EdgeStar FP430 User manual

V2.1-07122018
Portable Fridge / Freezer
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
To use the Ed
g
eStar sel
f
-
dia
g
nostic tool,
g
o to htt
p
s://su
pp
ort.ed
g
estar.com
FP430 / FP630 / FP861

i
Important Safety Information
Improper handling can cause serious damage to the EdgeStar portable fridge / freezer and / or
injury to the user. This fridge / freezer is designed for domestic use only. Do not use the unit
for industrial or commercial use. Any other use may invalidate the warranty. Please review
the ratings label located on the rear panel of the unit for electrical and other technical data
related to this unit. The unit must be used in a properly grounded wall outlet when using AC
power.
Please read and follow the safety information listed below to reduce the risk of fire,
electric shock, or injury.
Electrical Safety
 Do not exceed the power outlet ratings.
 Use outlets that cannot be turned off by a switch or pull chain.
 Never pull the power cord to disconnect it from the outlet. Grasp the plug directly and pull it from the
outlet.
 Never lift or carry the freezer by the power cord.
 Keep the power cord away from heated surfaces.
 Always turn the unit off and unplug it from the outlet when cleaning.
 Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
 Be sure the portable freezer is properly grounded.
 Never handle / operate the unit with wet hands or while standing on a wet surface.
 Keep the unit protected from rain, sleet, snow, and / or moisture.
 Do not bypass, cut, or remove the grounding plug.
 Do not use extension cords or power strips with this unit. Plug the power cord directly into an outlet.
 Do not modify the power cord’s length or share the outlet with other appliances.
 Do not start or stop the unit by switching the circuit’s power on and off.
 If the power cord is damaged, it must be replaced by the manufacturer or a qualified technician.
 Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and
contact customer service.
 Do not remove any part of the casing unless you are instructed to do so by an authorized
technician.
 You should never attempt to repair the unit yourself. Contact customer service for service options if
the unit needs service.
 Do not pinch or kink the power supply line between the unit and the cabinet.
Note: For your personal safety, this appliance must be grounded. It is equipped with a power
supply cord with a 3-prong grounding plug. To minimize possible shock hazard, the cord must
be plugged into a mating 3-pronged wall socket, and grounded in accordance with the
National Electrical Code and local codes and ordinances. If a mating wall socket is not
available, it is the personal responsibility of the customer to have a properly grounded, 3-
prong wall receptacle installed by a qualified electrician.

ii
Note: This owner’s manual is provided for reference use only. Specifications may change
without prior notice. Refer to the product label on your portable freezer for the latest technical
information.
General Safety
 To prevent back and other types of injuries, use at least two people to move the portable freezer.
 When positioning the portable freezer, ensure that there is at least 3” of clearance at the sides and
5” of clearance at the back of the unit to allow for proper ventilation of heat.
 To prevent the temperature from increasing dramatically, close the freezer lid immediately.
 This unit is not intended to be used by children. Children should be supervised to ensure that they
do not play with this appliance.
 Never allow children to crawl inside of the unit. If you are disposing of the unit, remove the door.
 If your model of portable freezer is equipped with a lock, be sure to keep the keys away from
children.
 Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
 Do not leave any cleaning solutions in the unit.
 Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
 Do not turn the unit upside down, on its side, or at an angle beyond 30 degrees.
 Only use the unit in an upright position on a flat and level surface.
 Make sure the unit is on a stable surface able to withstand the weight of the unit and all of its
contents.
 Do not move the unit without emptying the contents and securing the door in a closed position.
 The cord should be secured behind the unit and should not be left exposed to avoid damage and /
or injury.
 Unplug the unit if it is not going to be used for an extended period of time.

iii
Table of Contents
IMPORTANT SAFETY INFORMATION……………………………………………………………………………………... I 
TABLE OF CONTENTS……………………………………………………………………………………………………….. III
FIRST TIME OPERATING INSTRUCTIONS………………………………………………………………………………………….1
INTRODUCTION……………………………………………………………………………………………………………….. 1
PARTS IDENTIFICATION…………………………………………………………………………………………………….. 2
OPEN VIEW………………………………………………………………………………………………………………………..2
ACCESSORIES…………………………………………………………………………………………………………………….2
INSTALLING THE PORTABLE FRIDGE / FREEZER…………………………………………………………………….. 3
OPERATION LOCATION REQUIREMENTS………………………………………………………………………………………….3
HANDLING AND INSTALLATION…………………………………………………………………………………………………...4
OPERATION……………………………………………………………………………………………………………………. 4
TEST RUN:DC INPUT POWER……………………………………………………………………………………………………4
TEMPERATURE CONTROL SETTINGS……………………………………………………………………………………………..5
Set Button………………………………………………………………………………………………………………………..5
(+) and (-) Temperature Control Buttons……………………………………………………………………………………..5
Mode (Power) Button…………………………………………………………………………………………………………...5
Auto Indicator Light…………………………………………………………………………………………………………….. 5
Low Speed Mode Indicator Light………………………………………………………………………………………………5
Fast Freeze Indicator…………………………………………………………………………………………………………...6
Temperature Display (°F)………………………………………………………………………………………………………6
Voltage Display………………………………………………………………………………………………………………….6
Battery Display…………………………………………………………………………………………………………………..6
TEMPERATURE ADJUSTMENT……………………………………………………………………………………………………. 6
BATTERY CUT-OUT SETTING……………………………………………………………………………………………………..6
OFF MODE SETTING…………………………………………………………………………………………………………….. 6
FOOD STORAGE…………………………………………………………………………………………………………………..6
NORMAL SOUNDS…………………………………………………………………………………………………………………7
DEFROSTING AND DEODORIZING…………………………………………………………………………………………………7
PREPARING THE PORTABLE FREEZER FOR STORAGE…………………………………………………………………………...7
CLEANING AND MAINTENANCE…………………………………………………………………………………………… 8
CLEANING CHECK LIST…………………………………………………………………………………………………………...8
TROUBLESHOOTING………………………………………………………………………………………………………… 9
SPECIFICATIONS……………………………………………………………………………………………………………… 10
EDGESTAR LIMITED WARRANTY…………………………………………………………………………………………. 11

1
First Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure
to keep track of all included parts and pieces before discarding packaging materials. It is
advised that you keep the original box and packaging materials in case you ever need to move
or ship the appliance in the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components
time to settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar portable fridge / freezer. We hope that this purchase
will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We
will provide the customer support and exemplary products necessary to nurture that
relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your portable fridge / freezer. Following this manual will ensure that your
product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your beverage
cooler.
For Your Records:
Please write down the model number and serial number below for future reference.
Both numbers are located on the ratings label on the back of your unit and are needed
to obtain warranty service. You may also want to staple your receipt to this manual as it
is the proof of your purchase, and is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
 If you received a damaged product, immediately contact the retailer or dealer that sold you
the product.
 Read and follow this instruction manual carefully to help you install, use, and maintain
your portable fridge / freezer.
 Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
 Visit us on the web at http:/www.edgestar.com to register your product, download product
guides, and access additional troubleshooting resources and up-to-date information. You
can also find an interactive self-diagnostic tool at https://support.edgestar.com
 If you need warranty service, our friendly customer service representatives are available
via email at [email protected] or by telephone at 1 [phone].

2
Parts Identification
Open View
Accessories
1. DC Power Cord: This power cord is for use when traveling. It can be plugged directly into
your car lighter (12V power source).
2. AC Power Cord: This power cord is for use at home. It can be plugged directly into a
grounded outlet.
3. Interior Wire Baskets

3
Installing the Portable Fridge / Freezer
Operation Location Requirements
 Position your portable freezer in a location where there is proper air circulation and
electrical connections.
 Keep the portable freezer away from heat and direct sunlight if possible.
 This portable freezer is suitable for car use and camping. However, the appliance should
not be exposed to rain or any other severe weather elements.
 This portable freezer should not be placed in a built-in or recessed area. It is designed to
be freestanding.
 The normal operation of the freezer depends on heat radiation from the condenser. For
the initial use, remove all packaging and allow at least 5” of clearance at the back of the
freezer and 3” at the sides.
Note: Because this unit is compressor-based, ample space is required around the unit to allow
it to exhaust properly.

4
Important: Do not remove any safety, warning, or product information labels from your portable
fridge / freezer.
Warning: Use two or more people to move and handle this unit. Failure to do so can result in
back or other injury. Carefully remove the packaging materials and any shipping tape before
use.
Handling and Installation
1. Remove all interior and exterior packaging.
2. Position the freezer in a dry and well-ventilated place. Keep the freezer away from direct
sunlight, heaters, and corrosive gas.
3. Clean the interior surface with a small amount of lukewarm water and a soft cloth.
4. When inserting the AC power cord into the power socket. Make sure the power socket is a
grounded 115V~AC / 60 Hz socket. Also make sure that the unit’s grounding prong is not
damaged.
5. When moving the freezer, always use both handles to carry the unit as level as possible in
order to protect the compressor and the sealed system.
Operation
Test Run: DC Input Power
The control system allows for the voltage cut-out to be set to three (3) different settings
depending on the environment & situation that the appliance is being operated in. Low voltage
supply to the appliance can result in poor cooling performance and damage to the supply
battery.
When using 12V DC, the digital readout will show the factory setting 10.0V DC. To ensure that
suitable battery voltage can be maintained the controller has been programmed to offer three
(3) cut-out levels: 11.8, 10.7, and 10.0V DC.
When using 24V DC, the digital readout will show the factory setting 22.2V DC. To ensure that
suitable battery voltage can be maintained the controller has been programmed to offer three
(3) cut-out levels- 25.0, 23.5 & 22.2V DC.
To set the battery cut-out to the required level follow these steps:
1. Press “Set” to switch from temperature setting to low-voltage setting. Press once to set the
temperature, and press again to set the low voltage cut-out.
2. Push the “+” or “-” to adjust the setting. The display will flash four (4) times with the
selected setting. To check press “SET” once and the selected setting will flash and then
return to current voltage input.
When the appliance is disconnected from the power source the battery cut-out remains at its
last setting.
Note: When inserting the DC power cord, make sure the input is a 12V~DC / 24 V power
source.

5
Temperature Control Settings
Your portable freezer uses a digital control system for adjusting the thermostat.
Set Button
Press the “Set” button to toggle between setting the temperature and setting the low
voltage cut-off.
(+) and (-) Temperature Control Buttons
The unit’s temperature can be set within a range of –8° F to 50° F in 1° F increments.
Press the Set button and choose your desired temperature setting. For lower temperature
setting, press the Down (-) button and set to a lower temperature value. For higher
temperature setting, press the Up (+) button and set to a higher temperature value. Once
the desired temperature is set, the temperature display will flash four (4) times confirming
the chosen temperature and then it will revert back to current temperature setting. The set
temperature can be checked by pressing the Set button again.
Mode (Power) Button
Press the Mode button to turn on the portable freezer. To turn off, hold the Mode button
for five (5) seconds. When the portable freezer is in operation, press the Mode button to
cycle between Auto, Low Speed, and Fast Freeze Operation.
Auto Indicator Light
The Auto indicator light will illuminate a yellow light when the freezer is running on Auto
Mode. In this mode, the unit operates in a manner that ensures hassle-free operation
while automatically maintaining the set temperature. The temperature can be set between
–8° F to 50° F. The portable freezer measures the temperature inside the freezer cabinet
and automatically adjusts the appropriate temperature setting for optimal operation.
Low Speed Mode Indicator Light
The Low indicator light will illuminate a green light the freezer is running on Low Speed
Mode. In this mode, the portable freezer operates at the lowest fan speed while
automatically maintaining the set temperature. The temperature can be set between –8° F
to 50° F. The unit switches to lower activity level, and fan speed and compressor
operation are reduced, thus energy consumption is minimized.

6
Fast Freeze Indicator
LED displays “FF”. The freezer will rapidly cool the unit to -8°F. The freezer will then
maintain this temperature. To operate the unit in Fast Freeze mode when the unit is on,
press the MODE button until the FF indicator comes on.
Temperature Display (°F)
The LED display shows the actual temperature inside the portable freezer.
Voltage Display
If a 115 Volt connection is active and the AC Cord is plugged in, the LED Display will
display “AC” indicator. If 12 Volt connection is active and the DC Cord is plugged in, the
LED Display will display “DC” indicator.
Battery Display
The battery icon will be displayed only when connected to a DC power source. The battery
icon symbolizes the remaining battery source voltage.
Temperature Adjustment
When the freezer is connected to a power source, press the “Set” button. The LED will display
the factory pre-set freezing temperature of 0° F.
Temperature Adjustment:
1. Press the “Set” button.
2. While the LED is flashing, press the “+” or “-” button to reach the desired temperature.
Battery Cut-Out Setting
1. Press the “Set” button twice in a row. The LED display will flash the current low-voltage.
2. Press the “+” or “-” button to adjust the setting. The battery cut-out setting will be saved
after five (5) seconds without any further input.
The battery display on the LED screen will flash when the voltage is low.
OFF Mode Setting
Hold the “Mode” button for five (5) seconds to turn the unit off. The LED display will read
“OFF.”
Food Storage
Fresh foods should not be stored together with frozen foods. When the temperature is set
below 32° F, do not keep glass-bottled drinks such as beer and lemonade in the freezer as the
bottles might shatter.
Note: Do not run the unit on “FF” (fast freeze) for more than four (4) hours, as this might
adversely affect the refrigeration system.
Note: Do not use the refrigerator-freezer as a refrigerator when the ambient temperature is
lower than 41° F.
Note: The battery cut-out settings can only be operated with a DC power source.

7
Warning: Never remove ice with a sharp object or screwdriver.
Tip: To remove bad odors, place a piece of charcoal in the chest.
Normal Sounds
Your new portable fridge / freezer may make sounds that are not familiar to you. Most of the
new sounds are normal. Hard surfaces like the floor and walls can make the sounds seem
louder than they actually are. The following describes the kinds of sounds that might be new to
you and what may be making them.
 It is normal to hear gurgling sounds caused by the flow of refrigerant when each cooling
cycle ends.
 The noise emitted by the cooling fan on the condenser is a normal function.
 It is normal for the fan in the power supply to run all the time.
Defrosting and Deodorizing
When the ice layer on the inner cabinet sides is over 0.2”, the defrosting operation should be
performed to improve the refrigerating efficiency. To do this, follow these steps:
1. Turn off the power, and remove all items inside the portable freezer.
2. Allow the ice to melt completely.
3. Remove the drain plug and drain all of the water. Once the unit is defrosted and all the
water has drained out, clean the interior with a soft rag before using the unit.
Preparing the Portable Freezer for Storage
If the portable fridge / freezer will not be used for a long time, it will be necessary to defrost the
unit and dry the interior.
1. Disconnect the freezer from the power supply by removing the power plug from the wall
socket.
2. Leave the freezer lid open to allow for air circulation and to prevent mold, mildew, and
unpleasant smells.
Caution: Store the unit out of the reach of children. If you have children, you may want to take
additional precautions such as removing the door to prevent a child from being trapped inside
the freezer!
Important:
 Do not touch the power plug when your hands are wet.
 Never unplug the unit by pulling on the plug.

8
Cleaning and Maintenance
Periodic cleaning and proper maintenance will ensure efficiency, top performance, and long
life.
The exterior and interior may be cleaned with a mild detergent and lukewarm water solution
such as 2 tablespoons of baking soda to 1 quart of water.
Use a soft sponge and rinse with clean water. Wipe with a soft clean towel to prevent water
spotting. Never use an abrasive or caustic cleaning agent.
Cleaning Check List
1. Disconnect power to the unit.
2. Open the door and remove the contents and baskets.
3. Wait until the unit defrosts.
4. With a clean cloth, wipe down the interior of the unit.
5. Reinsert the contents and baskets.
6. Reconnect power to the unit.
Note: Do not use solvent based or abrasive cleaners.

9
Troubleshooting
Before Calling for Help
If the unit appears to be malfunctioning, read through the “Operation” section of this manual
first. If the problem persists, check the Troubleshooting Guide below. The problem may be
something that can easily be solved or explained.
Symptoms Possible Causes Solutions
The unit is not functioning at
all and shows no signs of
power.
The unit is not receiving
power.
Make sure the unit is plugged
in.
There is insufficient power to
the unit.
Move the unit to another
outlet. Check your circuit
breaker. Refer to the rating
label on the back of the unit to
determine the Amperage
draw.
There is an AC power cord
malfunction.
Test the unit with a different
cord. If the unit works, replace
the damaged AC cord.
There is a DC power cord
malfunction.
Test the unit with another
power supply, such as
another vehicle with a known
working DC power outlet.
There is a disconnected wire. Contact customer service.
The unit is making strange
noises.
Some noises are normal. Check the “Normal Sounds”
section.
The unit is not level. Move the unit to a level
surface.
The unit is making a loud
continuous metallic knocking
or pinging sound.
The unit may have been
shipped on its side.
Shut the unit off. Let the unit
sit on a level surface for at
least 24 hours and then
restart it.
The compressor is damaged. Contact customer service.
The unit runs for a little while,
then trips the power cord or
the circuit breaker.
The unit may be plugged into
an outlet that cannot supply
the correct amount of current.
Contact an electrician if the
unit works in a different room
or circuit.
The control panel lights blink
randomly.
The unit may have a faulty
control panel.
Restart the unit, and if the
issue persists, contact
customer service.
The unit has an OC error. A thermostat error was
detected.
Restart the unit, and if the
issue persists, contact
customer service.
The unit has a SC error. A short circuit in the
thermostat was detected.
Restart the unit, and if the
issue persists, contact
customer service.
The unit has power, but the
compressor does not run.
The ambient temperature is
too low.
Move the unit to a warmer
location.
A wire is disconnected. Contact customer service.

10
Specifications
Description of product Portable Fridge /
Freezer
Portable Fridge /
Freezer
Portable Fridge /
Freezer
Model FP430 FP630 FP861
Voltage / Frequency AC: 115V~60 Hz
DC: 12/24 V
AC: 115V~60 Hz
DC: 12/24 V
AC: 115V~60 Hz
DC: 12/24 V
Amperage 0.75 A 0.8 A 1.0 A
Input Power 65 W 75 W 80 W
Color Grey with black trim Grey with black trim Grey with black trim
Storage Capacity 43 qt. 63 qt. 83 qt.
Refrigerant R134a R134a R134a
Temperature Range -8° F to 50° F -8° F to 50° F -8° F to 50° F
Dimensions
(Height x Width x Depth )
20 1/2” x 24 5/8” x 18
1/8”
20 1/2” x 29 1/8” x 19
1/2”
23 3/8” x 29 1/8” x 19
1/2”
Weight 48.5 lbs. 61.7 lbs. 66.2 lbs.
Note: Technical data and performance information are provided for reference only.
Specifications are subject to change. Check the rating label on the portable fridge / freezer for
the most accurate information.

11
EdgeStar Limited Warranty
One (1) Year Parts & Ninety (90) Days Labor
This product is warranted by EdgeStar to be free from defective workmanship and materials, subject to any conditions set forth as follows:
WHAT IS COVERED:
LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at an authorized EdgeStar
repair facility. At its option, EdgeStar will repair the product with new or remanufactured parts, or exchange the defective product with a new,
refurbished, or remanufactured product. If a product is replaced, it will carry the remaining warranty of the original product. After the ninety
(90) day period, EdgeStar will no longer be responsible for labor charges incurred. All defective products and parts covered by this warranty
will be repaired or replaced on a mail-in basis to an EdgeStar authorized repair facility.
PARTS: For a period of ONE (1) YEAR from the date of original purchase, EdgeStar will supply new, rebuilt, or refurbished parts free of charge.
EdgeStar may request a defective part be returned in exchange for the replacement part. All replacement parts or products will be new,
remanufactured, or refurbished. All products and parts replaced by EdgeStar under warranty service become the property of EdgeStar.
This warranty applies to the original purchaser only, and only covers defects in workmanship experienced during operation of the
product under normal service, maintenance, and usage conditions. This warranty applies to the purchase and use of this product in
residential settings within the contiguous United States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty. This warranty does not cover:
 Labor charges for installation, setup or training to use the product.
 Shipping damage, and any damage caused by improper packaging for shipment to an authorized service center, and any damaged
caused by improper voltage or any other misuse, including abnormal service, handling, or usage.
 Cosmetic damage such as scratches and dents.
 Normal wear and tear on parts or replacement of parts designed to be replaced, e.g. filters, cartridges, batteries.
 Service trips to deliver, pick-up, or repair, install the product, or to instruct in proper usage of the product.
 Damages or operating problems resulting from misuse, abuse, operation outside environmental specifications, uses contrary to
instructions provided in the owner’s manual, accidents, acts of God, vermin, fire, flood, improper installation, unauthorized service,
maintenance negligence, unauthorized installation or modification, or rental or commercial use.
 Labor, service transportation, and shipping charges incurred 91 days or more after the date of original purchase.
 The use of EdgeStar products in commercial or rental settings.
 Optional accessories, attachments, and appearance items.
 Products that have been modified to perform outside of specifications without the prior written permission of
EdgeStar.
 Products lost in shipment, or theft.
 Products sold AS IS or from an unauthorized reseller.
 Products that have had their serial numbers removed or defaced. Products with serial numbers that have been invalidated.
 Damage to personal property from use of product.
 Replacement of repair of household fuses, circuit breakers, wiring, or plumbing.
OBTAINING WARRANTY SERVICE:
If you believe your product is defective, contact EdgeStar Customer Support for troubleshooting assistance and warranty service at www.edgestar.com
or 1-866-319-5473. Before contacting EdgeStar, have your serial number and proof of purchase available. Once an EdgeStar authorized representative
has confirmed that your product is defective and eligible for warranty service, the product must be returned to an EdgeStar repair facility. The
purchaser is solely responsible for prepaying all shipping related costs to and from the repair facility. EdgeStar is not responsible for damage resulting
from shipper mishandling or improper packaging. Do not return a defective product to the place of purchase. Products received without a return
authorization number will be refused.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS
WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT,
SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER
BASED IN CONTRACT, TORT, OR OTHERWISE. IN NO EVENT AND UNDER NO CIRCUMSTANCE OF ANY TYPE OR KIND SHALL THE SELLER, MANUFACTURER
AND/OR DISTRIBUTOR BE LIABLE FOR ANY REASON, UNDER ANY THEORY, FOR MORE THAN THE BASIC COST OF THE PRODUCT TO THE PURCHASER OR END
USER. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

