Eizo DuraVision FDS1903 User manual

Important
Please read this User’s Manual carefully to familiarize yourself with safe and
effective usage. Please retain this manual for future reference.
Wichtig
Lesen Sie die dieses Benutzerhandbuch aufmerksam durch, um sich mit
der sicheren und efzienten Bedienung vertraut zu machen. Bewahren Sie
dieses Handbuch zum späteren Nachschlagen auf.
Important
Veuillez lire attentivement ce Manuel d’utilisation an de vous familiariser
avec ce produit et de l’utiliser efcacement et en toute sécurité. Veuillez
conserver ce manuel pour référence ultérieure.
重要事项
请仔细阅读用户手册，掌握如何安全、有效地使用本产品。请保留本手册，
以备日后参考。

Cover

2
<For USA-California Only>
CR Coin Lithium Battery contains Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
This product has been adjusted specically for use in the region to which it was originally shipped. If operated
outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless prior
arrangements are made pursuant to EIZO Corporation’s receipt of said information.
Although every effort has been made to ensure that this manual provides up-to-date information, please note that
EIZO monitor specications are subject to change without notice.
SAFETY SYMBOLS
This manual and this product use the safety symbols below. They denote critical information. Please read them
carefully.
WARNING Failure to abide by the information in a WARNING may result in serious injury and
can be life threatening.
CAUTION Failure to abide by the information in a CAUTION may result in moderate injury and/
or property or product damage.
Indicates an attention to be required. For example, the symbol illustrates the
hazard type such as “the risk of electric shock”.
Indicates a prohibited action. For example, the symbol illustrates a particular
prohibited action such as “Do not disassemble”.
Indicates a mandatory action that must be followed. For example, the symbol
illustrates the notication of general prohibition such as “Grounding the unit”.

3
PRECAUTIONS
PRECAUTIONS
IMPORTANT
• To ensure personal safety and proper maintenance, please read this section and the caution statements on the
unit (refer to the gure below).
● Location of Caution Statement
WARNING
If the unit begins to emit smoke, smells like something is burning, or makes strange
noises, disconnect all power connections immediately and contact your local EIZO rep-
resentative for advice.
Attempting to use a malfunctioning unit may result in re, electric shock, or equipment damage.
Do not open the cabinet or modify the unit.
Opening the cabinet or modifying the unit may result in re, electric shock, or burn.
Refer all servicing to qualied service personnel.
Do not attempt to service this product yourself as opening or removing covers may result in re, electric
shock, or equipment damage.
Keep small objects or liquids away from the unit.
Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the
cabinet may result in re, electric shock, or equipment damage. If an object or liquid falls/spills into the
cabinet, unplug the unit immediately. Have the unit checked by a qualied service engineer before using
it again.
Place the unit at the strong and stable place.
A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit
falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not
continue using a damaged unit. Using a damaged unit may result in re or electric shock.

4PRECAUTIONS
WARNING
Use the unit in an appropriate location.
Not doing so may result in re, electric shock, or equipment damage.
• Do not place outdoors.
• Do not place in a transportation system (ship, aircraft, train, automobile, etc.) where it may be affected
by strong vibration or shock.
• Do not place in a dusty or humid environment.
• Do not place in a location where water is splashed on the screen (bathroom, kitchen, etc.).
• Do not place in a location where the steam comes directly on the screen.
• Do not place near heat generating devices or a humidier.
• Do not place in a location where the product is subject to direct sunlight.
• Do not place in an inammable gas environment.
To avoid danger of suffocation, keep the plastic packing bags away from babies and
children.
Use the enclosed power cord and connect to the standard power outlet of your country.
Be sure to remain within the rated voltage of the power cord.
Not doing so may result in re or electric shock.
Power supply: 100-120/200-240Vac 50/60Hz
To disconnect the power cord, grasp the plug rmly and pull.
Tugging on the cord may damage and result in re or electric shock.
The equipment must be connected to a grounded main outlet.
Failure to do so may result in re or electric shock.
Use the correct voltage.
• The unit is designed for use with a specic voltage only. Connection to another voltage than specied
in this User’s Manual may cause re, electric shock, or equipment damage.
• Do not overload your power circuit, as this may result in re or electric shock.
Handle the power cord with care.
• Do not place the cord underneath the unit or other heavy objects.
• Do not pull on or tie the cord.
If the power cord becomes damaged, stop using it. Use of a damaged cord may result in re or electric
shock.
Never touch the plug and power cord if it begins to thunder.
Touching them may result in electric shock.
When attaching an arm stand, please refer to the user’s manual of the arm stand and
install the unit securely.
Not doing so may cause the unit to become unattached, which may result in injury or equipment
damage. When the unit is dropped, please ask your local EIZO representative for advice. Do not
continue using a damaged unit. Using a damaged unit may result in re or electric shock. When
reattaching the tilt stand, please use the same screws and tighten them securely.

5
PRECAUTIONS
WARNING
Handle the batteries for the remote control with care.
Not doing so may result in battery explosion, liquid leakage, or burns.
• Do not disassemble, heat, short-circuit, or immerse the provided batteries in water.
• Install/change batteries in a correct way.
• When replacing batteries, use ones of the same type and model.
• When replacing batteries, replace all of them at the same time with new batteries of the same brand
and type.
• Insert batteries with correct direction of the plus (+) and minus (-) sides.
• Do not use the battery with coating damaged.
• Dispose of your battery in a designated disposal area.
Keep the batteries for the remote control away from babies and children.
Accidental swallowing of the batteries may cause choking or poisoning.
In the event the batteries are swallowed, immediately consult a physician.
Do not touch a damaged LCD panel directly with bare hands.
The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part
of the skin or body comes in direct contact with the panel, please wash thoroughly. If some physical
symptoms result, please consult your doctor.

6PRECAUTIONS
CAUTION
Handle with care when carrying the unit.
Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached
is dangerous. It may result in injury.
When handling the unit, grip the bottom of the unit rmly with both hands ensuring
the panel faces outward before lifting.
Dropping the unit may result in injury or equipment damage.
Do not block the ventilation slots on the cabinet.
• Do not place any objects on the ventilation slots.
• Do not install the unit in a closed space.
• Do not use the unit laid down or upside down.
Blocking the ventilation slots prevents proper airow and may result in re, electric shock, or
equipment damage.
Do not touch the plug with wet hands.
Doing so may result in electrical shock.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power quickly in case of a problem.
Periodically clean the area around the plug.
Dust, water, or oil on the plug may result in re.
Unplug the unit before cleaning it.
Cleaning the unit while it is plugged into a power outlet may result in electric shock.
If you plan to leave the unit unused for an extended period, disconnect the power
cord from the wall socket after turning off the power for safety and power conserva-
tion.

7
Notice for this monitor
Notice for this monitor
This product is suited for displaying surveillance camera images.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
• Power cords provided with the product
• Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
In order to suppress the luminosity change caused by long-term use and to maintain the stable luminosity, use of a
monitor at a lower “Backlight” setting is recommended.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page8)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until
the dew condensation disappears, otherwise it may cause some damage to the monitor.

8Notice for this monitor
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel,
and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
If necessary, the stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with
water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to
the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

9
CONTENTS
CONTENTS
Cover ...................................................................... 1
PRECAUTIONS .................................................. 3
Notice for this monitor ......................................... 7
Cleaning .................................................................... 8
To use the monitor comfortably ............................. 8
CONTENTS ............................................................. 9
Chapter 1 Introduction ..................................... 10
1-1. Features ........................................................10
1-2. Package Contents ........................................10
1-3. Controls and Functions ..............................11
●Monitor ...........................................................11
●Remote Control ..............................................12
Chapter 2 Connecting Cables ......................... 13
2-1. Connection Procedures ..............................13
2-2. Adjusting the Screen Height and Angle ....15
Chapter 3 Settings and Adjustments ............. 16
3-1. Using Quick-OSD menu ..............................16
●Basic operation of Quick-OSD menu .............16
●Functions ........................................................17
●Other Functions ..............................................17
3-2. Using OSD menu ..........................................18
●Basic operation of OSD menu .......................18
●Functions ........................................................19
Chapter 4 Troubleshooting .............................. 21
4-1. Common ........................................................21
4-2. When displaying on a PC screen ...............21
Chapter 5 Reference ........................................ 22
5-1. Attaching an Arm ........................................ 22
5-2. Specications ............................................. 23
5-3. Preset Timing .............................................. 25
Appendix .............................................................. 26
Trademark ............................................................... 26
License / Copyright ................................................ 26
FCC .......................................................................... i
CE ............................................................................. i
CCC .......................................................................... i
LIMITED WARRANTY .............................................ii
Recycling Information ......................................... xi
China Measures for RoHS Compliance in
ChinaRoHS ............................................................xv

10 Chapter 1 Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 19-inch screen
• SXGA (1280 × 1024) display compliant
• Analog signal support
- PC signal: D-Sub mini 15-pin connector × 1
Horizontal scanning frequency 24.8 kHz - 74.8 kHz
Vertical scanning frequency 56.2 Hz - 75.1 Hz
- Video signal: BNC connector × 1
Applicable Format NTSC, PAL, SECAM
• Video Aspect function
Alters the display range of the input image (overscan)
• Remote control enables easy operation, setting and adjustment of the monitor.
• A 2-year long-term warranty for 24-hour continuous use
1-2. Package Contents
Check that all the following items are included in the packaging box. If any items are missing or damaged, contact
your local EIZO representative.
Note
• Please retain the packing materials for future transport of the monitor.
• LCD Monitor
• Remote control
• Coin lithium battery (CR2032)
• Power cord
• User’s Manual (Limited Warranty included)

11
Chapter 1 Introduction
1-3. Controls and Functions
●Monitor
14
15
73 62 4 9 10 1211 51 8
13
1Remote control detector Receives the signal from the remote control.
2 button Displays the volume adjustment menu to volume up or down.
3 button
• Displays/Exits the OSD menu.
• Pressing the button while the OSD menu is displayed returns you to the
previous menu status.
4 button
• Used to: select the OSD menu tab; select the set value; or to increase/
decrease the adjustment value.
• Press twice to switch the input signals.
5 button • Displays the Quick-OSD menu.
• Used to select the setting or adjustment items in each menu.
6 button Turns the power on or off.
7 Power indicator
Indicates monitor’s operation status.
Blue : Operating
Orange : Standby mode
8 Speaker Outputs audio source.
9 Power connector Connects the power cord.
10 Input signal connector
(D-SUB)
D-Sub mini 15-pin connector
11 Input signal connector
(VIDEO)
BNC connector
12 Input signal connector Pin jack (L, R)
13 Stand*1 Used to adjust the hight and angle of the monitor screen.
14 Security lock slot Complies with Kensington’s MicroSaver security system.
15 Cable holder Covers the monitor cables.
*1 An optional arm (or an optional stand) can be attached by removing the stand (see “5-1. Attaching an Arm” (page 22)).

12 Chapter 1 Introduction
●Remote Control
1
2
3
8
4
6
5
7
1 POWER Turns the power on or off.
2INPUT
SELECT
PC Switches to PC input.
VIDEO Switches to video input.
3 VOLUME Displays the volume adjustment menu to volume
up or down.
4 MENU
• Displays/Exits the OSD menu.
• Pressing the button while the OSD menu is
displayed returns you to the previous menu
status.
5 RETURN Pressing the button while the menu is displayed
returns you to the previous menu status.
6∧ / ∨ / ＜ / ＞
• Used to: select the OSD menu tab; select
the set value; or to increase/decrease the
adjustment value.
• Pressing or while the OSD menu
is not displayed allows you to adjust the
brightness of the backlight.
7 ENTER Used to x the setting or adjustment items in
each menu.
8 MODE Switches the gamma setting.
Before Using Remote Control
● How to install batteries
1. While pushing the tab toward the arrow (1),
pull out the battery case (2).
(1)
(2)
2.
Insert a battery with the positive side up.
(Battery model number: CR2032)
3.
Insert the battery case until it clicks.
● Receivable Range of Remote Control
Use the remote control inside of the range as below.
5m
5m
30°
30°
7m
5m
30°
30°
7m
5m

13
Chapter 2 Connecting Cables
Chapter 2 Connecting Cables
2-1. Connection Procedures
1. Connects to external equipment compatible with the monitor.
• When used as a PC monitor: page 13
• When using video equipment: page 14
● When used as a PC monitor
Attention
• When replacing the current monitor with this monitor, be sure to change the PC settings for the resolution and vertical
scan frequency to those appropriate to the this monitor.
Compatible Resolutions/Frequencies
The monitor supports the following resolutions.
Resolution Display Mode Frequency Dot Clock
640 × 400 NEC PC-9801 56 Hz
~126 MHz
640 × 400 NEC PC-9821 AP2 70 Hz
640 × 480 Apple Macintosh 67 Hz
640 × 480 VGA, VESA ~75 Hz
720 × 400 VGA TEXT 70 Hz
800 × 600 VESA ~75 Hz
832 × 624 Apple Macintosh 75 Hz
1024 × 768 VESA ~75 Hz
1152 × 864 VESA 75 Hz
1152 × 870 Apple Macintosh 75 Hz
1280 × 960 VESA 60 Hz
1280 × 960 Apple Macintosh 75 Hz
1280 × 1024*1 VESA 60 Hz
*1 Recommended resolution (Set this resolution.)

14 Chapter 2 Connecting Cables
1. Connect the monitor to the PC with a signal cable that matches the connectors.
After connecting the cable connectors, tighten the screws of the connectors to secure the coupling.
DVI
● When using video equipment
1. Connect the monitor to the video equipment with a signal cable that matches the connectors.
VIDEO
*1 The monitor is equipped with a single audio input connector to connect for either a PC or visual equipment. Regardless of the
input device selected, the monitor will output sound.
Signal cable FD-C16 (optional)
Signal cable MD-C87 (optional)
or
Audio cable (Commercially available product) Audio output
connector
Audio input
connector*1
BNC cable (Commercially available product)
Audio output
connector
Audio input
connector*1
Audio cable (Commercially available product)

15
Chapter 2 Connecting Cables
2.
Plug the power cord of the monitor into a power outlet.
Plug the power cord into a power outlet and the Power connector on the monitor.
Attention
• For the maximum power saving, it is recommended that the Power button be turned off. Unplugging the power cord
completely shuts off power supply to the monitor.
2-2. Adjusting the Screen Height and Angle
Hold left and right edge of the monitor with both hands, and adjust the screen height, tilt and swivel the screen to
the best condition for working.
Attention
• Be sure that the cables are correctly connected.

16 Chapter 3 Settings and Adjustments
Chapter 3 Settings and Adjustments
Setting and adjustment of the monitor can be performed using the OSD (On Screen Display) menu.
The Quick-OSD menu is also available to directly operate frequently used functions without starting the OSD menu.
3-1. Using Quick-OSD menu
●Basic operation of Quick-OSD menu
1. Displaying Quick-OSD Menu
● The buttons on the monitor
Press .
● The remote control
Press , , or .
2.
Setting/Adjusting
● The buttons on the monitor
Use to select the set/adjustment items. Then, use or for setting/adjustment.
● The remote control
Use or to select the set/adjustment items. Then, use or for setting/adjustment.
3.
Storing/Exiting
● The buttons on the monitor
The setting/adjustment is saved at the time it is changed.
The Quick-OSD menu automatically closes when a button is not used for 5 seconds.
● The remote control
The setting/adjustment is saved at the time it is changed.
Selecting closes the Quick-OSD menu.

17
Chapter 3 Settings and Adjustments
●Functions
The adjustable settings in the Quick-OSD menu are shown below. The availability of functions depends on the
input signal (PC or Video).
√ : Configurable ― : Not configurable
Functions PC Video Description
Brightness 0 to 100 √ √ Adjusts the brightness.
Contrast 0 to 100 √ √ Adjusts the contrast.
H Position 0 to 100 √― Adjusts the display position (horizontal).
V Position 0 to 100 √― Adjusts the display position (vertical).
Saturation 0 to 100 ― √Adjusts the saturation.
Hue 0 to 100 ― √Adjusts the hue.
Screen Size Fill All/16:9/4:3 ― √Changes the screen display size.
* There are three sizes available for “16:9”. The sizes
change in the following order: .
Mode Light/Dark/
Dynamic
√ √ Switches the gamma setting.
Backlight 0 to 100 √ √ Adjusts the brightness of the backlight.
●Other Functions
In addition to setting/adjustment by basic operation, automatic screen adjustment can be performed according
to the following procedure (only when PC signal is input).
1. Press followed by .
The Quick-OSD menu (“Auto Adjust”) appears.
2.
Press while the menu is displayed.
Automatic screen adjustment is performed.

18 Chapter 3 Settings and Adjustments
3-2. Using OSD menu
●Basic operation of OSD menu
1. Displaying OSD menu
● The buttons on the monitor
Press .
● The remote control
Press .
2.
Setting/Adjusting
● The buttons on the monitor
Use or to select the menu and then press .
Use to select the set/adjustment items. Then, use or for setting/adjustment.
● The remote control
Use or to select the menu and then press .
Use or to select the set/adjustment items. Then, use or for setting/adjustment.
3.
Storing/Exiting
● The buttons on the monitor
After completing the setting/adjustment, selecting allows you to store the setting.
Selecting repeatedly closes the OSD menu.
● The remote control
After completing the setting/adjustment, selecting allows you to store the setting.
Selecting repeatedly closes the OSD menu.
Note
• To go back to the previous menu, press .

19
Chapter 3 Settings and Adjustments
●Functions
The settings adjustable in the OSD menu are as shown below. The availability of functions depends on the
input signal (PC or Video).
√ : Configurable ― : Not configurable
Menu Functions PC Video Description
Picture Brightness 0 to 100 √ √ Adjusts the brightness.
Contrast 0 to 100 √ √ Adjusts the contrast.
Phase √― Adjusts the ickering or blurring.
Frequency √― Adjusts the frequency (clock).
Sharpness 0 to 15 √ √ Adjusts the sharpness of the image
outline.
0 (blur) to 15 (sharp)
* This adjustment has no effect for
images of 1280 × 1024 resolution.
Saturation 0 to 100 ― √Adjusts the saturation.
Hue 0 to 100 ― √Adjusts the hue.
Color Temp Red/
Green/
Blue
0 to 100 √ √ Adjusts the intensity of each color: Red,
Green, and Blue.
Img. Adj. Screen Size Fill All/
1 TO 1/
Fill Aspect
√― Changes the screen display size.
Fill All/
16:9/4:3
―√Changes the screen display size.
* There are three sizes available for
“16:9”. The sizes change in the
following order: .
H Position 0 to 100 √― Adjusts the display position (horizontal).
V Position 0 to 100 √― Adjusts the display position (vertical).
Auto Adjust √― Performs the automatic screen
adjustment.
