EDIFIER R451 User manual

R451
User's Manual
VOLUME
REAR
BASS
Multimedia Desktop Theater
Made in China
Edifier Enterprises Canada Inc.
R451

Welcome !
Very thanks for choosing Edifier multimedia speaker,it can provide good sound formultimedia Computer and home
theater. Before operating the system, please read this manual thoroughly and retain it for future reference.
IMPORTANT SAFETY INFORMATION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flashwith arrowhead, withinan equilateral
triangle, is intendedto alert theuser to thepresence of
Uninsulated "dangerous voltage"within the product's
Enclosure that maybe of sufficientmagnitude to constitute
a risk ofelectric shock topersons.
CAUTION: TOPREVENT THE RISK OF
ELECTRIC SHOCK, DONOT REMOVE COVER
(OR BACK). NOUSER-SERVICEABLE PARTS
INSIDE. REFER SERVICINGTO QUALIFIED
SERVICE PERSONNEL.
The exclamation pointwithin an equilateral
triangle is intendedto alert theuser to thepresence
of important operatingand maintenance (servicing)
instructions in theliterature accompanying the
Appliance.
SAFETY INSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Install in accordancewith the manufacturer's
Instructions.
Do not usethe speakers nearwater, anddo not
immerse them inany liquid orpour any liquidon them.
Do not blockthe openings inthe speaker cabinets,
never push objectsinto speaker ventsor slots
because of fireor electric shockhazards, and provide
sufficient space around the speakersfor proper
ventilation.
The apparatus shallnot be exposedto dripping
or splashing andthat no objectsfilled with liquids,
such as vases,shall be placedon the apparatus.
Do not installnear any heatsources such asradiators,
heat registers, stoves,or other apparatus(including
amplifiers) that produceheat.
Do not defeatthe safety purposeof the polarizedplug.
A polarizedplug has twoblades with onewider than
the other.The wide blade is providedfor your safety. If
the provided plugdoes not fitinto your outlet,consult
an electrician forreplacement of theobsolete outlet.
Protect the powercord from beingwalked on or
pinched particularly atplugs, convenience receptacles,
and the pointwhere they exitfrom the apparatus.
For added protectionduring lightning storms,unplug
the speakers fromthe electrical outletand turn off the
computer.
Unplug this apparatuswhen unused forlong periods
of time.
Water and moisture ----Do not use the speakers near
water, anddo not immersethem in any liquid or pour
any liquid onthem.
Heat---- Place thespeakers away fromall heat sources.
Ventilation ----Do not blockthe openings inthe
speaker cabinets, neverpush objects intospeaker
vents or slotsbecause of fireor electric shock
hazards, and providesufficient space around the
speakers for properventilation.
Location ---- Placethe speakers ina stable location
so they willnot fall causingdamage to thespeakers or
bodily harm.
Cleaning ---- Unplugthe speakers fromthe computer
and from theelectrical outlet beforecleaning them
with a dampcloth.
Lightning ----For addedprotection during lightning
storms, unplug thespeakers from theelectrical outlet
and turn off the computer.
Servicing is requiredwhen the apparatushas been
damaged in anyway, such as power-supplycord or
plug is damaged,liquid has beenspilled or objectshave
fallen into theapparatus, the apparatushas been
exposed to rainor moisture, doesnot operate normally,
or has beendropped. Refer allservicing to qualified
service personnel.
Please adjust theaudio to propervolume to avoid
damaging your healthand the system.
One Year Limited Warranty
Edifier warrants tothe end userthat all ofits computer speakersystems are freefrom defects inmaterial and workmanshipin
the course ofnormal and reasonableuse for aterm of oneyear from thedate of purchase.
This warranty isthe exclusive andonly warranty ineffect relative to Edifier multimedia speaker systems and any other
warranties, either expressedor implied, areinvalid. Neither Edifiernor any authorizedEdifier reseller isresponsible for any
incidental damages incurredin the useof the speakers.(This limitation ofincidental or consequentialdamage is not
applicable where prohibited.)
Edifier obligation underthis warranty doesnot apply toany defect, malfunctionor failure asa result ofmisuse, abuse, improper
installation, use withfaulty or improperequipment or theuse of thespeaker systems withany equipment forwhich they werenot
intended.
The terms ofthis warranty applyonly to speakersystems when suchspeakers are returnedto the respectiveauthorized Edifier
reseller where theywere purchased.
Under the termsof this warrantythe original consumerpurchaser has certainlegal rights andmay have otherrights which vary
worldwide.
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
Notice
Edifier and Edifier logo are owned by Edifier Enterprises Canada Inc. and may be registered. And other
brand names and trademarks are the property of their owners. Edifier assumes no responsibility for any
errors that may appear in this manual. Information contained herein is subject to change without notice.
Copyright 2005
All Rights Reserved.
Manual Edition 1.1, Jun 2005
Printed in CHINA

Introduction
Open the packing
Overview
Introduction of backpanel
6.5 inch antimagnetic professionally enhanced subwoofer driver
3
Low noise designed
inch antimagnetic full range tweeter unit
Two dispartly frequency satellites design
R451 packinglist:
1 x Sub Woofer
5 x satellite Speakers
3 x Audio Connecting Cord
1 x User's Manual
1 Sub Woofer
2 Satellite Speakers
3
4 Surround Control
5 Volume Control
6 Power Indicator
7
8 User's Manual
9 Line In Port
10 Speaker Out
11 Power Switch
12 Power Cord
Super Bass Control
Audio connecting cord
Please check the speaker pattern marked on the package. Please contact the seller as soon as possible if you
find the speakeris not the pattern you want.
R451
Âþ²½Õß
SLSL LL
SRSR RR
CC
SWSW
CCLL
RR
+
-
+
-
++
--
+
-
+
-
++
--
SLSL
SRSR
+
-
+
-
++
--
+
-
+
-
++
--
Speaker Output LINE IN
POWER
ONONOFFOFF
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
VOLUME
REAR
BASS
Edifier
Edifier
Edifier
Edifier
Edifier
CONNECTING
R451
Âþ²½Õß
SLSL LL
SRSR RR
CC
SWSW
CCLL
RR
+
-
+
-
++
--
+
-
+
-
++
--
SLSL
SRSR
+
-
+
-
++
--
+
-
+
-
++
--
LINE IN
POWER
ONONOFFOFF
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Multimedia Desktop Theater
Multimedia Desktop Theater
Speaker Output
Speaker Output
Speaker Output

SPECIFICATIONS:
Surround sound speaker systems using 5.1 format are designed to connect to compatible audio devices offering
5.1 output. Many pc s and DVD players already offerthis type of output. If you only have a 2 channel stereo
output it may be possible to purchase a Dolby digital 5.1 decoder which will convert this into a 5.1 format. This is
not included with these speakers. If you must use a 2 channel input then this should be connected to the front L
and front R input. This will result in a stereo output only.
1.POSITIONING
If you have the 5.1 surround sound input then you can experience the full performance of this system. You will
have the indivedual outputs for the subwoofer, front stereo, rear stereo and front centre speakers. Position the
front stereo speakers in front of the listening position and an equal distance to the left and right sides. Ideally the
speakers should be about ear height(when sitting to listen)if possible and slightly away from a rear wall but they
can be hooded onto a wall if necessary. If they are placed on a slippery surface, a little blue-tack may help hold
them in place. These speakers contribute a lot to the overall audio so careful placement is crucial to your
enjoyment of the music.
The centre speaker should be placed on your TV screen or your computer screen(depending upon
application)as this speaker is used for vocal content. The voices in a movie need to sound as though they are
coming from the Tv set so try positioning this on top of the set.
The rear speakers are used for special effects and are not as crucial in their placement. Agood position for these
is high up on the wall behind the listening position, perhaps pointing downward a little.
The subwoofer houses a powerful bass driver and the positioning of this unit can have an effect on the quality of
the bass. If the unit is placed in a corner, the bass will be amplified by the reflection from the walls. This position
will give maximum bass but can sound quite boomy. Aposition near a rear wall but away from the corner is best
as this will give a little boost to the bass without being too much. Experiment with the position to achieve best
results. Also note that the unit receives the signals from the remote control. The range of transmission from the
remote is not too great so don`t position the bass unit too far from the listening position.
2.CONNECTING
(1).Switch off the power first before connecting any part of the system.
(2).Connect all 5 satellite speakers to their relative speaker output spring clips on the rear panel of the
subwoofer. Please note to match the colour, red to red and black to black. Note that the cable for the rear
speakers is longer than the front.
(3).Connect the inputs to your PC or DVD player as shown in figure.
(4).Plug the AC power plug into the wall outlet, as shown in figure.
OPERATING INSTRUCTIONS:
Total Power Output :
Input Impedance:
Input Sensitive:
Bass Unit:
M
Tweeter Unit:
Frequency Response:
Dimension(Subwoofer):
Dimension(Satellite):
Gross Weight:
id-range Unit:
RMS 6WX5+30W
10K Ohm
450 mV
Aluminum coil, 4 Ohm
3 Paper coil, 4 Ohm
1
42 Hz ~ 20 KHz
290(W) x 193(H) x 285(D)mm
96(W) x 167(H) x 108(D)mm
About 11Kg
6 1/2
PV membrane dome
