EGO PSA1000 User manual

POLE SAW ATTACHMENT
OPERATOR'S MANUAL
POLE SAW ATTACHMENT
MODEL NUMBER PSA1000
FOR USE ONLY WITH THE 56V LITHIUM-ION
POWER HEAD PH1400E
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.

B
1. End Cap
2. Soft Sleeve
3. Pole-saw Shaft
5. Wrench Holder
6. Cover-screw
7. Chain-sprocket Cover
8. Extension Pole (Optional, SOLD SEPARATELY)
13. Oil-tank Cap
12. Chain-tensioning
Screw
11. Guide Bar
10. Saw Chain
14. Oil Tank
15. Bucking Spikes
9. Chain Sheath
4. Dual-head
Wrench
A

E
G
I
H
J
F
C D
1
Minimum
15m
15m
60
Maximum
2
3
60
Maximum

M
R
K
N
O
Q
P
L
1.3mm
Chain Drive Links
Guide-bar Groove
Sprocket
Tension-adjusting
Pin
Alignment
Bulges Chain-tensioning
Screw
Lubricating Hole
Sprocket in Guide-bar Tip
Guide-bar Slot

POLE SAW ATTACHMENT — PSA1000 5
READ ALL INSTRUCTIONS!
READ OPERATOR’S MANUAL
Residual risk! People with electronic devices, such
as pacemakers, should consult their physician(s) before
using this product. Operation of electrical equipment
in close proximity to a heart pacemaker could cause
interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all
repairs and replacements should be performed by a
qualied service technician.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention
to possible dangers. The safety symbols and the
explanations with them deserve your careful attention
and understanding. The symbol warnings do not, by
themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand all
safety instructions in this Operator’s Manual, including all
safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, re,
and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER,
WARNING, or CAUTION. May be used in conjunction with
other symbols or pictographs.
WARNING: The operation of any power
tools can result in foreign objects being thrown
into your eyes, which can result in severe eye
damage. Before beginning power tool
operation, always wear safety goggles or safety
glasses with side shields and a full face shield
when needed. We recommend a Wide Vision
Safety Mask for use over eyeglasses or
standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may
appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble
and operate it.
Safety Alert Indicates a potential
personal injury hazard.
Read
Operator’s
Manual
To reduce the risk of
injury, user must read
and understand the
operator’s manual before
using this product.
Wear Eye
Protection
Always wear safety gog-
gles or safety glasses
with side shields and
a full face shield when
operating this product.
Wear Ear
Protection
Pole saw noise may
damage your hearing.
Always wear sound
barriers (ear plugs or ear
mufers) to protect your
hearing.
Wear Head
Protection
Wear an approved safety
hard hat to protect your
head.
Wear
Protective
Gloves
Protect your hands with
gloves when handling
saw and saw chain.
Heavy-duty, nonslip
gloves improve your grip
and protect your hands.
Wear
Safety
Footwear
Wear non-slip safety
footwear when using this
equipment.
Keep
sufcient
distance
away from
electrical
power
lines
To prevent electrocution,
do not operate within
50 ft. (15m) of overhead
electrical lines. Contact
with or use near power
lines may cause serious
injury or electric shock
resulting in death.
XX
NOISE dB
Noise Sound pressure level
IPX4
Ingress
Protection
Degree
Protection from splashing
water
V Volt Voltage

POLE SAW ATTACHMENT — PSA10006
mm Millimeter Length or size
cm Centimeter Length or size
in. Inch Length or size
kg Kilogram Weight
n0
No Load
Speed
Rotational speed, at
no load
... /min Per Minute Revolutions per minute
Direct
Current
Type or a characteristic
of current
IMPORTANT SAFETY INSTRUCTIONS
WARNING! When using electric gardening appliances,
basic safety precautions should always be followed to reduce
the risk of re, electric shock, and personal injury, including
the following:
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
DANGER! Do not operate near electrical power lines.
The unit has not been designed to provide protection from
electric shock in the event of contact with overhead electric
lines, Consult local regulations for safe distances from
overhead electric power lines and ensure that the operating
position is safe and secure before operating the tool.
POLE SAW SAFETY WARNINGS
◾Keep all parts of the body away from the saw chain
when the pole saw is operating. Before you start the
pole saw, make sure the saw chain is not contacting
anything. A moment of inattention while operating pole
saws may cause entanglement of your clothing or body
with the chain.
◾Avoid unintentional contact with the stationary saw
chain or guide bar rails. These can be very sharp.
Always wear gloves and long pants or chaps when
handling the pole saw, saw chain, or guide bar.
◾Always hold the pole saw with your one hand on
the rear handle and your other hand on the front
handle. Serious injury to the operator, helpers, and/or
bystanders can result from one-handed operation.
◾Hold the power tool by insulated gripping surfaces
only, because the saw chain may contact hidden
wiring. Saw chains contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
◾Wear safety glasses and hearing protection.
Further protective equipment for head, hands,
legs and feet is recommended. Adequate protective
clothing will reduce personal injury by ying debris or
accidental contact with the saw chain.
◾Do not operate a pole saw in a tree. Operation of a
pole saw while up in a tree may result in personal injury.
◾Always keep proper footing and operate the pole
saw only when standing on xed, secure and level
surface. Slippery or unstable surfaces such as ladders
may cause a loss of balance or control of the pole saw.
◾Never operate a pole saw that is damaged or
improperly adjusted or that is not completely and
securely assembled. Be sure that the saw chain stops
moving when the trigger switch is released.
◾Inspect the work piece for nails, wire, or other
foreign objects prior to cutting.
◾When cutting a limb that is under tension be alert
for spring back. When the tension in the wood bers
is released the spring loaded limb may strike the
operator and/or throw the pole saw out of control.
◾Use extreme caution when cutting brush and
saplings. The slender material may catch the saw chain
and be whipped toward you or pull you off balance.
◾Aggressive or abusive cutting or misuse of the
pole saw can cause premature bar, chain, and/
or sprocket wear, as well as broken chain or bar,
leading to kickback, chain throw or the ejection of
material.
◾Never use the guide bar as a lever. A bent guide bar
can cause premature bar, chain, and/or sprocket wear,
as well as a broken chain or bar, leading to kickback,
chain throw or the ejection of material.
◾Carry the pole saw with two hands on the handles,
with the pole saw switched off. When transporting or
storing the pole saw always t the guide bar cover.
Proper handling of the pole saw will reduce the likelihood
of accidental contact with the moving saw chain.
◾Do not remove cut material or hold material to be
cut when blades are moving. Make sure the switch
is off when clearing jammed material. Saw chain
continues to move after the switch is turned off. A
moment of inattention while operating the pole pruner
may result in serious personal injury.
◾Follow instructions for lubricating, chain
tensioning and changing accessories. Improperly
tensioned or lubricated chain may either break or
increase the chance for kickback. Keep cutting edge
sharp and clean for best performance and to reduce
the risk of injury.

POLE SAW ATTACHMENT — PSA1000 7
◾Keep handles dry, clean, and free from oil and
grease. Greasy, oily handles are slippery causing loss
of control.
◾Cut wood only. Do not use pole saw for purposes
not intended. For example: do not use pole saw
for cutting plastic, masonry or non-wood building
materials. Use of the pole saw for operations different
than intended could result in a hazardous situation.
◾Do not use the pole saw in bad weather conditions,
especially when there is a risk of lightning. This
decreases the risk of being struck by lightning.
◾Stop the motor and remove the battery pack
whenever you leave the tool.
◾Store Idle Appliances Indoors. When not in use,
appliances should be stored indoors in a dry and high
or locked-up place with the battery pack removed, out
of reach of children.
◾Check Damaged Parts. Before further use of the
product, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other condition
that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced
by an authorised service center unless indicated
elsewhere in this manual.
ADDITIONAL WARNINGS
◾Do not charge the battery pack in rain, or in wet
locations.
◾Use only with EGO’s battery packs and chargers.
BATTERY PACK CHARGER
BA1120E, BA2240E, BA3360,
BA1400, BA2800, BA4200
CH2100E, CH5500E
◾The battery pack must be removed from the
appliance before it is scrapped.
◾The battery shall be disposed of safely.
◾Do not dispose of the battery in a re. The cells may
explode. Check with local codes for possible special
disposal instructions.
◾Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
CAUTION! The electrolyte is a dilute sulfuric acid that
is harmful to the skin and eyes. It is electrically conductive
and corrosive.
◾Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns.
◾Battery tools do not have to be plugged into an
electrical outlet; therefore, they are always in
operating condition. Be aware of possible hazards
even when the tool is not operating. Take care when
performing maintenance or service.
◾Remove the battery pack before servicing, cleaning
or removing material from the tool.
◾Replacement Parts - When servicing, use only
identical EGO replacement parts. Use of any other
accessory or attachment may increase the risk of
injury.
◾Do not wash with a hose; avoid getting water in
motor and electrical connections.
◾If situations occur that are not covered in this
manual, use care and good judgment. Contact the
EGO Service Center for assistance.
◾Save these instructions. Refer to them frequently
and use them to instruct others who may use this tool.
If you lend this tool to someone else, also lend these
instructions to them to prevent misuse of the product
and possible injury.
SAVE THESE INSTRUCTIONS
NOTE: SEE YOUR POWER HEAD OPERATOR’S
MANUAL FOR ADDITIONAL SPECIFIC SAFETY RULES.
SPECIFICATIONS
Guide Bar Length 250 mm
Chain Pitch 9.5 mm
Chain Gauge 1.1 mm
Saw Chain Type 90PX040X
(Oregon)
Guide Bar Type 104MLEA041
(Oregon)
Chain Oil Tank Capacity 220 ml
Weight (with chain sheath) 1.89 kg
Sound pressure level 75 dB(A)

POLE SAW ATTACHMENT — PSA10008
PACKING LIST
PART NAME QUANTITY
Pole Saw Attachment 1
Chain Sheath 1
Dual-head Wrench 1
Operator’s Manual 1
Recommended Bar and Chain for this Pole Saw
PART NAME MODEL NUMBER
Guide Bar AG1000
Saw Chain AC1000
DESCRIPTION
KNOW YOUR POLE SAW ATTACHMENT (Fig. A)
1. End Cap
2. Soft Sleeve
3. Pole-saw Shaft
4. Dual-head Wrench
5. Wrench Holder
6. Cover-screw
7. Chain-sprocket Cover
8. Extension Pole (Optional, SOLD SEPARATELY)
9. Chain Sheath
10. Saw Chain
11. Guide Bar
12. Chain-tensioning Screw
13. Oil-tank Cap
14. Oil Tank
15. Bucking Spikes
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are replaced.
Use of this product with damaged or missing parts could
result in serious personal injury.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use with this
pole saw. Any such alteration or modication is misuse
and could result in a hazardous condition leading to
possibly serious personal injury.
CONNECTING THE POLE SAW ATTACHMENT TO THE
POWER HEAD
This pole saw attachment is designed for use with EGO
56V LITHIUM-ION Power Head PH1400E.
See “INSTALLING AN ATTACHMENT TO THE POWER
HEAD“ section in the power head PH1400E operator’s
manual.
CONNECTING THE EXTENSION POLE BETWEEN THE
POWER HEAD AND THE POLE SAW ATTACHMENT
(Optional)
The extension pole extends the cutting range. It should to
be connected between the power head and the pole saw
attachment.
Follow the process in the section “CONNECTING THE POLE
SAW ATTACHMENT TO THE POWER HEAD “to install and
secure the extension pole between the pole saw attachment
and power head (Fig. C).
WARNING: Failure to secure the attachment and
power head/extension pole as instructed above could
result in serious injury or death.
WARNING: Never attach or adjust any attachment
while the power head is running or with the battery
installed. Failure to stop the motor and remove the battery
may cause serious personal injury.
OPERATION
DANGER: Never cut near power lines, electric cords,
or other electric sources. If the bar and chain jams on
any electrical cord or line, DO NOT TOUCH THE BAR,
CHAIN OR THE ALUMINUM POLE! THEY CAN BECOME
ELECTRICALLY LIVE AND MAY BE VERY DANGEROUS.
Continue to hold the pole saw by the insulated rear handle
or lay it down and away from you in a safe manner.
Disconnect the electrical service to the damaged line or
cord before attempting to free the bar and chain from the
line or cord. Contact with the bar, chain, other conductive
parts of the pole saw, or live electric cords or lines could
result in death by electrocution or serious injury.
WARNING: Do not allow familiarity with this product
to make you careless. Remember that a careless fraction
of a second is sufcient to inict serious injury.

POLE SAW ATTACHMENT — PSA1000 9
WARNING: Always wear eye protection, along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
Before each use, inspect the entire product for damaged,
missing, or loose parts such as screws, nuts, bolts, caps,
etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts
are replaced.
WARNING: To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, changing attachments or removing material
from the unit.
APPLICATIONS
You may use this product for the purpose listed below:
◾Limbing
◾Pruning
NOTICE: The tool is to be used only for its prescribed
purpose. Any other use is deemed to be a case of misuse.
FILLING OILTANK WITH BAR AND CHAIN LUBRICANT
WARNING: Do not smoke or bring any re or ame
near the oil or the pole saw. Oil may spill and cause a re.
NOTICE: The pole saw is not lled with oil at the time of
purchase. It is essential to ll the tank with chain oil before
use. Chain life and cutting capacity depend on optimum
lubrication. The chain is automatically lubricated with chain
oil during operation. Oil level should also be checked after
every 20 minutes of use and relled as needed.
1. Remove the battery pack from the power head.
2. Clean the oil tank cap and the area around it to ensure
that no dirt falls into the oil tank.
3. Place the pole saw attachment upright and rotate the oil
tank cap counterclockwise to remove it (Fig. D).
4. Carefully pour the bar and chain oil into the tank until it
lls to the tank neck. Be careful not to let the oil spill from
the opening. Wipe off any excess oil and close the oil
tank cap.
NOTICE:
◾Use OREGON®bar and chain oil for best results. It is
specially designed to provide low friction and faster cuts.
◾Do not use dirty, used or other contaminated oils.
Damage may occur to the bar or chain.
PREPARATION FOR CUTTING (Fig. B)
Refer to “Important Safety Instructions” earlier in this
manual for appropriate safety equipment.
◾Lift the tip of the guide bar to check for any sagging
in the chain. The chain is correctly tensioned when
there is no sag on the underside of the guide bar and
the chain is snug, but it can be turned by hand without
binding. If the tension requires adjustment, refer to the
“REPLACING THE BAR AND CHAIN” section in the
MAINTENANCE section of this manual for adjustment
instructions.
◾Check the tension of the cover screw before use. If it
is loose, securely tighten the cover screw by turning it
clockwise.
◾Check the sharpness of cutting teeth on the saw chain
and make sure the chain is well lubricated.
◾Wear non-slip gloves for maximum grip and protection.
Never stand directly under the limb you are cutting.
Make sure that you have a secure and balanced footing.
Watch out for obstacles such as tree stumps, roots and
ditches, which could cause you to trip or stumble.
◾Maintain a proper grip on the unit whenever the motor
is running. Hold the unit rmly with both hands.
◾For safe and better operation, put on the shoulder
strap across the shoulder. Adjust the shoulder strap
into a comfortable operating position. Following
the instructions in the section “MOUNTING THE
SHOULDER STRAP” in PH1400E operator’s manual to
attach the shoulder strap onto the power head.
WARNING: The shoulder strap is also a quick
release mechanism in hazardous situation. When an
emergency occurs, take it off your shoulder immediately,
no matter what way the strap is in.
TO START/STOP THE TOOL
See “STARTING/STOPPING THE POWER HEAD” section
in the power head PH1400E operator’s manual.
BASIC CUTTING PROCEDURE (Fig. E & F)
Follow the steps below to prevent damage to tree or
shrub bark. Do not use a back-and-forth sawing motion.
1. Make a shallow rst cut (1/4 of limb diameter) on the
underside of the limb close to the main limb or trunk.
2. Make a second cut from the top side of the limb
outboard from the rst cut. Continue the cut through the
limb until the limb separates from the tree. Be prepared
to balance the weight of the tool when the limb falls.
3. Make a nal cut close to trunk.

POLE SAW ATTACHMENT — PSA100010
NOTICE: For second and nal cuts (from top of limb or
branch), hold the bucking spikes against the limb being
cut (Fig. F). This will help steady the limb and make it
easier to cut with light downward pressure. If you force
the cut, damage to the bar, chain, or motor can result in.
4. Release the trigger on the power head as soon as the
cut is completed.
NOTICE: Failure to follow proper cutting procedures will
result in the bar and chain binding and becoming pinched
or trapped in the limb. If this should happen:
1. Stop the motor and remove the battery pack.
2. If the limb can be reached from the ground, lift the
limb while holding the saw. This should release the
“pinch” and free the saw.
3. If the saw is still trapped, call a professional for
assistance.
LIMBING AND PRUNING
This pole saw attachment is designed for trimming small
branches and limbs up to 20cm in diameter. For best
results, observe the following precautions.
1. Plan the cut carefully. Be aware of the direction in
which the branch will fall.
WARNING: Branches may fall in unexpected
directions. Do not stand directly under the branch being cut.
2. The most typical cutting application is to position the
unit at an angle of 60° or less (Fig. G). As the angle
of the pole saw shaft to the ground increases, the
difculty of making the rst cut (from the underside
of limb) increases.
3. Remove long branches in several stages.
4. Cut lower branches rst to allow the top branches
more room to fall.
5. Work slowly, keeping both hands on the saw with a
rm grip. Maintain secure footing and balance.
6. Do not cut from a ladder; this is extremely dan-
gerous. Leave such operations for professionals.
7. Do not make the ush cut next to the main limb
or trunk until you have cut off most of the limb
to reduce the weight. Following proper cutting
procedures will prevent stripping the bark from the
main member.
8. Do not use the pole saw for felling or bucking.
9. To prevent electrocution, do not operate within 15m
of overhead electrical lines and keep bystanders at
least 15m away (Fig. G).
MAINTENANCE
WARNING: Before inspecting, cleaning or servicing
the unit, stop the motor, wait for all moving parts to stop,
and remove the battery pack. Failure to follow these
instructions can result in serious personal injury or property
damage.
WARNING: When servicing, use only identical
replacement parts. Use of any other parts can create a
hazard or cause product damage. To ensure safety and
reliability, all repairs, other than the items listed in these
maintenance instructions, should be performed by a
qualied service technician.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to damage from various types of commercial
solvents and may be damaged by their use. Use clean cloths to
remove dirt, dust, oil, grease, etc.
CLEAN THE UNIT
◾After each use, remove the battery and clean debris
from the chain and guide bar with a soft brush. Wipe
the pole saw surface with a clean cloth moistened with
a mild soap solution.
◾Remove the chain-sprocket cover, and then use a soft
brush to remove debris from the guide bar, saw chain,
sprocket and chain-sprocket cover.
◾Always clean out wood chips, saw dust, and dirt from
the guide bar groove when replacing the saw chain.
NOTICE: Do not use any strong detergents on the plastic
housing or the handle. They can be damaged by certain
aromatic oils such as pine and lemon.
REPLACING THE BAR AND CHAIN
WARNING: Never touch or adjust the chain while
the motor is running. The saw chain is very sharp; always
wear protective gloves when performing maintenance to
the chain.
NOTICE: When replacing the guide bar and chain, always
use the specied bar and chain combination listed in the
“Recommended Bar and Chain for this Pole Saw” section.
Disassembling the Worn Bar and Chain
1. Remove the battery, allow the pole saw to cool and
tighten the oil tank cap.
2. Position the pole saw attachment on its side with the
chain-sprocket cover facing upwards.

POLE SAW ATTACHMENT — PSA1000 11
3. Wear gloves. Using the dual-head wrench provided,
loosen the cover screw to remove the screw and the
chain-sprocket cover. Clean the chain-sprocket cover
with a dry cloth and save it for reassembly (Fig. H).
4. Remove the bar and chain from the mounting
surface. Remove the worn chain from the bar.
NOTICE: If there is difculty in removing the bar and chain
from the mounting surface, place the pole saw upright, with
one hand support the bar, to loosen the chain-tensioning
screw counterclockwise with the other hand (Fig. I) and
then remove the bar with the chain.
NOTICE: This is a good time to inspect the drive sprocket
for excessive wear or damage.
Assembling the New Bar and Chain
1. Lay the new saw chain in a loop on a at surface and
straighten any kinks (Fig. J).
2. Place the chain drive links into the guide bar groove.
Position the chain so there is a loop at the back of
the guide bar (Fig. K).
3. Hold the chain in position on the guide bar and place
the loop around the sprocket of the pole saw.
NOTICE: Small directional arrows are engraved in the
saw chain. Another directional arrow is molded into the
tool body (Fig. L). When looping the saw chain onto the
sprocket, make sure that the direction of the arrows on the
saw chain CORRESPOND to the direction of the arrow on
the tool body. If they face in opposite directions, turn over
the saw chain and guide bar assembly (Fig. M).
4. Place the guide bar on the mounting surface by
sliding the guide bar slot over the alignment bulges,
making sure that the tension adjusting pin is inserted
in the lower hole in the tail of the bar (Fig. L).
NOTICE: If there is difculty in inserting the tension
adjusting pin into the hole, adjust the chain-tensioning
screw properly until the tension adjusting pin is located
exactly in the hole.
5. Replace the chain-sprocket cover and the cover
screw. Slightly tighten them.
6. Remove all the slack from the chain by turning the
chain-tensioning screw clockwise until the chain
seats snugly against the guide bar with the drive
links in the guide bar groove and lift the tip of the
guide bar to check for sag. Release the tip of the
guide bar and turn the chain-tensioning screw
once clockwise. Repeat this process until the sag is
eliminated (Fig. N).
7. Hold the tip of the guide bar up and tighten the
chain-sprocket-cover screw securely.
NOTICE: To extend the guide bar life, invert the bar
occasionally.
NOTICE: If chain is too tight, it will not rotate. Loosen the
chain-sprocket-cover screw slightly and turn the tensioning
screw 1/4 turn counterclockwise. Lift the tip of the guide
bar and retighten the chain-sprocket-cover screw securely.
Assure that the chain will rotate without binding.
ADJUSTING THE CHAIN TENSION
CAUTION: The saw chain must be properly tensioned
before using.
1. Stop the motor and remove the battery pack before
adjusting the chain tension.
2. Loosen the cover screw to nger tight.
3. Turn the chain-tensioning screw clockwise to
tension the chain. See the “REPLACING THE BAR
AND CHAIN” section in this manual for additional
information.
◾A cold chain is correctly tensioned when there is
no slack on the underside of the guide bar and the
chain is snug, but it can be turned by hand without
binding. The chain must be re-tensioned whenever
the ats on the drive links do not sit in the bar
groove (Fig. O).
◾During normal saw operation, the temperature of
the chain will increase. The drive links of a correctly
tensioned warm chain will hang approximately
1.3mm out of the bar groove (Fig. P).
NOTICE: New chains tend to stretch; check chain tension
frequently and tension as required.
NOTICE: A chain tensioned while it is warm may be too
tight upon cooling. Check the cold tension before next use.

POLE SAW ATTACHMENT — PSA100012
TRANSMISSION GEARS LUBRICATION
The transmission gears in the gear case need be
lubricated periodically with gear grease. Check the gear
case grease level about every 50 hours of operation by
removing the sealing screw on the side of the case.
If no grease can be seen on the anks of the gear, follow
the steps below to ll with gear grease up to 3/4 capacity.
Do not completely ll the transmission gears.
1. Position the pole saw attachment on its side with
sealing screw facing upwards (Fig. Q).
2. Use the dual-head wrench provided to loosen and
remove the injection screw.
3. Use a grease syringe (not included) to inject some
grease into the screw hole; do not exceed 3/4 capacity.
4. Tighten the sealing screw after injection.
SPROCKET IN GUIDE BAR LUBRICATION
The guide bar has a sprocket at its tip. It must be lubricat-
ed weekly with chain oil injected into the lubricating hole
by a grease syringe (not included) to extend the guide bar
life (Fig. R). Turn the guide bar and check that the lubrica-
tion holes and chain groove are free from impurities.
TRANSPORTING AND STORING
1. Do not store or transport the pole saw attachment
when it is running. Always remove the battery pack
before storing or transporting.
2. Always place the guide bar sheath on the guide bar
and chain before storing or transporting the pole saw
attachment. Use caution to avoid the sharp teeth of
the chain.
3. Clean the pole saw thoroughly before storing.
Store the pole saw indoors, in a dry place that is
locked and/or inaccessible to children and keep
away from corrosive agents such as garden
chemicals and de-icing salts.
4. If the pole saw attachment is removed from the
power head and stored separately, t the end cap
on the attachment shaft to avoid dirt getting into the
coupler.
Protecting the environment
Do not dispose of electrical appliances as
unsorted municipal waste, use separate
collection facilities.
Contact your local government for infor-
mation regarding the collection systems
available.
If electrical appliances are disposed of in
landlls or dumps, hazardous substances
can leak into the groundwater and get
into the food chain, damaging your health
and well-being.

POLE SAW ATTACHMENT — PSA1000 13
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Motor does not
run.
◾The battery pack is not
attached to the pole saw.
◾Attach the battery pack to the pole saw.
◾No electrical contact between
the saw and battery.
◾Remove battery, check contacts and reinstall the battery pack.
◾The battery pack is depleted. ◾Charge the battery pack.
◾The lock-off button is not
depressed before pressing the
trigger.
◾Press down the lock-off lever and hold it, then depress the
trigger to turn on the pole saw.
◾The battery pack or power
head is too hot.
◾Allow the battery pack or power head to cool until the
temperature drops below 152°F (67°C).
◾Saw chain is bound in the
wood.
◾Release the trigger; remove the saw chain and guide bar from the
wood, then restart the pole saw.
◾Debris in bar groove. ◾Press the saw chain against the wood, move the pole saw back
and forth to discharge the debris.
◾Debris in chain-sprocket cover. ◾Remove battery pack, then remove chain-sprocket cover and
clean out debris.
Motor runs, but
chain does not
rotate.
◾Chain does not engage drive
sprocket.
◾Remove the battery pack and reinstall the chain, making
sure that the drive links on the chain are fully seated on the
sprocket.
Pole saw does
not cut properly.
◾Insufcient chain tension. ◾Remove the battery pack and readjust the chain tension,
following the section “ADJUSTING THE CHAIN TENSION”.
◾Dull chain. ◾Sharpen the chain cutters by a qualied service technician.
◾Chain installed backwards. ◾Remove the battery pack and reinstall the saw chain, following
the section “REPLACING THE BAR AND CHAIN”.
◾Worn chain. ◾Remove the battery pack and replace the chain following the
section “REPLACING THE BAR AND CHAIN”.
◾Dry or excessively stretched
chain.
◾Check the oil level. Rell the oil tank if necessary.
◾Chain not in bar groove. ◾Remove the battery pack and reinstall the saw chain, following
the section “REPLACING THE BAR AND CHAIN”.
Bar and chain
running hot and
smoking.
◾Check chain tension for over
tightened condition.
◾Remove the battery pack and re-tension the saw chain; see the
section “ADJUSTING THE CHAIN TENSION”.
◾Chain oil tank is empty. ◾Filling bar and chain lubricant.
◾Debris in guide bar groove. ◾Clear the debris in the groove.

POLE SAW ATTACHMENT — PSA100014
WARRANTY
EGO WARRANTY POLICY
5 year warranty on EGO outdoor power equipment and 3 year warranty on EGO Power+ System battery packs and
chargers.
Please contact EGO customer service on Australia 1300 000 EGO(1300 000 346),
New Zealand 0508 000 EGO (0508 000 346) any time you have questions or warranty claims.
LIMITED SERVICE WARRANTY
FOR FIVE YEARS from the date of original retail purchase, this EGO product is warranted against defects in material or
workmanship. Defective product will receive free repair.
FOR THREE YEARS from the date of original retail purchase, the EGO Power+ System battery pack and charger are
warranted against defects in material or workmanship. Defective product will receive free repair.
This warranty does not cover the blade, which is a part that can wear out from normal use within the warranty period.
◾This warranty applies only to the original purchaser at retail and may not be transferred.
◾The warranty period for any EGO product or part used for industrial, professional or commercial purpose is one year.
◾This warranty is void if the product has been used for rental purpose.
◾This warranty does not cover the damage resulting from modication, alteration or unauthorised repair.
◾This warranty only covers defects arising under normal usage and does not cover any malfunction, failure or defect
resulting from misuse, abuse (including overloading of the product beyond capacity and exposure to water or rain),
accidents, neglect or lack of proper installation, and improper maintenance or storage.
◾This warranty does not cover normal deterioration of the exterior nish, including but not limited to scratches, dents,
paint chips, or to any corrosion or discoloring by heat, abrasive and chemical cleaners.
HOW TO OBTAIN SERVICE
For warranty service, please contact EGO customer service on Australia 1300 000 EGO(1300 000 346),
New Zealand 0508 000 EGO (0508 000 346). When requesting warranty service, you must present the original dated
sales receipt. An authorized service center will be selected to repair the product according to the stated warranty terms.
ADDITIONAL LIMITATIONS
Chervon Australia Pty Ltd ABN 36 165 077 501(“Chervon”) warrants to the original domestic purchaser that this
product will be free from defects in materials and workmanship for 5 years from date of purchase, and any battery or
charger will be free from defects in materials and workmanship for 3 years from date of purchase. To make a claim,
return the faulty item together with proof of purchase directly to your closest service agent or to the place of purchase.
Any handling and transportation costs (and other expenses incurred in claiming this warranty) are not covered by this
warranty and will not be borne by Chervon. The replacement product or part or repaired product will be made available
for your collection at an address nominated by Chervon. Where a valid warranty claim is made, Chervon will replace the
defective product or repair the fault. Where the product is repaired, Chervon may use refurbished parts. This warranty
does not cover normal wear and tear, misuse or abuse. This warranty may also be further limited or voided as speci-
cally detailed in the product Manual. Chervon has no other liability under this warranty.The benets to you given by this
warranty are in addition to other rights and remedies imposed by State and Federal legislation that cannot be excluded.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure. Chervon Australia Pty Ltd, Unit 13, 1488 Ferntree Gully Rd, Knoxeld, VIC. 3180.
Phone Number: Australia 1300 000 EGO(1300 000 346), New Zealand 0508 000 EGO (0508 000 346).
Email address: [email protected].
