Ecowell LULU QUICK CLEAN User manual

SKU#/SKU#/SKU#/Artikelnummer#/
SKU#/SKU#: P05
USER MANUAL/
MANUEL D’UTILISATEUR/MANUAL DE
USUARIO/BEDIENUNGSANLEITUNG/
GEBRUIKERSHANDLEIDING/MANUALE
UTENTE
Lea y comprenda cuidadosamente el Manual de Usuario antes de usar este producto. Contiene información
importante sobre su seguridad, así como recomendaciones de operación y mantenimiento.
Lesen Sie diese Bedienungsanleitung vor der Benutzung des Geräts sorgfältig und machen Sie sich mit ihr vertraut. Sie
enthält wichtige Informationen für Ihre Sicherheit sowie Hinweise zu Betrieb und Wartung.
Lees en begrijp deze gebruiksaanwijzing grondig alvorens het product te gebruiken. Hij bevat belangrijke informatie
voor uw veiligheid en adviezen voor gebruik en onderhoud.
Prima di utilizzare il prodotto, leggere e comprendere con attenzione questo manuale di istruzioni. Contiene informazi-
oni importanti per la vostra sicurezza e consigli per l'uso e la manutenzione.
Read and understand this instruction manual thoroughly before
using the product. It contains important information for your
safety as well as operation and maintenance advice.
Veuillez lire et comprendre attentivement le présent manuel
d’utilisateur avant l’utilisation du produit. Il contient des
informations importantes pour votre sécurité ainsi que des
recommandations d’opération et de maintenance.
WET/DRY VACUUM & WASH
ASPIRATEUR-NETTOYEUR HUMIDE/SEC
LAVADORA HÚMEDA/SECA DE VACÍO
NASS/TROCKENSAUGER UND -WISCHER
NAT/DROOGZUIGEN & WASSEN
ASPIRAZIONE A UMIDO/SECCO E LAVAGGIO

IMPORTANT SAFETY INSTRUCTIONS..........................................................................2
PRODUCT OVERVIEW...........................................................................................................4
WHAT'S IN THE BOX...............................................................................................................5
DISPLAY.........................................................................................................................................6
ASSEMBLY & DISASSEMBLY.............................................................................................7
PRODUCT OPERATION.........................................................................................................8
SELF-CLEANING & SELF-DRYING.................................................................................10
DAILY MAINTENANCE & PRODUCT CARE................................................................11
CLEANING ROLLER COVER..............................................................................................12
STORAGE.....................................................................................................................................12
SPECIFICATIONS.....................................................................................................................13
DISPOSING OF THE BATTERIES.....................................................................................14
TROUBLESHOOTING............................................................................................................15
FREQUENTLY ASKED QUESTIONS...............................................................................16
WARRANTY................................................................................................................................17
WARRANTY CARD.................................................................................................................18
CONTENTS
EN

EN
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using your appliance. If you pass the appliance to a
third party for use, please attach this manual to the appliance. When using an
electrical, basic precautions should be observed, including the following:
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:
2
1. Use indoors only. Do not use the appliance in outdoor, commercial or industrial
environments.
2. Do not allow to be used as a toy. Children should be supervised to ensure that they do
not play with the appliance.
3. Only use as described in this user manual. Only use attachments recommended or
sold by the manufacturer.
4. Do not charge with damaged power cord or plug. Ensure not to damage the power
cord or plug.
5. Do not handle charging base, charging plug or appliance with wet hands.
6. Do not put any object into openings. Do not use with any opening blocked; keep free
of dust, lint, hair and anything that may reduce air flow.
7. Keep hair, loose clothing, fingers, and all parts of body away from openings and
moving parts of the appliance and its accessories.
8. Do not use to pick up flammable or combustible materials such as gasoline, printer or
copier toner, or use in areas where they may be present.
9. Do not use to pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
10. Do not use to pick up sharp objects, such as metallic nails, pieces of glass, metal
paper clips, or pins.
11. Do not use to pick up hazardous material and chemicals, such as solvent, drain
cleaner, strong acids, or strong alkali.
12. Do not use to pick up ultrafine particles, such as lime, cement, sawdust, gypsum
powder, or ashes.
13. Do not use the appliance in an enclosed space filled with vapors given off by
oil-based paint, paint thinner, some moth-proofing substances, flammable dust, or
other explosive or toxic vapors.
14. Do not use without filter in place.
15. Recharge only with the adapter specified by Ecowell. An adapter that is suitable for
one type of battery pack may cause a risk of fire when used with another battery
pack.
16. Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion or
risk of injury.
17. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
18. Do not expose a battery pack or appliance to fire or excessive temperature. Exposure
to fire or temperature above 130°C/265°F may cause explosion.

EN
3
19. Follow all charging instructions and do not charge the battery pack or appliance
outside of the temperature range 4-40°C/40-104°F. Charging improperly or at
temperatures outside this range may damage the battery and increase the risk of fire.
20. Always turn off the appliance before cleaning and servicing.
21. Do not charge the appliance outdoors.
22. Stop using immediately if the appliance is overheating, making unusual noises,
producing unusual odors, performing low suction, or leaking electricity.
23. Store appropriately indoors in a dry place after use.
24. Do not immerse in water or liquid. Do not place or submerge appliance in standing
water or try to clean flooded areas. Use only on surfaces moistened by the cleaning
process.
25. Keep cord away from heated surfaces.
26. Do not incinerate the appliance even if it is severely damaged. The batteries can
explode in a fire.
27. Plastic film can be dangerous. To avoid danger of suffocation, keep away from babies
and children.
28. The battery must be removed from the appliance before it is scrapped.
29. The charging base with drying function is only for Ecowell LULU QUICK CLEAN P05.
30. Do not add other solutions, such as alcohol, disinfectant, etc.
31. Do not add cleaning solutions that are prone to foaming.
1. Do not modify or attempt to repair the appliance except as indicated in the
instructions for use and care.
2. Charge the appliance with the Ecowell adapter. Input Voltage: 110-120V. Both high and
low voltages can damage the adapter, appliance, or even cause danger to the user.
3. Use extra care when cleaning on stairs.
4. Ensure that the Power Switch is in the OFF-position before picking up or carrying the
appliance. Do not lay flat or lean the appliance so as to prevent dirty water from
entering into the motor.
5. To avoid being tripped accidentally, please put away the appliance on the charging
base.
6. Always install the dirty water tank and clean water tank properly before use.
7. Do not allow the appliance, charging base or adapter to get wet to avoid risk of fire or
injury caused by a short circuit.
ABOUT THE APPLIANCE
1. The wet/dry vacuum & wash cleaner is to be used on indoor hard floors, such as vinyl,
tile, sealed wood, etc. Use on a rough surface may not get the best performance.
2. Keep the appliance away from heat sources, such as fireplace or heater, to avoid
causing deformation.
3. Do not use to pick up flammable or combustible liquids, ultrafine particles, sharp
objects, hazardous material, chemicals or anything that is burning or smoking, as
described above.
RANGE OF USAGE

AB
G
F
K
C
D
E
I
H
J
L
A. ECO/MAX Mode Button
B. Water Volume Button
C. Power Button
D. Handle
E. Display
F. Clean Water Tank
G. Clean Water Tank Release
H. Dirty Water Tank
I. Dirty Water Tank Release
J. Roller Cover
K. Charging Position
L. Roller
PRODUCT VIEW
EN
4

WHAT'S IN THE BOX
Handle & Body × 1 Charging Base with Adapter × 1
Roller × 2 Cleaning Tool × 1 Filter × 2
EN
5

EN
DISPLAY
A
B
D
E F
C
G
A.
B.
C.
D.
E.
F.
G.
Self-Cleaning Button
Clean Water Tank Shortage Indicator
Charging Indicator
Roller Error Indicator
Battery Level Indicator
MAX Mode Indicator
Dirty Water Tank Full Indicator
6

ASSEMBLY & DISASSEMBLY
Insert the handle connecting tube
into the machine component port,
and it will be installed in place when
you hear the "click".
To disassemble, insert a tool into
the disassembly hole on the back
of the body, press firmly against the
stopper, and pull the handle
upward to complete the disassem-
bly.
To disassemble the roller cover,
press the front button with your
thumb, break it up, and remove the
roller cover.
To disassemble the roller, pull up the
left roller handle with your fingers to
remove it.
Disassemble Roller Cover Disassemble Roller
White Button
Assemble Handle Disassemble Handle
EN
7

PRODUCT OPERATION
To remove, hold the fuselage with
one hand, grasp the clean water
tank groove and clean water tank
release with the other hand and
pull back.
Clean Water Tank
Release
Please align the groove on the right
side of the roller with the drive shaft,
and then press down on the left side
of the roller until it is installed in
place.
First align the snap of the roller
cover, then press the roller cover
and hear a "click" to install
successfully.
Assemble Roller Assemble Roller Cover
Unscrew the cap, and inject tap
water (under 40°C/104) to the max
water level. Close the cap of the
clean water tightly to make sure it is
tight and not loose.
Align the bottom of the clean water
tank with the groove and push the
tank until it "clicks" into place.
EN
8
1
2 3
click

Press the power button to turn
on. Switch ECO/MAX mode
according to floor conditions.
Tilt the angle properly.
Pull the machine backwards to start
using it. Stand the machine upright.
Tilt the angle properly.
Press the button once during
work, and the roller starts large
gear spraying water. Press this
button again, to return to the
default water volume.
Notice: The button can only be
used if the wet function on.
Before use, please make sure your
product is powered. If not, please
charge it in time (refer to and 
for details), and use it after fully
charged.
EN
9
4 5
6 7

Please place it on the base for
charging after use.
Notice:
Do not use this machine to absorb any high-temperature or corrosive
objects.
Do not tilt the machine to one side or lay it flat to prevent back sewage
from entering the motor.
The drying system is at the charging base. Remember to press the self-dry-
ing button on the charging base while starting self-cleaning.
Please do not rinse the base with water.
There will be a slight wind sound when the drying system is running, which
is normal. Please feel free to use.
Please empty the dirty water tank before
starting self-cleaning.
Press self-cleaning and self-drying but-
tons to clean and dry the roller.
The self-drying process starts automatically
after the self-cleaning process.
The drying system will operate for 34 minutes
to dry the roller.
To manually dry the roller and roller cover,
please check Page 12 of the user manual.
SELF-CLEANING & SELF-DRYING
Plug the machine adapter into
the outlet. Charging time is 3
hours.
EN
10
1
2
3
4
5
6
7
8
8
9
Self-cleaning can only be turned on over 10% of the battery.
WARNING

To remove, hold the fuselage with one hand, grasp the dirty water tank
groove and dirty water tank release with the other hand and pull back.()
Grab the front handle and pull the tank cover out.()
Dirty Water Tank
Release
DAILY MAINTENANCE & PRODUCT CARE
Clean up the dirt in the dirty water
tank. Remove the filter from above
the dirty water tank. ()
Clean the filter and the dirty water
tank cover with clean water. Dry the
components before reassembly. ()
Align the dirty water tank back into the body of the
machine. Insert the bottom of the tank first, then pivot
the top toward the machine until it "clicks" into place.
()
EN
11
click
1 2 3
4 5 6
7

Remove the roller cover, rinse with water and clean with a cleaning tool, and
wait until completely dry before installing.
CLEANING ROLLER COVER
1. Before routine maintenance or troubleshooting, unplug
the machine from the socket and turn off the power of
the machine.
2. Do not vacuum foam liquid.
3. Do not soak or rinse.
4. Do not store the product in a freezing and humid
environment.
WARNING
1. Clean the dirty water tank and the upper cover of the dirty
water tank immediately after use.
2. After using the machine, please store it in a dry place. A
humid place will affect the insulation and service life of the
machine.
STORAGE
EN
12
1 2 3 4

Product
Model
Operation Voltage
Rated Power
Battery Capacity
Charging Base Input
Charging Base Output
Clean Water Tank Capacity
Charging Time
Max Running Time
Weight
WET/DRY VACUUM & WASH
SC91
22.2V
220W
4400mAh
220-240V 50Hz
27V 1300mA
620ml
3h
30mins
4.5kg
SPECIFICATIONS
EN
13

1. The battery contains substances that are harmful to the environment and
must be removed from the body before discarding.
2. The machine must be powered off when the battery is removed.
3. Batteries, adapters, accessories, and packaging should be sorted for
environmental recycling.
4. Do not put them into fire, water or soil.
5. Do not dispose of batteries and adapters in the household garbage.
6. If battery fluid leaks come in contact with skin and clothing, rinse
immediately with water to avoid irritation and seek immediate medical
attention.
DISPOSING OF THE BATTERIES
EN
14

TROUBLESHOOTING
Problem
Not working
Low suction power
Strange sound from motor
No water coming out
Water leakage
Can not charge
Dirty water tank full
indicator flashing
Clean water tank shortage
indicator flashing
Roller error indicator
flashing
Motor malfunction
Possible Cause Solution
Low battery Charging before use
(100% battery is recommend)
Dirty water tank is full Take out the dirty water tank and
pour out the water
Debris blocking at the intake Clean the roller
Filter is dirty Clean the filter
Debris or tangled hair Clean the debris by the tube
or intake up
Hair or debris tangled
on the roller Clean the roller
Dirty water tank is full Take out the dirty water tank and
pour out the water
Clean water tank is empty Add water into clean water tank
The clean water tank is not
installed in place Reinstall the clean water tank
Filter not installed Install filter
Filter not dried completely Clean it up and dry it completely
Adapter is not plugged in well Check and plug the adapter into
a suitable wall outlet
Charging base not connected
with adapter well Check and reconnect
The dirty water in tank has
reached the MAX line
Empty the dirty water and then
reinstall the tank
Clean water tank is empty Refill the clean water tank
The roller is tangled or not
installed in place
Clean the roller or reinstall
the roller
Contact the after-sales service
Foam overflowing Too much cleaning solution.
Absorbed foamy material
We recommend using our
recommended cleaning solutions.
Do not absorb foamy material.
EN
15

FREQUENTLY ASKED QUESTIONS
Question Answer
What do you mean by 5-in-1? Wet pick up, dry pick up, multi-surface,
self-cleaning, self-drying.
What floors is this safe on? Hardwood, Laminate, Vinyl, Marble,
Linoleum, Low-Pile Carpet and Rugs.
Can I fill the water tank up with
just cleaning solution if it doesn’t
need to be diluted?
We recommend filling with water as well.
Too much cleaning solution can cause
sticky floors and streaks.
What cleaning solution
do you recommend?
Anything floor related, stay away
from dish soap.
Does my P05 get clogged? / too much
water coming out the roller
Yes, please empty out the dirt water tank.
You will hear the suction power kick.
Can I use vinegar and essential
oils with the water?
Yes, vinegar is ok, stray away from
essential oils as this may harm the floor.
Do I empty the dirty water tank
before or after self-cleaning?
Depends on if it is full or not! Ecowell
recommends waiting until after to get
all the debris off the roller!
Can I use it as just a vacuum? Yes.
Can I use it as a carpet cleaner?
No, it is not a carpet cleaner for
stain cleaning,
but can be used on carpet as a vacuum.
EN
16

EN
17
WARRANTY
Alton Industry Ltd. Group
2-Year Limited Warranty
This warranty covers any defects in materials or workmanship of the enclosed product. Alton
Industry Ltd. Group will repair or replace any defective materials due to craftsmanship of the
product. This warranty does not cover any problem caused by misuse, abuse, accidents or acts
of God, such as floods or hurricanes. Consequential and incidental damages are not covered
under this warranty. Coverage terminates if you sell or otherwise transfer the ownership. If you
feel you have a defective product, please submit a copy of your receipt to the address below
and call 1-888-899-0146 for instructions prior returning this item to the store or sending back to:
Alton Industry Ltd. Group
Alton Europe BV, Logistiekweg 18, 4906 AB Oosterhout, The Netherlands
We will inspect the product and contact you within 72 hours to give you the results of our
inspection. We reserve the right to repair or replace the product at our discretion. However, we
may replace the product with one of similar but not exact features.
Parts and Service Information available e-mail Alton Industry [e-mail].
This warranty gives you specific legal rights. You may have other rights which vary from state to
state.
ALTON INDUSTRY LTD. GROUP
Alton Europe BV, Logistiekweg 18, 4906 AB Oosterhout, The Netherlands
https://www.ecowell.com
[e-mail]

EN
18
[e-mail]
WARRANTY CARD
AFTER-SALE SERVICE
Purchase Date:
Signature:
Order#:
Ecowell products own 24 months manufacturer and disteibutor
combined after-service. Please contact with us first, we will assist
you to solve the issues within 24 hours.
24 Months Warranty
24
MONTH
