EcoQuest Ocean Breeze User manual

Common problems and troubleshooting
11
Water mist overflow
from the nozzle
Malfunction
Light is out, no
wind, no mist
Light is on, no
wind, no mist
Low mist density
Water can not
reach the base
Water shortage
alarm with water
in the water tank
Stops working
during use
Abnormal noise
Cause Analysis
No power
Water level of the water
tank is too high
Transducer with water
scale
Dirty water or water
stored for long time
Cracks between spray
nozzle and water tank
Dirty knob or improper
placement of the water
tank
Room humidity reaches
the selected level
Little water in the water
tank
Desktop resonance
Processing Method
Reconnect the power
Pour some water out
of the water tank and
close tightly the tank knob
Clean the transducer
Replace the water
Soak the spray nozzle
before using
Clean the knob cover
and replace the water
tank
Install the water
shortage protective
floater in place
If work continuously,
please turn off the
humidity function and
adjust the temperature
Add water into the
water tank
Place on a solid desktop
The water shortage
protective floater is
improperly installed
"Ocean Breeze"
Air Humidifier
Instruction Manual

Product working principle
Product features
Air humidifier is based on ultrasonic that produces high
frequency oscillation which atomize the water into 1~5
microns particles that further being spread into air by fan
as a water mist.
The optimal air humidity in the room is 45~60%RH and
the temperature is 68~77F°. These are optimal
conditions for your health & mind condition and
recommended for working & resting.
It can prevent static electricity & generate anion which
improves your feeling.
1. Improved design with larger capacity water tank for
extending working time.
2. Improved design for top water filler.
3. Touch pad and timer function for convenient control.
4. Safety protection system: automatic power off if
wateris in shortage.
6. Controllable humidity ratio.
12
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do
not play with the appliance.
•If the supply cord is damaged, it must be replaced
bythe manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
•Unplug the appliance during filling and cleaning.
•Children shall not play with the appliance.
•Before using the air humidifier, please confirm
whetherthe marked voltage is consistent with local
voltage.
•Place the machine far away from sources of heat, direct
sunlight, and at least 2 meters away from other
furniture to avoid moisture.
•Do not block the air inlet or outlet.
•Care should be taken when using the appliance due
tothe emission of hot water vapor.
Warning

34
Product structureProducts and accessories
1. Air humidifier 2. Instruction manual
3. Remote control
Technical parameters
Description Air humidifier
Model Ocean Breeze
Operating voltage 110V
Rated frequency 50-60Hz
Rated power 18W
Mist productivity 200mL/h
Water capacity 4.5L
Noise level ≤35dB(A)
1 2 3
"Ocean Breeze"
Air Humidifier
Instruction M anu al
POW ER
FOGMETER
TIM ER
HUMIDITY
BRIGHTNESS
Base
Water tank
Water tank cap
Touch Pad
Transducer
magnetic valve

5 6
Timer: Press "Timer" button to activate the timer
function. Set timer ranges from 1~12 hours. The
touch pad displays the time remaining.
TIMER
Humidity: Set the humidity, 40, 45, 50, 55, 60, 65,
70, 75, 80, 85 and 90% RH optionally. Touch pad
shows the relative humidity. Press "Humidity"
button, to display ranges by low - high - shutdown
grade & touch pad flashes accordingly. After setting
the humidity for 5 seconds, touch pad restores the
current humidity & "%RH" icon flashes.
HUMIDITY
Function menu
Fogmeter: Press the "Fogmeter" button to set the
density of the fog. Tap the button to vary and
choose from low- middle- high- grades. The touch
p a d d i s p l a y s l o w, m i d d l e o r h i g h l e ve l
correspondingly.
FOGMETER
Power: Press the "Power" button. The air
humidifier starts working and the touch pad lights
up. Press again for switching off.
POWER
Operating manual
1. Open the packaging and take out the product.
2. Remove any plastic packaging.
3. Remove the water tank cap.
4. Add water from the top with room-temperature water
(should be between 60 and 104F°).
5. Install the water tank cap.
6. Switch the power on.
BRIGHTNESS
HUMIDITY
Timer / H
FOGMETER
TIMER
POWER
Water shortage: When no water or water in level
is low, red water shortage icon start flashing and the
machine alarms. Then it automatically shut down.
Water shortage
Brightness: Press the "Brightness" button, the
touch pad turns off. Press any button, the touch
pad lights up again.
BRIGHTNESS

87
Security Guide
•Please study this instruction manual carefully before
using the product. Keep it for reference.
Warning
•Do not allow any liquid to come on a surface or into the
components of the touch pad and the bottom of the
product. It could lead to the electric circuit and fire.
•Do not immerse the air humidifier into water or any
other liquids.
Notice
•Place the appliance and keep it at room temperature for
30 minutes before the initial use.
•Do not allow to unplug with wet hands in order to avoid
electric shock.
•A loose contact between the plug and AC outlet may
cause overheating. Make sure of good connection
between the plug and AC outlet.
•Please place & use the air humidifier on a dry, stable,
flat and horizontal surface.
•Do not place the air humidifier under the air conditioner
directly to avoid the condensed water.
•Use at normal room temperature, humidity.
Matters needing attention
Remote control menu
The operation of remote control is the same as touch
pad.
POWER
FOGMETER
TIMER
HUMIDITY
BRIGHTNESS
Power: Power On / Off control.
Fogmeter: Fogmeter control.
Humidity: Humidity control.
POWER
HUMIDITY FOGMETER
TIMER BRIGHTNESS
Timer: Timer control.
Sleep: Brightness control.

•Before turning on the power, make sure that the water
tank is properly installed and filled with water according
to the instruction.
•Do not insert fingers or any other objects into air inlet
and outlet.
•Do not use the air humidifier in high humidity or high
temperature premises such as bathroom or kitchen,
and where combustible gases, heating appliances or
vapors are present.
•Do not move the air humidifier while the power is on
and water inside, to avoid burning the internal
electronic components.
Tips for using air humidifier
The most comfortable surrounding humidity
for human 45~65%RH
The most advantageous surrounding humidity
for disease control & treatment 40~55%RH
Surrounding humidity for computer & telecom
equipment 45~60%RH
Surrounding humidity for household & musical
instruments 40~60%RH
Surrounding humidity for library, art gallery &
museum 40~60%RH
Routine maintenance
9 10
Since different regions' water contains different calcium
& magnesium ion, etc., when air humidifier works, some
of surfaces to be sprayed with water mist & then become
whiting after drying. Some of them become water scale
in air humidifier. Please clean the water scale & use clean
filtered water to increase the effect of air humidifier.
1. How to keep air humidifier clean?
●Use pure filtered (or distilled) water to humidify.
●Clean the transducer, water tank & machine base
weekly. Change the water in time. If the air humidifier
is not been used for a long time, remove the water
from the water tank & water channels.
●Do not use hard objects when cleaning to avoid
scratching the transducer.
●When clearing away, please clean and wipe up every
part of the air humidifier, or air-dry the water.
2. How to clean the transducer and machine base?
●Before cleaning, please be sure to turn off the power
and unplug the power plug.
●Spray the cleanser onto the machine base, swipe it and
soak for 5~10 minutes.
●Wash the surface with a clean brush until the scale removed.
●Meanwhile clean the machine base and the transducer
surface.
