Eicom ATC-700 User manual

1

Column Oven
ATC-700
User’s Manual
ATC700MAN_0802 ®2008 Eicom Corporation. All rights reserved.

Ta le of Contents
Introduction ………………………………………………………… 1
Safety Precautions ……………………………………… 1-2
2. Specifications ………………………………………………… 3
3. Setup …………………………………………………… 3
3.1 Parts List ……………………………………… 3
3.2 Installation ……………………………………………… 4
3.3 Parts Names …………………………………………… 5
3.4 Power …………………………………………… 6
4. Operation …………………………………………………… 6
4.1 Display Panel …………………………………………… 6
4.2 Operations Keys ……………………………………………… 6
4.3 Display ……………………………………………… 7
4.4 Main Power ON/OFF ……………………………………………… 7
4.5 Operation …………………………………………………… 8
5. Error Messages …………………………………………… 10
6. Ventilation Duct ………………………………………………… 10
Limited Warranty ……………………………………………… 11

Introduction
Thank you for your purchase of Eicom Column Oven Model ATC-700.
This equipment is suita le for the temperature control of HPLC columns and
Eicom Electrochemical Detector Model ECD-700 near the room temperature.
The ATC-700 performss est when using with Eicom HPLC Pumps System EP-
700 and Eicom ECD-700.
The ATC-700 has a Peltier device to heat and cool the air inside the cham er y
convection. At the normal setting temperature range near room temperature, the
temperature regulation will e at the +/- 0.1°C accuracy. It works exceptionally
well to sta ilize the temperature of the mo ile phase and the electrochemical
detector cell.
Safety Precautions
Operation of the ATC-700 should only e performed y personnel trained in
la oratory work, and who are aware of the possi le dangers involved in
chemical reagents and other possi ilities. Read this manual carefully and in full.
All safety and operating instructions should e read prior to operation.
In this User’s Manual, the items that the users need to pay attention to are
denoted as the elow.
Warning; This mark indicates “a potential hazardous situation which,
if not avoided, could result in death or serious personal injury.
Caution. This mark indicates “a potentially hazardous situation
which, if not avoided, could result in minor or moderate personal
injury, or property damage.
Note; This indicates reference information.
1
Caution

If you are using a non-Eicom recommended analytical condition, please contact
Eicom and check if the condition meets to the product specification efore
setting up the experiment. If you do not check with Eicom and the product is
damaged, the cost of the repairs and associated costs will e charged to you
regardless of the warranty period.
Do not cover the ventilation slits on the ack and side pannel of the ATC-700. If
you do so, the electonic parts may overheat and e damaged. Please keep a
distance of at least 10 cm etween o jects and the ATC-700.
Please take care not to spill any fluids on the ATC-700. This includes any liquid
that may leak from loose tu e fittings. If any solution comes into contact with
the mechanical or electric parts, the ATC-700 will e damaged, possi ly eyond
repair..
2
Use of Hazardous Material
When using the ATC-700, the use of hazardous materials, such as chemical reagents, is
necessary. If you do not handle these materials appropriately, it may result in your death
or serious injury.
When necessary, safety gloves, safety masks, and safety glasses should e worn. The
instruments can e placed under a ventilated la oratory hood, if needed..
Flamma le Material
When using the ATC-700, you may use flamma le liquids such as organic solvents. These
materials have a high risk of fire or explosion. Do not use them near possi le sources of
ignition, such as flame or electric sparks.
Caution
Caution
Caution

2 . Specification
Method of temperature control Heating and cooling with a Peltier device y
convection
Setting Temperature Range 1°C～5°C (1°C increment)
Practical Setting Temp. Range 20°C～4°C when am ient is 25°C
Accuracy of Temp. Regulation ±0.1°C
Maximum Column Length 25 cm
Column Clips 2 pcs
Dimensions 400W x 400D x 145H mm
Weight approx. 10 kg
Power Supply AC100～240V 50/60Hz 210W
3
. S etup
3.1 A list of the parts in the package
When you open the ox, please confirm if the package contains the following accessory
parts.
List of Accessory Parts includedin the ATC-700 package
Item Code Qty Remarks
User’s Manual 1
Main Product ATC-700 1
Ventilation
Duct
1 ECD-700
Power Ca le 1
Power Ca le
Adapter
1 3 Pins to 2 Pins
Grounding
Wire
1
3

3.2 Installation
Make sure the installation location meets the following requirements.
Please keep o jects away at least 10 cm for the side, front and ack panels. Do not put
something other than another Eicom 700 series component on top of the ATC-700.
Place the ATC-700 on a level and sturdy ench top in an indoor la oratory which
meets the following requirements.
1. The room temperature during the operation needs to e in the range of 15~30C.
2. No high humidity environments where condensation may form on the equipment..
3. Not exposed to direct sunlight.
4. Away from air conditioning or heating vents.
5. No vi ration.
6. Clean environment with a minimum of dust.
7. Not near any other device that can generate strong electromagnetic fields.
8. Not exposed to any corrosive or flamma le gas.
4

3.3 Parts Names
5
Inside
Compartment
Temperature
Display
Vent for fan and
Peltier device
Main Door
Grounded Column Clips
Main Power
Switch
Back View
Main Power
Receptacle
Fuses
Ground Terminal
Cooling Fan
Auxillary
Door
Open Door Sensor
Inlet/ Outlet Tu ing Ports
Right Side
View
Front View
Left Side
View

3.4 Power Supply
Always use the power ca le came with the machine.
Power Voltage：AC 100V～240V (±10V)
Frequency：50-60 Hz
Consumption：210 W
4
. peration
4.1 Display Panel
Display Panel
4.2 peration Keys
Key Name Function
Set ・Enter the setting temperature
Arrows ・Choosing setting temperature
6
Temperature
Display
Increase/Decrease
Buttons

4.3 Display
PT displays the current temperature and ST displays the set point temperature.
4.4 Main Power N/ FF
The main power ON/OFF is located on the left side as you face the instrument.
After the initial display, the display will show the status.
＜Initial Display＞
＜Status Display＞
＊Set Point temperature is stored.
7
Current Temp
Set Point Temp

4.5 peration
How to change the setting temp
8
Turn the main power on
Status Display appears
after initialization
To set the temperature up, hit ▼ key
To set the temperature down, hit ▲ key
At the ST Mark will appear
When the required temperature is shown at ST,
hit SET Key
PT will match ST, when the new
temperature is reached.

5
. Error Messages
＜Error Messages and Solution＞
Error Cause Solution
OPEN Front Door Open Close firmly. While OPEN is display, the
temperature control is turned off.
ERROR 2
(with
eep)
Temperature Sensor Error Turn of the main power and wait 15 sec.
Then turn on again. If the error persists,
please contact us.
ERROR 3
(with
eep)
Peltier Unit Error Turn of the main power and wait 15 sec.
Then turn on again. If the error persists,
please contact us.
6
. Ventilation Duct
This ventilation duct comes with the ATC-700 and can e installed according you your
needs. If you need to attach the duct y yourself, please contact us.
9

Limited Warranty
Warranty Period: One year from the original purchase date as defined by the date of your
Eicom
invoice.
Warranty nformation: During the warranty period, this Eicom product is covered by a
limited
liability warranty covering manufacturer defects. n the case that the
machine is defective, it will be repaired or replaced free for charge.
Void of Warranty: The manufacturer’s warranty will be voided under the following
conditions:
1 Failure to follow instructions and warnings relating to product’s use.
2 Repair or alteration by anyone other than Eicom.
3 Damage during shipping or transit, or any other accidental damage.
4Damage due to use with hazardous voltages.
5 Damage due to improper connection of equipment.
6 Damage due to any act of God.
7 Any other inappropriate usage of parts or consumables that is not
authorized by Eicom.
All rights reserved. Use of images and/or wording of this manual without express
permission is completely prohibited. Specifications and descriptions in this user guide are
subject to change without prior notice. f you have any further questions, please feel free to
contact Eicom or its distributors.
