Eden C1102C User manual

SAFETY AND MAINTENANCE INSTRUCTIONS
INSTRUCTIONS DE SECURITE ET D'ENTRETIEN
SICHERHEITS- UND WARTUNGSHINWEISE
GB
D
VEILIGHEIDS- EN ONDERHOUDSINSTRUCTIES
NL
F
SPECIFICATIONS
Effective pixels : PAL: 960x582 / NTSC: 967x494
Electronic shutter : 1/50 (1/60) to 1/100,000 seconds
Infrared lamps : 30
Infrared view distance : 30m
Horizontal Resolution : 650TVL
Minimum illumination : 0Lux
Lens options : 4 - 9mm
S/N Ratio : =52dB (AGC off)
Video Output : 1.0Vp-p, 75 ohms
Video Output : Mini DIN / BNC
Power : 12V DC/1000mA
Power Consumption : 5W
C1102C

GB
D
NL
F
a. Camera Dome
b. camera lens
c. IR leds for nightview
d. Camera Dome
a.
b. Kamera-Objektiv
c. Infrarot-LEDs für Nachtsicht
d. Kamera dome
Kamera dome
a.
b. Cameralens
c. IR-projectoren voor nachtzicht
d. Camera Dome
Camera Dome
a. Caméra dome metal intérieure
b. Objectif de la caméra
c. LED Infrarouge pour vision nocturne
d. Caméra dome
How to connect
1. < 60m
Extension cables
Extra accessories
Mini DIN
extension cables
- C9112 5m
- C9113 15m
- C9114 30m
AV (bnc) Monitor
DVR-Recorder
Mini DIN plug
Adapter
Mini DIN plug Mini DIN extension BNC
Adapter
2. > 60m Mini DIN plug BNC
Adapter
Overview
C9126
BNC
extension cables
with female adapter
- C9122 5m
- C9123 10m
- C9124 25m
- C9125 50m
BNC extension
- C9126 BNC to BNC male adapter 1pcs
- C9120 BNC male plugs 4pcs - C9121 BNC to RCA adapter 4pcs - C9129 150m cable RG59 black
DC12V
a.
d.
b.
c.
