EIDT ZYPHO User manual

INSTALLATION MANUAL

2
Please note that this manual contains important information. Read it carefully before
starting the installation or use of the product.
The ZYPHO should only be installed by a competent plumber who has the expertise to
be guided by this manual.
If you have any technical questions, please do not hesitate to contact us.
?
IMPORTANT

3
Nº Description Material Connection Qty
1Valve cap Ø90 ABS - 1
2Trap ABS - 1
3Thread ring ABS - 1
4Sealing ring Rubber - 1
5Wrench PP - 1
6Adjustable foot Steel / Plastic - 4
7Input connector 1/2” Brass M1
8Output connector 1/2” Brass M1
9Water discharge Ø40 PVC M1
PACKAGE CONTENTS

4
TWO METHODS OF INSTALLATION
[I] pp. 5-7
[II] pp. 8-10
Installation above the slab / coupled to the shower tray
Installation under the slab / under the shower tray or bathtub with desired separation

5
INSTALLATION CONFIGURATIONS
AB
C

6
INSTALLATION - METHOD I
1
2
Using a spirit level and 4 adjustable feet (6), adjust the unit’s height and position it
horizontally in its final location. The internal evacuation of the ZYPHO already has a
slope of 2% to ensure the correct flow of waste water from the shower.
Remove components (1), (2), and (3).
Put the shower tray over the ZYPHO and align it. Remove the tray for implementing the
next steps.
3

7
4
6
Connect the mains cold water to the unit’s inlet (7), and preheated water outlet (8) from
the unit to the cold side of the shower mixer tap and/or domestic water heater (depending
on installation configuration). Use both of the provided Male 1/2’’ fittings and proceed to
their sealing in accordance with good plumbing practice.
Connect the ZYPHO drain water outlet (9) to the drain pipe sewer/floor drain.
Put the shower tray and components (1), (2), (3) and (4).
We recommend to perform a leak test on the mains water circuit and on the drain water
circuit to ensure the integrity of the inlet and outlet connections.
5

8
INSTALLATION - METHOD II
1
Remove components (1), (2), (3) and (4).
2
Install a curve of 90° Ø40mm. Ensure that the curve goes beyond the rubber.
3
If necessary, use a vertical PVC pipe of desired length.

9
4
Using screws, fix the ZYPHO to the slab.
6
Connect the mains cold water to the unit’s inlet (7), and preheated water outlet (8) from
the unit to the cold side of the shower mixer tap and/or domestic water heater (depending
on installation configuration). Use both of the provided Male 1/2’’ fittings and proceed to
their sealing in accordance with good plumbing practice.
Connect the ZYPHO drain water outlet (9) to the drain pipe sewer.
5
Make sure that the unit is installed horizontally. The internal evacuation of the ZYPHO
already has a slope of 2% to ensure the correct flow of waste water from the shower.

10
8
Install the shower tray and the shower valve.
We recommend to perform a leak test on the mains water circuit and on the drain water
circuit to ensure the integrity of the inlet and outlet connections.
7

11
The ZYPHO has been designed to require minimal maintenance other than usual
cleaning with traps and filters retaining almost all hair and dirt, thus preventing blockages.
To avoid losing efficiency in the long term, we recommend to periodically dissolve soap
residue on the inside copper pipe with your usual drain cleaner and/or to clean the unit
with a pipe cleaning brush and with hot water.
MAINTENANCE

12
USEFUL INFORMATION - CONTACTS
PRODUCT DEVELOPED BY
EIDT, SA
EDP Starter, Rua Cidade de Gôa, nº 4,
2685-039 Sacavém
Portugal
[phone]
[email protected]
www.zypho.eu
PATENTED (PCT054506)
