Elan SYSTEM6 User manual

NOTE: USE CAT5 OR 18/2
FOR POWER.SEE PVIA1
MANUA L FO R DE TAIL S
VIA!
P/N 9900305 REV: A
Sys6 ZONE 1234
DIP S witch #
1
2
3
4
5
6
DOWN DOWN DOWN
DOWN DOWN
DOWN DOWN DOWN
DOWN DOWN
DOWN DOWN
DOWN
UP
UP UP
UP
UP UP
UP UP
UP UP UP
DOWN
4
3
2
1
Z200/Z250
1234UP
S6KP/Z100
Figure 7
NOTE: If more than one ZPAD is to be installed in a single
zone, all wiring should be paralleled and both ZPADS
should be assigned the same Zone ID.
BLUE
WHITE/BLUE
ORANGE
WHITE/O RANG E
G REEN
WHITE/G REEN
BROWN
WHITE/BROWN
BLUE
WHITE/BLUE
ORANGE
WHITE/O RANG E
G REEN
WHITE/G REEN
BROWN
C45P RJ-45
Interface cable
C45P RJ-45
Interface cable
WHITE/BROWN
Syste m6
IR2020
Local IR Emitter in
parallel with ZPAD
Pa ra lle l or us e
TBK2000
punchdown block
+12V
(S tripe)
GROUND
IR
SYSTEM6 QUICK REFERENCE GUIDE
Connecting IR receivers and Emitters
into Keypad Wiring
System6 Keypad Input -- Straight Through W/ ELAN Keypads
Music-on-Hold
Volume Level
Adjustment
Page/Doorbell
Volume Level
Adjustment
Zone ON / OFF
Status LEDs
Power LED
IR Activity
Indicator
LED
S6 Front Panel Adjustments and Status Indicators
Power Switch
Modular Speaker Connectors
Source Status Inputs
Zone Keypad/VIA! Inputs
Zone Trigger Outputs
IR Emitter Outputs
Page/Doorbell/
Music on Hold
(Z600)
System
Trigger Outputs
Zone Preamp
Output Selector
Source Inputs
Zone Preamp
Outputs
Rear Panel -- Connections Overview
Connecting VIA! Touch Screens
to the System6
IMPORTANT DESIGN NOTES:
1. The S6 internal amplifier is ALWAYS VARIABLE! Volume commands
are IR controlled. There must be an IR keypad, VIA!, or IR receiver con-
ected to each Zone Input to control Volume.
2. RCA Preouts are provided for subzone applications. Use an external
amplifer and Volume Control for subzones requiring separate Volume
functions. Set preouts to fixed and connect preouts to auxiliary amp.
3. S6 can be controlled from any ELAN keypad, IR receiver, or VIA!
Connecting Multiple Keypads in a Single Zone
IMPORTANT NOTE
VSE's, ZPADS, & IR
Each ZONE KEYPAD INPUT RJ45 jack on the S6
provides 12VDC@300mA. You may choose to
load each INPUT with any combination of ZPADS,
IR Receivers, or VSEs as long as the total current
consumption DOES NOT EXCEED 300mA.
ZPADS (w/ IR Tube) = 65mA
Z025 = 85mA
VSE = 40mA
Additional IR Receivers = 10mA

VSE Connection Diagram: VSE Sense Feature Connections:
NOTE: Calculate your current requirements to ensure reliability! Note: Sense Wire goes to Tip and Ground goes to Sleeve
How the Sense Feature Operates:
When a user turns a zone off by keypad, the VSE's will mute auto-
matically. When a user turns the main zone keypad "on" the VSE's
stay muted with audio playing in the main zone only. The Mute light
on the VSE will illuminate green to indicate that the main zone is
turned "on". The user can touch the VSE or use the included remote
to make audio playback in the subzones.
OTHER NOTES:
Rack Shelf Available Directl
y
from Middle Atlantic Part# RSH4A3MELANS6
SYSTEM6 QUICK REFERENCE GUIDE
SLEEVE
Sleeve Green 5(Green)
(Green)
IR EMITTER OUTPUTS
Connecting the Z600 COM Controller to the S6
NOTE: Use a multimeter to determine polarity. Don't Guess!
Connecting the Z880 Video Controller to the S6
NOTE: If additional devices such as the ELAN DTNR or VIA!dj are present, use an ELAN
IRZ Infrared Expansion Block to increase the number of available ALL IR OUTPUT Jacks.
SEE NOTE ABOVE!
ZPA
Y
S6’
CAUTION: Make sure unit is powered
down before adjusting the ZONE PRE-
AMP OUTPUT MODE DIP switches.
EXAMPLE SYSTEM DIAGRAM
Single Zone w/ Speakers and Keypad -- Subzone requires secondary
amp and Volume Control -- Don't forget to set the preouts!
Complete Installation Manuals for all ELAN products are available at www.elanhomesystems.com
