ELARABY TORNADO THB-600W User manual
THB-600WTHB-600W
يوﺪﻳ طﻼﺧ
ﻞﻴﻐﺸﺘﻟا ﻞﻴﻟد
ﻰﺑﺮﻌﻟا ﺔﻛﺮﺸﺑ ﺔﺻﺎﺧ ﺔﻠﺠﺴﻣ ﺔﻳرﺎﺠﺗ ﺔﻣﻼﻋ ﻰﻫ وﺪﻴﻧرﻮﺗ ﺔﻣﻼﻌﻟا هﺬﻫ
ﻞﻳدﻮﻣ
وﺪﻴﻧرﻮﺗ -يوﺪﻳ طﻼﺧ كرﺎﻴﺘﺧ ﺮﻜﺷ
x x
xx
.On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
On/Off
5
CLEANING AND MAINTENANCE
Quick cleaning
Instruction for masher
Prepare 300g cooked potatoes, cut each potato into 4 pieces. Max operation duration per time
cannot exceed 30s, and 1minute rest time must be maintained at two consecutive cycles.
1. Insert the potato bar into the motor unit, when inserted in place, a click will be heard.
2. Simply plug the hand-held blender to power outlet.
3. Lower the blade into food, choose the speed setting by rotating the speed dial, then press and
hold the On/Off button. The unit will run at the highest speed when pressing and holding turbo
button.
NOTE:
1- On/Off button is also provided with variable speed function, when you press and hold it,
speed will vary according to your pressing pressure.
2- Please don’t use our cup to mash potatoes, you should use a big enough bowl to mash
potatoes.
3- Never use the masher to process the uncooked potatoes.
4. Release the On/Off button to stop operating when food consistency is obtained.
Unplug the appliance and remove the detachable blending rod.
Note: Do not immerse the detachable blending rod of the blender in water because overtime the
lubrication on the bearings may wash away.
2. Wash the detachable blending rod under running water, without the use of abrasive cleaner
or detergents. After nishing cleaning the detachable blending rod, place it upright so that any
water which may have got in, can drain out. The blending rod is dishwashing safe component.
3. Wash the cup, bowl, beater and blade in warm soapy water. The bowl and the beater are not
recommending to place in dishwashing machine as the plastic components deteriorate through
prolonged use of dishwasher cleaning.
4. Wipe the motor unit with a damp cloth. Never immerse it in water for cleaning as an electric
shock may occur.
5. Dry thoroughly.
Caution: Blades are very sharp, handle with care.
ENVIRONMENT FRIENDLY DISPOSAL
You can help protect the environment!
Please remember to respect the local regulations:
hand in the non-working electrical equipments to an
appropriate waste disposal center.
Between processing tasks, hold the hand-held blender in the cup half lled with water and turn
on for a few seconds
4
Instruction for egg white beater
Instruction for chopper
NOTE: On/Off button is also provided with variable speed function, when you press and hold it,
speed will vary according to your pressing pressure.
5. Release the On/Off button to stop operating when food consistency is obtained.
Max operation duration per time cannot exceed 20s, and 1minute rest time must be maintained
at two consecutive cycles.
1. Place the chopper bowl on a clean level surface.
2. Assemble the stainless chopping blade into the chopper bowl.
3. Place food into the chopper bowl.
Note: Remove the bone of the meat, cut small pieces, then place the meat into bowl, the max
quantity of meat can’t exceed 200g in every blending.
4. Attach the lid onto the chopper bowl.
5. Insert the top part of the chopper into the hole of the chopper lid.
6. Plug the appliance into power outlet.
7. Choose the speed setting by rotating the speed dial, then press and hold the On/Off button.
The unit will run at the highest speed when pressing and holding turbo button.
NOTE: On/Off button is also provided with variable speed function, when you press and hold it,
speed will vary according to your pressing pressure.
8. Release the On/Off button to stop operating when food consistency is obtained.
Caution:
-To reduce the risk of injury, never place cutting blade on base without rst putting bowl
properly in place.
-Be sure chopper lid is securely locked in place before operating appliance.
-There is chopper lid 2, after nish food processing, you can assemble it on the bowl for food
storage.
Max operation duration per time cannot exceed 1minute, and 1minute rest time must be
maintained at two consecutive cycles.
1. Insert the whisk into the motor unit, when inserted in place, a click will be heard.
2. Simply plug the hand-held blender to power outlet.
3. Place egg white into the cup, generally, put two eggs white is enough.
4. Lower the blade into food, choose the speed setting by rotating the speed dial, then press and
hold the On/Off button. The unit will run at the highest speed when pressing and holding turbo
button.
NOTE: On/Off button is also provided with variable speed function, when you press and hold it,
speed will vary according to your pressing pressure.
5. Release the On/Off button to stop operating when food consistency is obtained.
3
Know your blender (It is suitable for blending vegetable and fruit)
USE YOUR BLENDER
Instruction for blender
Before the rst use, clean the blender according to the section of “quick cleaning”.
The time of running unit without load can’t exceed 15s.
Important: Blades are very sharp, handle with care. Ensure that the hand-held blender is
unplugged from the power outlet before assembling or removing attachments.
The max operation time per time shall not exceed 30 seconds and only wait until the unit is
cooled to room temperature before performing next operation cycles.
1. Insert the detachable rod into the motor unit, when inserted in place, a click will be heard.
2. Put proper fruits or vegetables to be blended into cup. The amount of food shall not exceed
Max level as indicated on cup.
NOTE: Usually certain amount of puried water has to be added to facilitate the smooth running
of appliance when blending fruit. If blend carrot, please cut the carrot into small pieces (15mmX
15mmX15mm).
3. Plug the appliance into power outlet.
4. Lower the blade into food, choose the speed setting by rotating the speed dial, then press and
hold the On/Off button. The unit will run at the highest speed when pressing and holding turbo
button.
RECIPE
Speed Control Button
Motor Unit
Blend rod
Turn it anti-clockwise
to lock with motorunit.
to unlock.
turn it in adverse
direction
Lock
FOOD TYPE SPEC WEIGHT SPEED
Carrot
( .apple, pear etc)
Cut into
15mm*15mm*15mmm
Carrot: 200g
Water: 300g High speed
2
IMPORTANT SAFEGUARDS
Before using the electrical appliance, the following basic precautions should always be
followed including the following:
1. Read all instructions.
2. Before using checks that the voltage of wall outlet corresponds to the one shown on the
rating plate.
3. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair or electrical or mechanical adjustment.
4. If the supply cord is damaged it must be replaced by the manufacturer or a authorized
service agent or a qualied technician in order to avoid a hazard.
5. Unplug from outlet when not in use, before putting on or taking off parts, and before
cleaning.
6. Do not let cord hang over edge of table or hot surface.
7. Do not immerse upper part of blender into water as this would give rise to electric shock.
8. Close supervision is necessary when your appliance is being used near children or inrm
persons.
9. Avoid contacting moving parts.
10. Keep hands and utensils out of container while blending to reduce the risk of severe injury
to persons or damage to the blender. A scraper may be used but must be used only when the
blender is not running.
11. The appliance cannot be used for chopping ice or blending hard and dry substance,
otherwise the blade could be blunted.
12. To reduce the risk of injury, never place cutting blade on base without rst putting bowl
properly in place.
13. Be sure chopper lid is securely locked in place before operating appliance.
14. The use of accessory not recommended by the manufacturer may cause injuries to
persons.
15. Do not operate the appliance for other than its intended use.
16. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are older than 8 and supervised.
17. Children should be supervised to ensure that they do not play with the appliance.
18. Do not use outdoors.
19.Save these instructions.
THB-600WTHB-600W
Hand Blender
Thanks for Choosing Tornado
Hand Blender
