EE Systems Group eLEDing/TesLit EE828WTL-AI User manual

Rev: 05212023
Plug –In the
solar plug to
Activate the
system
5-min walk
test mode
Motion
If
Yes
Light ON
Light OFF No
5 min Daytime?
Light ON Yes Light
OFF
Light turns ON
When
night
comes
Thank you for choosing eLEDing! World’s First AI SMART Lighting:
This innovative AI SMART light is unlike all solar light on the current market without any manually functional setting up, it's able to Auto-
Optimization via AI firmware self-calibration in four seasons and its geographical location. US and international patents granted and pending
worldwide. All rights reserved. Users must read this manual before installation, comply with local standard and regulations of construction &
electrical/electronic projects, follow the safety guidelines to prevent any possible accidents, incidents and/or injuries. Consult experienced
contractor/installer and electrical technicians for assistance.
Automatically
Calibrate
No
One Step Setup (Just plug into the plug!)
Auto convert to
Dimming mode
AI SMART lighting profile
Dimming brightness
until dawn
Dusk to Dawn with
dimming brightness
Full brightness
Up to 3 hours
come to
Max
brightness
The fixed Hours high
brightness period is able
to automatically
adjusted depends on
the multiple factors to
ensure all-night
illumination
In most case, occur
on continuous
cloudy/snowing
days during the
winter season
Motion
detected
Motion
detected
If low power
(20% left) ON with full
brightness
Motion
Switch to
AUTO Mode
Light OFF
No
Yes
Yes
Full Charge
Back to AI Mode
NO Critical Reserve
(10% left)
ON with half
brightness
Motion
Light OFF
No
Yes
Second stage Intelligence Power Management (IPM) system : monitor & adjust power consumption
AI Mode In real critical weather
12346 Valley Blvd, El Monte, CA 91732 Phone Number: 1-877-579-3889 Fax: [phone] Web: www.eleding.com/www.eesgi.com
After Fully
Charged
eLEDing/TesLit EE828WTL-AI
AI SMART Solar Light … Built with Dual Ultra-Bright LED Head
Setup
10-3/4”
5-1/2”
Plug-in the solar panel plug under Sensor
head will turn On the light for automatically
normal operation
Mount solar panel must
directly facing to Sun always Mount/hanger-on it with screws, Light heads & Sensor adjustability
Installation Guidelines (video link: https://youtu.be/oaRHKocifVA)
1. Securely mount or even one screw hanger-on the unit on the wall or other surface, etc., Then One Step: Plug the solar panel into plug of light
body to lit-up the light, by adjust the light head direction and sensor angles based on your need.
2. Built with upgraded and full adjustable BIFACIAL solar panel, it is a must to place it in a completely unobstructed location where there is
direct sunlight for at least 5-6 hours on average every day throughout the year. For most of the North America projects, adjust the tilt of the
solar panel at 25°- 60°degrees based on your actual location. The solar panel can be pointed to between east and west, but south is the best
facing direction and definitely NOT to North. For northern hemisphere installations, a south-facing position is best and visa-versa for southern
hemisphere installation.
Optional AUX 12-15VDC/<1.0A power sources can be used as back-up power or fast charging source to give the light a quick charge before
installation or for indoor emergency lighting.
3. Solar Panel Maintenance: Use soft, wet cloth to clean the solar panel periodically (at least once a one year) to avoid energy output reduction
resulted from accumulated dust. Clean accumulated snow ASAP during snowing season.
4. Built in Li-ion battery is replaceable
Polycarbonate/PC with Beige color

Rev: 05212023
As an AI SMART version, after the initial power-on, it requires a
self-calibration process of at least two (2) days in sunny
weather conditions in most geographical environments to
ensure that the product can operate at its optimal performance.
12346 Valley Blvd, El Monte, CA 91732 Phone Number: 1-877-579-3889 Fax: [phone] Web: www.eleding.com
eLEDing/TesLit, EE828WTL-AI
EESGI guarantees this product to be free from defects in material & workmanship for (2) year.
This warranty does not apply to damage from misuse or incorrect installation/ connection.
This warranty does not cover accessories, bulbs, batteries, high voltage accidents, alterations, unauthorized use or repair, neglect, misuse, abuse, damages or defects resulting from normal wear and tear (including chips, fading scratches, abrasions
or discoloration due to usage or sun exposure), or failure to follow instructions for care and maintenance, fire, flood, and Acts of God.
This warranty does not include liability for incidental or consequential damages.
EESGI is not responsible for any damages in excess of the retail purchase price of the product under any circumstances. The consumer is responsible for the installation of, removal of, and reinstallation of the product.
Two Year Limited Warranty
AI SMART Solar Light … Built with Dual Ultra-Bright LED Head
