Edgetech 5112 User manual

EdgeTech
4 Little Brook Road
West Wareham, MA 02576
Tel: [phone]
Fax: [phone]
www.EdgeTech.com
5112 ROPELESS FISHING SYSTEM
USER HARDWARE MANUAL
0022081_REV_B 8/31/2021

ii
5112 Ropeless Fishing System 0022081_REV_B
The information, figures, and specifications in this manual are proprietary. They are issued in strict
confidence on condition that they not be copied, reprinted, or disclosed to a Third-Party, either wholly or
in part, without the prior, written consent of EdgeTech. Any reproduction of EdgeTech supplied software
or file sharing is strictly prohibited.
Copyright © 2019-2021 EdgeTech. All rights reserved.
Android® is a registered trademark of Google.
Bluetooth® is a registered trademark of Bluetooth® SIG.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG,
Inc. and any use of such marks by EdgeTech is under license. Other trademarks and
trade names are those of their respective owners.
iPhone® and iPad® are registered trademarks of the Apple Corporation.
Microsoft Excel® is a registered trademark of Microsoft Corporation.
Samsung® is a registered trademark of Samsung

iii
ATTENTION – READ THIS FIRST!
All personnel involved with the installation, operation, or maintenance of the equipment described in this
manual should read and understand the warnings and cautions provided below.
CAUTION!This equipment contains devices that are extremely sensitive
to static electricity. Therefore, extreme care should be taken when
handling them. Standard handling precautions involve the use of anti-
static protection materials and grounding cables for personnel.
WARNING!High Voltage may be present in all parts of the system.
Therefore, use caution when the electronics are removed from their
containers for servicing.
CAUTION!Operation with improper line voltage may cause serious
damage to the equipment. Therefore, always ensure that the proper line
voltage is used.
Warnings, Cautions, and Notes
Where applicable, warnings, cautions, and notes are provided in this manual as follows:
WARNING! Identifies a potential hazard that could cause injury or death.
CAUTION! Identifies a potential hazard that could damage equipment or
data.
NOTE: Recommendations or general information that is particular to the
material being presented.

iv
5112 Ropeless Fishing System 0022081_REV_B
HARDWARE VARIATIONS AND COMPATIBILITY
The 5112 Ropeless Fishing System contains both standard and proprietary hardware. At times, EdgeTech
may change the standard components due to their availability or performance improvements. Although
the component manufacturers and their models and styles may vary from unit to unit, replacement parts
will generally be interchangeable.
EdgeTech will make every effort to see that replacement components are interchangeable and use the
same software drivers (if applicable). At times, however, direct replacements may not exist. When this
happens, EdgeTech will provide the necessary drivers with the replacement part, if applicable.
EdgeTech may also change certain hardware per customer requirements. Therefore, portions of this
manual, such as parts lists and test features, are subject to change. These sections should be used for
reference only. When changes are made that affect system operation, they will be explicitly noted. Also,
some options and features may not be active in the customer’s unit at delivery time. Upgrades will be
made available when these features are implemented.
Contact EDGETECH CUSTOMER SERVICE with any questions relating to compatibility.

v
ABOUT THIS DOCUMENT
We, the employees at EdgeTech, would like to thank you for purchasing a 5112 Ropeless Fishing System.
At EdgeTech, our policy is to provide high-quality, cost-effective products and support services that meet
or exceed your requirements. We also strive to deliver them on time and to look for ways to improve
them continuously. We take pride in the products we manufacture and want you to be entirely satisfied
with your equipment.
Purpose of this Manual
The purpose of this manual is to provide the user with information on the setup and use of EdgeTech’s
5112 Ropeless Fishing System. Although this manual encompasses the latest operational features of the
5112 Ropeless Fishing System, some features may be periodically upgraded. Therefore, the information
in this manual is subject to change and should be used for reference only.
Liability
EdgeTech has made every effort to document the 5112 Ropeless Fishing System in this manual. However,
EdgeTech assumes no liability for errors or any damages resulting from the use of this manual or the
equipment it documents. EdgeTech reserves the right to upgrade this equipment's features and make
changes to this manual without notice at any time.
Revision History
REVISION
DESCRIPTION
DATE
APPROVAL
A
Release to Customers
9/17/2019
G.M.
B
Updated to New Product Specifications
8/31/2021
G.M.

vi
5112 Ropeless Fishing System 0022081_REV_B
WARRANTY STATEMENT
All equipment manufactured by EdgeTech is warrantied against defective components and workmanship
for a period of one year after shipment. Warranty repair will be done by EdgeTech free of charge.
Shipping costs are to be borne by the customer. Malfunction due to improper use is not covered in the
warranty, and EdgeTech disclaims any liability for consequential damage resulting from defects in the
performance of the equipment. No product is warranted as being fit for a particular purpose, and there is
no warranty of merchantability. This warranty applies only if:
i. The items are used solely under the operating conditions and in the manner recommended in
Seller's instruction manual, specifications, or other literature.
ii. The items have not been misused or abused in any manner, nor have repairs been attempted
thereon without the approval of EdgeTech Customer Service.
iii. Written notice of the failure within the warranty period is forwarded to Seller, and the directions
received for properly identifying items returned under warranty are followed.
iv. The return notice authorizes Seller to examine and disassemble returned products to the extent
Seller deems necessary to ascertain the cause for failure.
The warranties expressed herein are exclusive. There are no other warranties, either expressed or implied,
beyond those set forth herein, and Seller does not assume any other obligation or liability in connection
with the sale or use of said products. Any product or service repaired under this warranty shall be
warranted for only the remaining portion of the original warranty period.
Equipment not manufactured by EdgeTech is supported only to the extent of the original manufacturer's
warranties.
CAUTION! If your product is a portable topside, never attempt to ship it
in its Storm CaseTM alone. Shipping portable topsides without an exterior
shipping crate will void the warranty.

vii
SOFTWARE SERVICE OVERVIEW
The EdgeTech Trap Tracker application that controls the Ropeless Fishing system and database interface
is available from the Apple and Google Play stores. If the user wishes to add detailed Navionics charts for
integration with Trap Tracker, the Navionics Boating Marine & Lakes Application can be downloaded from
either the Apple Store (iPhone) or Boating HD Marine & Lakes Google Play Store (Android). This will
provide access to download their Boating Application and provide a login email address and password
that you’ll use in the Trap Tracker Application to gain access to their chart service.
Software Updates and Enhancements
EdgeTech customers can download new software releases with modifications and enhancements from
the EdgeTech Track Tracker Page at the Apple store and Google Play sites. Major software issues, should
they occur, will be reported directly to the customer. New software releases consist of the following:
•Software enhancements that are not on the price list
•Software fixes and changes
•Product integration
•Documentation updates to online help
•Tests for compatibility with other modules
Software patches consist of software that has undergone the following:
•Minor software enhancements
•Software fixes and changes
EdgeTech customers are entitled to contact EDGETECH CUSTOMER SERVICE by telephone, facsimile, or email
to report a difficulty, discuss a problem, or receive advice on the best way to perform a task. When
contacted, EdgeTech Customer Service will do the following:
•Respond within 24 hours via Telephone, Facsimile, and Email Support
•Immediately attend to serious problems affecting operations
•Attempt to find an immediate workaround

viii
5112 Ropeless Fishing System 0022081_REV_B
RETURNED MATERIAL AUTHORIZATION
Before returning any equipment to EdgeTech, a Returned Material
Authorization (RMA) Number must be obtained from CUSTOMER SERVICE.
RMA Purpose
The RMA Number identifies returned equipment when it arrives at our receiving dock and enables tracking
while at our facility. Refer to the RMA number on all documentation and correspondences.
All returned materials must be shipped prepaid. Freight collect shipments will not be accepted. All
equipment should be adequately insured for shipping, but equipment belonging to EdgeTech must be
insured for full value.
If there is more than one item per consignment, include a packing with the shipment. An invoice can
double as a packing slip only when the contents are clearly numbered and identified on the invoice.
CAUTION! Never attempt to ship a Portable Topside in its Storm CaseTM
alone. Although rugged, these cases are not intended to be used as
shipping containers, and the delicate internal components could be
damaged. Shipping in this manner will void any warranties.
NOTE: All shipping charges shall be the customer's responsibility, unless
under warranty, as EdgeTech will pay for return shipping.
NOTE: For International Shipments valued over $1000, the following
Shipper's oath must be sent with the invoice.
Shipper’s Oath:
"I, ______________________________, declare that the articles herein specified are the growth,
produce, or manufacture of the United States; that they were exported from the
United States from the port of _____________________, on or about _______________; that they
are returned without having been advanced in value or improved in condition by any
process of manufacture or any other means; and that no drawback, or allowance has
been paid or admitted hereof."
Signed ______________________________

ix
CUSTOMER SERVICE
Customer service personnel at EdgeTech are always eager to hear from users of our products. Your
feedback is welcome and is a valuable source of information that we use to improve these products
continually. Therefore, we encourage you to contact EdgeTech Customer Service to offer any suggestions
or to request technical support:
NOTE: Please have your system Model and Serial Number available when
contacting Customer Service.
E-mail: servic[email protected]om
Mail: 4 Little Brook Road
West Wareham, MA 02576
Telephone: [phone]
Facsimile: [phone]
24-Hour Emergency
Technical Support Line: [phone]
For more information, please go to www.EdgeTech.com.

x
5112 Ropeless Fishing System 0022081_REV_B
COMPANY BACKGROUND
EdgeTech (formerly EG&G Marine Instruments) traces its history in Underwater Data Acquisition and
Processing back to 1966. EdgeTech has designed, developed, and manufactured products, instruments,
and systems — for the acquisition of underwater data, including marine, estuarine, and coastal
applications — for over 50 years.
EdgeTech responds to the needs of the Scientific, Naval, and Offshore communities by providing industry-
leading equipment — such as Sub-Bottom Profilers, Side Scan Sonar, Acoustic Releases, USBL Positioning
Systems, and Bathymetric Systems — that have become standards in the industry.
EdgeTech consistently anticipates and responds to future needs with an active Research and Development
Program. Current efforts are focused on adapting new cutting-edge acoustic technology.

xi
TABLE OF CONTENTS
ATTENTION – READ THIS FIRST! .........................................................................................................iii
Warnings, Cautions, and Notes................................................................................................................ iii
HARDWARE VARIATIONS AND COMPATIBILITY..................................................................................iv
ABOUT THIS DOCUMENT....................................................................................................................v
Purpose of this Manual............................................................................................................................. v
Liability...................................................................................................................................................... v
Revision History ........................................................................................................................................ v
WARRANTY STATEMENT ...................................................................................................................vi
SOFTWARE SERVICE OVERVIEW........................................................................................................vii
Software Updates and Enhancements.................................................................................................... vii
RETURNED MATERIAL AUTHORIZATION ..........................................................................................viii
RMA Purpose ......................................................................................................................................... viii
CUSTOMER SERVICE..........................................................................................................................ix
COMPANY BACKGROUND ..................................................................................................................x
TABLE OF CONTENTS .........................................................................................................................xi
LIST OF FIGURES...............................................................................................................................xv
LIST OF TABLES ............................................................................................................................. xviii
1.0 OVERVIEW.............................................................................................................................1-1
1.1 Main System Components.........................................................................................................1-1
1.1.1 5112 Rugged Release, Remote Transducer, and NFC (Near Field Communication) Tag......1-1
1.1.2 5112 Configured Release Cages............................................................................................1-2
1.1.3 BLEAT or BLEAT Portable Deck Box and Transducer ............................................................1-3
1.1.4 iOS or Android Trap Tracker Mobile Application..................................................................1-4
2.0 SPECIFICATIONS.....................................................................................................................2-5
2.1 5112 Acoustic Release Specifications........................................................................................2-5
2.1.1 5112 Acoustic Release Mechanical Specifications................................................................2-5
2.1.2 5112 Acoustic Release Power Specifications........................................................................2-5
2.1.3 5112 Acoustic Release Command Receiver..........................................................................2-5
2.1.4 5112 Acoustic Release Standard Command Functions ........................................................2-6
2.1.5 5112 Acoustic Release Environmental Specifications ..........................................................2-6

xii
5112 Ropeless Fishing System 0022081_REV_B
2.1.6 5112 Acoustic Release Mechanical Drawings.......................................................................2-1
2.1.6.1 5112 Acoustic Release Drawing....................................................................................2-1
2.1.6.2 Legacy 5112 Acoustic Release Drawing (Discontinued) ...............................................2-3
2.2 5112 22.5-Inch Equipped Cage..................................................................................................2-5
2.2.1 22.5-Inch Cage Mechanical Drawing ....................................................................................2-6
2.3 5112 48-Inch Equipped Cage .....................................................................................................2-7
2.3.1 48-inch Cage Mechanical Drawing .......................................................................................2-8
2.4 5112 48-Inch XL Offshore Cage Equipped Cage ........................................................................2-9
2.4.1 48-Inch XL Offshore Cage Mechanical Drawing..................................................................2-10
2.5 BLEAT Deck Box .......................................................................................................................2-11
2.5.1 BLEAT Deck Box Mechanical Specifications........................................................................2-11
2.5.2 BLEAT Deck Box Electrical Specifications............................................................................2-11
2.5.3 BLEAT Deck Box Power Specifications ................................................................................2-11
2.5.4 BLEAT Deck Box Drawing ....................................................................................................2-12
2.6 BLEAT Portable Deck Box.........................................................................................................2-13
2.6.1 BLEAT Portable Deck Box Mechanical Specifications .........................................................2-13
2.6.2 BLEAT Portable Deck Box Electrical Specifications .............................................................2-13
2.6.3 BLEAT Portable Deck Box Power Specifications .................................................................2-13
2.6.4 BLEAT Portable Deck Box Drawing .....................................................................................2-14
2.7 5112 Dunking Transducers ......................................................................................................2-15
2.7.1 Dunking Transducer Mechanical Specifications .................................................................2-15
3.0 SETUP AND ACTIVATION ......................................................................................................3-16
3.1 BLEAT Deck Box Installation and Activation ............................................................................3-16
3.1.1 BLEAT Deck Box Installation and Activation .......................................................................3-16
3.1.2 BLEAT Portable Installation and Activation ........................................................................3-18
3.2 Trap Tracker Mobile Application Installation and Subscription Activation.............................3-20
3.2.1 iPhone /Android Trap Tracker ............................................................................................3-20
3.2.2 Installing Navionics Nautical Charts in Trap Tracker. .........................................................3-21
3.2.3 Trap Tracker Settings and Options .....................................................................................3-25
3.3 Connecting Track Tracker device to BLEAT Deck Unit.............................................................3-27
3.4 Release Cage Setup..................................................................................................................3-31
3.4.1 Lid-Lift Bungee Installation .................................................................................................3-31

xiii
3.4.2 Cage Lid Setup ....................................................................................................................3-32
3.4.2.1 48-Inch and 48-Inch XL Cage Lid Line Setup ...............................................................3-32
3.4.2.2 Lid Anti-Rotation Bungee Installation.........................................................................3-33
3.4.3 Rope Basket and Rope Installation and Setup....................................................................3-36
3.4.3.1 Cage Divider Installation.............................................................................................3-36
3.4.3.2 Rope and Rope Basket Setup......................................................................................3-36
3.4.4 Cage Float Setup .................................................................................................................3-40
3.5 Arming the 5112 Release.........................................................................................................3-41
3.5.1 Dry Testing the System .......................................................................................................3-43
3.5.1.1 Status Command Test.................................................................................................3-43
3.5.1.2 Release Command Test ..............................................................................................3-48
4.0 Operating Instructions: ........................................................................................................4-51
4.1 Cage Deployment: ...................................................................................................................4-51
4.1.1 Add the Release To Trap Tracker........................................................................................4-51
4.1.1.1 Add Release By Scanning the Cage NFC Tag...............................................................4-51
4.1.1.2 Manually Adding a Release Into Trap Tracker............................................................4-55
4.1.2 Deploy the Cage or Line of Cages and Mark them As So in Trap Tracker...........................4-58
4.2 Cage Recovery .........................................................................................................................4-61
4.2.1 Use Trap Tracker to Navigate Position of Cage Release.....................................................4-61
4.2.1.1 Syncing........................................................................................................................4-61
4.2.1.2 Trap Tracker Chart Display .........................................................................................4-62
4.2.1.3 Trap Tracker Underwater Unit Screen Position..........................................................4-64
4.2.2 Use Transducers and Trap Tracker’s Status Command to Find A 5112 Release ................4-65
4.2.2.1 Transducer Deployment and Usage ...........................................................................4-66
4.2.2.2 Trap Tracker Status Update Function.........................................................................4-68
4.2.3 Use Transducer and Trap Tracker to Send the Recover Command....................................4-70
4.2.4 Trap Tracker ID Command..................................................................................................4-72
4.2.5 Sending Commands to Releases Not In The Underwater Units List...................................4-74
4.3 Post Deployment .....................................................................................................................4-78
4.3.1 Trap Tracker History ...........................................................................................................4-78
4.3.1.1 Deleting History .........................................................................................................4-81
4.3.2 Removing A Unit From The Underwater Unit List. .............................................................4-85

xiv
5112 Ropeless Fishing System 0022081_REV_B
4.3.3 Data Export .........................................................................................................................4-87
4.3.3.1 Exporting Historical Data............................................................................................4-87
4.3.3.2 Exporting GPX Unit Data in Charts..............................................................................4-89
5.0 MAINTENANCE ....................................................................................................................5-91
5.1 General Cleaning and Inspection.............................................................................................5-91
5.2 Battery and O-Ring Replacement ............................................................................................5-92
5.2.1 Removing the 5112 Acoustic Release from the Cage.........................................................5-92
5.2.2 Opening the 5112 Acoustic Release ...................................................................................5-93
5.2.3 AA Battery Replacement Procedure...................................................................................5-95
5.2.4 Legacy 9-Volt Battery Replacement Procedure..................................................................5-99
5.2.5 O-Ring Replacement Information.....................................................................................5-101
5.2.6 Reassembling the 5112 Release .......................................................................................5-101
5.2.7 Installing the 5112 Acoustic Release into an EdgeTech Configured Cage ........................5-102
6.0 TROUBLESHOOTING...........................................................................................................6-105
6.1 Cage Physically Deployed Without Deployment Button Being Pressed................................6-105
6.2 Unit Incorrectly Marked As Deployed ...................................................................................6-109
6.3 Unit Already Deployed Message ...........................................................................................6-112
6.4 5112 Release Not found in Underwater Units List ................................................................6-114
6.5 NFC Scanning Not Functional ................................................................................................6-114
6.6 Sync Conflicts.........................................................................................................................6-114
6.7 Failed to Recover Message....................................................................................................6-115
6.8 Location Not Available Message When Sending Command..................................................6-115
6.9 Trap Tracker Subscription Issues ...........................................................................................6-116
6.10 The trap is Tilted Greater than 45⁰........................................................................................6-117
6.11 BLEAT Box Not Appearing in the Found List During Pairing ..................................................6-117
7.0 Kits ....................................................................................................................................7-118
7.1 Cage Assembly and Integration Kit........................................................................................7-118
7.2 5112 Release Upgrade Kit......................................................................................................7-118
7.3 Spares Kit ...............................................................................................................................7-119

xv
LIST OF FIGURES
Figure 1-1: 5112 Release and Transducer..................................................................................................1-1
Figure 1-2: NFC Tag ....................................................................................................................................1-1
Figure 1-3: 48-inc 5112 RFS Configured Cages ..........................................................................................1-2
Figure 1-4: 22.5-in 5112 RFS Configured Cage...........................................................................................1-2
Figure 1-5: BLEAT System: Command Box, Junction Box, and Dunking Transducer .................................1-3
Figure 1-6: BLEAT Portable System: BLEAT Portable and Transducer .......................................................1-3
Figure 1-7: Trap Tracker iOS.......................................................................................................................1-4
Figure 1-8: Trap Tracker Android...............................................................................................................1-4
Figure 2-1: 5112 Release Mechanical Drawing pg.1 ICD-0021701 ............................................................2-1
Figure 2-2: 5112 Release Mechanical Drawing pg.2 ICD-0021701 ............................................................2-2
Figure 2-3: Legacy 5112 Release (Discontinued) Mechanical Drawing pg.1 ICD-0021701 Rev A..............2-3
Figure 2-4: Legacy 5112 Release (Discontinued)Mechanical Drawing pg.2 ICD-0021701 Rev A ..............2-4
Figure 2-5: 22.5-Inch Cage System ICD-0022380.......................................................................................2-6
Figure 2-6: 48-Inch Cage System Mechanical Drawing ICD-0022382........................................................2-8
Figure 2-7: 48-Inch XL Offshore Cage System Mechanical Drawing ICD-0023286 ..................................2-10
Figure 2-8: Bleat Command and Junction Box Mechanical/Electrical Drawing-0022384 .......................2-12
Figure 2-9: BLEAT Portable Mechanical Drawing-0022383 .....................................................................2-14
Figure 3-1: BLEAT Command, Junction Box and Transducer ...................................................................3-16
Figure 3-2: BLEAT Junction Box and Transducer Connection ..................................................................3-17
Figure 3-3: BLEAT Portable and Dunking Transducer ..............................................................................3-18
Figure 3-4: BLEAT Portable Battery Installation.......................................................................................3-19
Figure 3-5: BLEAT Portable and Transducer Connection .........................................................................3-20
Figure 3-6: Lid Lift Bungee Installed.........................................................................................................3-31
Figure 3-7: Lid-Lift Bungee Secured By A Hog Ring..................................................................................3-32
Figure 3-8: 48-Inch Cage Knot Lid Line Attachment ................................................................................3-33
Figure 3-9: Anti-Rotation Bungee Installation .........................................................................................3-34
Figure 3-10: Anti-Rotation Bungee Tight Enough To Hold Release Knob In Place But Loose Enough to
Maneuver Into Place................................................................................................................................3-35
Figure 3-11: Anti-Rotation Bungee Installation Objective-Holding Release Knob in Place .....................3-35

xvi
5112 Ropeless Fishing System 0022081_REV_B
Figure 3-12: 48-Inch Cage with Installed Divider.....................................................................................3-36
Figure 3-13: Rope Flaking into Basket......................................................................................................3-37
Figure 3-14: Rope Basket Placement in Cage ..........................................................................................3-37
Figure 3-15: Rope Lock Knot Positioning .................................................................................................3-38
Figure 3-16: Line Exit Location and Stop Knot .........................................................................................3-38
Figure 3-17: Bridle and Exit Line Attachment ..........................................................................................3-39
Figure 3-18: Cage Lid Installation: Tabs under Cage Edge .......................................................................3-39
Figure 3-19: 22.5-Inch Cage Flotation Setup- Long Line Clips Attached 7-8 Cage Squares From Release End
.................................................................................................................................................................3-40
Figure 3-20: Standard 48-Inch and 48-Inch XL Offshore Cage Floatation Shackle Location- Long Line Clips
Attached 14-15 Squares from Release End..............................................................................................3-40
Figure 3-21: Long Line Clip Location ........................................................................................................3-41
Figure 3-22: 5112 Bungee and Knob Installation.....................................................................................3-42
Figure 3-23: 5112 Bungee and Know Alignment .....................................................................................3-42
Figure 5-1: 5112 Release Mounting Plates ..............................................................................................5-92
Figure 5-2: 5112 Release Upper Plate Support Post and Bolt Assembly Locations.................................5-92
Figure 5-3: 5112 Support Post Unthreaded from 3/8-16 Bolt .................................................................5-93
Figure 5-4: 5112 Removing [4] Top Plate Bolt Assembly Hex Nuts and Washers ...................................5-93
Figure 5-5 Release Orientation in Mounting Plate ..................................................................................5-94
Figure 5-6: Unthreading Release Endcap Using Spanner and Strap Wrenches.......................................5-95
Figure 5-7: 5112 Release Main Sub-Assembly.........................................................................................5-96
Figure 5-8: 5112 Release Battery Replacement- Disconnecting Power ..................................................5-96
Figure 5-9: 5112 Release Battery Replacement-Mounting Plate Removal .............................................5-97
Figure 5-10: 5112 Battery Replacement Electrical Tap Removal.............................................................5-97
Figure 5-11: 5112 Release Battery Replacement- Battery Module .........................................................5-98
Figure 5-12: 5112 Release Battery Replacement- Reconnecting Power .................................................5-98
Figure 5-13: Battery Mounting Plate Removal ........................................................................................5-99
Figure 5-14: Battery Removal ................................................................................................................5-100
Figure 5-15: Battery Mounting Plate Mounting.....................................................................................5-100
Figure 5-16: Release Endcap and Mounting Plate Orientation .............................................................5-101
Figure 5-17: 5112 Installation- Release Mounting Plates ......................................................................5-102

xvii
Figure 5-18: 5112 Installation- Release Upper Mounting Plate Support Post, Bolt Assemblies, and
Transducer Cable Connector Locations .................................................................................................5-102
Figure 5-19: 5112 and Top Mounting Plate Installed ............................................................................5-103
Figure 5-20: Mounting Plate Notch Alignment......................................................................................5-103
Figure 5-21: 5112 Installation- Threading [4] Bolt-Assemblies Attacking Top Mounting Plate to Cage5-103
Figure 5-22: 5112 Installation: Support Post Assembly .........................................................................5-103
Figure 5-23: 5112 Release, Top Mounting Plate, Bolt Hardware, and Support Posts Installed ............5-104
Figure 5-24: Transducer Mounted to Mesh Platform In Cage ..............................................................5-104

xviii
5112 Ropeless Fishing System 0022081_REV_B
LIST OF TABLES
Table 2-1: Acoustic Release Mechanical Specifications.............................................................................2-5
Table 2-2: Acoustic Release Power Specifications ....................................................................................2-5
Table 2-3: Acoustic Release Command Receiver Specification .................................................................2-5
Table 2-4: Release Commands, Responses, and Command Functions......................................................2-6
Table 2-5: Acoustic Release Environmental Specifications........................................................................2-6
Table 2-6: 22.5-Inch Cage Mechanical Specifications................................................................................2-5
Table 2-7: 48 Inch Cage Mechanical Specifications ...................................................................................2-7
Table 2-8: 48-Inch XL Offshore Cage Mechanical Specifications ...............................................................2-9
Table 2-9: Bleat Deck Box Mechanical Specifications..............................................................................2-11
Table 2-10: Bleat Deck Box Electrical Specifications................................................................................2-11
Table 2-11: Bleat Deck Box Power Specifications....................................................................................2-11
Table 2-12: Bleat Deck Box Mechanical Specifications............................................................................2-13
Table 2-13: BLEAT Deck Box Electrical Specifications..............................................................................2-13
Table 2-14: BLEAT Deck Box Power Specifications ..................................................................................2-13
Table 2-15: Dunking Transducer Mechanical Specifications ...................................................................2-15
Table 7-1: 5112 Cage Integration Kit .....................................................................................................7-118
Table 7-2: 5112 Release Upgrade Kit.....................................................................................................7-119
Table 7-3: 5112 Spare Kit .......................................................................................................................7-119

1-1
1.0 OVERVIEW
The EdgeTech 5112 Ropeless Fishing System (RFS) was designed with fishers to eliminate the need for a
persistent vertical line to connect fishing gear to a surfaced buoy until just before retrieval. The intent is
to alleviate possible whale and other marine-life entanglement and help prevent line tangles, cuts, tipped
cages, and other adverse effects of seafloor to-surface lines.
The RFS consists of a modified fishing cage with an attached EdgeTech 5112 rugged acoustic release with
transponder, a BLEAT (Bluetooth® Low Energy Acoustic Transceiver) Deck Box unit or a Portable BLEAT
deck box connected to a hull-mounted or portable dunking transducer and the EdgeTech Trap Tracker
application running on an iOS or Android device. The system is deployed like any other rope-and-buoy
cage, independent or at the head or tail of a line of unmodified fishing cages. The cage contains the 5112
release with transponder, rope, floats, and an attached NFC (Near Field Communication) tag.
5112 Ropeless Fishing system operation is straightforward. Commands are made in the Trap Tracker
phone application, sent by a Bluetooth® wireless connection to the BLEAT deck box. The commands are
interpreted, and an attached dunking or hull-mounted transducer sends the commands via an acoustic
signal to an in-range 5112 release attached to the cage. The release receives the command, acts, and
replies to and with information to the Trap Tracker phone application through the same system.
Commands include ID information, status information, and recover. Cage recovery is accomplished by
sending a unique recovery command to an in-range modified cage that responds by sending range
information to the phone application and mechanically releasing the line and buoys to the surface. The
line and buoys are retrieved like any other Trap. Trap Tracker collects and stores information during the
entire process to help fishers make decisions in the future. This includes underwater unit information,
real-time status information, and user-added operational details.
1.1 Main System Components
The systems main components are:
1.1.1 5112 Rugged Release, Remote Transducer, and NFC (Near Field
Communication) Tag.
Figure 1-1: 5112 Release and Transducer
Figure 1-2: NFC Tag

1-2
5112 Ropeless Fishing System 0022081_REV_B
1.1.2 5112 Configured Release Cages
Optional release cages with EdgeTech, Rope Basket, Line, and Floatation. EdgeTech currently
offers preconfigured 22.5-INCH, 48-INCH, and 48-INCH XL cages. In addition, KITS with parts and
instructions are available for customers who want to build their own cages.
Figure 1-3: 48-inc 5112 RFS Configured Cages
Figure 1-4: 22.5-in 5112 RFS Configured Cage
