DESCRIPTION
4
Delete
Up / Down
Speaker
Newcallindicator
Callback / OK
Speakervolume
adjustment
Phonebook
Recall
Mute
Redial/Pause
Hands-free/Headset
LINE1 LINE2
DC9V
LO HI LO HI
ETR R
Linejack
9VDCadaptorsocket
Headsetsocket
Flashmode
Receivervolumeadjustment
Ringervolumeadjustment

1 - FITTING THE DESK SUPPORT
YourJUPITER4canbeusedintheflatpositionorraisedwiththedesk
support.ThedesksupportwillgiveyouthebestviewingangleoftheLCD
display.Tofitthedesksupport,turnthetelephoneover,insertthetwoupper
hooksintotheopeningsprovidedandpushthedesksupportfirmlyhome.
2-CONNECTING
BatteriesarerequiredforthephonebookandcallerIDfunction.
Thebatteriesalsoretainthememoriesinthephonebook.Incaseofpower
cutandiftherearenobatteries,thememorieswillbekept2mins.
ALWAYS ENSURE THAT THE UNIT IS DISCONNECTED FROM THE
TELEPHONE LINE WHEN INSTALLING OR CHANGING BATTERIES.
INSTALLATION
* Classified TNV-3 according to EN60950 standard. ** Classified «hazardous voltage» according to EN60950 standard.
Adaptor(option)
(*)PTTplug
(**)Wallsocket230V Headset(option)
Telephonecord
Adaptorcord
1
2
5

INSTALLATION
-Connectthehandsetcord.
-Openthebatterydoor.
-Insert4xAAAalkalinebatteriesinthebatterycompartment.
-Snapthebatterydoorbackinplace.
-ConnectthetelephonecordinLINE1jack.(*)TheLINE2canbeused
toconnectamodem.
-Connecttheadaptorcord.(**)(optional)
-Connecttheheadsetcord(optional).
TheACadaptorcanreplacethebatteriesforthephonebookandcallerID
functions.Butincaseofpowercut,batterieswillalwaysbeusefultoretain
thememoriesandforthephonebookandCIDfunction.
2 - RINGER SELECT SWITCH
Settheringerswitchtothedesiredlevel(HI/LO).
Forthemaximumringervolume,movetheringselectortoHIposition.If
youpreferagentlering,movetheringselectortotheLOposition
Note : Subscription may be required to use the Caller ID and other
valueaddedservices.PleasecontactyourNetworkService
Provider for further details. If you have not subscribed to the Caller
ID or some of the other Value added services, the Caller ID and
MessageWaitingfeatureswillnotworkbutallotherfeaturesand
functions in your JUPITER 4 telephone will work normally.
3 - FLASH MODE (ETR / R SWITCH)
-ETR:earthrecall.
-R:recall(R=100ms)=UKsetting.
6
*ClassifiedTNV-3accordingtoEN60950standard. **Classified«hazardousvoltage»accordingtoEN60950standard.

SETTING UP
Inthestandbymode,youcanentertheMAINMENUbypressingthe
button.
The menu includes PHONE BOOK,SET TIME and SET PHONE
functions.
Use or buttontoselecttherequiredfunction,thenpressOKbutton
toenterorpressXbuttontoexit.
1 - SET TIME AND DATE
-AfterenteringtheSETTIMEmenu,pressOK.
-Use or buttontoselectthecorrectnumber.
-PressOKbuttontoconfirmandmovetothenextitem.
-Aftersettingthetime,youcansetthecorrectmonthanddaybyusing
or buttontoselectthecorrectnumber.
-Whenyoufinishthesetting,pressOKbuttontoconfirm.
-PressXbuttontoexit.
NOTE:Whenyoureceiveafirstcalltothisunit,timeanddatewillbe
automaticallysetifyouhaveCallerIDservice.(FSKstandard)
The setting sequence is HOUR-MINUTE-MONTH-DAY.
2 - SET PHONE
-AfterenteringtheSETPHONEmenu,pressOK.
There are 10 menus: SET RING / CALL WAITING / AUTO ON HOOK /
SET LANGUAGE / LCD CONTRAST / SET AREA & LDS (LONG
DISTANCE CODE) / SET FLASH / DIM:X- - ->X / HOUR FORMAT /
DATE FORMAT.
7

SETTINGUP
-Use or buttontoselectoneoftheseitems.
-PressOKbuttontoenterorpressXbuttontoexit.
2.1 - SET RING
Thereare4kindsofringtype.
-AfterenteringtheSETRINGmenu,pressOK.
-Use or buttontoselecttheringtoneyouprefer.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaulttypeisType3)
2.2 - CALL WAITING
-AfterenteringtheCALLWAITINGmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/de-activatethecall
waitingfunction.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaultmodeisOFF)
2.3 - AUTO ON HOOK
-AfterenteringtheAUTOONHOOKmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/de-activatetheauto
onhookfunction.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(ThedefaultmodeisOFF)
Theautoonhookfunctionallowsyoutodisconnectthelineautomatically
about8secondsafterdiallingoutifthelineisbusy.
8

SETTINGUP
2.4-SETLANGUAGE
Theunitsupportsmultilanguages,includingChinese,Korean,Greek,
AustralianEnglish,Turkish,Spanish,Dutch,French,German,Polish,
Swedish,Danish,Finnish,NorwegianandEnglish.
-AfterenteringtheSETLANGUAGEmenu,pressOK.
-Use or buttontoselecttherequiredlanguage.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.(Thedefaultlanguageis
English)
2.5 - LCD CONTRAST
-AfterenteringtheLCDCONTRASTmenu,pressOK.
-Use or buttontoselecttheLCDcontrastlevel.
-PressOKbuttontoconfirm.
-PressXbuttontoexittothepreviousmenu.
2.6 - SET AREA & LDS CODE
Whenyouusethisphoneforthefirsttime,ormovetoanareathathas
differentareacode,youmustenteryourareacode.Thisisnecessary
becausethephonemustdistinguishlocal(AREA)orlongdistancecalls
(LDS)toproperlydialcallsformthecallerIDlist.
-AfterenteringtheSETAREA&LDSmenu,pressOK.
- The LCD displays «AREA CODE»
-Use or buttontoselectthefirstdigitoftheareacode.Ifthearea
codeis09,thenthefirstfourdigitsmustbeleftblank.Toinsertablank,
press OK.9

-PressOKbuttontoconfirmandenterthenextdigitsetting.
-Whentheareacodehasbeenset(6digitslength),press OKbuttononce
toenterthelongdistancecode(LDSCODE)setting(4digitslength).
- The LCD displays SET LDS CODE.
-Use or buttontoselectthefirstdigitoftheLDScode.Ifthelong
distancecodeis01,thenthefirsttwodigitsmustbeleftblank.Toinserta
blank,pressOK.
-PressOKbuttontoconfirmandenterthenextdigitsetting.
-PressXbuttontoexittothestandbymode.
2.7 - SET FLASH
-AfterenteringtheSETFLASHmenu,pressOK.
-Use or buttontoselecttheflashtime(100ms/300ms/600ms).
-PressOKbuttontoconfirm.
(IntheUK,thedefaultvalueis100ms,inFrance,thedefaultvalueis
300ms.)
-PressXbuttontoexittothepreviousmenu.
2.8 - DIM: X- - ->X
-AfterenteringtheDIM:X--->Xmenu,pressOK.
-Use or buttontoselectON/OFFtoactivate/deactivatethe
DIM:X--->Xfunction.
-PressOKbuttontoconfirm.(ThedefaultmodeisON)
IftheDIM:X--->Xfunctionisactivated,themaximumnumberofdigitsthat
canbeshownontheLCDis18smalldigits.
IftheDIM:X--->Xfunctionisnotactivated,themaximumnumberofdigits
SETTINGUP
10

thatcanbeshownontheLCDis8largedigits.
Ifmorethan18smalldigitsor8largedigitsareentered,thelatestentered
digitwillbedisplayedandthefirstentereddigitwillscrolloffthedisplay.
-PressXbuttontoexittothepreviousmenu.
2.9 - HOUR FORMAT
-AfterenteringtheHOURFORMATmenu,pressOK.
-Use or buttontoselectthehourformat(12h/24h).
-PressOKbuttontoconfirm.(Thedefaultformatis24h.)
-PressXbuttontoexittothepreviousmenu.
2.10 - DATE FORMAT
-AfterenteringtheDATEFORMATmenu,pressOK.
-Use or buttontoselectthedateformat(DD-MM/MM-DD).
-PressOKbuttontoconfirmandexit.
OntheDD-MMmode,thetimedisplaysequenceisday-monthandonthe
MM-DDmode,thesequenceismonth-day.(ThedefaultformatisDD-MM.)
-PressXbuttontoexittothepreviousmenu.
SETTINGUP
11
For product support and help
visitourwebsiteatwww.geemarc.com
telephone[phone]
orfax01707372529

1 - SET PHONE BOOK
-AfterenteringthePHONEBOOKmenu,pressOK.
TheLCDshowstwomenus:ADDandREVIEW.
-Use or buttontoselectone.
-PressOKbuttontoconfirm.
2 - TO ADD THE PHONE BOOK NUMBER & NAME
-SelectADDmenu.
-PressOKbuttontoconfirm.
-Enterthetelephonenumberbykeypad(30digitsmax.foreachmemory).
-Ifyoumakeamistake,pressXbuttontodeletethepreviousdigit.
-Aftersettingthenumbers,press buttontoconfirmandenterthe
name’ssetting.Presstheappropriatekeypadbuttontogetthefollowing
characters:
 웍 









  
Toinsertablank,pressOKbuttontwice.
PHONEBOOKOPERATION
12

-Ifthenextcharacterstobeenteredisonthesamebuttonastheprevious
one,youwillfirstneedtopressOKbutton.
-Ifyoumakeamistake,pressXbuttontodeletethepreviousdigit.
-Whennumberandnamesettingiscompleted,press buttontostorethe
recordinyourphonebook.
Toenteranothernumber,repeatstepsfromthepoint3.
-PressXbuttontoexittothestandbymode.
Youcanalsojustpickupthehandsetordonooperationfor20secondsto
exittothestandby.
3 - OTHER PHONE BOOK FUNCTIONS
-AfterenteringthePHONEBOOKmenu,pressOK.
-SelectREVIEWmenuandpressOKbuttontoconfirm.
(Oryoucanenterdirectlyinthereviewfunctionbypressingthe button)
-TheLCDwillshowthelastrecordinthephonebookandyoucanuse
or buttontoreview.
a. To review the phone book number:
-Use or buttontoreviewtherecordinthephonebook.Alsoyou
canquicklyreviewthecallbypressingthefirstletterofthenamewhenthe
handsetison-hook.
PHONEBOOKOPERATION
13

b. To delete a single phone book number:
-Use or buttontoselectthephonebooknumberwhichyouwantto
delete.
-PressXbuttononceandtheLCDshowsDEL?
-PressXbuttononcemoretoconfirm.
c. To speed dial out a phone book number:
-Press button.
-Use or buttontoselectthenumberyouwanttodialoutfromthe
phonebook.
-Thenpickupthehandsetorpress button,thenumberwillbedialedout.
d. To modify the number & name in phone book :
-Use or buttontoselectthenumberyouwanttomodifyinphonebook.
-PressandholdOKbuttonuntilthelastdigitofthenumberflashes.UsetheX
buttontodeletetheninsertthemodification.
-Press button,youcanthenmodifythename.
-Afterthemodification(Refer:Toaddthephonebooknumber&name
page12),press buttontoconfirm.
-PressXbuttontoexit.
e.Copy the CID numbers andlast 30 dialed numbers tophonebook.
-Withthehandsetonhook,press or button,youcanreviewtheCID
list.
-WhenthedesirednumbershowsontheLCD,youcanpressandholdOK
buttonuntilthelastdigitofthenumberflashestoindicateyoucanenterthe
modification.(Refer:Toaddthephonebooknumberandname,page12).
PHONEBOOKOPERATION
14

1-REGULARDIALING
-Liftthehandsetorpressthe button.
-Enterthetelephonenumberyouwanttocallbypressingtheappropriate
digitsonthekeypad.
PRE-DIALLING:Donotpickupthehandsetorpressthe button.
Enterthetelephonenumberyouwanttocallbypressingtheappropriate
digitsonthekeypad.Thepre-diallednumberwillbedialledoutautomatically
whenyoupickupthehandsetorpressthe button.
ThedialednumberwillbeshownontheLCDdisplay.
Thedisplaywillswitchtothecalltimermode.Tostopthetimer;pressX
buttonandthetimercanberesetbypressingagaintheXbutton.
2 - USING THE CALL BACK FEATURE (THE LAST 30 NUMBERS)
A.CALLBACKtheoutgoingnumber:
Theunitcanstoreupto30outgoingnumbers.
-Withthehandseton-hook,pressOKbuttononce.
-Use or buttontoselectthenumberyouwanttodialout.
-Thenpickupthehandsetorpress button,thephonenumberwill
bedialedoutautomatically.
B. CALL BACK the incoming number (see CALLER ID SYSTEM
OPERATIONfordetails,page22)
TELEPHONEKEYFUNCTION
15

3-REDIAL(


)
Thisfeatureallowsyoutoredialthelastnumberyouhavedialledbyone-
touchoperation.
-Liftthehandsetorpressthe button.
-Press


buttontoredialthelastdiallednumber.
4-PAUSE ()
Allowsyoutoinsertatemporarypauseduringdialingsequence.
Forexample,dialinganinternationalnumber(eg:00-886-22-795-1234),
somePBXsystemswillnotregistertheentirenumberentrywithouta
pausebetweentheprefixnumbers.
Youmayhaveto dial00- ,dial886- .
ThisallowsadequatetimingforthephonenumbertoregisterwiththePBX
systemandcompletethecall.Incaseofdifficulty,contactyourPBX
manufacturerorinstaller.
5-SPEAKER()
Toswitchyourcalltospeakerphone:
-Pressthe buttonandhanguphandset.
-Toswitchback,simplypickupthehandset.
Note:Ifyouinserttheheadset(option)intothe socketlocatedbehind
thephone,pressthe buttontotransferthecalltoheadset.
TELEPHONEKEYFUNCTION
16

6 -RECEIVERVOLUME ( )
Toadjustthereceivervolumetoyourdesiredlisteninglevel,movethe
switchlocatedbehindthephonetotheHIorLOposition.
7 - NEW CALL INDICATOR
TheredindicatorlightofyourphonewillflashwhenyouhaveNewCalls.
Thelightwillcontinuetoflashuntilallthenewcallshavebeenreviewed.
8 - MUTE ()
Ifyouwishtospeakprivatelytosomeoneelseintheroomwithoutyour
calleroverhearing,pressthe buttononce.Youwillstillbeabletohear
thecaller’sbuttheycannothearyouduringthemuteoperation.
Toresumenormalconversation,press buttononceagain.
9-RECALL(R)
PressRbuttontoterminateacallandinstitutedialingtoneforanothercallor
togetanothercallfrom“CallWaiting”(aspecialtelephoneservice).
NOTE:Ifyoudonothavespecialtelephoneservicesfromyouroperator,
suchasCallWaiting,pressingRbuttonduringacallmaydisconnectyour
currentconversation.
TELEPHONEKEYFUNCTION
17

AcallerIDrecordconsistsofthefollowinginformation:










1-MESSAGE WAITING
Ifyouhavevoicemailservicefrom
yourtelephonecompanyanda
recordedmessageisleft,thescreen
willdisplayMSGWAITINGandthe
MESSAGE WAITING will be saved
asacall.
NOTE:Thisfunctionshouldbe
supportedbyyourtelephonecompany.
18
REVIEWINGDISPLAYMESSAGES

2-TOTAL & NEW CALLS
Thisshowsyouthetotalandnewcalls
tobereviewed.
Inthisexample,youhaveatotalof
15callswhichinclude5newcalls.
3 - NO CALLS
Whenallcallshavebeendeleted,
the display will show NO CALL.
4 - PRIVATE
Ifthecallerhasexercisedtheoption
topreventhisnameandnumberfrom
being sent, “PRIVATE” will be shown
onthescreen.
5 - END OF LIST
Thismessageisdisplayedwhenuse
or toreachthetop(end)ofthe
callhistorylist.Iftherearenocalls,
then LCD shows NO CALL.
REVIEWINGDISPLAYMESSAGES
19

6 - OUT OF AREA
Willdisplaywhensomeonecallsfrom
anareawherethetelephonecompany
isnotofferingthecalleridentification
servicesoranareathatisnotyet
providingnameandnumberdelivery
toyourareaviathelongdistancenet-work.
7-BATTERY LOW INDICATOR
Ifthebatteryisfull,the iconwill
bedisplayed.
Ifthebatteryislow,thebattery
lowicon willturnon,ifthepower
isnearlyempty,thebatteryicon
willturnonandifthepowerisempty,
theicon willturnon.
REVIEWINGDISPLAYMESSAGES
20
