Echo EchoLink IR User manual

EchoLink（IR）
Wireless TV System
TM
Product Code: 917

CONTENT
1. Accessories Picture
2. Safety Instructions and Precautions
3.
Setup and User Instructions 4.
5. Setup and User Instructions Continued
6.
EchoLink (IR)
TM
Wireless InfraredTV system
Please read and follow the safety
instructions before using the product
Safety Instruction and precautions continued
7.
8.
Setup and User Instructions Continued
Setup and User Instructions Continued
9.
Connection Solutions
10.
11.
Connection Solutions Continued
Replacement Parts
Technical Specifications

Accessories Picture:
①Receiver ②Charger ③Transmitter ④SCART\Adapter
⑤12V DC Power adapter ⑥12V DC Power adapter
⑦Headset ⑧Phono plugs ⑨Echo ILoop
①③
②
⑤⑥
④
⑦
⑧
1
⑨
⑩
⑩
Microphone

Safety Instructions and Precautions:
●Listening to uncomfortable sound levels for prolonged periods
could adversely affect your hearing.
●If using a microphone, line input, headset or neck loop the plug
MUST be fully inserted into the correct socket and the volume
turned to the lowest level before turning the unit on. Failure to do
so can result in high sound levels that could adversely affect your
hearing.
●If using a headset or neck loop it MUST be fully inserted into
the headset socket before turning the unit on. Failure to do so
can result in high sound levels that could adversely affect your
hearing.
● Using this product inappropriately could adversely affect your
hearing. Please follow the step-by-step instructions carefully!
●Do not use in an environment that is damp, wet, very hot or very
cold.
●To clean the EchoLink (IR)TM and its accessories, use only a soft
cloth and an inorganic cleaner.
●Only use the Hearing Products approved mains adapter. Do not
use any other type of mains adapter.
●When using this unit, basic safety precautions as below should
always be followed to avoid the risk of electrical shock or personal
injury.
2

●Install the unit securely on a stable surface and install the unit
where the power cord will not be subject to damage or cause a
tripping hazard.
●The unit may get warm when being used. Ensure the unit has
adequate ventilation.
●Please refer all servicing to qualified personnel ONLY! Do not
attempt to open the unit!
●The battery must be fully charged before use.
●It will take about 5 to 7 uses and recharges before the battery
is at full capacity.
3

Setup and User Instructions:
1.Place the EchoLink (IR)TM transmitter (see Fig 1) on top of or
next to your TV or fix to the side of the TV with the Velcro pad.
(To do this, remove the stand by firmly pulling the
transmitter and stand apart). Place one piece of the Velcro on
the bottom of the transmitter and with the second piece fix to the
side of the TV, making sure the transmitter is facing where you
are sitting and that there is a clear line of sight between the
transmitter and receiver, with no obstruction.
2.Plug the 12V DC power adapter into an electrical power socket
then plug the power lead into the transmitter DCsocket (see Fig 2).
3.If your TV has audio output sockets connect the Phono/Phono
lead to these sockets and plug the 3.5mm jack plug end of the
lead into the EchoLink (IR) TMAudio input socket (see Fig 3).
4.If your TV has no audio output sockets but has a spare SCART
socket, plug the scart into the TV and connect the Phono/Phono
lead. Then connect the 3.5mm jack plug end into the Audio Input
socket of the transmitter (see Fig 4).
①
②
Fig 1
4

Fig 3
Fig 4
5

5.If the SCART connection is not successful,
connect the microphone.Simply plug the
3.5mm plug of the microphone cable into
the Mic socket on the transmitter (see Fig
5) and then fix the microphone onto the
TV speaker using the Velcro.
6.The transmitter base has a switch that
allows you to switch between stereo and
mono operation. Leave the switch set to
mono.
7.Plug the 12V DC mains power adapter
into a standard electrical power socket,
then plug the power lead into the EchoLink
(IR) TM charging cradle socket (see g 2).
8.Rotate the volume wheel ON/OFF switch
u n t i l t h e O N / O F F L E D i s o ff on t h
e receiver and place the receiver on
the charging base.
9.When charging the charge LED on
the receiver will be red, when fully
charged t h e c h a r g e L ED w i l l t u r n t
o g re en . R em o ve f ro m b as e a nd f
u l l y i n s e r t the Headset or Neckloop
plug into the receiver phone jack .
10.Put on Headset or Neckloop, if you are using
the Neckloop, set your hearing aids to the
“T” setting. Ensure the volume is set to zero
then adjust the volume to a comfortable
listening level using the yellow on/off volume
wheel. (the ON/ OFF LED will be GREEN).
6
Fig 5

11.The universal receiver must have a clear and unobstructed view
of the transmitter to work properly.
12.When you are finished using the universal receiver turn
the volume fully counter clockwise until the ON/OFF LED is
off .
13.Place the universal receiver back into the charging cradle.
14.The charge LED will turn RED and when the batteries are fully
charged the charge LED will turn green again. The
charging cradle power LED will always be red when connected
to mains. This indicates that power is available for the receiver.
15.The receiver can also be recharged by plugging the 12V DC
power lead directly into the receiver socket.
16.When the battery level is low, the ON/OFF LED will flash RED.
Then after a few minutes the receiver will automatically turn off
to protect the batteries. The receiver must be recharged if this
occurs.
17.There are no user serviceable parts in the universal receiver. Do
not attempt to replace the batteries. Contact Hearing Products
International Limited if you have any service issues.
18.Note: if the serial numbers or labels are removed your warranty
is invalid.
7

Help and advice for connecting to TV with analogue audio output.
When connecting a MegaLoop, EchoLink or RadioLink to a TV. It is
usually best not to use the SCART sockets as this can result in picking
up the wrong sound or sound that isout of sync with the picture.
L
R
Aerial Audio out SCART sockets
Step 1. When connecting to a TV the first thing to look for is red
and White Audio out sockets these are usually at the back of the
TV. and usually indicated by a circle with an arrow pointing out of it.
Connecting from audio out will always provide the correct sound for
the program that is being watched. Note the red white and yellow
sockets that are normally on the front or side of TVs are for
sound and picture in and not sound out. On some of the newer
flat screen TVs the sockets may be covered by a removable panel
at the rear of the TV.
Step 2. If the TV. has no audio out sockets or they are not working
the next thing to try is the headphone socket simply switch the TV.
on and insert the 3.5mm jack plug into the headphone socket, if the
sound is not cut from the speakers then connect from this and into
the line in/Audio in on the loop or Transmitter . You will then have
to adjust the headphone volume level on the TV. this is done by
pressing the menu button on the TV. remote, selecting sound and
then moving the headphone volume to about two thirds full.
Step 3. If the TV. has no audio out and the headphone connection
cuts the sound from the TV speakers simply pick up sound by fixing
the microphone provided to the speaker of the TV. To provide the
best results adjust the TVs bass and treble levels to ¼ of max bass
and ¾ of max treble and if possible set the sound to mono.
8

Help and advice for connecting to a TV. that has Digital Optical
Audio Output
Many of the newer TV. models no longer have analogue audio
output, they have Digital Optical Audio Out or Digital Coaxial Audio
Out. The picture below shows the type of socket to look for.
To connect your equipment from this socket you will require an
optional Digital to Analogue Converter available from Hearing
Products International Ltd.
DIGITAL AUDIO OUT
OPTICAL
COAXIAL
The picture below shows the front and rear of a typical Digital to
Analogue converter. Set up is easy the converter is
connected from the TV to the (in) socket on the converter and the
MegaLoop, EchoLink, or other analogue device is then
connected to the phono out sockets. The converter is supplied
with a mains adapter and Optical connecting cable as this is the
most common. If the Coaxial connecting cable is required this will
have to be purchased separately.
N COAX OPTICAL OUT R L
For further details about the Digital to analogue converter please
contact Hearing Products International on 01614808003 or visit
www.hear4you.com
9

Replacement Parts
10
P/ N Qty Descr ipti on
475-1002-02
475-1000-02
475-1003-02
Echolink (I R) Receiver
Echolink (IR) Transmitter
Universal Charging Base
1
1
2
1
12V DC ,500mA power supply570-1011-01
Echolink sleeve490-1008-01
490-1005-01
940-1009-01
Headset under chin101
Echo ILoop910-1003-01
EchoLink (IR) instructions
202/M Microphone on a 1.5m lead
1
1
1
1
1
1
306/B Combo lead1
Echolink carton
1201/B Scart/ phono plug

Technical Specifications
11
Optional：
2 x AAA Alkaline batteries
Single channel 2.3 / 2.8Mhz
Stereo or mono mode of operation
1,060mAh LI-ION battery (receiver)
(not serviceable by the end user)
Volume (dB) 0 ~ -20dB (receiver)
DC 12V
TX can also be powered by
Power supply of receiver：Li-ion rechargeable battery
Dimensions: transmitter 115 x 75 x 20mm,
receiver 90mm x 55mm x 30mm,
charging base 75mm x 85mm x 30mm
Power supply of transmitter
Positive Centre min 200mA
:

Conformity
UK: Waste electrical products and batteries should not
be disposed of with household waste. Separate disposal
facilities exist, for your nearest facility see www.recycle-
more.co.uk or Hearing Products International Limited for
full details www. hear4you.com
Hearing Products International Limited
Echo House, 26/27 Haigh Park, Stockport, SK4 1QR, England
Tel. [phone]
Fax [phone]
www.hear4you.com
RoHS
E & O.E
Hearing Products International Ltd. reserve sole right to alter prices, design
and/ or technical specifications or colours without prior notice. EchoLink (IR)
Universal Instructions © Copyright Hearing Products International Limited.E&OE 19/07/16. Version 2.
