 1 PLUNGERASY
15 43706237330 1 CAP, OIL PUMP
16 43701537330 1 SPRING,ADJUSTER
17 43702937330 1 WASHER
18 43701639130 1 ADJUSTER,OILER
19 43620502832 1 STRAINER,OIL
20 13211501461 1 GROMMET
21 13011014330 1 IMPULSEPIPE
22 V470000180 1 PIPE
23 V362000010 1 COLLAR 22
24 90070600012 2 CIRCLIP 12
25 9404206001 4 BEARING,BALL 6001
26 V651000030 1 GEAR, BEVEL
27 V253000010 1 SCREW 5X10
28 43706338330 1 GEAR, WORM
29 C534000020 1 SHAFT,GEAR
30 61031122060 1 GEAR, BEVEL
31 V354000010 1 COLLAR 6
32 C200000000 1 TANK,OIL
33 13104528230 2 SPACER
34 V253000020 3 SCREW 5X16
35 P021000950 1 CAP, OIL ASY
36 13131406320 1 VALVE, CHECK
37 C531000020 1 CASE, GEAR LOWER
38 V224000000 2 BOLT,STUD 6
39 43301639131 1 BOLT,TENSIONER
40 43301403931 1 TENSIONER
41 1121374401 1 BAR, GUIDE 12" 91 VG
41 1122374401 1 BAR,INTENZGUIDE 12" 91 VG
42 1917044 1 CUTTINGCHAIN12" 91VG
43 89541522160 1 TOOL,BOXSPANNER
44 89561203430 1 L-WRENCH,TOOL3MM
45 89851322360 1 COVER,GUIDEBAR
GEARCASE,GUIDEBAR,SAWCHAIN,AUTOOILER,TOOLS
REVISED07/03

PPSR-2433 TYPE 1E
12
1
5
67
11 12
13
14 15
16
17
16
18
19
20
21
22
23
25
24
26
27
28
29
10
9
8
4
3
2
CARBURETOR
17
30

PPSR-2433 TYPE 1E
13
KEY PARTNUMBER QTY DESCRIPTION REMARKS
CARBURETOR
12300052133 1 CARBURETOR WT-424C INCLUDESTHEFOLLOWING
1 12311043130 2 SCREW
2 12314209560 1 COVER,PRIMERPUMP
3 12318109560 1 PUMP,PRIMER
4 12317135630 1 VALVE,PURGE CHECK
5 12312443230 1 COVER,FUEL PUMP
6 12313304260 1 SPRING,IDLEADJUST
7 12313404260 1 SCREW,IDLEADJUST
8 A B 1 GASKET, FUEL PUMP
9 A B 1 DIAPHRAGM,FUELPUMP
10 A 1 SCREEN,INLET
11 12311352130 1 SPRING,THROTTLESHAFT
12 12311752130 1 SHAFT,THROTTLE
13 12317307930 1 CLIP
14 12314926030 1 WASHER
15 12317226030 1 SWIVEL
16 12312052131 2 NEEDLE,MIXTURE
17 12315139230 2 CAP,LIMITER
18 A 1 PLUG,WELCH
19 A 1 SPRING,METERINGLEVER
20 A 1 LEVER,METERING
21 A B 1 GASKET,METERINGDIAPHRAGM
22 A B 1 DIAPHRAGM,METERING
23 12314203930 1 COVER,METERINGDIAPHRAGM
24 A 4 SCREW
25 A 1 PIN,METERINGLEVER
26 A 1 SCREW
27 A 1 VALVE,INLETNEEDLE
28 12311652130 1 VALVE,THROTTLE
29 12311403930 1 SCREW
30 12312715030 1 CLIP
A 12310052130 1 REBUILDKIT
B 12310152130 1 GASKET/DIAPHRAGMKIT
