About Re/Vue
Re/Vue is a video recording product that fulfills
the specific capture, compression, and data archive
requirements found in ATC, training and simula-
tion, and command and control environments.
Re/Vue consists of video and audio recording hard-
ware, supporting driver, and control software. It
delivers lossless recording and compression with
remote and local data storage. Re/Vue integrates
with an existing workstation and monitor and
records from any DVI (digital) source at resolutions
up to 2048
× 2048 and 2560 × 1600. It also has a
web-based control interface to manage and control
single or multiple Re/Vue systems through a pass-
word-protected web-based browser.
Lossless Recording and Compression
Video recorders record data with varying levels of
quality. Many use compression algorithms like JPEG,
MPEG and H.264. While these lossy compression
algorithms are fine for some surveillance applica-
tions, their compression artifacts cause video play-
back quality to suffer. Only Re/Vue’s lossless video
recording with synchronized audio can guarantee
playback data quality will be identical to the original
source data. Even at a resolution of 2048
× 2048,
Re/Vue can record a full 60 frames per second.
Minimized Data Storage
Lossless recording of ATC video creates a huge
amount of data. Depending on configuration param-
eters and video data type, Re/Vue delivers lossless
recording with extremely high compression ratios
of 10,000:1 to 20,000:1 for typical ATC data.
Whereas, traditional video recorders typically only
offer a compression ratio of up to 300:1, Re/Vue’s
compression efficiency significantly minimizes data
storage. This allows approximately 30 days of stor-
age per terabyte.
Configurable Archival
Capturing and recording screen images and audio
doesn’t mean much if the data can’t be properly
archived and immediately accessed locally or
remotely. Re/Vue not only offers local storage
but also provides the ability to remotely archive
recorded data. Remote archival can be configured
to take advantage of existing storage servers on
the network and an archival schedule can be eas-
ily configured using the web-based interface. This
offers convenient retrieval of data from any remote
machine on the network for review of any incident
for investigative or training purposes.

Playback Utility
Of prime importance in mission-critical applications
is the ability to record screen events as they happen
so data from any incident can be searched, retrieved,
and distributed for investigative or training pur-
poses. Re/Vue’s playback utility supports playback
on any Linux or Windows based system. If playback
is at a lower resolution than the original recording,
Re/Vue’s playback utility offers enhanced features
such as pan and zoom that can be used to help com-
pensate for resolution differences.
Platform and Graphics Card Independence
Video recording solutions are known to be tempera-
mental. They typically require a very specific oper-
ating system, drivers, application software. Some
even require recording and playback to occur on the
same computer. The Re/Vue video recording system,
however, is platform and graphics card independent,
so even if recording is done on one computer, play-
back can be easily viewed on any Linux or Windows
based computer.
Centralized Control
Re/Vue has a web-based ‘Dashboard’ interface that
can be controlled from any machine on the network.
It also offers administrators the ability to man-
age and control single or multiple Re/Vue systems
through a password-protected web-based browser.
© 2010 Eizo Nanao Corporation
All product names are trademarks or registered trademarks of
their respective companies.
Re/Vue is a trademark, and EIZO is a registered trademark of
Eizo Nanao Corporation. Specifications are subject to change
without notice.
Published on chlorine-free paper.
(100209) Printed in Japan, 2, 2010, 0.2K
Recording & Compression Hardware, Driver and Control Software
About EIZO
Eizo Nanao Corporation (EIZO) is a leading
worldwide manufacturer of high-end visual display
products for such fields as medical imaging, digi-
tal photography, printing, and financial trading.
With its acquisition of Tech Source in 2007 and the
monitor business of eg-electronic in 2009, EIZO
is committed to bringing the same level of reliable
and innovative display solutions to the ATC market.
Based in Japan, EIZO is listed on the first section of
the Tokyo Stock Exchange (TSE: 6737) and repre-
sented in more than 60 countries by a network of
subsidiaries and exclusive distributors.
Specifications
Add Device
Device Working
Device Error
Re/Vue offers admin-
istrators centralized
control of one or
more Re/Vue systems
via a password-pro-
tected web browser.
Video Compression Ratio
(Based on typical ATC data)
Compression ratio of 8,000:1 to 30,000:1*
Supported Resolutions 1280 × 1024, 1600 × 1200, 1920 × 1200,
2560 × 1600, 2048 × 2048
Maximum Video Resolution
4MP – 2048 × 2048 dual link DVI
Maximum Frames Per Second
85 Hz for most resolutions (60 Hz for 2048 x 2048)
Video Connectors Dual link DVI-D input and output with full EDID/
DDC support
(also supports single link)
Audio Connectors 2.5 mm (3/32") stereo
Audio Format MP3 standard – two channel up to 48 KHz sample
frequency
Dimensions (W x H x D) 222 mm x 176 mm x 276 mm
Hardware Warranty 2 years
* Actual compression ratio is dependent upon configuration parameters and video data type
Re/Vue allows recorded files
to be played back on any
Linux or Windows worksta-
tion and provides features
such as pan and zoom.
