Electra Professional Level II Manual

THIS MANUAL The Installation Service Manual provides the information required to install, program,
and maintain the ElectraProfessional Level IIand Level II Advanced systems.
This manual isdivided into three chapters asfollows:
Chapter 1: Hardware Specifications and Installation
Chapter 1 provides the information required to prepare and install the systems,
including applicable FCCrequirements and ULregulatory information.
Chapter 2: Programming
Chapter 2provides detailed instructions for performing System Programming.
Chapter 3: Guide to Feature Programming
Chapter 3 provides a guide or “roadmap” of the Memory Blocks associated with a
feature that are either required or can be programmed.
Chapter 4: System Maintenance
Chapter 4provides maintenance instructions and flowcharts for the systems.
SUPPORTING
DOCUMENTS In addition to the Installation Service Manual, the Electra Professional Level II and
Level IIAdvanced systemsare supportedby the following technical manuals:
Electra Professional Level II and Level II Advanced General Description
Manual (Stock Number 722020)
Designed and developed to provide a general overview of the Electra Professional Level
II and Level II Advanced systems, its features, configuration, service features,
specifications, and standards.
Electra Professional Level II and Level II Advanced Features and
Specifications Manual (Stock Number 722021)
Provides an expanded discussion of each feature that is available for the Electra
Professional Level II and Level II Advanced systems. In addition, the Features and
Specifications Manual provides Station Application, Operating Procedures, and Service
Renditions.
Electra Professional Level II and Level II Advanced Station Operations Manual
(Stock Number 722023)
This manual explains in detail the station operations for all station user features. This
manual isdesigned for useby installersand end users.

Electra Professional Level II and Level II Advanced Job Specifications Manual
(Stock Number 722024)
Used in conjunction with the Installation Service Manual, the Job Specifications
Manual is designed for the service technicians who are responsible for planning the
system installation, maintaining the system, and keeping records of system
programming and configuration. [This manual isincluded with the CPU-F( l-20 KTU.]
Electra Professional Level II and Level II Advanced Automatic Call
Distribution Manual (Stock Number 720234)
This manual is also included with the MIF-F(A)-10 KTU ( Stock Number 720233). It is
designed to provide the service technician with the instructions for programming the
ACD feature. This manual is also intended for the ACD supervisor, at the customer’s
site, to use to become familiar with the system in order to take full advantage of the
ACD/MIS feature.
Electra Professional Level II and Level II Advanced Least Cost Routing Manual
This manual is included with the Least Cost Routing software (Stock No. 722302). It
provides instructions for the service technician for programming the customer’s site for
Least CostRouting.
Electra Professional Level II and Level II Advanced Svstem Program
Technician Manual
This manual is included with the System Program Technician Software (Stock No.
722305). It is intended for use by the service technician when using the PC software to
program the Electra Professional Level IIand Level IIAdvanced systems. This manual _
explains the use of the various screenswithin the PC software that allow the technician
to program the systemto meet the individual customer’s needs.
Electra Professional Level II and Level II Advanced Ssstem Program End-User
Manual
This manual is included with the System Program End-User Software (Stock No.
722306). It is intended for use by the end-user when using PC software to make
day-to-day changes in the Electra Professional Level II and Level II Advanced systems
program. This manual explains the useofvarious screenswithin the PC software.
