ELA AP282-UV User manual

Air Purifier
MODEL AP282-UV
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

GENERAL INFORMATION
Packaging
Please DO NOT dispose of any packaging until you have checked the
appliance is operational.
After removing the packaging ensure the contents are intact and
complete. In the unlikely event of missing parts; contact your
retailer.
DO NOT leave children unattended with any of the packaging since
it is a potential source of danger. Disposal of all packaging must be
carried out responsibly safely and in accordance with your local
authority
regulations
.
authority
regulations
.
ALWAYS recycle the packaging material where possible.
1

IMPORTANT SAFETY INSTRUCTIONS
Important Safet Instructions
When using any electrically powered product, basic safety precautions
should always be followed.
PLEASE READ THE INSTRUCTIONS CAREFULLY & IN FULL BEFORE USING
THE PRODUCT.
WARNING - to reduce the risk of fire, electrical shocks or injury to persons or
property:
1. Always operate the product from a power source of the same voltage,
frequency and rating as indicated on the product identification plate.
2. Close supervision is necessary when any product is used by or near children
the elderly or the infirm. Do not allow children to use the appliance as a toy.
3. Do not operate any product with a damaged cord or plug, or after the product
malfunctions, or appears damaged in any way. Return the complete product to
the place of purchase for inspection, repair or replacement.
4
.
To
reduce
the
risk
of
electric
shock,
do
not
expose
the
unit
or
power
cord
to
2
4
.
To
reduce
the
risk
of
electric
shock,
do
not
expose
the
unit
or
power
cord
to
moisture of any sort.
5. Switch off and unplug from the power socket when not in use, before
assembling or before cleaning.
6. Do not place objects on the product or allow objects to obstruct the outlet
openings, or operate in close proximity to walls or curtains, etc.
7. The use of attachments or accessories not recommended or sold by the
product distributor may cause injury to persons or damage to property.
8. This product is intended for normal domestic/household use only.
9. Do not attempt to disassemble the appliance.
10. Do not operate the appliance on a metal surface.
11. Do not use the appliance in artificially hot or humid conditions or allow to be
used in a hazardous environment.
12. Do not clean the appliance with organic solvent.
13. This instruction manual is an integral part of the appliance and should be
stored for safe keeping and must always accompany the appliance in the event
of ownership transfer or for reference to by a service engineer.

Product Description
Control Panel
Air Inlet
Negative Ion Generator
U.V Lamp
3
Front Panel
DO NOT OBSTRUCT THE AIR INLET OR AIR OUTLET
3 Stage Filter system
•HEPA
•Active Carbon
•TiO2

Fitting & Replacing the Filter
1. Open the front cover.
2. Remove the filter from its packaging and
insert the filter as shown in fig.2
Fig.1
Ensure the appliance is switched OFF and unplugged from the mains socket
4
Fig.2
Fig.3
3. Re-fit the front panel and continue with
normal operation.

The Filtration S stem
HEPA - The High Efficienc Particulate Air filter captures up to
99.97% of contaminates as small as 0.3microns in size. These
include dust, dust mites, pollen, animal dander tobacco smoke.
Active Carbon - Is charcoal that has been treated with oxygen to
open millions of pores between the carbon atoms. These pores
absorb harmful gases and odours.
Titanium Dioxide (TiO₂) - Is active under U.V light and has anti-
bacterial, anti-viral, sterilising deodorising properties.
U
.
V
Lamp
-
The
ultra
violet
light
is
used
for
sterilisation
against
5
U
.
V
Lamp
-
The
ultra
violet
light
is
used
for
sterilisation
against
micro-organisms and acts as a supplement to the TI0₂ filter.
Ioniser - Negative ions are electrically-charged particles in the air
that remove airborne contaminates from the air we breathe, and
have a rejuvenating effect when interacting with physiological
systems (such as the respiratory system).

CONTROL PANEL INSTRUCTIONS
Modes of operation
POWER
UV ION 1H 3H 8H HighQuiet
Timer Mode Power
6
Press the POWER button once to switch the appliance ON.
With the power ON, press the POWER button once to switch the
appliance OFF.
Mode
Press the MODE button to operate the appliance in Quite mode (low
fan speed). Press the MODE button again to operate the appliance in
High mode (high fan speed)
In both modes of operation the UV and ION functions are on
permanently.

CONTROL PANEL INSTRUCTIONS CONTINUED
Timer Function
•Press the TIMER button to select auto power OFF in 1hour(1H).
•Press the TIMER again to select auto power OFF in 3hours(3H).
•Press the TIMER again to select auto power OFF in 8hours(8H).
•Press the TIMER button again and the timer function is switched
OFF.
At each selection, the corresponding L.E.D on the control panel will
illuminate.
1 Hour
x1
3 Hour
x2
8 Hour
x3
7
x1
x2
x3
Timer OFF
x4

MAINTENANCE INSTRUCTIONS
Cleaning the Air Purifier
Before carry out routine maintenance or cleaning the appliance,
switch the power OFF and remove the plug from the mains socket
outlet.
For exterior cleaning, use a lint free, soft moist cloth with a mild
detergent.
DO NOT clean the appliance with organic solvents or abrasive
cleaning chemicals.
Use a vacuum cleaner and hose attachment to clean the front panel
inlet
grille
.
8
inlet
grille
.
Replacing the Filter
In normal household conditions, the filter is designed to last for
approximately 6~12months. However, the filter may require
changing more frequently in areas where increased amounts of
airborne impurities are present.

BS Plug Wiring
Wiring Instructions: Should it be necessary to change the plug please note
the wires in the mains lead are coloured in accordance with the following
code:
BLUE - NEUTRAL
BROWN - LIVE
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
1. The BLUE wire is the NEUTRAL and must be connected to the terminal
that is marked with the letter Nor coloured BLACK.
2
.
The
BROWN
wire
is
the
LIVE
and
must
be
connected
to
the
terminal
that
TECHNICAL DATA
2
.
The
BROWN
wire
is
the
LIVE
and
must
be
connected
to
the
terminal
that
is marked with the letter Lor coloured RED.
3. Neither wire is to be connected to the terminal which is marked with the
letter Eor earth symbol , coloured GREEN or GREEN/YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 3A (BS 1362)
fuse. If in doubt consult a qualified electrician.
Wiring for a 13 Amp plug (BS 1363)
The Earth Terminal is marked with the letter E or Earth Symbol
9

TECHNICAL DATA
Voltage: 230 – 50Hz
Power: 30watts
Noise Level: <48dB(A)
Ozone Concentration: <0.05ppm
Protection Class: II
Net Weight: 1.75kg
Gross Weight: 2.1kg
Dimensions: 24.7 x 12 x 27.8cm
10
GENERAL MAINTENANCE
I. Ensure the appliance is switched OFF and the power cord is removed
from the mains socket outlet .
II. Use a soft moist cloth to remove dirt dust and wipe dry .
III. DO NOT use detergents, chemicals or solvents to aid cleaning.
IV. Store the heater in its original packaging in a well ventilated, dry place.
V. Repairs should only be carried out by a qualified service agent.
VI. DO NOT modify the appliance or use in a manor not originally intended.

WARRANTY
ONE (1) YEAR LIMITED WARRANTY
Retain this warranty information
ELA undertakes to replace or repair at its discretion goods (excluding
batteries) should they become defective within one year solely as a result of
faulty materials workmanship.
If the product has not been operated, maintained or if any attempt has been
made to rectify, dismantle or alter the appliance in any way the warranty will
be
invalidated
.
be
invalidated
.
If the unlikely event of a fault, the appliance must be returned to the point of
sale with proof of purchase and a FULL description of the fault.
In the unlikel event of a problem, please contact our help desk on
01588 620126
This product has been manufactured to comply with EEC directives
73/23/EEC 89/336/EEC
Electrical products should not be disposed of with general household waste.
Please recycle where facilities exist.
For more information on disposal contact your local authority.
11
