Eizo DuraVision DX0211-IP User manual

Important
Please read this “Installation Manual”, “Instruction Manual”, and
“Setup Manual” carefully to familiarize yourself with safe and effective
usage.
•For the latest product information including the “Installation Manual”,
refer to our web site :
www.eizoglobal.com
IP Decoding Box
Installation Manual
Software Version 5.1

Related Manuals
Setup Manual
Describes precautions and procedures for connecting network cameras and
for displaying camera images on the monitor. (Installation and initialization
guidance)
Installation Manual
(this manual)*1
Describes network camera registration, function settings, and system settings.
(Detail settings guidance)
Instruction Manual*1 Describes operation of live image screen menus. (Operation guidance)
*1 The Instruction Manual and Installation Manual for the latest software version used can be obtained from
our web site. Select “Manuals” from “Support”, enter “DX0211-IP” in the “Enter model name” box, and click
“Search”.
www.eizoglobal.com
Installation of Adobe®Acrobat®Reader®is required.
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.
2

CONTENTS
CONTENTS............................................................. 3
Chapter 1 Product Overview ............................. 4
1-1. Features ......................................................... 4
1-2. SystemConguration .................................. 5
1-3. Compatible Network Cameras .................... 5
Chapter2 BeforeConguration........................ 6
2-1. Logging In to the System............................. 6
●Conguring from this product.......................... 6
●Conguring from a web browser..................... 8
2-2. Setting Screen............................................... 9
●Basic Information ............................................ 9
●System Settings .............................................. 9
●Live Image Screen Settings ............................ 9
Chapter 3 System Settings.............................. 10
3-1. Performing Network Settings.....................10
3-2. Performing Communication Settings .......12
3-3. Setting the Current Date and Time ............14
3-4. Other System Settings ................................15
3-5. Initializing the System.................................16
3-6. Restarting the System.................................17
3-7. Updating Software .......................................18
3-8. Saving Settings Data .................................. 20
3-9. Loading System Settings Data...................21
3-10. Checking Logs ............................................ 23
3-11. Saving Logs................................................. 24
Chapter 4 Management of Network Cameras ... 25
4-1. Registering the Network Cameras............ 25
4-2.
Changing Network Camera Information ... 27
4-3. Deleting Network Cameras........................ 29
4-4.
Exporting Network Camera Information ... 30
4-5. Importing Network Camera Information ...31
4-6. Setting Network Camera Time .................. 33
4-7. Setting Quality of Transmission Video
Images.......................................................... 34
Chapter 5 Live Image Screen Settings........... 36
5-1. Setting Display Positions of Camera
Video Images............................................... 36
5-2. Setting Display Methods of Camera
Video Images............................................... 38
5-3. Setting Custom Screen Layouts ............... 39
5-4. Setting the Display Methods of Live
Image Screens............................................. 40
5-5. Setting Current Monitor Display Status ....41
Chapter 6 Management of the User Account ... 42
6-1. Registering the User Account ................... 42
6-2. Changing the User Account ...................... 44
6-3. Deleting the User Account......................... 45
6-4. ConguringAutoLoginSettings .............. 46
Chapter 7 Troubleshooting.............................. 47
7-1. Imaging Problems........................................47
7-2. Setting Problems ........................................ 49
List of Functions ................................................. 50
Appendix.............................................................. 51
Trademark ................................................................51
License .....................................................................51
3
CONTENTS

4Chapter 1 Product Overview
Chapter 1 Product Overview
This product is a device that outputs video images from a maximum of 16 network cameras*1 to monitors
connected using HDMI cable.
This manual describes network camera settings, system settings, and product specications.
*1 A type of camera which converts images into network signals and transmits the signals.
1-1. Features
●Communication with network cameras
• Possible to receive video images from a 4K camera (3840 × 2160 / 30 fps)
• Possible to display video signals from network cameras on a monitor
- Supports H.264 and MJPEG video compression format.
- A maximum of 16 network cameras can be registered.
- Allows a free layout of video images (1 Screen, 4 Screens, 9 Screens, 16 Screens, and Custom
Screen) from multiple network cameras.
- Supports Unicast and Multicast communication methods.
- Possible to switch the display position of camera video images while displaying video images.
●Possible to output to a 4K monitor
• Supports 4K output (3840 × 2160 / 60 fps max.)
●Possible to freely select a display monitor depending on the application scene
• Supports monitors with a resolution up to 3840 × 2160
• Possible to attach to a monitor using a separately sold attachment
●SupportsONVIFProleSnetworkcameras
●System management
• Possible to register network cameras or set the live image screen using a Web browser
• Possible to save and load settings data
Possible to save or load the setting data onto a computer.
●Security
• Alert display
Possible to display an alert on the live image screen when communication with network cameras is lost.
●Support
• A 2-year long-term warranty for 24-hour continuous use
●Operation
• Operations can be performed by using a keyboard or mouse
●Supports PoE+

5
Chapter 1 Product Overview
1-2. SystemConguration
This product is designed to communicate with network cameras and to display video images on the
monitor.
Network camera*1
Network hub*2
DX0211-IP
Monitor
HDMI cable
PC*3
Network cable
Network cable
Network cable
Network cable
*1 Up to 16 network cameras can be registered.
*2 Use a network hub that supports PoE+. If the hub does not support the PoE+ standard, network cameras and
DX0211-IP must be individually connected to the power supply.
*3 When setting the network cameras using a Web browser, use a computer on the same network as the DX0211-
I P.
1-3. Compatible Network Cameras
This product supports ONVIF Prole S network cameras. Depending on the software version of this
product, different cameras are supported.
For details, refer to our web site (www.eizoglobal.com).
The software version can be conrmed on the basic Information screen. For details, refer to “2-2. Setting
Screen” (page 9).
For installing and setting the network cameras, refer to the network camera User’s Manual.

6Chapter 2 Before Conguration
Chapter 2 BeforeConguration
System settings can be made from the screen (application screen) displayed on the monitor connected to
this product or from the web browser of a computer connected to the same network.
2-1. Logging In to the System
To congure this product, you need to log in to the system.
Login is allowed only when the level of the user accessing the product is “ADMIN”.
Long in to the system according to the following procedure.
Note
• The following user information is set by default.
- Username: “admin”
- Password: “admin”
- User Level: “ADMIN”
• For information on user settings, refer to “Chapter 6 Management of the User Account” (page 42).
• It is recommended to log out after completing the setup so as to prevent a third party from operating the network
camera or altering the settings.
• When the Auto Login settings are congured, it is possible to log in to the system without the username and
password. For details, refer to “6-4. Conguring Auto Login Settings” (page 46).
●Conguringfromthisproduct
A USB mouse is required when operating from the application screen.
Connect a USB mouse to the USB downstream port of this product.
Attention
• Adjust the monitor in advance so that the HDMI input can be displayed.
Note
• When connected to a device that has the USB hub function, both the USB mouse and USB keyboard can be
used.
• For entering characters, refer to “Entering characters” (page 8).
1.
Press on the front of this product.
The power indicator lights up blue and the live image screen is displayed on the monitor connected to
this product.
(For information on the live image screen, refer to the “Instruction Manual”.)
Note
• The power supply is set to “On” by default.

7
Chapter 2 Before Conguration
2.
Select (Login) under “System”.
The login screen is displayed.
3.
Enter a username and a password.
4.
Select “Login”.
The display returns to the live image screen.
5.
Select (Settings).
The setting screen is displayed.

8Chapter 2 Before Conguration
Entering characters
• When entering using a USB keyboard
Typed characters are entered in the text box. Move to the next item using the “Tab” key.
• When entering using a USB mouse
Clicking an item that requires characters to be input, such as a text box, will display a software keyboard.
When the focus is moved out of the software keyboard, the software keyboard is hidden.
●Conguringfromawebbrowser
Attention
• Internet Explorer 11 is the recommended web browser.
• When conguring from the web browser, the power supply must be connected to this product.
1.
Start the web browser of the PC to be used.
2.
Enter the following address for access.
Address: http://Address of this product*1
*1 The default address for access is http://192.168.0.150
The login screen is displayed.
3.
Enter a username and a password.
4.
Select “OK”.
The setting screen is displayed.

9
Chapter 2 Before Conguration
2-2. Setting Screen
The setting screen consists of Basic Information, Unit Settings, and Live Image Screen Settings.
●Basic Information
Information on various settings of this product is displayed in a list.
The following settings can be conrmed: ”System Information”, “System Status”, “Camera / Display
Position”, ”Date and Time”, “Network”, and “Communication”.
Clicking on an item tab at the top of the screen will display each setting item.
System Information
Displays the current status.
• Model Name
• S/N
• Software Version
• Resolution
• MAC Address
• Communication speed
System Status
Displays the current status.
Camera / Display Position / Date and Time / Network / Communication / Other
Displays the current settings status of the monitor.
●System Settings
Various settings such as registration of network cameras and system settings are performed.
●Live Image Screen Settings
Display settings such as changing the live image screen layout are performed.

10 Chapter 3 System Settings
Chapter 3 System Settings
Perform settings for the date and time of the system, network settings, and maintenance.
These operations can be performed from the application screen or from the web browser.
This chapter explains procedure using the web browser. However, except for a few functions, the same
functions can be used either way.
3-1. Performing Network Settings
Perform network settings such as IP address, DNS, and NTP.
Attention
• IP Setting Method When any one of the IP Address, Subnet Mask, or Gateway is changed and “Apply” is selected,
a warning message saying “The network settings will be changed.” is displayed.
Select “OK”.
• The same warning message is displayed when the IP address is changed from the web browser. Selecting “OK”
will display a message requesting reaccess. Access again using the changed IP address.
1.
Select “Network” under “System”.
The “Network” screen is displayed.
