EENOUR P2001 User manual

Please read this manual before use and follow its guidance. Keep this manual for future reference.
Portable Power StationUser Manual
取扱説明書
󹥦󴴯
P2001

1~17
18~31

Thank you for purchasing the EENOUR Portable Power Station. Before
use, please read the user manual of this product to ensure correct use
after a complete understanding. After reading, please keep the user
manual in a safe place for future reference. If you need any assistance,
please contact our support team at: [e-mail] with your
product model number and Amazon order number.

01. Introduction------------------------------------------------------------------------ 1
02. Safety Instructions------------------------------------------------------------ 2
03. Packing List------------------------------------------------------------------------ 3
04. Specifications---------------------------------------------------------------- 4~5
05. Features------------------------------------------------------------------------- 5~7
06. Display Icon Introduction------------------------------------------------- 8
07. Trouble Shooting--------------------------------------------------------------- 8
08. Recharging------------------------------------------------------------------ 9~11
09. Discharging---------------------------------------------------------------------- 12
10. UPS Introduction------------------------------------------------------------- 13
11. Application Scenario------------------------------------------------------- 13
12. FAQs (Frequently Asked Questions)-------------------- 14~15
13. Maintenance-------------------------------------------------------------- 15~16
14. Disclaimer------------------------------------------------------------------------ 16
15. Warranty & Customer Support------------------------------------- 17
CONTENTS

EENOUR P2001 is a portable power station, that features higher contin-
uous output power at 2000W from its pure sine wave inverter, with multi-
ple outlets suitable for home emergency power backup, outdoor travel,
emergency disaster, field work, and other applications.
The product has a built-in lithium iron phosphate battery, which supports
AC fast charging, car charging, and solar panel charging (the product
has a UPS function when the power fails, it can switch the power supply
to the electrical appliance within 10ms).
The AC output is a pure sine wave, which will provide better protection
for electrical appliances.
INTRODUCTION
111

● DO keep the P2001 away from the fire and heat.
● DO operate the P2001 in a dry and well-ventilated place. If it gets
moisturized or damp, please dry it thoroughly before use.
● DO NOT obstruct fan openings to ensure proper ventilation in use.
Otherwise, permanent damage to the P2001 may occur.
● DO NOT use this product in a high-temperature environment.
● DO NOT move the unit while operating as vibrations and sudden
impacts may lead to poor connections to the hardware inside.
● Please use the original charger and cables only designed for the
P2001.
The company shall not be liable for damage caused by third-party
equipment, which also may invalidate your warranty.
● Please carefully read the operating instructions of the electrical prod-
ucts to be connected. Failure to operate the electrical products properly
may result in accidents or injuries.
● Please use the P2001 power station carefully and children or those
with sensory discomfort and lack of experience should use under the
supervision of other adults.
Warning
● In case of fire, ONLY dry powder fire extinguisher works.
● DO NOT insert foreign objects into any ports of the P2001 (AC, DC,
or ventilation holes). The power station generates the same potentially
lethal AC power as a household wall outlet.
●DO NOT use a broken plug or wire with this product, it may cause
unpredictable risks.
● It is hazardous for anyone other than the authorized person to carry
out any service or repair operation involving replacing the internal
battery or other equipment components.
Please keep this manual for future reference.
SAFETY INSTRUCTIONS
2

1 2 3
56
1 × Portable Power Station
1 × AC Charger
1 × Solar Charging Cable (MC4 to Anderson)
1 × Car Charger Cable ( Anderson - Cigarette Lighter Plug)
1 × User Manual
1 × Thank You Card (Quick Start Card)
Portable power station AC charger Solar Charging Cable
Car Charger Cable User Manual Thank You Card
PACKING LIST
3
Pleaseread this manual before use and follow its guidance. Keep this manual for future reference.
Portable Power StationUser Manual
取扱説明書
󹥦󴴯
P2001

110V Rated Power 2000W
(Peak 4000W)
5V 2.4A Total 24W
5V 3A/9V 2A/12V 1.5A
18W Total 36W
5V 3A/9V 3A/12V 3A/
15V 3A/20V 5A
100W PD compatible,
total 200W
12V 10A 120W
2W Light/SOS/Blinking
14°F-113°F / -10°C-45°C
32°F-113°F / 0°C-45°C
AC Output
(6 outlets)
USB-A
(2 outlets)
QC3.0
(2 outlets)
TYPE-C
(2 outlets)
DC Output
(2 outlets)
Cigarette Lighter
Output (1 outlet)
XT60(1 outlet)
LED Light
Operating Temp
Charging Temp
Output
Model
Battery
Type
Capacity
Frequency
Input
Weight
Size
Cycle Life
Built-in
MPPT
Controller
P2001
LiFePO4
2000Wh 3.2V/625600mAh
(51.2V/39100mAh)
AC
PV
Car Charger
Function to improve solar
recharging efficiency
About 3500 times
15.5*11*13inches
(39.4*27.9*33cm)
48.5Lbs (22KG)
60Hz
1100W
100-120V
12V-15V 8A/
15V-30V 10A/
30V-48V 15A
500W Max
12V 3A 36W
12V 8A
24V 10A
SPECIFICATIONS
4

FEATURES
LiFePo4
51.2V(2000Wh) 15.5*11*13inches48.5Lbs
3500
Cycle lifeCapacity Weight Size
5V/2.4A QC3.0-18W 12V/10A12V/3A
PD-100W
USB-C *2USB-A*2
12V/10A
XT60*1
USB-A*2 Output*2 Cigar Lighter*1
2000W
AC 110V
1100W
100-120V 2W
12-48V Max 15A
500W Max
Anderson InputAC Output*6 AC Input LED Light
Main power control
1
Light control
2
USB control
3
DC control
4
LCD display
5
5
4
3
1
2
Anderson input port
(for solar panel / car charger)
8
AC input port
9
Overload protection
10
Air intake/outlet
6
AC on/off control
7
7
6
9
6
10
8
OVERLOAD
PROTECTION
5
Lbs

1. Main power control
Main Control for the whole system turns on/off.
Operate method: long press the button for 3s to turn on/off the system.
P2001 will automatically turn off if you do not operate it for 5 minutes.
2. LED light control
Long press to turn the light on. Each time a short press, the lighting
mode switches as follows.
Lighting Mode → SOS Mode → Blinking Mode → Off.
In either mode, you can turn off the light by pressing and holding the light
switch for 1 second or longer.
3. USB button
Operate method: short press to turn on/off
4. DC button
Operate method: short press to turn on/off.
5. LCD display
Display the remaining power and use data.
6. Cooling system
It is a device to prevent overheating inside the product. When the fans
are working, please don’t block the channel.
● Fan operating conditions
a. When powered on, the fans will rotate for 3 seconds to check the func-
tion of fans.
b. When the battery temperature exceeds 113°F/45 ° C during charging
/ discharging, the fan will start rotating. If it drops below 104°F/40 ° C, the
rotation will stop.
c. The fans will start to rotate when heat sink exceed 65 ℃, once drops
below 55° C, they will stop.
5V/2.4A QC3.0-18W PD-100W
TYPE-C*2USB-A*2 USB-A*2
12V/3A 12V/10A 12V/10A
XT60*1Output*2 Cigar Lighter*1
6

7. AC button (AC output*6, total output≤2000W)
Operate method: short press to turn on/off.
8. Anderson port
Anderson port for recharging through a car charger or solar panel.
9. AC input
Can get a quick charge through 1100W main AC from the wall outlet or
generator.
10. Overload protector
To protect the P2001 portable power station, an overload protector is
added. Prevent damage to the product due to excessive AC input
current caused by lightning and power grid fluctuations. When such a
situation occurs, the overload protector will cut off the AC input to protect
the product.
● When the overload protector is activated, it’s unable to charge the
devices. Please follow the steps below to restore the functions of P2001.
a. For safety reasons, turn the product OFF and unplug all ports.
b. After confirming that there is no abnormality in each part, turn on the
product.
c. Press the overload protection button to restart AC input.
AC Outputs*6
Anderson input
7
2000W
Peak 4000W

DISPLAY ICON INTRODUCTION
TROUBLE SHOOTING
6
1 2 3 4 5
7
89101112131415
1Charge/Discharge remaining time
2Fan state
3High/low temperatureprotection
4Battery percentage
9Type-C output
10 USB output
11 AC charging
12 Anderson charging
13 DC output
14 Cigar lighter output
15 XT60 output
6Total output power
7LED light
8AC output
5Total input power
Icon Status Explanation Recover method
icon blinking
icon blinking
The icon corresponds to the
port short-circuit and overload
protection
Power Grid abnormal
Remove the load and press
the key to return to normal
Check whether there is an
abnormality in the power grid
icon blinking Input voltage is too high Check whether the nput
voltage is too high
icon light up
On behalf of the temperature
rise, the machine starts to
dissipate heat normally
icon light up
When H light up, the
temperature is high, and when
L light up, the temperature is
low. The device may start the
smart protection program and
stop working
Need to wait for the machine
to return to the normal
temperature range to
continue working
8

This product can be charged from wall outlets, solar panels (sold sepa-
rately), car cigarette lighters, or generators.
(1)Recharging Through the AC Wall Outlet
Connect the plug of the AC charging cable to the wall outlet, and the
other side to the AC input port.
When charging, the LCD display shows the remaining battery level in %,
and the battery level indicator flashes. In addition, the AC input icon,
input wattage, and estimated time to complete charging are also
displayed.
(2) Recharging Through the Solar Panels
Place your solar panel (sold separately) in a place exposed to direct sun-
light.
● Connect the solar panels with the Voltage range 12V-48V. If the volt-
age is over 48V, the over-voltage protection will work and stop charging.
● The maximum input current of this product is 15A. The maximum PV
input power is up to 500W. Even if the wattage is 500W or more, it will be
input with 500W.
RECHARGING
9

Connecting Pattern ①
Connecting Pattern ②
The area of charging
AC input Anderson port
Solar panel(Not include accessory)
+ +
- -
Device
OVERLOAD
PROTECTION
Solarpanel(Notincludeaccessory)
Device
ACinput Andersonport
+
-
+
-
+
-
Solarpanel ASolarpanel B
The area of charging
OVERLOAD
PROTECTION
10

(4)Recharging Through the Generator (gasoline,
propane, or diesel)
Connect the AC charging cable to the generator and the input to the AC
charging port of P2001.
Start the generator; the P2001 will start recharging. When it gets fully
charged, the charging will automatically stop.
(3) Recharging Through Car Charger
Connect the P2001 to the cigarette lighter port of the car via the car
charging cable.
● While charging, the LCD display shows the remaining battery level in
%, and it blinks. It also displays the Anderson input icon, input wattage,
and an estimated time to full charge.
(Not include accessory)
AC input Anderson port
Device
OVERLOAD
PROTECTION
11

(1)AC Output
● Press and hold the main power switch for 3 seconds to make P2001
into standby mode. Short press the AC output switch to turn on the AC
output.
● Check the battery level. If the battery level is 10% or less, charge it.
● Make sure that the power of the connected device is less than the
rated power (2000W) of P2001.
● Connect the device to the AC output port for use.
* When not in use, turn off the AC output to save power.
* The maximum AC output of the equipment is 2000W (4000W at the
peak).
(2)DC Output
●Press and hold the main power switch for 3 seconds to make P2001
into standby mode. Short press the DC output switch to turn it on.
●Check the battery level. If the battery level is 10% or less, recharge it.
●Connect the device to the cigarette lighter port, DC output port, and
XT60 output side.
* When not in use, turn off the DC output to save power.
(3)USB Output
●Press and hold the main power switch for 3 seconds to make P2001
into standby mode. Short press the USB output switch to turn on the
USB output.
●Check the battery level. If the battery level is 10% or less, recharge it.
●Connect a USB device to the USB output port.
* Quick charging (QC3.0, PD) may not be possible depending on the
USB device to be charged and the cable used for charging.
* When not in use, turn off the USB output to save power.
DISCHARGING
12

UPS INTRODUCTION
APPLICATION SCENARIO
You can connect the P2001 AC charge cable to the wall outlet, and
then connect the electrical appliances to the AC outlet of the P2001
then turn the AC output on (as shown in the below).
Attention
1. The UPS ONLY supports appliances under 1100W.
2. Before the power cut, the power supply will directly come from the
power grid.
3. When power is cut, the devices will switch the power supply from the
power grid to the P2001 battery automatic in 10ms, and keep your appli-
ances working.
(1) Outdoor
Car equipment: car fridge, car vacuum cleaner, and other car equipment;
Camping equipment: garden electric tools (power tools such as blowers,
lawnmowers, electric drills, electric saws), BBQ grills, LED lights, etc.
(2) Indoor
Refrigerator, kitchen devices such as kettle, toaster, blender, coffee
maker, rice cooker, laptops, phones, lighting, etc.
TV
13

1. The appliance's power is within the rated output power range of
the product but it cannot be used?
When some electrical appliances started, the peak power is higher than
the product power(4000w).
2. Why is there a sound when using it?
The sound comes from the fan or relay when you start or using the prod-
uct.
3. Is it normal for the charging cable to heat up during use?
Yes, it is. The cable complies with national safety standards and with
related certificates.
4. What kind of battery do we use in this product?
The battery type is lithium iron phosphate.
5. What devices the product can support by the AC output?
The AC output power consumption is rated 2000W, peak 4000W. It’s
available to power most the home appliances, which rated power con-
sumption is lower than 2000w. Please make sure the total loading by AC
is under 2000W before using.
6. How can we know the remaining using time?
Please check the data on the screen, it will show the remaining using
time when you turn it on.
7. How can we confirm the product is recharging?
When the product is under charging, the product screen will show the
input wattage, and the power percentage indicator will blink.
8. Can it charge and recharge at the same time?
Yes, it supports pass-through charging. Please keep the equipment laid
flat during use, charging, and recharging.
FAQs
14

9. How should we clean the product?
Please use a dry, soft, clean cloth or tissue to wipe the product.
10. How to store P2001?
a. Please turn off the product and place it in a dry, ventilated place under
room temperature. Do not place this product near water sources.
b. For long-term storage, we recommend using the product every three
months (Runout the remaining battery first and full charge).
11. Can we take this product on an airplane?
No, you can't.
12. Is the actual output capacity of the product the same as the
target capacity in the user manual?
The capacity of the user manual is the rated capacity of the battery pack
of this product. Because this product has a certain efficiency loss during
the recharging and charging process, the actual output capacity of the
product is lower than the capacity specified in the user manual.
(1)Fully charge the product before storing it. If the battery is unused for
a long time when the battery is seriously insufficient, it will cause
irreversible damage to the battery and shorten the cycle life of the prod-
uct.
(2)Turn off all power buttons.
(3)To prolong the life of the battery, charge it at least once every three
months until it is fully charged.
(4)Store in a well-ventilated place. Never use it in a place with volatile,
flammable gas, or fire nearby. If the storage environment is not good, it
may cause defects in the product.
(5)Do not store in a damp or wet place such as in the rain or in a bath-
room.
MAINTENANCE
15

(6)Store in a place with little dust, low humidity, and no moisture.
(7)Please keep it out of reach of children and pets.
(8)If it is dirty, squeeze out the water from the rag before wiping it.
(9)Use or store this product at 20-30°C (68-86°F)
(10)Do not store this product at a high temperature of 45°C/113°F or low
14°F/-10°C for a long time.
●Our company cannot be held liable for damages caused by fire, earth-
quake, used by a third party, other accidents, intentional misconduct on
the part of customers, abuse, or other abnormal conditions.
●Do not repair any damage to the AC plug or power supply on your own.
●The warranty covers all terms and conditions of the warranty. Contents
that are not specified in the warranty terms and conditions are beyond
our responsibility.
●Our company assumes no liability for damaged caused by incorrect
use or non-compliance with this instruction manual.
Intended use: The EENOUR P2001 portable power unit is intended as a
power supply for electronic devices with a maximum power consumption
of 2000W. Our product is not suitable to be used with equipment that is
related to one's own personal safety and relies heavily on electricity,
such as medical devices, equipment for nuclear facilities, the manufac-
ture of air and spacecraft, etc. We, therefore, assume no liability for acci-
dents involving personal safety, fires, or machine failures, caused by
using our product with the aforementioned devices.
DISCLAIMER
16
