ELBOX nSplitter Pro 1x2 MK-II DE/QS User manual

nSplitter Pro 1x2 MK-II DE/QS
USER MANUAL
ver. 3.3en
nSplitter Pro 1x2 MK-II QS is an advanced HDMI splitter which allows sending digital video and audio signals from one source
(BD/DVD player satellite receiver computer game console or HDMI switch with signals from many sources) to two or more (when
cascaded) receivers (plasma LCD projector amplifier).
nSplitter Pro supports the HDCP protocol and has its own HDCP keys.
nSplitter Pro supports 3D signal in the following formats: Frame Packing Side-by-Side and Top-and-Bottom up to 1080p@24. nSplitter Pro
supports mixed combination of 2D and 3D sets.
nSplitter Pro 1x2 MK-II QS is the first splitter with the QuickSwitc ™ function. It is used for dynamic changing of video and audio formats so as to
optimally adapt them at any time to the capabilities of the receivers connected to nSplitter. The distinguishing feature of the QuickSwitc ™ function
is that the receiver which is in the stand-by mode is omitted in determining the formats accepted by the receivers connected to nSplitter.
The QuickSwitc ™ function is especially useful for display devices with significant variation in parameters. For example if the signal has to be
displayed simultaneously on two receivers but only one of them supports the 1080p@24 format nSplitter Pro MK-II 1x2 forces the source of the
signal to convert it from 1080p@24 to 1080i@60. As soon as the receiver which does not support 1080p@24 is switched off nSplitter Pro MK-II
1x2 QS informs the source of the signal that the transmission format can be changed to the one optimal for the active receiver - 1080p@24 in this
case.
If you have TV and projector which are not used simultaneously then the QuickSwitc ™ mode is the best option for you.
Since MK-II version nSplitter Pro supports the DreamEDID™ function which gives the possibility to replace the receivers EDID tables with the
predefined tables containing the list of the highest video and audio formats supported by nSplitter. This new feature missing in other HDMI splitters
allows expansion of the compatibility between devices compliant with different versions of the HDMI specification. It solves the problem with AV
devices which incorrectly report the range of the supported video or audio formats.
The DreamEDID™ function eliminates the lack of a 3D image when the 3D player compatible with HDMI 1.4a is connected to a 3D ready TV set
through an HDMI 1.3 compliant amplifier. The source signal should then be splitted with nSplitter Pro and sent separately to the TV set and to the
amplifier. The DreamEDID™ function provides the appropriate signalling of formats accepted by both devices.
Note. Some amplifiers cannot decode audio from the HDMI signal with the 3D flag. If this is the case contact the manufacturer's service for the
firmware update. If this update is not available the additional audio connection via optical or coaxial cable is necessary to play audio signal from
some 3D formats.
Apart from the HDMI splitter function nSplitter Pro is perfectly suited as an intermediate device to solve any incompatibility in the HDCP
authentication between the connected devices.
1. Package contents
• nSplitter Pro 1x2 MK-II QS
• power supply
• user manual.
2. Features
nSplitter Pro 1x2 MK-II QS can be set to work in t e QuickSwitc ™ or DreamEDID™ mode.
In the QuickSwitc ™ mode nSplitter builds a virtual EDID table which contains only those video and audio formats which are commonly supported
by the connected devices which are switched on. The EDID table of the device which is in the stand-by mode is omitted in determining the accepted
formats. In this mode the virtual table is rebuilt always as soon as any of the connected devices is switched on or off. When the virtual EDID table is
changed the displays may turn black for a moment.
In the DreamEDID™ mode nSplitter replaces the EDID tables of both devices connected to its HDMI output ports by the virtual EDID table with the
following formats:
Video formats:
• 1920 x 1080p at 59.94Hz/60Hz - HDTV (16:9 1:1) Top-and-bottom Side-by-side
• 1920 x 1080p at 50Hz - HDTV (16:9 1:1) Top-and-bottom Side-by-side
• 1920 x 1080p at 29.97Hz/30Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1920 x 1080p at 25Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1920 x 1080p at 23.976Hz/24Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1920 x 1080i at 59.94Hz/60Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1920 x 1080i at 50Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1280 x 720p at 59.94Hz/60Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 1280 x 720p at 50Hz - HDTV (16:9 1:1) Frame Packing Top-and-bottom Side-by-side
• 720 x 576p at 50Hz - EDTV (16:9 64:45) Frame Packing Top-and-bottom Side-by-side
• 720 x 480p at 59.94Hz/60Hz - EDTV (16:9 32:27) Frame Packing Top-and-bottom Side-by-side

• 1920 x 1080p at 59.94Hz/60Hz - HDTV (16:9 1:1)
• 1920 x 1080p at 50Hz - HDTV (16:9 1:1)
• 1920 x 1080p at 29.97Hz/30Hz - HDTV (16:9 1:1)
• 1920 x 1080p at 25Hz - HDTV (16:9 1:1)
• 1920 x 1080p at 23.976Hz/24Hz - HDTV (16:9 1:1)
• 1920 x 1080i at 59.94Hz/60Hz - HDTV (16:9 1:1)
• 1920 x 1080i at 50Hz - HDTV (16:9 1:1)
• 1280 x 720p at 59.94Hz/60Hz - HDTV (16:9 1:1)
• 1280 x 720p at 50Hz - HDTV (16:9 1:1)
• 720 x 576p at 50Hz - EDTV (16:9 64:45)
• 720 x 480p at 59.94Hz/60Hz - EDTV (16:9 32:27)
Audio formats:
• LPCM 2-channel 16/20/24 bit depths at 32/44/48/88/96/176/192 kHz
• LPCM 8-channel 16/20/24 bit depths at 32/44/48/88/96/176/192 kHz
• AC-3 8-channel 640k max. bit rate at 32/44/48 kHz
• DTS 8-channel 1536k max. bit rate at 44/48 kHz
• SACD 6-channel at 44 kHz
• DD+ 8-channel at 44/48 kHz
• DTS-HD 8-channel 16-bit at 44/48/88/96/176/192 kHz
• D-TrueHD 8-channel at 44/48/88/96/192 kHz
3. Installation
Connect the HDMI source (BD/DVD player satellite receiver computer game console or HDMI switch with signals from many
sources) to the nSplitter HDMI input port.
The nSplitter HDMI outputs are dedicated for connecting HDMI displays (plasma LCD projector monitor) or audio (amplifier)
devices.
For the nSplitter QuickSwitc ™ mode connect the power supply to nSplitter and turn it on before connecting any devices to the nSplitter HDMI
output ports. Wait at least five seconds before connecting your display and/or audio devices to the nSplitter HDMI output ports. nSplitter has to be
powered during all this time. The QuickSwitc ™ function will be active as long as nSplitter is powered.
For the DreamEDID™ mode connect any display/audio device to the nSplitter HDMI port before powering nSplitter.
You can always switch nSplitter from QuickSwitc ™ to DreamEDID™ by disconnecting it from the power supply for a short time when your
display/audio devices are connected.
4. Correct Disposal of T is Product (Waste Electrical & Electronic Equipment)
This marking on the product indicates that the product and its electronic accessories should not be disposed of with
other household waste at the end of their working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal please separate these items from other types of waste and recycle them responsibly
to promote the sustainable reuse of material resources. Household users should contact either the retailer where they
purchased this product or their local government office for details of where and how they can take these items for environmentally
safe recycling. This product and its electronic accessories should not be mixed with other commercial wastes for disposal.
5. Specification
• one HDMI input
• two HDMI outputs
• HDCP support
• Supported video formats:
[email protected]/60Hz [email protected]/60Hz 576i@50Hz 576p@50Hz [email protected]/24/50/59.94/60Hz
1080i@50/59.94/60Hz [email protected]/24/50/59.94/60Hz and computer formats up to 1920x1200
3D HD formats: Frame Packing up to 1080p@24Hz; Side-by-Side Top-and-Bottom up to 1080p@60Hz
• Supported audio formats:
Dolby TrueHD DTS-HD Master Audio Dolby Digital Plus DST (Super Audio CD)
Dolby Digital DVD-Audio i PCM (up to 8 channels 24-bit@192kHz)
• TDMS clocking: 25MHz - 225MHz
• 36-bit Deep Color up to 1080p@60Hz format
• 48-bit Deep Color up to 1080p@24Hz format
• Filtering and regeneration of the HDMI signal
• 4 signalling LED
• Max current: 0.8A @5V
• Power supply parameters: 1A @5V
• Dimensions: 65 mm x 65 mm x 23 mm weight net: 185 g
For more detail info contact [email protected] at www.iHDMI.eu
ELBOX COMPUTER Sp. J. address: ul. Lipowa 4c 30-702 Kraków WEEE no: E0002687WZ www.elbox.com
