Eldes EWM1 User manual

WIRELESS POWER SOCKET
USER GUIDE
V1.2
EWM1
Contents of Pack
1 x 1 x
EN PTES FR

2
EN
METAL
0,5 - 30m
(1.64 - 98.43t)
INSTALLATION
EN
INSTALACIÓN
ES
INSTALLATION
FR
INSTALAÇÃO
PT

EN
3
1
3
2

4
EN
1. GENERAL OPERATIONAL
DESCRIPTION
MAIN FEATURES:
• Control your household equipment remotely by
wireless keyfob, keypad, ELDES Cloud Services or
automaically by scheduled ime or system event
• Compaible with any 230V electrical appliance
• View real-ime, daily and monthly power con-
sumpion report
• Fault indicaion and protecion: circuit thermal,
overvoltage, overcurrent, undervoltage, relay
fault indicaion
Control
(turn
ON/OFF)
Power
consumpion
monitoring
Fault
indicaion
ESIM364  (by EKB2) (by EKB2)
EPIR3 
ELDES
Cloud
Services
  

EN
5
EWM1 is a wireless device intended to expand
ELDES alarm system capabiliies by providing a
wireless connecion access to any 230V electrical
appliance, such as lights, air-condiioner, water-
ing equipment etc. By plugging the appliance into
the electrical outlet of EWM1, the user gains the
possibility to control it by wireless keyfob, keypad,
scheduled ime or a speciic system event. In addi-
ion, EWM1 lets you monitor the power consump-
ion and view the reports. In another safety and
protecion feature EWM1 will prevent the electrical
appliance from powering up if certain fault condi-
ions are present (see 4. FAULT INDICATIONS). In
order to start using EWM1, it has to be paired with
ELDES alarm system using ELDES Configuration
Tool sotware or by sending a corresponding SMS
text message to ELDES alarm system.
It is possible to connect up to 16 EWM1 devices to
EPIR3 system, while to ESIM364 alarm system -
up to 32 EWM1 devices at a ime. The maximum
wireless connecion range is 150m (492.13t) (in
open areas).

6
EN
LED indicaion
Type E, F
or G outlet
Buton for restoring
default parameters or
turning ON/OFF EWM1
when paired with
ELDES alarm system
LED indicaion Descripion
Flashing (green)
EWM1 is unpaired or
wireless connecion with
ELDES alarm system
is lost
Steady ON (red) Fault is present
OFF Relay is turned OFF
Steady ON (green) Relay is turned ON
Flashing (red) EWM1 is reseing to
default
TYPE F TYPE G TYPE E
TYPE F TYPE G TYPE E
EWM1-E (type E) EWM1-F (type F)
TYPE F TYPE G TYPE E
EWM1-G (type G)

EN
7
2. CONFIGURING AND PAIRING
WITH THE SYSTEM
For more details on how to
conigure and pair the device
with the system, please refer
to ELDES Configuration Tool
sotware’s HELP secion or
ELDES alarm system’s instal-
laion/user manual.
3. EWM1 PGM
OUTPUT AND TAMPER
Upon successful EWM1 pairing process, the system
adds 1 wireless PGM output intended for electrical ap-
pliance connecion, control and power consumpion
monitoring and 1 Instant-type wireless zone (by default
- disabled) for tamper control.
Once the wireless zone is enabled, the wireless con-
necion loss between EWM1 and ELDES alarm sys-
tem would lead to tamper alarm followed by SMS text
message to the listed user (-s) (by default - disabled)
as well as fault indicaion by the keypad. The SMS text
ELDES
Coniguraion Tool
If you are unable to pair the wireless de-
vice, please restore the parameters of the
wireless device to default and try again
(see 5. RESTORING DEFAULT PARAM-
ETERS for more details)

8
EN
message contains the wireless device model, wireless
ID code and tamper name. However, the delivery of the
data message to the monitoring staion regarding this
event is permanently disabled for EWM1 device.
4. FAULT INDICATIONS
For safety and protecion purposes, EWM1 will
instantly power down/prevent from powering up
the electrical appliance plugged into EWM1 outlet
when the following faults are present:
• OVERVOLTAGE
– voltage has increased
above 260VAC.
• UNDERVOLTAGE – voltage has dropped be-
low 190VAC.
• OVERCURRENT – current has increased
above 12,5A.
• RELAY FAULT – unable to power up the appli-
ance due to faulty relay.
• TEMP. FAULT – the environmental temper-
ature has dropped below -35°C (-31°F) or in-
creased above +90°C (+194°F).
In addiion, the user can view the exising faults
by EKB2 keypad (only for ESIM364) or by access-
ing the ELDES Cloud Services account. In order to
clear the exising faults, please press the but-
ton on EWM1, turn OFF the electrical appliance or

EN
9
turn OFF the wireless PGM output associated with
EWM1.
5. RESTORING
DEFAULT PARAMETERS
1. Unplug EWM1 from the household electricity
socket.
2. Press and hold the buton.
3. Plug in EWM1 back to the electricity socket
4. Hold the buton unil red LED indicator
shortly lashes several imes.
5. Release the buton.

10
EN
6. TECHNICAL SPECIFICATIONS
Compaible with:
• ESIM364 v02.11.00 and up.
• EPIR3 v1.07.00 and up.
• ELDES Cloud Services - htps://security.eldes.lt
Power supply 230VAC, 50Hz,
protecion class I
Rated load current 12,5A (for resisive
load – 2,8kW)
Power consumpion Up to 1W
Electrical outlet
Type E (EWM1-E)/
Type F (EWFM1-F)/
Type G (EWM1-G)
Wireless band ISM868
Wireless commu-
nicaion range
Up to 30m (98.43t) in
premises; up to 150m
(492.13t) in open areas
Range of operaing
temperatures -20...+45°C (-4... +113°F)
Circuit thermal
protecion
Below -35°C (-31°F);
above +90°C (+194°F)
Humidity
0-70% RH @ 0...
+40°C (0-70% RH
@ +32... +104°F)
Dimensions 95x53x71mm
(3.74x2.09x2.80in)
Compaible with
alarm systems ELDES Wireless

EN
11
Technical Support
If you experience diiculty during the installaion or subse-
quent use of the system, you may contact “ELDES UAB” dis-
tributor in or dealer in your country/region.
Warranty Procedures
To obtain warranty service, you may return a defecive system
to your original point of purchase, or the authorized “ELDES
UAB” dealer or distributor from whom you purchased the EL-
DES product.
Limited Liability
The buyer must agree that the system will reduce the risk of
ire, thet, burglary or other dangers but does not guarantee
against such events. “ELDES UAB” will not take any respon-
sibility regarding personal or property or revenue loss while
using the system. “ELDES UAB” liability according to local laws
does not exceed value of the purchased system. “ELDES UAB”
is not ailiated with any of the Internet providers therefore is
not responsible for the quality of Internet service.
Manufacturer Warranty
“ELDES UAB” warrants this system only to the original purchaser
and only in case of defecive workmanship and materials under
normal use of the system for a period of twenty four (24) months
from the date of shipment by the “ELDES UAB”. Warranty
obligaions do not cover expandable materials (power elements
and/or bateries), holders and enclosures . The warranty remains
valid only if the system is used as intended, following all guidelines
outlined in this manual and in accordance with the operaing
condiions speciied. The warranty is void if the system has been
exposed to mechanical impact, chemicals, high humidity, luids,
corrosive and hazardous environments or force majeure factors.
Safety Instrucions
Please read and follow these safety guidelines to safeguard
yourself and others:
• DO NOT use the device where it can interfere with other
devices - such as medical devices
• DO NOT use the device in hazardous environments

12
EN
The EWM1 is designed in accordance with
protecion class I. The power source that
may be used is the household electrical out-
let (230VAC, 50Hz) with the protecive earth
conductor of the public power supply system.
The device is not meant for outdoor use, i.e.
you should use it inside a building. Protect the
device against cold, heat and keep away from
direct sunlight while in storage or operaion.
The device must be kept out of the reach of
children. Take paricular care when children
are around!
Never install or carry out maintenance during
stormy weather. The electric socket that pow-
ers the device must be easily accessible.
To switch the system of, unplug the device
from the household electrical outlet. A blown
fuse cannot be replaced by the user. The re-
placement fuse has to be of the kind indicated
by the manufacturer (fuse F1 model – SIBA
160000.0,25 0.25A 250V).
• DO NOT expose the device to high humidity, chemical en-
vironments or mechanical impact
• DO NOT atempt to repair the device yourself - any repairs
must be carried out by fully qualiied personnel only
• NEVER atempt to dismantle the device.
• DO NOT connect the device to the supply voltage if any
damage is suspected. Life-threatening danger!
• DO NOT touch the device with damp or wet hands!
• Never use the device with AC power plug adapters!

EN
13
Copyright © “ELDES UAB”, 2015.
All rights reserved
It is not allowed to copy and distribute infor-
maion in this document or pass to a third
party without advanced writen authorizaion
by “ELDES UAB”. “ELDES UAB” reserves the
right to update or modify this document and/
or related products without a warning. Hereby,
“ELDES UAB” declares that the wireless power
socket EWM1 is in compliance with the essenial
requirements and other relevant provisions of
Direcive 1999/5/EC. The declaraion of con-
formity may be consulted at www.eldes.lt
The WEEE (Waste Electrical and Electronic
Equipment) marking on this product (see right)
or its documentaion indicates that the product
must not be disposed of together with house-
hold waste. To prevent possible harm to human
health and/or the environment, the product
must be disposed of in an approved and envi-
ronmentally safe recycling process. For further
informaion on how to dispose of this product
correctly, contact the system supplier, or the
local authority responsible for waste disposal
in your area.
