Ecom Tab-Ex 03 DZ2 User manual
1
Operating Instructions | Betriebsanleitung
Instructions d‘utilisation | Istruzioni per l‘uso
Instrucciones de uso | Instruções de funcionamento
Tab-Ex® 03 DZ2
ZONE 2 / 22
2
English Page 3
Deutsch Seite 24
Français Page 45
Italiano Page 66
Español Página 87
Portoguês Sida 108
3
Content
1. Application ....................................................................................................................4
2. Safety precautions .......................................................................................................4
3. Radiation Exposure Statement.....................................................................................4
4. Band and mode ............................................................................................................5
5. Repair ...........................................................................................................................5
6. Inserting the SIM/USIM card (LTE/WWAN model only) and microSD card ................5
7. Charging the tablet computer........................................................................................6
8. Safety precautions for the battery ................................................................................6
9. Cleaning, maintenance and storage.............................................................................7
10. Disposal ......................................................................................................................7
11. Warranty and liability...................................................................................................8
12. Device layout and functions........................................................................................8
Note:
The current Operating Instructions, Ex-Safety Instructions, EU Declaration of Conformity
and the Certicate of Conformity can be downloaded from the relevant product page at
www.ecom-ex.com, or alternatively they can be requested directly from the manufacturer.
4
1. Application
The Tab-Ex
®
03 is an intrinsically safe Zone 2 / Zone 22 water-, dust- and impact resis-
tant tablet computer for industrial application in hazardous areas with gaseous and dust
atmospheres according to ATEX Directive 2014/34/EU and the IECEx System.
2. Safety precautions
These safety instructions contain information and safety regulations which are to be
observed. Non-observance of this information and these instructions can have serious
consequences and may violate regulations. Please read these safety instructions
carefully before starting to use the device. In the event of conicting information the
details specied in the safety instructions shall apply. In case of any doubt (in the form
of translation or printing errors) the English version shall apply.
3. Radiation Exposure Statement
Warning: This equipment complies with International Commission on Non-Ionizing
Radiation Protection (ICNIRP), IEEE C95.1, Federal Communications Commission
Ofce of Engineering and Technology (OET) Bulletin 65 and European Committee
for Electrotechnical Standardization (CENELEC) EN62311 limits for exposure to radio
frequency (RF) radiation.
The FCC ID is printed on the device label.
The Ex-Protective Case has to be removed to nd the info.
3.1 SAR values for European countries:
The SAR values below are only for devices developed for use in European countries.
The SAR limit is 2.0 W/kg.
Maximum SAR for this model and conditions under which it was recorded:
Body-worn SAR: 1.390 W/kg
Head SAR: 1.091 W/kg
3.2 SAR values for USA:
The SAR values below are only for devices developed for use in USA.
The SAR limit is 1.6 W/kg.
Maximum SAR for this model and conditions under which it was recorded:
Body-worn SAR: 1.390 W/kg
Simultaneous Transmission: 1.58 W/kg
5
4. Band and mode
Band and mode Output power
EGSM 850/900 33 dBm
DCS 1800/1900 30 dBm
WCDMA 900/2100 24 dBm
LTE 1/2/3/4/5/7/8/12/13/17/20/28/38/40/41/66 23 dBm
Wi-Fi 2.4 GHz 20 dBm
Bluetooth 2.4 GHz 20 dBm
Wi-Fi 5.1-5.7 GHz 23 dBm
Wi-Fi 5.8 GHz 25 mW
NFC 13.56 MHz 42 dBuA/m at 10 m
The use of WLAN band is restricted to indoor use only. This restriction will be applied in
all EU member states.
AT BE BG CH CY CZ DE DK EE ES EL
FI FR HR HU IE IS IT LI LT LU LV
MT NL NO PL PT RO SE SI SK TR UK
5. Repair
Repairs are to be conducted by ECOM Instruments GmbH or by personnel or service
centers authorized by ECOM Instruments GmbH only, due to the safety of the device
needs to be tested after repairs are implemented. The actual repair report sheet can be
downloaded from the service area at
www.ecom-ex.com.
6. Inserting the SIM/USIM card (LTE/WWAN model only) and microSD card
1. Remove the Ex-Protective Case of the device.
2. Pull out the tray gently from the tray slot.
3. Place the SIM or USIM card on the tray with the gold-coloured contacts facing
downwards.
4. Gently press the SIM or USIM card into the tray to secure it.
5. Attach the Ex-Protective Case.
See also Picture Page 19
6
7. Charging the tablet computer
Charging the tablet computer is allowed only outside hazardous areas!
The battery of the tablet computer is delivered not fully charged. It is recommended to
charge the tablet computer’s battery for ve hours before using it for the rst time. The
full capacity of the battery is reached after 3 - 4 complete charge / discharge cycles.
Note:
•
There is a risk of explosion if the device is exposed to a ame.
•
Only use ECOM-approved chargers.
Due to EX-relevant safety, the battery cover is sealed and may only be opened by
ECOM service personnel. Likewise, battery replacement may only be carried out by
these personnel.
8. Safety precautions for the battery
Damaged chargers should be removed from use and sent to ECOM Instruments GmbH
for inspection.
Note:
•
Extreme temperatures can have an adverse effect on charging the battery.
•
Do not dispose of the device in a re.
•
Dispose of the device in accordance with local regulations and not with normal house-
hold waste.
A high quality lithium-ion battery is used in your Tab-Ex®03. These batteries have
numerous advantages in everyday use, such as a low weight and high capacity in a
nevertheless compact construction. In addition these batteries also exhibit practically
no memory effect. However, these batteries are susceptible to a natural aging process
which impairs their functionality.
Modern batteries today have a lifespan of around 500 charge cycles, which, when used
daily, corresponds to a service life of approximately two years. The ageing process in-
creases rapidly after this period, which means that the batteries are deemed technically
defective after 500 charge cycles. Moreover, the battery cells could expand and cause
irreparable damage to your device in a worst case scenario. For this reason recharge-
able batteries with lithium cells should be replaced from ECOM service personnel,after
two years at the latest or after reaching a battery capacity that is 50% of its initial value.
7
Note:
The battery used in this unit poses a re hazard and can cause chemical injuries if it is
used improperly. Neither the battery nor the battery cells should be opened or disas-
sembled and they should not be burned or exposed to temperatures exceeding 60 °C.
9. Cleaning, maintenance and storage
•
Only use a suitable cloth or sponge to clean the tablet computer.
•
Do not use any solvents or abrasive cleaning agents when cleaning.
•
It is recommended that you have the functionality and accuracy of the phone
inspected by the manufacturer every two years.
•
Do not exceed the permissible storage temperature range of -20 °C to +60 °C
10. Disposal
Old electrical devices by ECOM Instruments GmbH will be directed to disposal at our
expense and disposed of free of charge in accordance with European Directive 2012/19/EU.
Please follow local regulations for the disposal of electronic products. The costs associated
with returning devices to ECOM Instruments GmbH are to be borne by the sender.
Old electrical devices should not be disposed of along with normal or household waste.
Dispose of batteries in accordance with European Directive 2006/66/EC.
Batteries should not be disposed of with normal or household waste.
Disposal can be done via appropriate collection points in your country.
8
11. Warranty and liability
The warranty of this product follows the General Conditions of Delivery and Payment of
ECOM Instruments GmbH, which are available at www.ecom-ex.com, or alternatively
they can be requested directly from the manufacturer.
This warranty can be extended by the optional Service Level Agreement.
12. Device layout and functions
Package contents
Refer to the quick start guide for package contents.
• The items supplied with the device and any available accessories may vary
depending on the region or service provider.
• The supplied items are designed only for this device and may not be compatible
with other devices.
• Appearances and specications are subject to change without prior notice.
• A case is supplied to protect your device. If you want to remove the case attached
to the device, it is recommended to detach it from the top corners.
9
Device layout (WWAN / WiFi)
Proximity
Light sensor
Speaker
(WWAN)
WWAN:
SIM card /
Memory
card tray
► WiFi:
Memory
card tray
Keyboard
dock port
Recents key
Home key
(Fingerprint
recognition
sensor only
with
Tab-Ex®03 D2
)
Front camera
Volume key
Side key
(Power/Bixby)
Active key
Touchscreen
Back key
Multipurpose
jack
(USB Type- C)
10
Device layout (WWAN / WiFi)
Rear camera
Main antenna
(WWAN)
Flash
Back Cover
Microphone
Microphone
GPS antenna
NFC antenna
Speaker
Earphone jack
The Tab-Ex
®
03 is based on the Samsung tablet SM-T57x.
We do not make any changes to the operating system.
You will therefore receive software updates directly from Samsung (via OTA).
You can obtain the latest security information at https://security.samsungmobile.com/
11
• When using the speakers, such as when playing media les or using speakerphone,
do not place the device close to your ears.
• Be careful not to expose the camera lens to a strong light source, such as direct
sunlight. If the camera lens is exposed to a strong light source, such as direct
sunlight, the camera image sensor may be damaged. A damaged image sensor is
irreparable and will cause dots or spots in pictures.
• If you use the device with its glass or acrylic body broken, there may be a risk of
injury. Use the device only after it has been repaired at a ECOM Service Centre.
• If dust or foreign materials enter the microphone, speaker, or receiver, the device’s
sound may become quiet or certain features may not work. If you attempt to
remove the dust or foreign materials with a sharp object, the device may be
damaged and its appearance may be affected.
• Connectivity problems and battery drain may occur in the following situations:
– If you attach metallic stickers on the antenna area of the device
– If you attach a device cover made with metallic material to the device
– If you cover the device’s antenna area with your hands or other objects while
using certain features, such as calls or the mobile data connection (WWAN)
• Using a ECOM-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
• Do not cover the proximity/light sensor area with screen accessories, such
as a screen protector, stickers, or a cover. Doing so may cause the sensor to
malfunction.
• The light may icker at the top of the device during calls due to proximity sensor
operation.
12
Hard keys
Volume key
Side key
(Power/Bixby)
Active key
Back key
Home key
Recents key
Key Function
Volume key • Press to adjust the device volume.
Side key • When the device is off, press and hold to turn it on.
• Press to turn on or lock the screen.
• Press and hold to start a conversation with Bixby.
Refer to Using Bixby for more information.
•
Press twice or press and hold to launch the app or feature you set.
Side key +
Volume Down key
• Press simultaneously to capture a screenshot.
• Press and hold simultaneously to turn off the device.
Active key • Press or press and hold to launch preset apps.
Recents key • Press to open the list of recent apps.
Home key • Press to turn on the screen while the screen is locked.
• Press to return to the Home screen.
• Press and hold to launch Google Assistant app.
Back key • Press to return to the previous screen.
13
Setting the Side key
Select an app or feature to launch by pressing the Side key twice or pressing and
holding the Side key.
Launch the Settings app, tap Advanced features → Side key, and then select an option
you want.
S Pen
S Pen button
S Pen nib
Name Functions
S Pen nib • Use the S Pen to write, draw, or perform touch actions on the
screen.
• Hover the S Pen over items on the screen to access additional
S Pen features, such as the Air view feature.
S Pen button • Hover the S Pen over the screen and press the S Pen button to
display the Air command features.
• While pressing and holding the S Pen button, drag the S Pen over
items to select them.
Replacing the S Pen nib
If the nib is dull, replace it with a new one.
1 Firmly hold the nib with the tweezers and remove it.
2 Insert a new nib into the S Pen.
14
Be careful not to pinch your ngers with the tweezers.
• Do not reuse old nibs. Doing so may cause the S Pen to malfunction.
• Do not press the nib excessively when inserting the nib into the S Pen.
• Do not insert the round end of the nib into the S Pen.
Doing so may cause damage to the S Pen or your device.
• Do not bend or apply excessive pressure with the S Pen while using it.
The S Pen may be damaged or the nib may be deformed.
• Do not hard press on the screen with the S Pen. The pen nib may be deformed.
• If you use the S Pen at sharp angles on the screen, the device may not recognise
the S Pen actions.
• If the S Pen is not working properly, take it to a ECOM Service Centre.
Battery
Do not bend or twist the Ex-Battery cover.
Doing so may damage the Ex-Battery cover.
Charging the battery
Charge the battery before using it for the rst time or when it has been unused for
extended periods.
Use only ECOM-approved charger and cable specically designed for your
device. Incompatible charger and cable can cause serious injuries or damage
to your device. See MAS-0178 for additional battery charging safety.
15
• Connecting the charger improperly may cause serious damage to the device.
Any damage caused by misuse is not covered by the warranty.
• Use only USB Type-C cable supplied with the device.
The device may be damaged if you use Micro USB cable.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
1 Connect the USB cable to the USB power adaptor.
2 Plug the USB cable into the device’s multipurpose jack.
3 Plug the USB power adaptor into an electric socket.
4After fully charging, disconnect the charger from the device.
Then, unplug the charger from the electric socket.
The battery cover or battery may only be removed by ECOM service personnel!
This may damage the device.
16
Reducing the battery consumption
Your device provides various options that help you conserve battery power.
• Optimise the device using the device care feature.
• When you are not using the device, turn off the screen by pressing the Side key.
• Activate power saving mode.
• Close unnecessary apps.
• Deactivate the Bluetooth feature when not in use.
• Deactivate auto-syncing of apps that need to be synced.
• Decrease the backlight time.
• Decrease the screen brightness.
Battery charging tips and precautions
• When the battery power is low, the battery icon appears empty.
• If the battery is completely discharged, the device cannot be turned on immediately
when the charger is connected. Allow a depleted battery to charge for a few minutes
before turning on the device.
• If you use multiple apps at once, network apps, or apps that need a connection to
another device, the battery will drain quickly. To avoid losing power during a data
transfer, always use these apps after fully charging the battery.
• Using a power source other than the charger, such as a computer, may result in a
slower charging speed due to a lower electric current.
• The device can be used while it is charging, but it may take longer to fully charge the
battery.
• If the device receives an unstable power supply while charging, the touchscreen may
not function. If this happens, unplug the charger from the device.
• While charging, the device and the charger may heat up. This is normal and should not
affect the device’s lifespan or performance. If the battery gets hotter than usual, the
charger may stop charging. If this occurs during wireless charging, disconnect the
device from the charger to let it cool down, then charge the device again later.
•
If you charge the device while the multipurpose jack is wet, the device may be damaged.
Thoroughly dry the multipurpose jack before charging the device.
• If the device is not charging properly, take the device and the charger to a ECOM
Service Centre.
Fast charging
The device has a built-in fast charging feature. You can charge the battery more quickly
while the device or its screen is turned off.
17
Increasing the charging speed
To increase the charging speed, turn the device or its screen off when you charge the
battery. If the fast charging feature is not activated, launch the Settings app, tap Device
care → Battery → Charging, and then tap the Fast charging switch to activate it.
• While charging, you cannot activate or deactivate this feature.
• You cannot use the built-in fast charging feature when you charge the battery
using a standard battery charger.
• If the device heats up or the ambient air temperature rises, the charging speed may
decrease automatically. This is a normal operating condition to prevent damage to
the device.
SIM or USIM card (nano-SIM card) (WWAN)
Installing the SIM or USIM card
Insert the SIM or USIM card provided by the mobile telephone service provider.
• Use only a nano-SIM card.
• Use caution not to lose or let others use the SIM or USIM card. ECOM is not
responsible for any damages or inconveniences caused by lost or stolen cards.
Some services that require a network connection may not be available depending on
the service provider.
18
1Pull out the tray gently from the tray slot.
2 Place the SIM or USIM card on the tray with the gold-coloured contacts facing
downwards.
3Gently press the SIM or USIM card into the tray to secure it.
If the card is not xed rmly into the tray, the SIM card may leave or fall out of the tray.
4Insert the tray back into the tray slot.
• If you insert the tray into your device while the tray is wet, your device may be
damaged. Always make sure the tray is dry.
• Fully insert the tray into the tray slot to prevent liquid from entering your device.
Memory card (microSD card)
Installing a memory card
Your device’s memory card capacity may vary from other models and some memory
cards may not be compatible with your device depending on the memory card manu-
facturer and type. To view your device’s maximum memory card capacity, refer to the
Samsung website.
• Some memory cards may not be fully compatible with the device.
Using an incompatible card may damage the device or the memory card, or corrupt
the data stored in it.
• Use caution to insert the memory card right-side up.
• The device supports the FAT and the exFAT le systems for memory cards.
When inserting a card formatted in a different le system, the device will ask to
reformat the card or will not recognise the card. To use the memory card, you must
format it.
19
If your device cannot format or recognise the memory card, contact the memory
card manufacturer or a ECOM Service Centre.
• Frequent writing and erasing of data shortens the lifespan of memory cards.
• When inserting a memory card into the device, the memory card’s le directory
appears in the My Files → SD card folder.
► WWAN:
► WiFi:
20
1Pull out the tray gently from the tray slot.
When you remove the tray from the device, the mobile data connection will be
disabled. (WWAN)
2 Place a memory card on the tray with the gold-coloured contacts facing downwards.
3Gently press the memory card into the tray to secure it.
If the card is not xed rmly into the tray, the memory card may leave or fall out of the
tray.
4Insert the tray back into the tray slot.
• If you insert the tray into your device while the tray is wet, your device may be
damaged. Always make sure the tray is dry.
• Fully insert the tray into the tray slot to prevent liquid from entering your device.
Removing the memory card
Before removing the memory card, rst unmount it for safe removal.
Launch the Settings app and tap Device care → Storage → Advanced → SD card →
Unmount.
Do not remove external storage, such as a memory card or USB storage, while the
device is transferring or accessing information, or right after transferring data. Doing
so can cause data to be corrupted or lost or cause damage to the external storage or
device. ECOM is not responsible for losses, including loss of data, resulting from
the misuse of external storage devices.
Table of contents
Languages:
Other Ecom Tablet manuals
