TheaterPoint - Hitting the Sweet Spot
In the Home Theater
Or Any Room in
the House
Front stage left, center, right. Rear or side channel surround. There's
no reason to compromise on sonic quality and imaging just because
you want to place your speakers in the ceiling.
With three innovative models to choose from, there's a THP800
Series ceiling speaker that can bring high-end stereo sound into
any room.
Regardless of the application, one listen to TheaterPoint in-ceiling
speakers and you'll know you've made the right choice.
THP800 Series 3-way speakers set a new
standard for in-ceiling sound quality and
design. With their deep bass, smooth mids
and accurate highs, the THP800 Series
excels at any job –
front left/right
or center,
rear
or side channel surround, or in any stereo
application where the best in high-fidelity
in-ceiling audio is desired.
Radically Innovative Design
ELAN's unique patent-pending, 3-way
design allows the sound field to be
steered directly into the
optimal listening area.
Since bass frequencies
are omni-directional,
each 8-inch woofer
is aimed directly
downward for
maximum
dispersion. Mids
and highs,
however, are
considerably
more directional.
The 800 Series’ midrange drivers and
tweeters are set into an angled rotating
assembly that allows them to be steered
into the listening area, providing for
unparalleled separation and imaging, and
making for incredibly smooth and articulate
vocal reproduction.
Laser-Guided Calibration
Additionally, each tweeter pivots
independently, allowing for even more
pin-point accuracy of upper frequencies.
A precision laser pointer, included with each
800 Series speaker, fits snugly into a notch
built in to the tweeter's housing, allowing
meticulous calibration of high frequencies
into your Home Theater's “sweet spot” in
only minutes.
Mix and Match
TheaterPoint is the only family of speakers
so precisely timbre-matched that any
combination of free-standing, in-wall, on-wall
or ceiling speakers can be used to create the
ideal Home Theater listening environment
regardless of a room's size, shape or
aesthetics.
TheaterPoint In-Ceiling Speakers
A Pointedly Different Speaker
PRINTER’S INSTRUCTIONS: P/N: CSTHP800_REV:A - INK: CMYK, VARNISH - MATERIAL: 140G GLOSS ART - SIZE: 8.5” X 11” - SCALE: 1-1 - MUST BE RoHS COMPLIANT
CSTHP800 REVA IMAGE 1
Experience a Step Up
In Performance.
THP803C/802C/801C
CSTHP 2/13/07 10:51 AM Page 1

System Type 3-way focused sound field 3-way focused sound field 3-way focused sound field
Woofer 8 in. woven Kevlar fiber cone,
inverted butyl rubber surround,
cast aluminum basket
8 in. Graphite-reinforced polymer cone,
inverted butyl rubber surround,
pincushion-stamped steel basket
8 in. mineral-filled polypropylene cone,
inverted butyl rubber surround,
pincushion-stamped steel basket
Midrange 2.5 in. woven Kevlar cone 2.5 in. injected Graphite polymer cone 2.5 in. mineral-filled polypropylene cone
Tweeter .75 in. (19mm) woven Kevlar dome, pivoting .75 in. (19mm) open silk dome, pivoting .75 in. (19mm) cloth dome, pivoting
Frequency Response 35Hz to 22kHz 40Hz to 20kHz 42Hz to 20kHz
Crossover 2nd order custom Q @ 300Hz & 4kHz 2nd order custom Q @ 250Hz & 3kHz 2nd order custom Q @ 250Hz & 3kHz
Sensitivity 90dB 89dB 88dB
Normal Impedence 6 Ohms 6 Ohms 6 Ohms
Rated Power 125 Watts RMS 120 Watts RMS 100 Watts RMS
Switches EQ (Bright/Neutral/Warm) & Bass Limiting EQ (Bright/Neutral/Warm) N/A
Dimension Frame: 12-1/8 in. (308mm)
Cutout: 11-1/4 in. (286mm)
Mounting Depth: 7 in. (178mm)
Frame: 12-1/8 in. (308mm)
Cutout: 11-1/4 in. (286mm)
Mounting Depth: 7 in. (178mm)
Frame: 12-1/8 in. (308mm)
Cutout: 11-1/4 in. (286mm)
Mounting Depth: 7 in. (178mm)
Weight 11 lbs (5kg) 11 lbs (5kg) 11 lbs (5kg)
Features & Specifications
www.elanhomesystems.com
© ELAN Home Systems • 2007 • All rights reserved • ELAN Home Systems is a trademark of ELAN Home Systems, LLC • CSTHP800 REVA
Life Just Got Better
®
CSTHP800 REVA IMAGE 2
Common Features
Patent-pending, focused sound field, 3-way design
Downward-firing 8 in. woofers for maximum bass
dispersion
360° vibration-free rotating baffle for pin-point
focus of mids & highs
Independently pivoting tweeters
Easy, 1-screw adjustment
Removable baffle
Paintable narrow frame & low-profile grille
(paint shield incl.)
ELAN Laser Pointer (incl.)
Unmatched sound at any price point
Lifetime Limited Warranty
THP802C
Maximum performance – great price
point
Graphite-reinforced polymer woofer
Injected graphite polymer midrange
Open, silk dome tweeter
3-position bright/neutral/warm room
compensation switch
THP801C
Amazing, cost-effective, in-ceiling sound
Mineral-Filled Polypropylene woofer
Mineral-Filled Polypropylene midrange
Cloth dome tweeter
THP803C
Audiophile sound quality and imaging
Woven Kevlar woofer
Woven Kevlar midrange
Woven Kevlar tweeter
3-position bright/neutral/warm room
compensation switch
-20dB bass limiting switch
Specifications
THP803C THP802C THP801C
ELAN Home Systems reserves the right to change hardware and specifications without notice.
