Owner’s Manual
Model
20" Compact
7207250100R05
IMPORTANT SAFETY INFORMATION: Always read this manual rst
before attempting to install or use this replace. For your safety, always
comply with all warnings and safety instructions contained in this manual
to prevent personal injury or property damage.

2 www.dimplex.com
Table of Contents
Always use a qualied technician
or service agency to repair
this stove.
!NOTE: Procedures and
techniques that are
considered important
enough to emphasize.
CAUTION: Procedures and
techniques which, if not
carefully followed, will result
in damage to the equipment.
WARNING: Procedures
and techniques which, if not
carefully followed, will expose
the user to the risk of re,
serious injury, or death.
Welcome & Congratulations .................3
IMPORTANT INSTRUCTIONS ...............4
Installation ...............................7
Operation ................................8
Maintenance ............................10
Warranty ...............................12
Replacement Parts ........................15

3
Welcome & Congratulations
Thank you and congratulations for choosing to purchase an electric
replace from Electralog, the world leader in electric replaces.
Please carefully read and save these instructions.
CAUTION: Read all instructions and warnings carefully before
starting installation. Failure to follow these instructions may result in a
possible electric shock, re hazard and will void the warranty.
Please record your model and serial numbers below for future
reference: model and serial numbers can be found on the Model and
Serial Number Label.
NO NEED TO RETURN TO THE STORE
Questions with operation or assembly? Require Parts Information?
Product Under Manufacturer’s Warranty?
Contact us at: www.dimplex.com/customer_support
For Troubleshooting and Technical Support
OR Toll-Free 1-888-346-7539
Monday to Friday 8:00 a.m. to 4:30 p.m. EST
Please have your model number and product serial
number ready. (See above)
Serial Number
Model Number

4 www.dimplex.com
IMPORTANT INSTRUCTIONS
① Read all instructions before using
this heater.
②This heater is hot when in use.
To avoid burns, do not let bare skin
touch hot surfaces. The trim around
the heater outlet becomes hot during
heater operation. Keep combustible
materials, such as furniture, pillows,
bedding, papers, clothes, and
curtains at least 3 feet (0.9 m) from
the front of the heater and keep them
away from the sides and rear.
③ Extreme caution is necessary
when any heater is used by or near
children or invalids and whenever the
unit is left operating and unattended.
④ Always unplug the heater when
not in use.
⑤ Do not operate any heater with a
damaged cord or plug, or if the heater
has malfunctioned, or if it has been
dropped or damaged in any manner.
Return heater to authorized service
facility for examination, electrical or
mechanical adjustment, or repair.
⑥ Do not use outdoors.
⑦ This heater is not intended for
use in bathrooms, laundry areas and
similar indoor locations. Never locate
this heater where it may fall into a
bathtub or other water container.
⑧ Do not run cord under carpeting.
Do not cover cord with throw rugs,
runners, or the like. Arrange cord
away from trafc area and where it
will not be tripped over.
⑨To disconnect heater, turn
controls to off, then remove plug from
outlet.
⑩Do not insert or allow foreign
objects to enter any ventilation or
exhaust opening as this may cause
an electric shock or re, or damage
the heater.
⑪ To prevent a possible re, do not
block air intakes or exhaust in any
manner. Do not use on soft surfaces,
like a bed, where openings may
become blocked.
⑫ All electrical heaters have hot
and arcing or sparking parts inside.
Do not use in areas where gasoline,

5
SAVE THESE INSTRUCTIONS
IMPORTANT INSTRUCTIONS
paint, or ammable liquids are used
or stored or where it will be exposed
to ammable vapors.
⑬Do not modify the heater. Use it
only as described in this manual. Any
other use not recommended by the
manufacturer may cause re, electric
shock, or injury to persons.
⑭ To reduce the risk of electric
shock, this heater has a polarized
plug (one blade is wider than the
other). This plug will t in a polarized
outlet only one way. If the plug does
not t fully in the outlet, reverse the
plug. If it still does not t, contact
a qualied electrician to install the
proper outlet. Do not change the
plug in any way. Avoid the use of an
extension cord. Extension cords may
overheat and cause a risk of re. If
you must use an extension cord, the
cord must be No. 14 AWG minimum
size and rated no less than 1875
Watts.
⑮ Do not burn wood or other
materials in the Compact Fireplace.
⑯Do not strike the front glass.
⑰Always use a certied electrician
should new circuits or outlets be
required.
⑱ Always use properly grounded,
fused and polarized outlets.
⑲ Disconnect all power supply
before performing any cleaning,
maintenance or relocation of the
heater.
⑳ When transporting or storing the
heater and cord, keep in a dry place,
free from excessive vibration and
store so as to avoid damage

6 www.dimplex.com
IMPORTANT INSTRUCTIONS
!NOTE: This equipment has
been tested and found to comply
with the limits for Class B digital
device, pursuant to part 15 of
the FCC Rules. These limits are
designed to provide reasonable
protection against harmful
interference in a residential
installation. This equipment
generates, uses and can radiate
radio frequency energy and, if not
installed and used in accordance
with the instructions,may cause
harmful interference to radio or
television reception, which can
be determined by turning the
equipment off and on, the user is
encouraged to try to correct the
interference by one or more of the
following measures:
Reorient or relocate the•
receiving antenna.
Increase the separation•
between the equipment and
the receiver.
Connect the equipment into•
an outlet on a circuit different
from that to which the
receiver is connected.
Consult the dealer or an•
experienced radio/TV
technician for help.
Operation is subject to the
following two conditions: (1)
this device may not cause
interference and; (2) this device
must accept any interference,
including interference that may
cause undesired operation of the
device.

7
Installation
Figure 1
Rear Support
Main Body
Mantel Top
Hardware
!NOTE: A 15 Amp, 120 Volt
alternating current (VAC) circuit
is required. A dedicated circuit
is preferred but not essential in
all cases. A dedicated circuit will
be required if, after installation,
the circuit breaker trips or fuse
blows on a regular basis when the
heater is operating. Additional
appliances on the same circuit
may exceed the current rating of
the circuit breaker.
WARNING: Ensure the power
cord is not installed so that it is
pinched or against a sharp edge
and ensure that the power cord is
stored or secured to avoid tripping
or snagging to reduce the risk
of re, electric shock or injury to
persons.
WARNING: Construction
and electrical outlet wiring must
comply with local building codes
and other applicable regulations
to reduce the risk of re, electric
shock and injury to persons.
WARNING: Do not attempt
to wire your own new outlets or
circuits. To reduce the risk of re,
electric shock or injury to persons,
always use a licensed electrician.
(No assembly required for the
at wall mantel)
Corner Mantel Assembly
Assemble the top of the1.
mantel to the rear support
using the supplied hardware.
Using the supplied hardware2.
assemble the top and rear
support assembly to the main
replace body (Figure 1).
Fireplace Installation
Make sure the unit’s Main1.
ON/OFF switch is switched
OFF (refer to operating
instruction section).
Plug the unit into a 15 Amp, 2.
120 VAC outlet. If the cord
does not reach, you may use
a No. 14 AWG minimum size
extension cord rated for a
minimum of 1875 Watts.

8 www.dimplex.com
Operation
Figure 2
AC B
To access the controls, swing
down the front cover panel
located on the lower front of the
replace. (Figure 3)
A. Main Three Position ON/OFF
Switch
The switch has two ON positions
marked with and “Manual”.
The “Manual“ position is for
manual operation. In this position
the built-in remote control is by-
passed.
The position is for operating
the unit with the provided remote
control.
When in position, the unit is
operated with the ON and OFF
buttons of the remote control.
When the switch is in the center
position the unit is off.
B. Heater ON/OFF Switch
The Heater ON/OFF Switch
supplies power to the heater
fan and the heater element.
When the switch is in the ON
position the heater operates if the
thermostat calls for heat.
C. Heater Thermostat Control
To adjust the temperature to
your individual requirements,
turn the thermostat control
clockwise all the way to turn
on the heater. When the room
reaches the desired temperature,
turn the thermostat knob counter
clockwise until you hear a click.
Leave in this position to maintain
the room temperature at this
setting. For additional heat, turn
clockwise until you hear the click
again and the heater will turn on.
Resetting the Temperature
Cutoff Switch
Should the heater overheat, an
automatic cut out will turn the
heater off and it will not come
back on without being reset. It
can be reset by switching the
Main Three Position ON/OFF
Switch to OFF and waiting 5

9
Operation
minutes before switching the unit
back on.
CAUTION: If you need to
continuously reset the heater,
unplug the unit and call technical
support at 1-888-346-7539.
!NOTE: The heater may emit
a slight, harmless odor when
rst used. This odor is a normal
condition caused by initial heating
of internal heater parts and will
not occur again.
Remote Control (Figure 3)
The replace is supplied with an
integrated on/off remote control.
!NOTE: Ensure that the
replace 3 position switch
is set to the remote control
setting (up position).
ON
Button
Battery Cover
OFF
Button
Battery
Figure 3
To operate, push the ON button
to turn replace on, push the OFF
button to turn the replace off.
Remote Control Initialization/
Reprogramming
In the event that your remote
control ceases to operate your
replace, follow these steps to re-
initialize the hand held transmitter
and the remote control receiver in
the replace:
Place the1. Three Position
Switch (Figure 2A) in the Off (“
O ”) position.
Wait a minimum of ve (5) 2.
seconds and then place the
Three Position Switch in
the Remote Control (“ II ”)
position.
Within3. 10 seconds of
changing the switch position,
press the ON button located
on the remote control
transmitter (Figure 2).
This will synchronize the remote
control transmitter and the
replace receiver.
!NOTE: You will have only 10
seconds to perform this last step.
Failure to do so will result in these
steps needing to be followed
again.

10 www.dimplex.com
Operation
WARNING: Disconnect
power before attempting any
maintenance or cleaning to
reduce the risk of re, electric
shock or damage to persons.
Light Bulb Replacement
Allow at least 5 minutes for light
bulbs and heater to cool off before
touching bulbs to avoid accidental
burning of skin.
Light bulbs need to be replaced
when you notice a dark section
of the ame or when the clarity
and detail of the log exterior
disappears. There are two bulbs
under the log set which generate
the ames and embers.
Helpful Hints
It is a good idea to replace all
light bulbs at one time if they are
close to the end of their rated life.
Group replacement will reduce
the number of times you need
to open the unit to replace light
bulbs.
Light Bulb Requirements
Quantity of 2 clear chandelier
or candelabra bulbs with a J-12
(small) socket base, 60 Watt rat-
ing. Example GE 60BC or Philips
60 CTC.
Replacement:
Unplug the unit from power1.
outlet.
On the back of the Compact2.
Fireplace remove the screws
from the light access cover
(Figure 4).
Battery Replacement
(Figure 3)
To replace the battery:
Slide battery cover open on1.
the hand held transmitter.
Correctly install one (1) 12 2.
Volt (A23) battery in the
battery holder.
Close the battery cover. 3.
Maintenance

11
Maintenance
Remove the light access3.
cover.
Reach into the opening, 4.
locate and examine the bulbs
to determine which bulb(s)
require replacement.
Unscrew the bulb(s) counter 5.
clockwise.
Insert new bulb(s).6.
Install the light access cover7.
and install the screws.
Glass Cleaning
The glass is cleaned in the
factory during the assembly
operation. During shipment,
installation, handling, etc., the
front glass panel may collect
dust particles; these can be
removed by dusting lightly with
a clean dry cloth.
To remove ngerprints or other
marks, the front glass panel
can be cleaned with a damp
cloth. The front glass panel
should be completely dried with
a lint free cloth to prevent water
spots. To prevent scratching,
do not use abrasive cleaners or
spray liquids on the clear door
surface.
Compact Fireplace
Surface Cleaning
Use warm water only to clean
painted surfaces of the Compact
Fireplace. Do not use abrasive
cleaners.
Servicing
Except for light bulb replacement
and cleaning described above, an
authorized service representative
should perform any other
servicing.
Figure 4
Light Bulbs
Screws
Light Access
Cover

12 www.dimplex.com
One Year Limited Warranty
Products to which this limited
warranty applies
This limited warranty applies to your
newly purchased Electralog electric
compact replace. This limited
warranty applies only to purchases
made in any province of Canada
except for Yukon Territory, Nunavut,
or Northwest Territories or in any
of the 50 States of the USA (and
the District of Columbia) except for
Hawaii and Alaska. This limited
warranty applies to the original
purchaser of the product only and is
not transferable.
Products excluded from this limited
warranty
Light bulbs are not covered by
this limited warranty and are the
sole responsibility of the owner/
purchaser. Products purchased in
Yukon Territory, Nunavut, Northwest
Territories, Hawaii, or Alaska are
not covered by this limited warranty.
Products purchased in these States,
provinces, or territories are sold
AS IS without warranty or condition
of any kind (including, without
limitation, any implied warranties
or conditions of merchantability or
tness for a particular purpose) and
the entire risk of as to the quality and
performance of the products is with
the purchaser, and in the event of a
defect the purchaser assumes the
entire cost of all necessary servicing
or repair.
What this limited warranty covers
and for how long
Products covered by this limited
warranty have been tested and
inspected prior to shipment and,
subject to the provisions of this
warranty, Electralog warrants such
products to be free from defects
in material and workmanship for a
period of 12 months from the date of
the rst purchase of such product.
The limited 12 month warranty period
also applies to any implied warranties
that may exist under applicable
law. Some jurisdictions do not allow
limitations on how long an implied
warranty lasts, so the above limitation
may not apply to the purchaser.
What this limited warranty does not
cover
This limited warranty does not apply
to products that have been repaired
(except by Electralog or its authorized
service representatives) or otherwise
altered. This limited warranty does
further not apply to defects resulting
from misuse, abuse, accident,
neglect, incorrect installation,
improper maintenance or handling,
or operation with an incorrect power
source.
What you must do to get service
under this limited warranty
Warranty

13
Defects must be brought to the
attention of Electralog Technical
Service by contacting Electralog at
1-888-346-7539, or 1367 Industrial
Road, Cambridge Ontario, Canada
N1R 7G8. Please have proof of
purchase, catalogue/model and serial
numbers available when calling.
Limited warranty service requires a
proof of purchase of the product.
What Electralog will do in the event of
a defect
In the event a product or part
covered by this limited warranty is
proven to be defective in material or
workmanship during the 12 month
limited warranty period you have the
following rights:
Electralog will in its sole •
discretion either repair or replace
such defective product or part
without charge. If Electralog is
unable to repair or replace such
product or part, or if repair or
replacement is not commercially
practicable or cannot be timely
made, Electralog may, in lieu of
repair or replacement, choose
to refund the purchase price for
such product or part.
Limited warranty service will•
be performed solely by dealers
or service agents of Electralog
authorized to provide limited
warranty services.
The purchaser is responsible•
for removal and transportation
of such product or part (and
any repaired or replacement
product or part) to and from the
authorized dealer’s or service
agent’s place of business.
This limited warranty does not•
entitle the purchaser to on-site
or in-home services. On-site
or in-home services may be
performed at the purchaser’s
specic request and expense at
Electralog’s then-current rates for
such services.
Electralog will not be responsible •
for, and the limited warranty
services shall not include, any
expense incurred for installation
or removal of the product
or part (or any replacement
product or part) or any labour
or transportation costs. Such
costs shall be the purchaser’s
responsibility.
What Electralog and its dealers
and service agents are also not
responsible for:
IN NO EVENT WILL ELECTRALOG,
OR ITS DIRECTORS, OFFICERS,
OR AGENTS, BE LIABLE TO
THE PURCHASER OR ANY
THIRD PARTY, WHETHER IN
CONTRACT, IN TORT, OR ON
ANY OTHER BASIS, FOR ANY
INDIRECT, SPECIAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL,
Warranty

14 www.dimplex.com
Warranty
OR INCIDENTAL LOSS, COST,
OR DAMAGE ARISING OUT OF
OR IN CONNECTION WITH THE
SALE, MAINTENANCE, USE,
OR INABILITY TO USE THE
PRODUCT, EVEN IF DIMPLEX OR
ITS DIRECTORS, OFFICERS, OR
AGENTS HAVE BEEN ADVISED
OF THE POSSIBILITY OF SUCH
LOSSES, COSTS OR DAMAGES,
OR IF SUCH LOSSES, COSTS, OR
DAMAGES ARE FORESEEABLE.
IN NO EVENT WILL DIMPLEX,
OR ITS OFFICERS, DIRECTORS,
OR AGENTS BE LIABLE FOR
ANY DIRECT LOSSES, COSTS,
OR DAMAGES THAT EXCEED
THE PURCHASE PRICE OF THE
PRODUCT.
SOME JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO
THE PURCHASER.
How State and Provincial law apply
This limited warranty gives you
specic legal rights, and you may
also have other rights which vary
from jurisdiction to jurisdiction. The
provisions of the United Nations
Convention on Contracts for the
Sale of Goods shall not apply to
this limited warranty or the sale of
products covered by this limited
warranty.

15
Log Set Assembly ............................ 0487550100RP
Flicker Motor ................................ 2000220100RP
Heater Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2200490800RP
Thermostat ................................. 2300150100RP
Cutout ..................................... 2300270100RP
3 Position On/Off Switch . . . . . . . . . . . . . . . . . . . . . . . 2800071100RP
Heater On/Off Switch. . . . . . . . . . . . . . . . . . . . . . . . . . 2800070200RP
Capacitor ................................... 3200030100RP
Cord Set ................................... 4100090100RP
Flicker Rod ................................. 5900340100RP
Mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5900620100RP
Front Glass ................................. 5900420100RP
Remote Control Transmitter .................... 3000370800RP
Remote Control Reciever . . . . . . . . . . . . . . . . . . . . . . . . 3000380200RP
Thermostat Knob. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8800000300RP
Light Wire Harness ........................... 2500170300RP
Replacement Parts
© 2011 Dimplex North America Limited
Electralog
1367 Industrial Road
Cambridge ON
Canada N1R 7G8
