PARTS MANUAL
PN: 12330
Rev. 070113
Companion to 12331
SN Range: D04579 to Current
WHEELED
TRIMMER
WT190 - 190cc BRIGGS & STRATTON PUSH
WT190S - 190cc BRIGGS & STRATTON SELF-PROPELLED
WT190T - 190cc BRIGGS & STRATTON PUSH W/TILT

© 2011, CRARY INDUSTRIES, ALL RIGHTS RESERVED. PRODUCED AND PRINTED IN THE U.S.A.
Before You Begin
DEAR ECHO BEAR CAT CUSTOMER
Thank you for purchasing a ECHO Bear Cat product. The ECHO Bear Cat line is designed, tested, and manufactured
to give years of dependable performance. To keep your machine operating at peak efciency, it is necessary to adjust
it correctly and make regular inspections. The following pages will assist you in the operation and maintenance of your
machine. Please read and understand this manual before operating your machine.
If you have any questions or comments about this manual, please call us toll-free at 1.888.645.4520.
If you have any questions or problems with your machine, please call or write your local authorized ECHO Bear Cat Dealer.
This document is based on information available at the time of its publication. ECHO Bear Cat is continually making
improvements and developing new equipment. In doing so, we reserve the right to make changes or add improvements
to our product without obligation for equipment previously sold.
PLEASE SEND US YOUR WARRANTY CARD
A warranty card is included in your owner's kit packaged with your machine. Please take the time to ll in the information
requested on the card. When you send your completed card to us, we will register your machine and start your cover-
age under our limited warranty or go to bearcatproducts.com/warranty/warranty-registration/.
HOW TO CONTACT ECHO BEAR CAT
ADDRESS PHONE E-MAIL HOURS
237 NW 12th Street
P.O. Box 849
West Fargo, ND 58078
888.645.4520
701.282.5520
FAX: [phone]
[email protected]
[email protected]
Monday - Friday,
8 am to 5 pm
Central Time
SERIAL NUMBER
MANUFACTURED BY CRARY INDUSTRIES
MANUFACTURED IN U.S.A.
XXXXXX
WEST FARGO, NORTH DAKOTA 58078 U.S.A.
SERIAL NUMBER
SERIAL NUMBER LOCATION
Please record the serial number in the space provided and
on the warranty and registration card.
ORDERING PARTS
Only genuine ECHO Bear Cat replacement parts should
be used to repair the machine. Replacement parts man-
ufactured by others could present safety hazards, even
though they may t on this machine. Replacement parts
are available from your ECHO Bear Cat dealer.
Provide the following when ordering parts:
The SERIAL NUMBER of your machine.
The PART NUMBER of the part.
The PART DESCRIPTION.
The QUANTITY needed.
FOR MACHINE SERVICE OR PARTS:
For service assistance, contact your nearest authorized
ECHO Bear Cat dealer or the factory. For parts, contact
your authorized dealer. The parts manual for your machine
is available at http://bearcatproducts.com/main/support/in-
dex_html. Your dealer will need to know the serial number
of your machine to provide the most efcient service. See
below for information on how to identify and record the se-
rial number for your machine.
FOR ENGINE SERVICE OR PARTS:
For engine service or parts, contact your nearest autho-
rized engine dealer. ECHO Bear Cat does not handle any
parts, repairs or warranties for engines.
*Original Instructions

TABLE OF CONTENTS
DESCRIPTION PAGE
WT190 DRIVE.................................................................................................................................................................2
PUSH
WT190 HANDLEBAR .....................................................................................................................................................4
PUSH
WT190 BODY..................................................................................................................................................................6
PUSH
WT190S DRIVE...............................................................................................................................................................8
SELF-PROPELLED
WT190S HANDLEBAR.................................................................................................................................................10
SELF-PROPELLED
WT190S BODY .............................................................................................................................................................12
SELF-PROPELLED
WT190T DRIVE.............................................................................................................................................................14
PUSH W/TILT
WT190T HANDLEBAR.................................................................................................................................................16
PUSH W/TILT
WT190T BODY .............................................................................................................................................................18
PUSH W/TILT
SERVICE PARTS & OPTIONS .....................................................................................................................................20

WHEELED TRIMMER
2
WT190 DRIVE PUSH 07/13
1
2
3
4
5
6
7
8
9
10
9
11
12
13
14
15
16
17
18
19

WHEELED TRIMMER 3
07/13 PUSH WT190 DRIVE
ITEM PART NUMBER DESCRIPTION
1 12319 PULLEY, 5.0 X 7/8 AB
2 14560-00 DECAL, 6.5 HP INFORMATION
3 15131 SCREW, 5/16-18 X 5/8 SQ HD SET
4 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP
5 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP
6 15250 WASHER, 5/16 FLAT ZP
7 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP
8 15301 BOLT, 5/16 X 1 CRG GR5 ZP
9 15356 NUT, 5/16 NE NYLOCK ZP
10 15406 PUSHNUT, 5/8 ZP
11 15416 WASHER, 5/16 SAE FLAT ZP
12 15434 KEY, 3/16 SQUARE X 1-1/2 LONG PLAIN
13 16155 DECAL, SERIAL NUMBER
14
ENGINE, 6.5 HP QUANTUM HD 49 STATE (CALIF. EMISSION COMPLIANT)
(FOR SERVICE SEE ENGINE OWNER’S MANUAL OR YOUR NEAREST AUTHO-
RIZED HONDA ENGINE DEALER.)
15 18957-00 WHEEL, 15 INCH TRIMMER (BLACK)
16 69126 SPACER, IDLER PIVOT
17 73630-35 BODY, TRIMMER
18 75503-12 WELDMENT, TRIMMER AXLE
19 75504-12 BOTTOM, TRIMMER FRAME

WHEELED TRIMMER
4
WT190 HANDLEBAR PUSH 07/13
1
2
3
5
6
6
7
8
9
9
10
11
12
13
14
16
18
4
4
6
9
17
19
20
21
15

WHEELED TRIMMER 5
07/13 PUSH WT190 HANDLEBAR.
ITEM PART NUMBER DESCRIPTION
1 12324 CABLE, BRAKE CONTROL
2 12326 PAD, FOAM HANDLEBAR
3 15030 WASHER, 1/4 FLAT ZP
4 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
5 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP
6 15250 WASHER, 5/16 FLAT ZP
7 15342 BOLT, 1/4 X 1-1/2 HHCS GR5 ZP
8 15355 NUT, 1/4 NE NYLOCK ZP
9 15356 NUT, 5/16 NE NYLOCK ZP
10 15403 BOLT, 5/16-18 X 1-3/4 HCS GR5 ZP
11 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5
12 17320 STRAP, 11 IN. BLACK TIE
13 18008-00 CONTAINER, MANUAL
14 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE
15 31890-00 DECAL, ATLANTIC BRIDGE LTD INFO
16 72732-12 BAIL, TRIMMER
17 72760 HANDLEBAR, TRIMMER
18 73630-35 BODY, TRIMMER
19 74964-12 TUBE, CONTAINER MANUAL
20 75504-12 BOTTOM, TRIMMER FRAME
21 75518-12 CHANNEL, HANDLE SUPPORT

WHEELED TRIMMER
6
WT190 BODY PUSH 07/13
1
2
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
19
20
21
22
23
24
25
26
27
28
18

WHEELED TRIMMER 7
07/13 PUSH WT190 BODY
ITEM PART NUMBER DESCRIPTION
1 12254 DECAL, GRINDER DANGER
2 12314 BEARING, 3/4 BALL
3 12317 BELT, 4L 53 ARAMID
4 12348 STRING, .155 X 20-1/2
5 14184-00 DECAL, 101 DB
6 15003 BOLT, 5/16 X 3/4 HEX HD GR5 ZP
7 15098 WASHER, 3/4 SAE FLAT ZP
8 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
9 15250 WASHER, 5/16 FLAT ZP
10 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP
11 15356 NUT, 5/16 NE NYLOCK ZP
12 15402 NUT, 5/16-18 TINNERMAN U-TYPE
13 17913 DECAL, ECHO BEARCAT 6.82 X 1.90
14 18947-00 DECAL, MODEL WT190
15 18949-00 DECAL, MANUAL/SAFETY INFO
16 18950-00 RIVET, PLASTIC 1/4 X 7/8
17 31392-00 DECAL, RECLAIM IT
18 32392-00 DECAL, ECHO BEAR CAT QR CODE
19 72705-12 DISK, TRIMMER HEAD
20 72723 FLAP, TRIMMER
21 72754 WELDMENT, TRIMMER PULLEY
22 72755-12 WELDMENT, SPINDLE HUB
23 72759 SPACER, TRIMMER SPINDLE
24 72781-12 SPACER, TRIMMER HEAD
25 73116-12 WELDMENT, TRIMMER HEAD USE 72704-12
26 73630-35 BODY, TRIMMER
27 75504-12 BOTTOM, TRIMMER FRAME
28 75519-35 COVER, FRONT TRIMMER

WHEELED TRIMMER
8
WT190S DRIVE SELF-PROPELLED 07/13
1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
15
15
15
16
17
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32 33
34
35
36
37
38
40
41
42
39

WHEELED TRIMMER 9
07/13 SELF-PROPELLED WT190S DRIVE
ITEM PART
NUMBER DESCRIPTION WT160S QTY
WT190S
QTY
1 12319 PULLEY, 5.0 X 7/8 AB 1 1
2
ENGINE, 5.5 HP HONDA GCV (FOR SERVICE SEE ENGINE OWNER’S
MANUAL OR YOUR NEAREST AUTHORIZED HONDA ENGINE DEALER.) 1
ENGINE, 6.5 HP QUANTUM HD 49 STATE (CALIF. EMISSION COMPLIANT)
(FOR SERVICE SEE ENGINE OWNER’S MANUAL OR YOUR NEAREST
AUTHORIZED HONDA ENGINE DEALER.)
1
3 12568 PULLEY, 7-1/2 X 12MM A GROOVE 1 1
4 12571 SPROCKET, 35A60 W/HOLES 2 2
5 12572 CHAIN, EZ TRIMMOWER 2 2
6 12574 BEARING, 1/2 FLANGE 2 2
712755 DECAL, 5.5 HP INFORMATION 1
14564-00 DECAL, 6.5 HP SP INFORMATION 1
8 12834 TRANSMISSION, 3 SPEED 1 1
9 15131 SCREW, 5/16-18 X 5/8 SQ HD SET 2 2
10 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP 1
11 15180 SET SCREW, 1/4 X 5/8 SQ HD 2 2
12 15238 BOLT, 1/4 X 3/4 CRG GR5 ZP 4 4
13 15250 WASHER, 5/16 FLAT ZP 8 8
14 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP 3 2
15 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP 10 10
16 15355 NUT, 1/4 NE NYLOCK ZP 4 4
17 15356 NUT, 5/16 NE NYLOCK ZP 19 19
18 15372 KEY, 3/16 SQUARE X 1.00 LONG 1 1
19 15397 NUT, 10/24 NYLOCK TYPE NM, ZP 2 2
20 15406 PUSHNUT, 5/8 ZP 2 2
21 15416 WASHER, 5/16 SAE FLAT ZP 5 3
22 15560 BOLT, 5/16 X 2-3/4 HCPS GR5 6 6
23 15594 SCREW, #10X24 X 1-1/2 PAN PHP ZP 2 2
24 15598 KEY, 4MM SQUARE X 20 MM 1 1
25 15680-00 SCREW, #8-32 X 3/16 KNR CUP PT 1 1
26 15683-00 CLIP, 1/2" E 2 2
27 16155 DECAL, SERIAL NUMBER 1 1
28 16900 STRAP, 4 IN. BLACK 1 1
29 18950-00 RIVET, PLASTIC 1/4 X 7/8 4 4
30 31310-00 MUFFLER DEFLECTOR, HONDA 5.5 HP GCV 1
31 31311-00 SCREW, MUFFLER DEFLECTOR 2
32 72723 FLAP, TRIMMER 1 1
33 72989 WELDMENT, LH WHEEL CLUTCH 1 1
34 72990 WELDMENT, RH WHEEL CLUTCH 1 1
35 73266-12 PAN, TRIMMER BOTTOM 1 1
36 73630-35 BODY, TRIMMER 1 1
37 74836-00 TUBE, 1.5" X 2.125" HEAT SHRINK 2 2
38 75512-12 SHEET, CAP WHEEL 2 2
39 75534-00 ASSEMBLY, TRIMMER WHEEL 2 2
40 76733-12 BOTTOM, TRIMMER FRAME 1 1
41 76734-12 PLATE, TRANSMISSION 1 1
42 76736-12 WELDMENT, TRIMMER AXLE 1 1

WHEELED TRIMMER
10
WT190S HANDLEBAR SELF-PROPELLED 07/13
1
2
3
4
5
6
6
7
8
8
9
10
11
12
12
13
13
14
15
16
17
18
19
20
21
22
23
24
26
27
28
29
14
14 12
25

WHEELED TRIMMER 11
07/13 SELF-PROPELLED WT190S HANDLE BAR
ITEM PART NUMBER DESCRIPTION
1 12324 CABLE, BRAKE CONTROL
2 12326 PAD, FOAM HANDLEBAR
3 12842 CABLE, TRANSMISSION CONTROL
4 12849 DECAL, 3 SPEED
5 12856 CABLE, SP CONTROL
6 15030 WASHER, 1/4 FLAT ZP
715093 BOLT, 1/4 X 2 HEX HD GR5 ZP (WT160S ONLY)
15094 BOLT, 1/4 X 1-3/4 HHCS GR5 ZP (WT190S ONLY)
8 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
915197 BOLT, 1/4 X 2-1/4 HCS GR5 ZP (WT160S ONLY)
15342 BOLT, 1/4 X 1-1/2 HHCS GR5 ZP (WT190S ONLY)
10 15214 BOLT, 1/4 X 1-1/4 HEX HD GR5 ZP
11 15219 BOLT, 5/16 X 1 HEX HD GR5 NC ZP
12 15250 WASHER, 5/16 FLAT ZP
13 15355 NUT, 1/4 NE NYLOCK ZP
14 15356 NUT, 5/16 NE NYLOCK ZP
15 15403 BOLT 5/16-18 X 1-3/4 HCS GR5 ZP
16 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5
17 16239 THROTTLE CONTROL (WT160S ONLY)
18 17320 STRAP, 11 IN. BLACK TIE
19 18008-00 CONTAINER, MANUAL
20 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE
21 31890-00 DECAL, ATLANTIC BRIDGE LTD INFO (WT190S ONLY)
22 72732-12 BAIL, TRIMMER
23 72760 HANDLEBAR, TRIMMER
24 72995-12 WELDMENT, SP BAIL
25 72999-12 ANCHOR, SP CABLE
26 73630-35 BODY, TRIMMER
27 74964-12 TUBE, CONTAINER MANUAL
28 75518-12 CHANNEL, HANDLE SUPPORT
29 76733-12 BOTTOM, TRIMMER FRAME

WHEELED TRIMMER
12
WT190S BODY SELF-PROPELLED 07/13
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
18
19
20
21
22
23
25
2
9
26
24
17

WHEELED TRIMMER 13
07/13 SELF-PROPELLED WT190S BODY
ITEM PART NUMBER DESCRIPTION
1 12254 DECAL, GRINDER DANGER
2 12314 BEARING, 3/4 BALL
3 12348 STRING, .155 X 20-1/2
4 12573 BELT, 3L X 52
514182-00 DECAL, 98 DB (WT160S)
14184-00 DECAL, 101 DB (WT190S)
6 15003 BOLT, 5/16 3/4 HEX HD GR5 ZP
7 15098 WASHER, 3/4 SAE FLAT ZP
8 15176 SCREW, 11/32 X 7/8 HWH AB THREAD ZP
9 15250 WASHER, 5/16 FLAT ZP
10 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP
11 15356 NUT, 5/16 NE NYLOCK ZP
12 15402 NUT 5/16-18 TINNERMAN U-TYPE
13 17913 DECAL, ECHO BEARCAT 6.82 X 1.90
14 18949-00 DECAL, MANUAL/SAFETY INFO
15 18953-00 DECAL, MODEL WT160S
18951-00 DECAL, MODEL WT190S
16 31392-00 DECAL, RECLAIM IT
17 32392-00 DECAL, ECHO BEAR CAT QR CODE
18 72705-12 DISK, TRIMMER HEAD
19 72754 WELDMENT, TRIMMER PULLEY
20 72755-12 WELDMENT, SPINDLE HUB
21 72759 SPACER, TRIMMER SPINDLE
22 72781-00 SPACER, TRIMMER HEAD
23 73116-12 WELDMENT, TRIMMER HEAD USE 72704-12
24 73630-35 BODY, TRIMMER
25 75519-35 COVER, FRONT TRIMMER
26 76733-12 BOTTOM, TRIMMER FRAME

WHEELED TRIMMER
14
WT190T DRIVE PUSH W/TILT 07/13
1
2
3
4
5
6
7
89
9
9
10
11
11
12
12
13
14
15
15
15
16
16
17
18
15
19
20
21
22
23
24
25
26 26
27
28

WHEELED TRIMMER 15
07/13 PUSH W/TILT WT190T DRIVE
ITEM PART
NUMBER DESCRIPTION WT160T QTY
WT190T
QTY
1 12177 SPRING, HEAVY DUTY COMPRESSION 1 1
2 12275 FITTING, 1/4 SELF-TAP GREASE 1 1
3 12319 PULLEY, 5.0 X 7/8 AB 1 1
4 12325 GRIP, TILT CONTROL 1 1
5
ENGINE, 5.5 HP HONDA GCV (FOR SERVICE SEE ENGINE
OWNER’S MANUAL OR YOUR NEAREST AUTHORIZED HONDA
ENGINE DEALER.)
1
ENGINE, 6.5 HP QUANTUM HD 49 STATE (CALIF. EMISSION
COMPLIANT) (FOR SERVICE SEE ENGINE OWNER’S MANUAL
OR YOUR NEAREST AUTHORIZED HONDA ENGINE DEALER.)
1
6 12520 DEFLECTOR, EXHAUST (WT160T ONLY) 1
712755 DECAL, 5.5 HP INFORMATION 1
14563-00 DECAL, 6.5 HP TILT INFORMATION 1
8 15003 BOLT, 5/16 X 3/4 HEX HD GR5 ZP 4 4
9 15129 WASHER, 5/8 SAE FLAT ZP 4 4
10 15131 SCREW, 5/16-18 X 5/8 SQ HD SET 2 2
11 15154 BOLT, 5/16 X 2-1/2 HEX HD GR5 ZP 1 2
12 15250 WASHER, 5/16 FLAT ZP 7 7
13 15282 BOLT, 5/16 X 1-1/2 HEX HD GR5 ZP 3 2
14 15349 BOLT, 5/16 X 7/8 CRG GR5 NC ZP 3 3
15 15356 NUT, 5/16 NE NYLOCK ZP 12 12
16 15375 PIN, 1/8 X 1.00 COTTER ZP 2 2
17 15406 PUSHNUT, 5/8 ZP 2 2
18 15416 WASHER, 5/16 SAE FLT ZP 3 3
19 15434 KEY, 3/16 SQUARE X 1-1/2 LONG PLAIN 1 1
20 16155 DECAL, SERIAL NUMBER 1 1
21 17897 BEARING, SIDE FLANGE MOUNT, 5/8 2 2
22 18957-00 WHEEL, 15 INCH TRIMMER (BLACK) 2 2
23 72710-12 WELDMENT, AXLE PIVOT 1 1
24 72724 HANDLE, TRIMMER HEIGHT ADJUST 1 1
25 72736-12 PLATE, HANDLE LOCK 1 1
26 72762-12 SPACER, 7/8 X .281 3 3
27 73298-35 WELDMENT, TRIMMER BODY 1 1
28 75505-12 WELDMENT, TRIMMER AXLE 1 1

WHEELED TRIMMER
16
1
2
3
4
4
5
6
7
7
7
8
9
9
9
10
11
12
13
14
15
16
18
19
20
21
17
WT190T HANDLEBAR PUSH W/TILT 07/13

WHEELED TRIMMER 17
07/13 PUSH W/TILT WT190T HANDLEBAR
ITEM PART NUMBER DESCRIPTION
1 12324 CABLE, BRAKE CONTROL
2 12326 PAD, FOAM HANDLEBAR
3 15030 WASHER, 1/4 FLAT ZP
4 15176 SCREW,11/32 X 7/8 HWH AB THREAD ZP
515197 BOLT, 1/4 X 2-1/4 HCS GR5 ZP (WT160T ONLY)
15342 BOLT, 1/4 X 1-1/2 HCS GR5 ZP (WT190T ONLY)
6 15219 BOLT, 5/16 X 1 HHCS GR5 NC ZP
7 15250 WASHER, 5/16 FLAT ZP
8 15355 NUT, 1/4 NE NYLOCK ZP
9 15356 NUT, 5/16 NE NYLOCK ZP
10 15403 BOLT, 5/16-18 X 1-3/4 HCS GR5 ZP
11 15754-00 BOLT, 5/16 X 2-1/4 HCPS GR5
12 16239 THROTTLE CONTROL (WT160T ONLY)
13 16740 DECAL, THROTTLE (WT160T ONLY)
14 17320 STRAP, 11 IN. BLACK TIE
15 18008-00 CONTAINER, MANUAL
16 18955-00 CAP, PLASTIC 3/4 X 1-1/2 TUBE
17 31890-00 DECAL, ATLANTIC BRIDGE LTD INFO (WT190T ONLY)
18 72732-12 BAIL, TRIMMER
19 72760 HANDLEBAR, TRIMMER
20 74964-12 TUBE, CONTAINER MANUAL
21 75518-12 CHANNEL, HANDLE SUPPORT

WHEELED TRIMMER
18
1
2
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
17
19
20
21
22
23
24
25
26
27
28
18
WT190T BODY PUSH W/TILT 07/13
