Eiki LC-X71 User manual

X71 Series
PjNET-30
Pj-to NetDirector
Network Capture 3
Network Viewer 3
Network Communication
OWNER'S MANUAL
LINK ACT

2
Compliance
Federal Communication Commission Notice
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment causes harmful interference to radio or televi-
sion reception which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart B of Part 15 of
FCC Rules.
Do not make any changes or modifications to the equipment unless otherwise specified in
the instructions. If such changes or modifications should be made, you could be required
to stop operation of the equipment.
Model Numbers : PjNET-30
Trade Name : EIKI
Responsible party : EIKI International, Inc.
Address : 30251 Esperanza Rancho Santa Margarita CA 92688-2132
Telephone No. : 800-242-3454 (949-457-0200)
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
EIKI PjNET-30

3
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Compliance and Caution
CAUTION
Eiki International, Inc. assumes no responsibility for the loss or damage of data or
damage of the computer caused by usung this product.
CAUTION ON USE IN NETWORK
- When you receive an alert e-mail from the projector, you must check the projector
immediately. Fire or accident may result if the projector is used in an abnormal
condition.
- When you install the projector at remote location and use it through the network, you
must perform the safety inspections periodically. In this case you must pay attention to
the change of environment in which you installed the projector. It may cause fire or an
accident depending on the change of environment.
The CE Mark is a Directive conformity mark of the European Community (EC).
NOTES ON Lithium Battery (CALIFORNIA USA ONLY)
This product uses a Lithium Battery which contains Perchlorate Material - special han-
dling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate
Notas acerca de pilas de litio (SOLO PARA CALIFORNIA, EE.UU.)
Este producto usa una pila de litio que contiene el material perclorato – puede ser nece-
sario una manipulación especial.
Consulte la página www.dtsc.ca.gov/hazardouswaste/perchlorate

4
Compliance ..........................................................................................................................................................................2
Federal Communication Commission Notice ......................................................................................2
Chapter 1 Preparation ................................................................................................7
Features...................................................................................................................................................................................8
Operating environment of network unit ....................................................................................................... 11
Before use........................................................................................................................................................................... 12
Chapter 2 Installation...............................................................................................15
Flow of installation........................................................................................................................................................ 16
[1] Name and function of each part .................................................................................................................. 17
[2] Installation and network configuration.................................................................................................... 18
Mounting .................................................................................................................................................................. 18
Connection of LAN cable ............................................................................................................................... 19
Network configuration.....................................................................................................................................20
Network PIN code setting..............................................................................................................................22
How to enter the numbers with the screen 10-key pallet.........................................................23
Notice about system construction...........................................................................................................24
[3] Installing the software.........................................................................................................................................25
Network Viewer & Capture 3 installation..............................................................................................25
File Converter 2 Installation...........................................................................................................................27
Chapter 3 Basic Setting and Operation............................................................. 29
Login the setting page of the projector.........................................................................................................30
1 Enter the IP address........................................................................................................................................30
2 Select a display mode and login............................................................................................................30
3 Display of main setting page ...................................................................................................................31
How to use the setting page .................................................................................................................................32
Initial setting.....................................................................................................................................................................34
Network PIN code setting..............................................................................................................................35
PJLink and password setting.........................................................................................................................35
Date and time setting.......................................................................................................................................36
Network configuration...............................................................................................................................................37
E-mail setting ...................................................................................................................................................................38
Examples: Type and contents of alert mail..........................................................................................40
SNMP setting....................................................................................................................................................................42
Chapter 4 Controlling the Projector ................................................................... 45
Power control and status check...........................................................................................................................46
Controls................................................................................................................................................................................48
Input.............................................................................................................................................................................48
System.........................................................................................................................................................................49
Image adjustment..............................................................................................................................................50
Sound .........................................................................................................................................................................51
Menu ...........................................................................................................................................................................51
PC adjustment.................................................................................................................................................................52
Setting up the projector...........................................................................................................................................53
Save the controls and settings..............................................................................................................................55
Save/delete the settings..................................................................................................................................55
Check the saved items......................................................................................................................................56
Load a control set ................................................................................................................................................56
Timer setting ....................................................................................................................................................................57
How to set the timer..........................................................................................................................................57
Check the timer events....................................................................................................................................58
Change the event mode.................................................................................................................................58
Projector information..................................................................................................................................................60
Multi-control.....................................................................................................................................................................62
Controlling and setting the multi-projectors ....................................................................................62
Contents

5
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Contents
Start/stop the multi control...........................................................................................................................63
Register the projector .......................................................................................................................................64
Confirmation of registered projector......................................................................................................64
Change the mode of the registered projector .................................................................................65
Status ...........................................................................................................................................................................65
Conf. & Change page in the light mode ...............................................................................................66
Controlling all together....................................................................................................................................66
Setting all together.............................................................................................................................................66
Viewer auto setting all together.................................................................................................................67
Chapter 5 Network Capture................................................................................... 69
About Network Capture function.......................................................................................................................70
Launching the Network Capture 3...........................................................................................................70
Commands on the task bar...........................................................................................................................70
Parameter set up ..................................................................................................................................................71
Using the Real Time Capture..................................................................................................................................72
Registering the computers............................................................................................................................72
[1] Control by the computer..........................................................................................................................73
[2] Control by the web browser.................................................................................................................. 74
[3] Control by the projector...........................................................................................................................75
Advanced using example...............................................................................................................................76
Using the Network Communication.................................................................................................................77
Settings before using the Network Communication ...................................................................78
Description of capture editing window................................................................................................79
How to use the Network Communication....................................................................................................81
Start the communication................................................................................................................................81
Join the communication (only for Sub PC)..........................................................................................81
Exit from the communication (only for Sub PC) ..............................................................................81
End the communication..................................................................................................................................81
Acquire and release of editing authority..............................................................................................81
Edit capture image..............................................................................................................................................82
Network Communication operation and change of state .................................................................84
Executing the forcing mode ..................................................................................................................................85
Error information............................................................................................................................................................86
Chapter 6 Network Viewer..................................................................................... 87
Creating the available data [Network Viewer 3].........................................................................................88
[1] How to use the Network Viewer 3 (File Converter 1) .............................................................88
[2] How to use the Network Viewer 3 (File Converter 2).............................................................92
Creating a program file [Program Editor].......................................................................................................93
Procedure of making program....................................................................................................................93
Setting up the display order and time of the images...................................................................95
Using the Network Viewer function..................................................................................................................98
[1] Control by the web browser..................................................................................................................98
[2] Control by the projector........................................................................................................................ 102
Chapter 7 Use of Serial Port.................................................................................105
Serial port setting....................................................................................................................................................... 106
Control examples ....................................................................................................................................................... 108
Use of telnet....................................................................................................................................................................110
Chapter 8 Appendix ..............................................................................................113
Examples of connection.........................................................................................................................................114
Web browser setting.................................................................................................................................................116
Examples: OS/Browsers ...........................................................................................................................................117
Product specification................................................................................................................................................121
Port specification........................................................................................................................................................ 122
Q&A ..................................................................................................................................................................................... 123

6

Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
7
ENGLISH
1
Chapter 1
Preparation
Describes features and operating environment of this product.

8
Chapter 1 Preparation
Real Time Capture function (+p.72)
To display the screen image of
the computer by the projec-
tor through the network in real
time.
Features
Network Viewer function (+p.87)
To acquire the JPEG image data
from the file servers placed in
the network and project them
by the projector.
PC4PC3 PC6
Capture
PC5
PC1 PC2
PC4PC3 PC6
PC5
PC1 PC2
FTP file server
JPEG
Prog.
JPEG
PJ2 PJ1
Network Communication function (+p.77)
To communicate by sharing the
captured image of a computer
with multiple computers and
a projector. User can draw the
text and figure on the captured
image by using a drawing tool.
PC2
PC6
Capture
PC5
PC1
PJ1
Capture a screen
image of PC5 and
make marking with
a tool.

9
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
E-Mail Alert function (+p.38)
The projector (Network Unit)
sends messages to the regis-
tered e-mail addresses when
a lamp abnormality or power
failure occurs with the projec-
tor. This message describes
how to solve the cause of the
problems. You can take efficient
action for quick recovery.
PC4PC3 PC6
PC5
PC1 PC2
You’ve got
Mail.
PJ2 PJ1
Web Management function (+p.45)
With this function, you can
monitor projector functions
such as power status, lamp
status, input mode, signal
condition, lamp-use time, etc.
through the network by using
the web browser installed on
your computer.
PC4PC3 PC6
PC5
PC1 PC2
Turn ON PJ2
PJ2 PJ1
Features
SNMP Agent function (+p.42)
To send the information of the
projector to the SNMP manager.
Enables you to manage the pro-
jector condition with the sup-
plied SNMP manager software.
PJ1
PC6
PC4
PJ2 PJ3 PJ4
PC5
You received
a Trap.
SNMP Manager
Trap
Trap

10
Chapter 1 Preparation
Multi-control function (+p.62)
A single computer can con-
trol and set up the multiple
projectors at the same time.
PJ1
PC6
PC4
PC5
Select Input2 for
PJ1 to PJ4.
PJ2 PJ3 PJ4
Automatic On/Off using Clock function (+p.57)
Automatically turn on or off the
projectors at specified date/day
and time by using the clock func-
tion.
Now it’s 11:30
I am ready to turn ON,
and select Input 3 (Video)
SNMP Manager function
A func tion to manage the
condition of projectors in the
network by using the SNMP
protocol. The managing com-
puter needs to provide an
SNMP managing software. Refer
to the owner's manual of the
"PJ Network Manager" supplied
separately for further details.
PJ1
PC6
PC4
PJ2 PJ3 PJ4
PC5
You received
a Trap.
SNMP Manager
Trap
Trap

11
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Standard mode
Operating System Windows 98, Windows Me, Windows NT4.0SP6
Windows 2000, Windows XP
Computer environment
Recommended CPU Higher than Pentium III 900MHz
Memory 64MB (Minimum)/ 128MB or more(Recommended)
128MB or more for WindowsXP
HDD free area 100MB or more
Drive equipment CD-ROM drive
Display setting of
computer
Support one of following resolutions;
VGA (640 x 480), SVGA(800 x 600), XGA(1,024 x 768) Number of col-
ors: Either of 16 bit (65,536 color 24/32 bit (16,77 million colors))
Network card The computer must provide a 10Base-T or 100Base-TX network
card.
Web Browser*
Internet Explorer version 5.0, 5.5 or 6.0
Netscape Navigator version6.2, 7.0 or 7.1
* Used to control and set up the projector. The layout of pages in
the browser may slightly differ from each type of application or
operating system you use.
Plug-Ins Adobe Flash Player version 6,0,79,0(6.0r79) or later
Internet Mailer*
- Microsoft Outlook - Microsoft Outlook Express
- Netscape Mail
* Required the internet e-mail application software to receive an
e-mail alert sent from this product. If you do not use the function
E-mail Alert, this application is not required.
FTP Service *
- FTP server (Windows 2000 Professional or Windows XP
Professional)
* The FTP service provided with the Windows 2000 Professional
or Windows XP Professional is required when using the Network
Viewer function.
Operating environment of network unit
To perform the managing and setting of the projector by using this product, the environ-
ment described below is required.
*1 The "Light Mode" and "Standard Mode" will be explained on item "Display Mode" (+p.30-32)
Operating Environment
PDA restriction
The PDA can be used for the Light mode*1only. The operating system of the PDA is
PocketPC2002 or higher. The version of the Adobe Flash Player is 6,0,81,0 or higher.
This product has been designed for the projectors listed below.
LC-X71 series, LC-XG250 series, LC-XG300 series and LC-X80 series

12
Chapter 1 Preparation
The limitation*1 of connection between this product and hub or computer
Suitable LAN cables are limited by length and type as follows;
Connection Type of usable LAN cable Maximum length
Network Unit - Hub UTP Straight Cable with category 3 or 5 *2100m
Network Unit - Computer UTP Cross Cable with category 3 or 5*2100m
*1 There may be other limitations depending on your network environment or LAN specification.
Please consult your network administrator for further details.
*2 Category of LAN cable indicates the cable quality. Normally, a cable with category 3 or 5 is used
for 10Base-T network, and a cable with category 5 is used for 100Base-TX network.
Before use
Package contains
The package contains following items. Check each item as you unpack the package. If you
have any of the following items missing, contact the sales dealer.
LINKACT
❑Network unit 1 piece
❑CD-ROM 1 piece
NetworkViewer& Capture3 software
PJNetworkManager software
❑Document CD-ROM 1 piece
Pj-to NetDirectorOwner'sManual
PJNetworkManager Owner'smanual
❑Quick Setup Guide 1 piece
English/Japanese
Quick Setup
Guide

13
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Notice
Expression/Abbreviation
The word "projector" found in this manual means "projector provided with Network unit"
unless otherwise noted.
The OS of the computer and the Web browser described in this manual is Windows XP
Professional and Internet Explorer 6.0. In case of another OS or Web browser, some instruc-
tion procedures may differ from the actual operation depending on your computer envi-
ronment.
Use of this manual
This manual does not provide the description of basic operation and functions for com-
puter, web browser, projector and network. For instructions about each piece of equip-
ment or application software, please refer to the respective booklet.
Trademarks
Ethernet is a registered trademark of Xerox Corporation. Microsoft, Windows, Windows
NT are registered trademarks of Microsoft Corporation. Internet Explorer is a registered
trademark of Microsoft Corporation. Netscape Navigator and Netscape Communicator are
trademarks or registered trademarks of Netscape Communications Corporation. JavaScript
is a registered trademark of Sun Microsystems, Inc. PJLink is a registered trademark of
JBMIA (Japan Business Machine and Information System Industries Association).
Other product or brand names in this manual are registered trademarks or trademarks of
their respective owners.
* Unauthorized use of a part or whole of the contents in this manual is prohibited.
* The contents of this manual are subject to change without notice.
Before use

14
Chapter 1 Preparation

Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
15
ENGLISH
Chapter 2
Installation
2
Describes how to install the network unit and software, and config-
ure the network.

16
Chapter 2 Installation
The following are instructions for attaching this product to the projector and connecting it
to the network. Please review the entire procedure to become familiar with it.
Function of the network unit (+p.17)
1
Installation and network configuration (+p.18-24)
2
Installation of the software (+p.25-27)
3
Set up is complete
1Mount this product onto the projector.
2Connect the LAN cable and join it to the network.
3Configure the network of the network unit.
4Set the Network PIN code.
Explains how to install the software Network Viewer & Capture 3 into your com-
puter.
Flow of installation
The preparation is completed to control the projector connected to the network. At next
step, set up and control the projector via the network by using the web browser installed
on your computer. Please see chapter 3 "Basic setting and operation". (+p.29)
Explains the name and functions of each part of the network unit.

17
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Name and function of each part
[1] Name and function of each part
LINK ACT
Serial port
Used to control the external equipment
via the network. (+p.105)
POWER indicator
This lights up red when the network
function is set ON in the projector
menu.
LAN port
Connecting the LAN cable. (+p.19)
Connector plug
Connecting to the terminal on the pro-
jector. (+ p.18)
Mounting screws
Mount by using a coin etc. (+ p.18)
LINK indicator
This lights up red when the network unit is
connected to the network correctly.
ACT indicator
This turns on and off with green when
sending or receiving of data
(Top View)
(Bottom View)

18
Chapter 2 Installation
Mounting
✐AC cord must be disconnected when mounting or removing this product otherwise it may dam-
age the product.
✐Do not install multiple network units into a projector otherwise it may damage the product.
✐Connect the AC cord after connecting the LAN cable and computer.
[2] Installation and network configuration
Caution
!
1 Disconnect the AC plug from the projector.
2 Remove the connector cover and screw
covers (2 pieces) from the projector and
insert plug on this product to the option
connector.
3 Tighten two screws by using a coin
etc.
Connector cover
Screw cover

19
Pj-to NetDirector
OWNER'S MANUAL [X71 Series]
ENGLISH
Connection of LAN cable
To connect to the network, it is required to use the UTP (Unshielded Twisted Pair) straight cable
with RJ-45 plug. There are two different types of cables depending on whether the network is
constructed with 10Base-T or 100Base-TX. Prepare the Hub (10Base-T or 100Base-TX) to distrib-
ute the network cable if required.
1 Disconnect the AC plug from the projector.
2Connect the UTP straight cable to the LAN
port on the network unit.
3Connect the UTP straight cable to the hub.
✐Use the UTP cross cable when you connect the computer and projector directly not using the
hub.
✐When you connect the projector into the 10Base-T network, use cable with category 3 or 5. When
you connect the projector into the 100Base-TX network, use cable with category 5.
✐The length of cable between hub and projector should be less than 100m.
Hub
(10Base-T, 100Base-TX)
UTP straight cable
Projector
Installation and network configuration

20
Chapter 2 Installation
1Selection of network menu
Turn on the projector and display the menu on the screen. Select network icon from the
main menu and then press SELECT button once. Check that the mode is "On". If not,
change mode to "On" using the point buttons (7,8).
Network configuration
Confirmation of the network menu
When installing this product to the projector, the network on-screen menu items for this
product are activated automatically. If not activated, the product may not have been
installed correctly. Please check item "Mounting" (+p.18).
Configure the network
Before performing the network configuration, prepare network address numbers (IP
Address, Subnet Mask, Default Gateway, DNS) assigned to the projector. Ask your network
administrator for the network address.
For example, the case where the following network address is set up is explained.
IP Address : 192.168.1.201
Subnet Mask : 255.255.255.0
Default Gateway : 192.168.1.1
DNS : 0.0.0.0
The default network configuration is set as follows.
IP Address : 192.168.0.2
Subnet Mask : 255.255.255.0
Default Gateway : 0.0.0.0
DNS : 0.0.0.0
LINKACT
Network icon
Select "On" or "Off"
with 7,8button
✐The network unit begins restarting each time the mode is set "On".
