Elba EGSI-M1563 User manual

GARMENT STEAM IRON
MODEL: EGSI-M1563(PK)
Owner’s Manual
Please read this manual carefully
before operating your set.
Retain it for future reference.
Record model number and serial
number of the set.
See the label attached on the set and
quote this information to your dealer
when you require service.
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate.

1
IMPORTANT SAFEGUARDS
When using the appliance, basic precautions should always be followed including the following:
1. Read all instructions before using.
2. To reduce the risk of electric shock, do not disassemble or attempt to repair the appliance
on your own. Return the appliance to the nearest authorized service centre for examination,
repair or adjustment.
1. Do not use the appliance if the plug, the mains cord or other parts aredamaged.
2. To avoid the hazard caused by the overload of the circuit, do not use the extension cord.
3. Do not immerse the appliance, power cord or plug in water or any other liquids.
4. Do not leave the appliance unattended whileoperating or it is still hot.
5. Do not contact directly the steam head to people, animals or cloth that one is wearing.
6. Please fill in water before power on the appliances. Observe the water level in the water tank
while operating.
7. Never use any accessories or parts from other manufacturers or that ELBA does not
specifically recommended.
8. The use of foreign accessory attachments that are not supplied by ELBA is not
recommended as it may result in fire, electric shock or personal injury.
9. Do not lay the hose on the ground or wind it.
10.Only use the steam head in an up and down vertical position. Never use the steam head in
a horizontal position or tilt into a backward position, this may result in water discharge.
11.Be cautious of hot steam that sprays out from the steam head. To reduce the risk of contact
with hot steam emitting from the steam head, hold the handle away from your body while
operating the appliance.
12.Move the appliance by grasping the telescopic pole. Do not force the casters if they are
struck. Drain the water from water tank and water reservoir before inspecting the casters.
13.Allow the appliance to cool completely for at least 30 minutes and drain the water from the
water tank and water reservoir before storing.
14.Allow the appliance to cool completely for at least 30 minutes and drain the water from the
water tank and water reservoir before storing.
15.Unplug the appliance before cleaning, moving or when the appliance is not in use.
16.Keep the appliance away from inflammable materials and chemicals.
17.Do not operate the appliance in the event of abnormity, or damage to the cord or the plug.
18.Grasp the plug to unplug it, do not unplug by pulling the power cord.
19.Do not fill the water tank with hot water, corrosive cleaning agent, perfume, vinegar, starch,
ironing aids or any other chemicals, or otherwise, the appliance will be damaged. De-
mineralized water or distilled water is strongly recommended.
20.Use this appliance for its intended use only.
21.This product has been designed for domestic use only. Any commercial use, inappropriate
use or failure to comply with the instructions, the manufacturer accepts no responsibility and
the warranty will not apply.
22.This appliance is intended for household useonly. This is a floor appliance and never carries
it while in use.
23.Children must be supervised to ensure that they do not play with the appliance.
24.This appliance is not intended for used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliances by a
person responsible for their safety.
25.Children should be supervised to ensure that they do not play with the appliance.
26.Save these instructions for future reference

2
PRODUCT DESCRIPTIONS
1.
Steam Nozzle
7.
Pole Connector
2.
Steam Nozzle Hanger
8.
Hose Connector
3.
Folding Hanger
9.
Water Tank
4.
Handle
10.
Switch
5.
Hose
11.
Rear Wheel
6.
Telescopic Pole
12.
Indicator Light
ASSEMBLE AND OPERATING THE APPLIANCE
Before installing, please check carefully the product to avoid missing any parts, for some of
them place at the sides of polystyrene foam.
1. Put the hanger within in the telescopic pole along the flute. (See Fig.1)
2. Insert the telescopic pole into the pole connector. (See Fig.2)
3. Screw the connector of pole clockwise until its tightened. (See Fig.3)
4. Loose the clips on the telescopic pole.
5. Stretch the pole to its full extension, and then tighten the clip of telescopic pole.
6. Install the hose into the hose connector according to the direction of arrow and turn in
clockwise until it is tightened. Please don’t make it too tight. (See Fig.3)
7. Hang the steam nozzle on the steam nozzle hanger. (See Fig.4)

3
Cautions:
1. Always hang the steam nozzle on the steam head hanger when not in use to prevent
scalding.
2. The telescopic pole must be fully extended during steam operation to ensure smooth
lining of the hose and provide a free flow of steam.
3. Don’t pull the hose with excessive force or else damage will occur and cause steam
leakage. Do not move the appliance by pulling the hose. Move the appliance by
grasping the telescopic pole.
FABRIC BRUSH ASSEMBLY
The garment steamer iron come with fabric brush. To attach this accessory to the steamhead.
1. Turn off the appliance and wait until no steam is emitted from the steam head.
2. Assemble the flute of fabric brush toward the peg that at the top of the steam nozzle.
3. Press the brush to the steam nozzle until it is tightened.
Caution: Do not install the accessory while steam is emitting from the steam nozzle to avoid
burns.
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5

4
OPERATING THE APPLIANCE
➢Before operation, please ensure the garment steamer is turned off.
➢Remove the water tank, twist off the water tank valve from the bottom. (See Fig.6)
➢Then fill up water tank with cold water and then tighten the water tank valve cap. Do not
use hot water.
➢To prolong the service life of your garment steam iron, we recommend to use distilled or
de-mineralized water. Place the water tank back into the unit and make sure it sits properly
and securely in the cavity. (See Fig.7)
Note: Do not let the appliance operate with a dry water tank, as it may cause damage to
the unit.
➢Connect the plug to the wall outlet and power on.
➢Turn the appliance to “ON” switch. When indicator is on, the garment steam iron start
working. After 45 seconds, the steam will be sprayed from the nozzle.
➢When you have finished with your steaming sessions, turn the switch in the “OFF” position
and power off the appliance. Remove the plug from the outlet.
INSTRUCTIONS FOR USING FOLDING HANGER
➢Firstly, insert the hanger (A) in the pole (B) (as Fig.a)
➢Insert the hook (D) of the folding hanger (C) into the hole of hanger (A) about tilting 40°(as
Fig.b)
➢Press and fasten the hook (D) vertically (as Fig.c)
➢Gently pull the hanging arm (E) of the folding hanger with hands toward both sides, until
two supporting poles (F) are on the same straight-line (as Fig.e)
➢Push hard the positioning sleeve (G) to the supporting pole (F), to make the small hole of
the positioning sleeve align at the bump of the supporting pole. (as Fig.f)
Fig.6
Fig.7

5
HOW TO OPERATING STEAM FUNCTION
➢The high temperature steam is for softening the cloth fiber only. The correct way of steaming cloth
is to make the cloth straight with the pulling force. Therefore, grasp the bottom of cloth with hands
and pull it downwards. (See Fig.8)
➢Then put the steam nozzle against the cloth firmly, gently press downwards, and then drag the
nozzle up and down. Softening the fiber by the high temperature steam, and then fixing the shape
with the pulling force. (See Fig.9)
➢When ironing the bottom of the cloth, please grasp both sides of the cloth for tightening, and then
steam from left to right, up and down. Please aware of the hot steam from nozzle. (See Fig.10)
➢When ironing the collar, please press downward a little bit harder. The nozzle should be pressed
on the folding of the collar for a little longer and steam pressed back and forth and up and down.
(See Fig.11)
➢When ironing the cloth sleeve, please straighten the sleeve a little hard. The steam nozzle should
be longer pressed on the sleeve folding of the sleeve for a little longer and steam pressed back
and forth. (See Fig.12)
Fig.8
Fig.9
Fig.10
Fig.11
Fig.12

6
HOW TO USE THE DRAINAGE VALVE
➢Unscrew the drainage valve which is at the back of the appliance anti-clock wise. (See
Fig.13)
➢Empty the water reservoir after finished steaming. When the appliance is not in use or before
storage. This is to avoid water deterioration and bacteria breeding. Fasten the drainage
valve after all the water is drained off before storage.
Note: Do not touch the water reservoir’s inlet hole right after steaming. Allow the appliance to cool
completely for at least 30minutes before draining to avoid scalding to hands.
CLEANING AND MAINTENANCE
We recommend you follow this procedure at least once per week.
1. Switch off your garment steam iron.
2. Unplug the unit from the wall outlet.
3. Allow the steam nozzle to cool down for at least 30 minutes.
4. Disconnect the hose from the hose base and shorten the telescopic pole, then set them
aside.
5. Remove and drain the water from water tank. Rinse the water tank with fresh water, and
drain completely. Place the water tank back on the water reservoir.
6. Wrap the hose around the telescopic pole one time. Place the steam head on the steam
head holder.
Fig.13
Fig.13

7
REMOVING MINERAL BUILD-UP
It is common for minerals found in hard water to build up inside the appliance, causing
intermittent or weak steam. If you do not use de-mineralized or distilled water in your
steamer, follow these steps monthly:
1. Turn the unit off, and unplug the power cord.
2. Remove the hose and telescopic pole from the unit.
3. Drain the water reservoir by unfasten the drainage valve. Empty water from the water tank.
4. Mix a solution of 50% vinegar and 50% water. In general, appropriate up to 900ml mixing liquid
is sufficient.
5. Slowly pour the water-vinegar solution into the hose connector.
6. The water-vinegar solution will become visible in the water reservoir’s inlet hole, continue
to pour the solution into the hose connector until it is full, monitor from the hose inlet.
7. Allow the water-vinegar solution in the hose connector for 40 minutes.
8. After that, drain the solution out of the water reservoir by removing the drainage valve to
allow the liquids to drain into a sink.
9. Drain the remaining solution out from the hose connector by tilting the unit over a sink.
10. Pour clean water into the hose connector and water reservoir inlet and drain again. Repeat
this step until the vinegar odor dissipates
11. Reassemble the unit and operate normally.
TROUBLESHOOTING
Problem
Reason
Solution
The garment steam iron fails to
spray the steam, and the
indicator light does not illuminate.
The appliance is not plugged in
Insert the plug into power outlet
The house power fuse is tripping
off or blew out
Check the power or ask for
qualified electrician help
The garment steamer fails to
spray the steam and the indicator
light is illuminates
There is sediment accumulation
in the water tank.
Refer to the instruction manual
for the cleaning method of
sediment.
There is no water in the water
tank.
Refill the water into water tank.
The steam hose makes a noise.
The steam is condensed inside
the steam hose, to become the
small drop, so that it stops the
steam to spray normally.
It is normal that there is a little
sound when spraying the steam.
If is too noisy, please make the
steam hose become vertical, so
that the water will flow back to the
water tank.
The steam is successively
spraying
Mineral build-up in the unit.
It’s normal for the unit to
periodically stop steaming for
a few seconds. If the steam
stays off for longer periods,
follow the removing mineral build-
up procedure.

8
