MODERNE COOKER
MODEL EL 370
INSTALLATION AND USERS'
INSTRUCTIONS

Welcome to your new Electra cooker. Its stylish and practical design will enhance your kitchen and make "cooking
electric" a pleasure.
Features include a radiant hob for responsive, economical cooking with two large and two small radiant rings, full
width grill and fan assisted oven and three removable shelves.
Even if you have used an electric cooker before, it is important that you read these instructions thoroughly before
starting to cook, paying particular attention to the installation and safety instructions.
Getting Help If you have any problems with installing or operating your new cooker please contact your
Electricity Company for advice.
For your own safety, make sure that these instructions on installation, use and
maintenance are followed.
IMPORTANT We advise you to keep these instructions in a safe place for future reference.
If you sell or transfer ownership of this product, please pass on these instructions to the
new owner.
1
PREFACE

10
MODEL NO. EL 370
Voltage: 230/240 Volts AC 50Hz
Wattage: 9.9/10.8kW
Height: 900mm
Width: 500mm
Depth: 600mm
This appliance complies with: European Council Directive 73/23/EEC.
EMC Directive 89/336/EEC.
CE Marking Directive 93/68/EEC.
2
TECHNICAL DETAILS

Preface ........................................................................................... 1
Technical Details ................................................................................. 2
Contents ......................................................................................... 3
Safety ............................................................................................. 5
Before Installation ........................................................................... 5
During Operation ........................................................................... 5
After Use ................................................................................... 6
General .................................................................................... 6
Introduction ...................................................................................... 7
Rating Plate ................................................................................ 7
Installation .................................................................................. 7
Reversible Main Oven Door ................................................................. 8
General Notes on Using Your Cooker ........................................................ 8
About Condensation and Steam ............................................................. 8
Oven/Grill Indicator Neons .................................................................. 8
Grill and Oven Furniture ..................................................................... 8
Getting to Know Your Cooker .................................................................... 9
The Control Panel .......................................................................... 9
The Electronic Minute Minder ............................................................... 10
The Ceramic Hob ................................................................................ 12
Recommended Saucepans ................................................................. 12
Hints and Tips ............................................................................. 12
Deep Fat Frying ........................................................................... 13
Preserving ................................................................................. 13
The Grill ......................................................................................... 14
Selecting the Grill .......................................................................... 14
Things to Note ............................................................................. 14
The Grill Pan and Handle ................................................................... 14
Hints and Tips ............................................................................. 15
Grilling Chart .............................................................................. 15
The Top Oven ................................................................................... 16
Uses of the Top Oven ...................................................................... 16
Selecting the Top Oven .................................................................... 16
Things to Note ............................................................................. 16
To Fit the Top Oven Shelf .................................................................. 16
Hints and Tips ............................................................................. 16
The Main Fan Oven .............................................................................. 18
Selecting the Main Fan Oven ............................................................... 18
Things to Note ............................................................................. 18
To Fit the Main Oven Shelves .............................................................. 19
Hints and Tips ............................................................................. 19
Oven Cooking Chart ............................................................................. 20
Roasting Chart .................................................................................. 21
3
CONTENTS

Defrost Feature .................................................................................. 22
Uses of Defrost Feature .................................................................... 22
Selecting Defrost .......................................................................... 22
Things to Note ............................................................................. 22
Hints and Tips ............................................................................. 22
Care and Cleaning ............................................................................... 23
Cleaning Materials ......................................................................... 23
Cleaning the Ceramic Hob ................................................................. 23
Things To Note ............................................................................ 23
Cleaning the Outside of the Cooker ......................................................... 24
Cleaning the Grill Pan, Grill Pan Grid and Oven Shelves ..................................... 24
Cleaning Inside the Grill/Oven Compartments ............................................... 24
Care of Stayclean Surfaces ................................................................ 25
Hints and Tips ............................................................................. 25
Something not Working? ........................................................................ 26
Guarantee ....................................................................................... 27
Service call record .............................................................................. 28
4
CONTENTS

THESE WARNINGS ARE PROVIDED IN
THE INTERESTS OF YOUR SAFETY.
ENSURE THAT YOU UNDERSTAND
THEM ALL BEFORE INSTALLING OR
USING THE COOKER.
PLEASE
READ
CAREFULLY
BEFORE INSTALLATION
This appliance is heavy and care
must be taken when moving it.
Ensure that all packaging, both
inside and outside the appliance,
has been removed before the
appliance is used.
Do not try to move the appliance by
pulling the door handles.
The electrical installation work must
be undertaken by a qualified
electrician/competent person.
It is dangerous to alter or modify
the specifications of the product in
any way.
After installation, please dispose of
the packaging with due regard to
safety and the environment.
DURING OPERATION
Do not use this appliance if it is in
contact with water. Never operate it
with wet hands.
This appliance is designed to be
operated by adults. Young children
MUST NOT be allowed to tamper
with the product or play with the
controls.
Accessible parts especially around
the grill area may become hot when
the appliance is in use. Children
should be kept away until it has
cooled.
Take great care when heating fats
and oils as they will ignite if they
become too hot.
This product has been designed for
cooking edible foodstuffs only, and
must not be used for any other
purposes.
Never place plastic or any other
material which may melt in the oven
or on the hob.
Ensure cooking utensils are large
enough to contain foods to prevent
spillages and boil overs.
The handles of saucepans which are
smaller than the heated area on the
hob will become hot. Ensure your
hand is protected before handling the
pan.
Take care to follow the
recommendations given for tending
the food when grilling.
Do not leave the handle in position
when grilling as it will become hot.
5
SAFETY

Always use oven gloves to remove
and replace food in the oven.
Similarly always use oven gloves to
remove and replace the grill pan
handle when grilling.
given on page 14.
Ensure that you support the grill pan
when it is in the withdrawn or partially
withdrawn position.
Ensure that all vents are left
unobstructed to ensure ventilation of
the oven cavity.
Ensure that the anti-tilt shelves are
put in place correctly. Refer to
instructions on pages 16 and 19.
Never line any part of the appliance
with aluminium foil.
Always stand back from the
appliance when opening the oven
door to allow any build up of steam
or heat to release.
Do not place sealed cans or
aerosols inside the oven. They may
explode if they are heated.
Do not leave the hotplates switched
on for long periods when not covered
by a saucepan. The controls and
cabinets may overheat.
AFTER USE
Ensure that all control knobs are in
the OFF position when not in use.
For hygiene and safety reasons this
appliance should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire,
especially in the grill pan.
Do not leave utensils containing
foodstuffs, e.g. fat or oil in or on the
appliance in case it is inadvertently
switched ON.
Cookers and hobs become very hot,
and retain their heat for a long period
of time after use. Children should be
kept well away from the appliance
until it has cooled.
GENERAL Under no circumstances should
repairs be carried out by
inexperienced persons as this may
cause injury or serious malfunction.
This product should be serviced by
an authorised Service Engineer and
only genuine approved spare parts
should be used. Details of servicing
and repair arrangements are given on
page 28 of this book.
Do not stand on the appliance or on
the open oven door.
Do not hang towels, dishcloths or
clothes from the appliance or its
handles. They are a safety hazard.
Only clean this appliance in
accordance with the instructions
given in this book.
6
Recommendations
Your safety is of paramount importance.
Therefore, if you are unsure about any of the
meanings of these WARNINGS contact your
local Electricity Company.

RATING PLATE
Record the model, product and serial numbers on the
back cover of this instruction book, from the rating
plate. This is situated on the lower front frame of the
appliance and can be seen upon opening the oven
door.
The appliance must be protected by a suitably rated
fuse or circuit breaker. The rating of the appliance is
given on the rating plate.
INSTALLATION
If your cooker has been damaged in transit, contact
your supplier immediately. DO NOT attempt to install
it.
Your cooker left the factory fully packaged to protect
it from damage. If it is delivered without packaging
and damage has occurred, the manufacturer cannot
accept responsibility. Contact your supplier for
advice.
Once the packaging has been removed the cooker
should only be moved by hand. DO NOT use a sack
barrow or any other aid to lift the cooker as damage
may occur.
Connection to the electricity supply must be carried
out by a qualified electrician/competent person.
The electrical connection should be made using a
double pole isolating switch (cooker socket) with at
least 3mm contact separation. The cable must have
conductors of sufficiently high cross-sectional area to
prevent overheating and deterioration.
The cable should be routed away from potentially hot
areas marked by X in the diagram below.
To move the cooker, open the main oven door and
lift the cooker by holding inside the top of the
compartment.
This is a type X appliance which means it is
free-standing and can be fitted with cabinets on one
or both sides. It may also be fitted in a corner setting.
Side walls which are above hob level should be
protected by heat resistant non-combustible material
and MUST NOT be nearer than 40mm to the hob
side.
A nominal air gap of 2mm at either side of the cooker
is required to enable the cooker to be moved into
position. It is recommended that proprietary trims are
fitted to protect the worktops of either side of the
appliance. These are available from most DIY stores.
Two spacers have been incorporated into the back of
the appliance to ensure an air gap of 10mm is
maintained at hotplate level. Tiles or other forms of
deep wall covering should not obscure this gap.
7
Six square millimetres (6.00mm²) is the recommended
cross-section area.
INTRODUCTION
WARNING: THIS APPLIANCE MUST BE EARTHED

Overhanging surfaces or a cooker hood should be a
minimum of 685mm above the hob.
It is important to ensure that the appliance is level
after installation. Levelling feet are fitted to the front
of the appliance to accommodate uneven floors.
REVERSIBLE MAIN OVEN DOOR
If you require the oven door to be hinged on the
opposite side, you will need to contact your local
Electricity Company's Service Department. PLEASE
NOTE that a charge may be made.
GENERAL NOTES ON USING YOUR
COOKER
We suggest that you run all the elements for a short
period to burn off any residue from their surfaces.
To do this, run the ovens at 220°C for approximately
45 minutes. The procedure should be repeated with
the grill for approximately 5 - 10 minutes.
During this period an unpleasant odour may be
emitted, it is therefore advisable to open a window
for ventilation.
ABOUT CONDENSATION AND STEAM
When food is heated it produces steam similar to a
boiling kettle. The ovens are vented to allow some of
this steam to escape between the wall and the rear
of the appliance. However, always stand back from
the appliance when opening the oven door to allow
any build up of steam or heat to release.
If the steam comes into contact with a cool surface
on the outside of the appliance, e.g. a trim, it will
condense and produce water droplets. This is quite
normal and is not caused by a fault on the appliance.
To prevent discolouration, regularly wipe away
condensation and also soilage from surfaces.
For your safety, wall coverings at the rear of the
appliance should be securely fixed to the wall.
OVEN / GRILL INDICATOR NEONS
These lights indicate whether the ovens or grill are
switched on. In the case of the ovens, they also
indicate when the set temperature has been reached.
They will cycle on and off during use to show that the
temperature is being maintained. The grill neon may
cycle when the grill is switched on.
THE COOLING FAN FOR THE CONTROL
The cooling fan will always come on when the grill
and the top oven are switched on. If they are only
used for a short period of time the fan will switch off
when the controls are turned off. If the grill or the top
oven are used for a longer period of time the fan will
run on depending on the temperature, and may cycle
on and off until the cooker has cooled.
In the case of the main oven the cooling fan may not
switch on except when used for a longer period of
time. The cooling fan may run on, and cycle on and
off after the control knobs have been switched off,
until the cooker has cooled. Do not switch the cooker
off at its power point until the fan has cooled the
cooker down.
GRILL AND OVEN FURNITURE
The following items of oven furniture have been
supplied with the cooker:
1 grill pan
1 grill pan handle
1 grill pan grid
1 grill deflector
1 cranked shelf for
grilling and top oven
cooking only
2 straight shelves
for main oven cooking
8
S

THE CONTROL PANEL
FEATURES
A - Main Oven Temperature Control
B - Main Oven Indicator Neon
C - Top Oven/Grill Control
D - Top Oven/Grill Indicator Neon
E - Hotplate Controls
9
E
B D
A C
GETTING TO KNOW YOUR COOKER

1 = (-) DECREASE CONTROL & MINUTE
MINDER SETTING BUTTON
2 = (+) INCREASE CONTROL
( ) COOKPOT SYMBOL
( ) CLOCK SETTING
SYMBOL
( ) MINUTE MINDER SYMBOL
The electronic minute minder can indicate the time of
day, operate as a minute minder and it can be used
to time and switch off the main oven.
1. SET THE TIME OF DAY
When the electricity supply is first switched ON,
the display will flash 0.00. See Fig. 1.
Press buttons (1) and (2) together. The display
will momentarily read 88.88. See Fig. 2. Release
buttons, 0.00 will appear in the display as Fig. 3.
Within 5 seconds press button 2, 12.00 will
show in the display as Fig. 4.
Within 5 seconds press and hold either button
(1) to decrease or button (2) to increase the time
until the correct time of day on the 24 hour clock
is reached, e.g.14.30. See Fig. 5.
Note: The increase and decrease control
buttons operate slowly at first, and then more
rapidly. They should be pressed separately.
10
ELECTRONIC MINUTE MINDER
12
Fig.2
Fig.5
Fig.4
Fig.1
Fig.3

2. THE MINUTE MINDER
IMPORTANT
The minute minder can be used to time a set cooking
period. At the end of the cook time the minute minder
will automatically switch off the main oven if in use.
The minute minder gives an audible reminder at the
end of any period of cooking up to 23 hours and 59
minutes.
To set press button (1) and the display will read
0. 00, see Fig. 6.
Release button (1) and press and hold button (2).
The display will count up in one minute intervals until
the interval to be timed is reached e.g. 30 minutes,
see Fig. 7. If necessary press and hold button (1) to
achieve the correct time interval.
The minute minder will begin to count down once set.
At the end of the timed period the minute minder will
click, switching the main oven OFF if in use.
An audible signal will sound for up to 2 minutes. The
second oven, if in use will remain ON. The cookpot
symbol will flash and the time of day will show in the
display. See Fig. 8.
To stop the sound press button (1). The display will
stop flashing and show the time of day, e.g. 15.00.
The cookpot symbol ( ) will go out, see Fig. 9.
If using the main oven it will come on again once
button (1) has been depressed. The second oven will
remain on. When cooking is complete remove food
and turn OFF oven temperature control.
3. TO CANCEL THE MINUTE MINDER
Press and release button (1). Press and hold button
1 and the display will count down in one minute
intervals to 0. 00 See Fig 10. Release button (1).
After a few seconds the cookpot symbol will flash
and the time of day will show in the display. See Fig.
11.
If the main oven is in use this will switch OFF after a
few seconds. The second oven if in use will remain
ON.
To reset, press buttons (1) and (2) together. See Fig.
12.
4. THINGS TO NOTE
1. The time of day must be set before the main
oven will operate. There will be a few
seconds delay before the oven switches on.
2. The minute minder function controls the main
oven only and will switch the oven OFF at the
end of a timed period. This function is useful
if you want to begin cooking now and have
the oven switch OFF automatically.
3. If you have used the minute minder to time
food cooking in the main oven you will need
to reset the timer by pushing both buttons
before the oven can operate again.
11
Fig.7
Fig.8
Fig.9
Fig.6
Fig.10
Fig.11
Fig.12

l For single hotplates, turn the control knob in
either direction to vary the heat setting. The
highest number represents the hottest setting
and the lowest the coolest setting. Choose a
setting appropriate to the quantity and type of
food to be cooked.
RECOMMENDED SAUCEPANS
For speed and economy only good quality
saucepans with flat bases and close fitting lids are
recommended. The saucepan base should be
approximately the same size as the cooking area, a
base diameter of up to 225mm (9") may be used on
a 180mm (7") heated area.
Ensure that new saucepans are well scrubbed to
remove edges and take off any deposits left from
manufacture.
Pressure cookers, preserving pans etc., should
comply with the recommendations given above.
Traditional round bottomed Woks must not be used
even with a stand. Woks with flat bottomed-bases
are available and do comply with the above
recommendations.
NOTE
Occasionally the heated areas may be seen to
switch ON and OFF when higher heat settings are
being used. This is due to a safety device which
prevents the glass from overheating. Some switching
ON and OFF when cooking at high temperatures,
e.g. deep fat frying is quite normal, causes no
damage to the hob and little delay in cooking times.
Excessive switching may however be caused by the
use of an unsuitable saucepan or a saucepan which
is smaller than the heated area. If excessive
switching occurs, discontinue use of the saucepan.
HINTS AND TIPS
l Lift, rather than slide saucepans on and off
the heated areas, This will reduce the risk of
scratches and metal marks from saucepans
with aluminium bases. Metal marks can be
easily cleaned off providing they are not
allowed to burn on.
l Follow any guidelines provided by the
saucepan manufacturer, particularly those
relating to recommended heat settings.
l Avoid using thin, badly dented or distorted
saucepans as they can lead to sticking and
burning of food.
l To prolong the life of the hotplates:-
l DO NOT place aluminium foil and plastic
vessels on the hot surface of the ceramic
hob and DO NOT use the surface for
storage purposes.
12
CAUTION: DO NOT USE THE COOKER IF THE CERAMIC GLASS IS DAMAGED. IF A FAULT OR CRACK
BECOMES VISIBLE DURING COOKING, DISCONNECT THE COOKER IMMEDIATELY FROM THE
ELECTRICITY SUPPLY AND CONTACT THE SERVICE DEPARTMENT OF YOUR LOCAL ELECTRICITY
COMPANY.
USING THE HOB
THE CERAMIC HOB

l Never use utensils with a skirt, e.g. a bucket.
l Never use an asbestos mat.
l Never leave the hotplates ON when not
covered with a saucepan.
l Ensure that hob and saucepans are clean and
dry before the start of cooking to reduce
cleaning.
l Follow the cleaning instructions very closely to
keep the hob looking like new.
l If spillage occurs with sugar solutions, e.g.
jams and syrups, it must be wiped from the
hob before it sets and becomes hard
otherwise damage to the hob will occur.
DEEP FAT FRYING
SPECIAL FRYING NOTE:
For safety purposes when deep fat frying, fill the pan
one-third full of oil, DO NOT cover the pan with a lid
and DO NOT leave the pan unattended. In the
unfortunate event of a fire, switch OFF at the
electricity supply and cover the pan with a lid or
damp cloth to assist in smothering the flames.
DO NOT use water on the fire. Leave the pan to cool
for at least 30 minutes before moving it.
DO NOT leave the fat or oil in the frying pan on the
hob to store it in case the hob is inadvertently
switched ON.
1. Preparing the food
Seal the food by coating with flour, egg and
breadcrumbs or batter. Do not use a basket with
batter coated foods as they will stick.
2. Amount of oil
For safety purposes fill the pan only one-third full
of oil.
3. Testing the temperature of the oil
It is advisable to use a thermometer to test the
temperature of the oil. Alternatively, drop a small
cube of bread into the oil which should brown in
just under a minute if the oil is at the correct
temperature of 190°C/375°F.
4. Cooking the food
Lower the food gently into the oil. Do not add
too much food at once or the temperature of the
oil will be reduced and may result in soggy,
greasy food.
Turn the food if necessary; doughnuts float to the
surface so will not brown on the upperside if not
turned. Once cooked, drain the food on
absorbent paper.
5. Double frying chips
Double frying will ensure good chips. First fry the
chips for a few minutes at 170°C/340°F to seal
the outside. Remove the chips from the oil.
Increase the temperature of the oil to
190°C/375°F to finish cooking and brown the
chips.
Chips may be kept for several hours after the first
frying before finishing off with the second frying.
6. Frying temperatures Celsius Fahrenheit
Scale (oC) Scale (oF)
150 300
First frying of potatoes 170 340
175 350
180 360
Second frying of potatoes 190 375
Frying chicken and fish 195 380
200 390
PRESERVING
1. DO NOT use a pan that overlaps the perimeter of
the hob trim.
2. To allow for a full rolling boil, the pan should be
no more than one third full when all the
ingredients have been added. It is better to use
two pans rather than overfill one, or use half
quantities.
3. Use firm fruit or vegetables and wash well before
using.
4. Preserving sugar gives clear jam, however
granulated sugar is cheaper and gives equally
good flavour.
5. Crystallization may be caused if sugar is not
completely dissolved before bringing jam to the
boil. Over boiling will affect the flavour, setting
properties and colour of the jam.
6. To test jam for setting:
If a jam thermometer is available, boil jam to
104°C. Marmalade should be boiled to 106°C.
If a jam thermometer is not available, remove
pan from heat, place sample of jam on a cold
dish and cool quickly (i.e. in a freezer or frozen
food storage compartment of a refrigerator).
When cold, it will crinkle and hold the mark of a
finger run through it, if it is ready.
7. The scum should be removed as soon as
possible after setting, but marmalade should be
allowed to cool before potting to prevent the peel
rising.
13

l To operate the grill open the grill door and turn
the top oven/grill control clockwise so that '0' on
the control knob lines up with setting 1, 2 or 3.
l Setting 3 represents the grill on Full.
At settings 1 and 2 the grill may cycle on and off
over time and you may prefer to use these
settings for keeping food warm.
l The grill neon will illuminate. It may cycle on and
off during cooking.
THINGS TO NOTE
THE GRILL DOOR MUST BE LEFT FULLY OPEN
DURING GRILLING. IF THE DOOR IS CLOSED
THE TOP OVEN WILL OPERATE.
If the grill door is accidentally closed during grilling,
the grill will cut out and the top oven will operate.
The cranked shelf MUST only be used in the grill
compartment, but a straight shelf from the main oven
may be used to provide alternative positions.
Some smoke from fat splashes may be evident as
the grill element cleans itself.
The top oven cannot be operated when the grill is in
use.
Only the inner element will operate when grilling.
THE GRILL PAN AND HANDLE
The grill pan is supplied with a removable handle.
To insert the handle, press the button on the handle
with the thumb and pivot the handle slightly upwards
inserting the lip into widest part of the bracket. Move
the handle towards the left, lower into position and
release the button.
Ensure the handle is positively located.
When removing the handle, press the button on the
handle with the thumb and pivot the handle slightly
upwards and towards the right to remove from the
bracket.
Ensure your hand is protected when inserting
and removing the grill pan handle as the control
panel trim and grill element can become very
hot.
ALWAYS REMOVE THE GRILL PAN HANDLE
DURING GRILLING.
14
CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE
KEPT AWAY.
SELECTING THE GRILL
THE GRILL

To correctly locate the grill pan on the shelf, ensure
that the cut out on the underside of the handle
bracket locates over the front bar of the shelf.
To check the progress of the food being grilled, the
grill pan should be withdrawn on the shelf to tend the
food during cooking, or the carrier shelf can be lifted
away from the cooker and rested on a heat resistant
work surface.
HINTS AND TIPS
l Food should be thoroughly dried before
grilling to minimise splashing. Brush lean
meats and fish lightly with a little oil or melted
butter to keep them moist during cooking.
l Adjust the grid and grill pan runner position to
allow for different heights of food.
l Place food on the grill pan grid or directly
onto the grill pan base.
l Accompaniments such as tomatoes and
mushrooms may be placed around the outer
edges or underneath the grid when grilling meats.
l When toasting bread use the shelf in position 2
with the grid in the high position and placing the
bread in the centre of the grid.
l Preheat the grill on a full setting for five minutes
before cooking. Adjust the shelf as necessary
during cooking.
l The food should be turned over during cooking
as required.
GRILLING CHART
FOOD SHELF GRILL TIME
(mins)
Bacon Rashers
Beefburgers
Chicken Joints
Chops - Lamb
Pork
Fish - Whole
Trout/Mackerel
Fillets - Plaice/Cod
Kebabs
Kidneys - Lamb/Pig
Liver - Lamb/Pig
Sausages
Steaks - Rare
Medium
Well Done
Toasted Sandwiches
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2 crk.
2-3 each side
6-10 each side
15-20 each side
7-10 each side
10-15 each side
8-12 each side
4-6 each side
10-15 each side
4-6 each side
5-10 each side
10-15 each side
3-6 each side
6-8 each side
7-10 each side
1¼-1½ each
side
crk. = cranked shelf
Shelf positions are counted from the bottom
upwards.
The times quoted above are given as a guide and
should be adjusted to suit personal taste.
15

l Turn the top oven temperature control to the
required setting. Our diagram shows the oven set
to 150°C. Close the oven door.
THINGS TO NOTE
1. The grill cannot be operated when the top oven is
in use. Only the outer part of the top oven
element in conjunction with the base element will
operate when using the top oven.
2. The top oven indicator neon will glow until the
oven has reached the desired temperature and
then go out. It will then cycle ON and OFF
showing that the oven temperature is being
maintained.
3. Always place plates on the oven shelf to warm.
Never place directly on the top oven base as it
becomes very hot and damage may occur.
TO FIT THE TOP OVEN SHELF
The cranked shelf must only be used in the top oven
compartment.
The shelf should be fitted with the straight rods
uppermost on the frame and the forms towards the
back of the oven. If not fitted correctly the anti-tilt and
safety stop mechanism will be affected.
HINTS AND TIPS
l All cooking should be carried out using an oven
shelf positioned in one of the shelf runners.
l Stand dishes on a suitably sized baking tray on
the shelf to prevent spillage onto the oven base
and to help reduce cleaning.
16
USES OF THE TOP OVEN
The top oven is the smaller of the two ovens. It is heated by elements in the top and bottom of the oven. It is
designed for cooking on one level and for smaller quantities of food. It gives especially good results if used to cook
fruit cakes, sweet or savoury flans or quiche.
The top oven is also ideal for use as a warming compartment to warm dishes and keep food hot. Use a
temperature setting of 90-100°C on the top oven control dial.
SELECTING THE TOP OVEN
Frame
Straight Rods
Back of the Oven
THE TOP OVEN

l There should always be at least 2.5cm (1")
between the top of the food and the element.
This gives best cooking results and allows room
for rise in yeast mixtures, Yorkshire puddings,
etc.
l When cooking cakes, pastry, scones, bread, etc.,
place the tins or baking trays centrally on the
shelf directly below the element.
l DO NOT place dishes directly onto the oven
base as it becomes very hot and damage may
occur.
l The material and finish of the baking trays and
dishes will affect the degree of base browning of
the food. Enamelware, dark, heavy or non-stick
utensils increase base browning. Shiny
aluminium or polished steel trays reflect the heat
away and give less base browning.
l DO NOT use the grill pan as a baking tray as this
will increase base browning of the food.
l Because of the smaller cooking space, lower
temperatures and shorter cooking times are
sometimes required. Be guided by the
recommendations on page 20.
l For economy leave the door open for the
shortest possible time, particularly when placing
food into a pre-heated oven.
17

l Turn the main oven temperature control to the
required setting. THINGS TO NOTE
1. The main oven indicator neon will glow until the
oven has reached the required temperature and
then go out. It will cycle ON and OFF periodically
during cooking showing that the temperature is
being maintained.
2. The cooling fan for the controls may switch in
after a time. See page 8 for more information on
the operation of the cooling fan.
18
USES OF THE FAN OVEN
PREHEATING
The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without
preheating, however, you may find you need to add an extra 5 - 10 minutes on the recommended cooking times.
For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés, etc., best results are achieved if the
oven is preheated first.
COOKING TEMPERATURES
Fan oven cooking generally requires lower temperatures than conventional cooking. Follow the temperatures
recommended in the chart on page 20. As a guide reduce temperatures by about 20°C - 25°C for your own
recipes.
BATCH BAKING
The fan oven cooks evenly on both shelf levels, especially useful when batch baking.
SELECTING THE FAN OVEN
THE MAIN FAN OVEN
