EKO LS-100 User manual

Instruction Manual
Thank you very much for using EKO products.
Before operating this system, you should first thoroughly read this manual.
Keep this manual on hand to read when necessary.
1. Safety precautions 1
2. Contents 2
3. General description 3
4. Description of components 5
5. Notes to Users 7
6. Software 8
7. LS100.exe software 12
8. Maintenance 31
9. Trouble shooting 31
10. Specifications 32
11. After-sales service 34
Solar Simulator
Spectroradiometer
LS-100

1
1
1
1. Safety precautions
Our products are designed and manufactured in consideration of safety. However, they
would invite unexpected accident according to the circumstances of users. You should
thoroughly read this manual and operate the system according to the directions.
Warnings/Cautions
Neglecting this sign will invite serious or fatal accidents.
Prohibitions
This sign notifies that you must not do it.
Obligations
This sign notifies that you must do it.
Warnings
Installation
Put LS-100 and a PC on the installation base that endures enough load and vibration. The
drop of LS-100 or a PC causes the unexpected accidents.
Cautions
Power supply
Confirm the input voltage of the AC adaptor of LS-100 is matched to the voltage of mains
power supply. Turn on the power of LS-100 after confirming the voltage.
Instruction Manual
This manual contains instructions for the basic and critical operations of the system.
Before operating this system, thoroughly read and understand this manual.
Keep this manual at hand so that you can use it anytime.
Handling precautions
Remove the optical fiber from the LS-100 body when you set up the optical head. Fix the
optical fiber at the proper point, and connect the fiber to the LS-100 body.
When the optical head is set up with an optical fiber, which is connected with the LS-100
body, the fiber could be damaged due to the twist or bend.
When the optical head is illuminated for long time by the solar simulator etc., the optical
head becomes very hot.
Do not touch the optical head directly, without using gloves etc. It could get hands
burned.
!
!
!

2
2
2
2. Contents
1. Safety precautions 1
2. Contents 2
3. General description 3
3-1. General descrip tion 3
3-2. Characteristic s 3
3-3. Block di agram 4
4. Descriptions of components 5
5. Notes to Users 7
5-1. Notes 7
5-2. B efo re use 7
5-3. Connecti on 7
6. Software 8
6-1. General descrip tion 8
6-2. Installati on 8
6-3. Unin stallation 11
6-4. Data fil e format 11
7. LS100.exe software 12
7-1. Start-up 12
7-2. Measur em ent control wi n dow 14
7-3. Measu rement displ ay window 16
7-4. Stand a rd data disp lay 29
7-5. Others 30
8. Maintenance 31
Periodic maintenan ce 31
9. Trouble shooting 31
10. Specifications 32
10-1. Sp ecificati on s 32
10-2. Stan dard ac c essori es 33
11. After-sales service 34
Contact Addre s s 34
Wa rranty 34
Instruction manua l 34
Renewal Record 34

3
3
3
3. General description
3-1. General description
Solar simulator spectroradiometer LS-100 is developed for the spectral irradiance
measurement of the solar simulator, which is mainly used for the evaluation of the
photovoltaic cells.
The compact grating spectrometer is integrated in the body to measure the spectral
irradiance by using photodiode array. The obtained data is downloaded to PC, and the
spectral irradiance is calculated by the attached software. Attached software 1) compares
the obtained data with the Reference solar radiation at AM1.5 provided by JIS C 8941, 2)
calculate the cumulative spectral irradiance in the specified wavelength, JIS C8912 spectral
mismatch, and the deference/ratio comparing to the Reference data.
JIS C 8941-2009 Secondary reference crystalline solar cell
JIS C 8912-2011 Solar simulator for crystalline solar cells and modules
3-2. Characteristics
1. Long Stability
The less aging diffuser, grating spectrometer and diode-array are adopted in LS-100.
LS-100 is durable because there is no movable part to change the wavelength. This is
accomplished by the adoption of photodiode-array.
2. Substantial software functions
LS-100 software automatically determines the optimal shutter opening time for the spectral
measurement based on the intensity of the light source. It saves the obtained measured
spectral data as the Reference data, and compares it with the other data.
Both “Catalogue View” of the plural spectral data and the “Detailed View” of the single
spectral data are available by LS-100 analysis software. The measured data of 1nm or
5nm interval can be saved by the setting of this software. The obtained data can be
compared with the standard solar radiation provided by JIS.

4
4
3-3. Block diagram
Block diagram of solar simulator spectroradiometer LS-100 Hardware is shown below.
Fig. 3-1. Hardware block diagram
The incident radiation goes into the integrated spectrometer through the optical head. The
spectral data is saved in the internal memory at the processing unit.
The data can be downloaded to PC through RS-232C or USB cable, and
displayed/saved/converted by the attached software.
Fig. 3-2. LS-100 structure
Processing
unit
PC
Photodiode-array
Optical fiber
Spectrometer
Shutter
Incident
window
Body
RS-232C
Optical fiber
RS-232C cable
Incident
light
LS-100
*PC is not included in LS-100.
PC
LS-100
body
Optical
head
AC adapter

5
5
250
150
55
22 40
150
3
SPECTRORADIOMETER
Solar Simulator
50
4
4. Descriptions of components
The names and functions of LS-100 components are shown in Fig. 4-1. and Table. 4-1
Fig. 4-1. Schematic diagram
⚫Optical head
⚫Body
Side view
a) LED lamp
b) Optical fiber
receptacle
(fixing screw
included)
c) Power switch
d) RS-232C
connector
e) Power supply
connector
f) Stand
* Vertical installation is possible with the optional stand.
Backside view
Front view
g. Incident window
h. Optical fiber joint
I Optical fiber 700mm

6
6
Table 4-1. Functions (Body)
Part
Description
Function
a
LED lamp
For the power supply status
Blink during the measurement
b
Optical fiber
receptacle
Connect the optical fiber with the fixing screw
c
Power switch
Set the switch to the side of ”I” to turn on the power
Set the switch to the side of “●” to turn off the power
d
RS-232C
connecting
connector
Connect the RS-232C cable for PC connection
e
Power supply
connector
Connect the output plug of the attached AC adapter
(Input:AC100-240V, Output:DC12V, 0.8A)
f
Stand
Use when the LS-100 is set vertically.
LS-100 can be used horizontally without stand.
Table 4-2. Functions (Optical head)
Part
Description
Function
g
Incident window
Transfer the incident radiation
h
Optical fiber
joint
Connect the optical head and optical fiber
Cannot be dismantled
i
Optical fiber
Transfer the radiation to the body
*Do not bend or twist the optical fiber smaller than 40mm radius. The
measurement cannot be performed if the optical fiber is broken.

7
7
5
5. Notes to Users
5-1. Notes
1.
Grating solar simulator spectroradiometer LS-100 perform the spectral measurement of the
manufactured light. Remove the block out objects in the range of aperture angle.
2.
Keep away from the water and dust, and set on the stable basement. It could be the cause
of failure.
5-2. Before use
1. Install the optical head
Remove the optical fiber from the body.
Fix the optical head at the measurement point.
2. Install the body
The body can be set horizontally and vertically with the stand for the measurement.
5-3. Connection
1. Connect the optical fiber
Connect the optical fiber to the body.
Fix the optical fiber connector with the fixing screw to connect the optical fiber to the body.
For optical fiber handling
1) Do not bend or twist the optical fiber smaller than 40mm radius.
2) Do not twist the optical fiber.
2. Connect the power supply cable
Connect the DC output cable of the AC adapter cable to the DC5V terminal. Make sure the
power supply is AC100V~240V, the frequency is 50Hz/60Hz. Connect the AC adapter to
the AC power supply socket.
3. Connect the communication cable
Connect the PC COM port and RS-232C port at the backside of the body via RS-232C cable.
!

8
8
6
6. Software
6-1. General description
The software only used for LS-100 Solar Simulator Radiometer performs measurement and
analysis. Fig. 6-1 shows the concept of LS-100 Software.
Fig.6-1 Concept of LS-100 software
6-2. Installation
1. Click “Setup.exe” in the attached CD-ROM “Solar Simulator Spectroradiometer LS-100
software”.
2. Select “Agree a software license” in “License agreement” window.
Fig.6-2 License agreement window
LS100.exe
For measurement and analysis
RS-232C
LS-100
CSV file
ESM file

9
9
3. Select “LS-100” in “Selection of a package” window.
Fig.6-3 Selection of a package window
4. Select the folder for software installation in “Setup” window. Shortcut to the software
can be made on desktop and/or start menu by checking the checkboxes.
Fig.6-4 Setup window
